Honeywell F-HE User manual

1
USER MANUAL
Wet and Dry Vacuum Cleaner
C ongratulations on the purchase of your new Honeywell wet/dry vacuum cleaner.
Prior to using the appliance for the first time, be sure to read this manual completely and
keep it available for use.
The vacuum cleaner is intended for use as a domestic/household multipurpose product, corresponding to
the description given in these operating and safety notes.
The vacuum cleaner is not to be used for commercial and or professional use.
Any use extending beyond this is not considered as proper use. The manufacturer is not liable for any loss.
PURPOSE AND INTENDED USE
DEAR CUSTOMER

2
! ATTENTION: REVIEW IMPORTANT SAFETY INSTRUCTIONS BE THIS VACUUM
CLEANER. RETAIN FOR FUTURE USE.
! DANGER: Never operate this unit when flammable materials or vapors are present
because
electrical devices produce arcs or sparks that can cause a fire or explosion. NEVER
OPERATE UNATTENDED!
! WARNING: Always wear eye protection to prevent rocks or debris from being blown or
ricocheting into the eyes or face which can result in serious injury.
When using an electrical appliance, basic precautions should always be followed, including the
following:
READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER.
! WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
Use this vacuum cleaner only as described in this manual. Use only Manufacturer’s recommended
attachments.
Never immerse the appliance, the connection cord or plug in water as doing so presents the risk of
electric shock. When working with the appliance, make sure that the connection cord and, where
applicable, an extension cord are not lying in water.
WARNING Do NOT use this vacuum cleaner to vacuum lead paint debris. Fine lead particles may be
dispersed into the air. This vacuum cleaner is not intended for use under EPA Regulation 40 CFR
Part 745 for lead paint material clean up.
Never vacuum up the following materials: explosive or combustible gases, liquids and dust particles
(reactive dust particles), reactive metal dust particles (such as aluminum, magnesium, zinc) in
combination with highly alkaline or acidic detergents, undiluted and strong acids and alkalis or
organic solvents such as petrol, paint thinners, acetone, heating oil and similar products.
Risk of fire. Do not vacuum up any burning or glowing objects.
Do not not pick up flammable or combustible liquids such as gasoline, liquids, reactive dust particles
or use in areas where they may be present.
Do not use use your vacuum cleaner as a sprayer of flammable liquids such as oil base paints,
lacquers, household cleaners, etc.
Do not attempt to vacuum hot or warm ashes. Maximum temperature of ashes should not be warmer
than 102 degrees Fahrenheit / 40 degrees Celsius.
Do not vacuum toxic carcinogenic, combustible or other hazardous materials such as asbestos,
arsenic, barium, beryllium, lead, pesticides or other health endangering materials.
Do not pick up soot, cement, plaster, or drywall dust without a HEPA filter and without using the
Filter Cleaning System. These are very fine particles.
To avoid spontaneous combustion, empty tank after each use.
NOTE: A static shock may occur if the environment is too dry. This will not affect the use of the
vacuum cleaner. To eliminate shock, add humidity to the air with a console or a humidifier.
The operation of this vacuum cleaner can result in foreign objects being blown into eyes, which can
result in eye damage. Always wear safety goggles when operating the vacuum.
IMPORTANT SAFETY INSTRUCTIONS

3
Turn off all controls before unplugging power cord.
Do not use without a filter installed.
STAY ALERT and use common sense. Do not use vacuum cleaner when you are under the
influence of drugs, alcohol, medication, or if you are tired or distracted.
Do not leave cord lying on the floor once you have finished the cleaning job. It can become a tripping
hazard.
Use extra care when cleaning on stairs.
Keep hands, hair, clothing, and all other parts of body away from openings and moving parts.
Do not put any object into openings. Do not use with any openings blocked; keep free of dust, lint,
hair and anything that may reduce air flow.
Do not handle plug or appliance with wet hands.
Do not allow to be used as a toy. Close attention is necessary when used by or near children.
Keep packaging material away from children. There is a risk of suffocation!
Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped,
damaged, left outdoors or dropped into water, contact your authorized service center or licensed
electrician for assistance. Not to be used before service has been carried out.
Do not pull or carry by cord, use cord as a handle, close a door on cord or pull cord around sharp
edges or corners. Do not run vacuum cleaner over its power cord. Keep cord away from heated
surfaces.
Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
Unplug before connecting hose.
Do not pick up anything that is burning or smoking, such as cigarettes, matches.
Do not pick up sharp objects such as needles or pieces of glass.
Protect the unit from rain. Store indoors.
Do not operate the vacuum cleaner in the rain.
Wear protection mask, when tank is emptied for fine dust of all kinds.
Unplug before connecting hose and any attachments.
Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing it.
Connect to a properly grounded outlet only. See Grounding Instructions.
SAVE THESE INSTRUCTIONS
Included? Yes / No
HWP4045
HWP5555
HWP5560S
HWI4045
HWI5555
HWI6560S
Tank Size
4.0 gal**
5.5 gal**
5.5 gal**
4.0 gal**
5.5 gal**
6.5 gal**
Tank Material
Plastic
Stainless Steel
Peak HP
4.5
5.5
6.0
4.5
5.5
6.0
Power Socket/Tool Adaptor
No
No
Yes
No
No
Yes
Dust Bag
No
No
No
No
No
No
Inflator/Blower Kit
Yes
Yes
Yes
Yes
Yes
Yes
** Gallons relate to size of tank, not the capacity for material or water
Product Features

4
For technical assistance or service parts, contact the Customer Service Department at:
Producteers Inc.
811 Overhills Drive, Suite 101
Old Hickory, TN 37138
[e-mail]
Toll free phone: [phone] Monday – Friday, 8:00AM to 5:00PM, Central Time
This appliance must be grounded. If it should malfunction or breakdown, grounding provides a path of least
resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord
having an equipment-grounding conductor and grounding plug. The plug must be inserted into an
appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
OVERVIEW
FIG. 1
11. HEPA filter (installed at factory)
12. Dust bag (optional)
13. Hose
14. Wands (2)
15. Crevice tool
16. Floor brush with 2 inserts
17. Inflator/blower kit
18. Power tool adaptor (optional)
19. Round brush
Note: Some accessories may be packed inside the tank. If
parts are missing, contact Customer Service Department at
866-814-4103 or [e-mail].
1. Switch
2. Handle
3. Filter Cleaning Button
4. Socket (optional)
5. Blower outlet
6. Suction inlet
7. Clamps
8. Wand/hose storage slot
9. Hooks for cord
10. Flexible foam filter (black, not installed)
GROUNDING INSTRUCTIONS
CUSTOMER SERVICE

5
WARNING – Improper connection of the equipment-grounding conductor can result in a risk of electric
shock. Check with a qualified electrician or service person if you are in doubt as to whether the outlet is
properly grounded. Do not modify the plug provided with the appliance – if it will not fit the outlet, have a
proper outlet installed by a qualified electrician.
This appliance is for use on a nominal 120-V circuit and has a grounding
attachment plug that looks like the plug illustrated in sketch in Figure 2.
Make sure that the appliance is connected to an outlet having the same
configuration as the plug. No adaptor should be used with this appliance.
When using where an extension cord is necessary, a 2-conductor grounding cord must be used for safety
as well as cord and plug must be of watertight construction. This will also prevent overheating and a loss of
power. Do not use any AWG smaller than 14. Use AWG 14 for 25-50 feet cord and AWG 12 for cord over
50 feet.
Before using appliance, inspect power cord for loose or exposed wires and damaged insulation. Make any
needed repairs or replacements before using your appliance. Use only three-wire outdoor extension cords.
When vacuuming liquids, be sure the extension cord connection does not come in contact with any liquids
and water.
NOTE: INADEQUATE EXTENSION CORDS CAN BE DANGEROUS
NOTE: STATIC SHOCKS ARE COMMON IN DRY AREAS OR WHEN THE RELATIVE HUMIDITY OF AIR
IS LOW. THIS IS ONLY TEMPORARY AND DOES NOT AFFECT THE USE. TO REDUCE THE
FREQUENCY OF STATIC SHOCKS IN YOUR HOME, THE BEST REMEDY IS TO ADD MOISTURE TO
THE AIR WITH A CONSOLE OR INSTALLED HUMIDIFIER.
FIG. 2
EXTENSION CORDS
