Honeywell HWS200 User manual

1
______________________________________________
User Manual
Dry Vacuum Cleaner
Model: HWS200

2
Prior to using the appliance for the first time, be sure to read this manual
completely and keep it available for use.
The vacuum cleaner is intended for use as a domestic/household multipurpose product,
corresponding to the description given in these operating and safety notes.
The vacuum cleaner is not to be used for commercial and or professional use.
Any use extending beyond this is not considered as proper use. The manufacturer is not liable
for any loss.
! ATTENTION: REVIEW IMPORTANT SAFETY INSTRUCTIONS BEFORE
ATTEMPTING TO USE THIS VACUUM CLEANER. RETAIN FOR
FUTURE REFERENCE.
! DANGER: Never operate this unit when flammable materials or vapors are
present because electrical devices produce arcs or sparks that can
cause a fire or explosion.
NEVER OPERATE UNATTENDED!
! WARNING: Do NOT use this vacuum cleaner to vacuum lead paint debris
because this may disperse fine lead particles into the air. This
vacuum cleaner is not intended for use under EPA Regulation 40
CFR Part 745 for lead paint material clean up.
! WARNING: This Dry vacuum cleaner must not be used for the suction of water
or other liquids.
When using an electrical appliance, basic precautions should always be followed,
including the following:
IMPORTANT SAFETY INSTRUCTIONS
PURPOSE AND INTENDED USE
DEAR CUSTOMER

3
READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER.
WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
Use this vacuum cleaner only as described in this manual. Use only Manufacturer’s
recommended attachments.
Do not pick up anything that is burning or smoking such as cigarettes, matches or hot
ashes.
Never immerse the appliance, the connection cord or plug in water as doing so presents
the risk of electric shock. When working with the appliance, make sure that the
connection cord and, where applicable, an extension cord are not lying in water.
Do not pick up sharp objects such as needles or pieces of glass.
Do not use the machine without filters properly fitted and installed.
WARNING Do NOT use this vacuum cleaner to vacuum lead paint debris. Fine lead
particles may be dispersed into the air. This vacuum cleaner is not intended for use
under EPA Regulation 40 CFR Part 745 for lead paint material clean up.
Never vacuum up the following materials: explosive or combustible gases, liquids and
dust particles (reactive dust particles), reactive metal dust particles (such as aluminum,
magnesium, zinc) in combination with highly alkaline or acidic detergents, undiluted and
strong acids and alkalis or organic solvents such as petrol, paint thinners, acetone,
heating oil and similar products.
Risk of fire. Do not vacuum up any burning or glowing objects.
Do not pick up flammable or combustible liquids such as gasoline, liquids, reactive dust
particles or use in areas where they may be present.
Do not use your vacuum cleaner as a sprayer of flammable liquids such as oil base
paints, lacquers, household cleaners, etc.
Do not vacuum toxic carcinogenic, combustible or other hazardous materials such as
asbestos, arsenic, barium, beryllium, lead, pesticides or other health endangering
materials.
Do not pick up soot, cement, plaster or drywall dust without a filter and without using the
Filter Cleaning System. These are very fine particles.
To avoid spontaneous combustion, empty tank after each use.
NOTE: A static shock may occur if the environment is too dry. This will not affect the use
of the vacuum cleaner. To eliminate shock, add humidity to the air with a console or a
humidifier.
Turn off all controls before unplugging power cord.
STAY ALERT and use common sense. Do not use vacuum cleaner when you are under
the use of drugs, alcohol or medication or even if you are tired or distracted.
Do not leave cord lying on the floor once you have finished the cleaning job. It can
become a tripping hazard.
Use extra care when cleaning on stairs or on a ladder.
Keep hands, hair, clothing, and all other parts of body away from openings and moving
parts.
Do not put any object into openings. Do not use with any openings blocked; keep free of
dust, lint, hair and anything that may reduce air flow.

4
Do not handle plug or appliance with wet hands.
Do not allow to be used as a toy. Close attention is necessary when used by or near
children.
Keep packaging material away from children. There is a risk of suffocation!
Do not use with damaged cord or plug. If appliance is not working as it should, has been
dropped, damaged, left outdoors or dropped into water, contact your authorized service
center or licensed electrician for assistance. Not to be used before service has been
carried out.
Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
Do not pull or carry by cord, use cord as a handle, close a door on cord or pull cord
around sharp edges or corners. Do not run vacuum cleaner over its power cord. Keep
cord away from heated surfaces.
Do not leave this appliance when plugged in. Unplug from outlet when not in use and
before servicing. Connect to a proper outlet only.
Do not use outdoors or on wet surfaces.
Carry out the maintenance work according to operating instructions.
Wear protection mask, when emptying the vacuum cleaner for fine dust.
This appliance is provided with double insulation. Use only identical replacement parts.
See GROUNDING INSTRUCTIONS section for servicing of double-insulation
appliances.
Unplug before connecting hose and nozzles.
SAVE THESE INSTRUCTIONS
! WARNING: To reduce the risk of electric shock, this appliance has a polarized plug
(one blade is wider than the other). This plug will fit in a polarized outlet only one way. If
the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician to install the proper outlet. Do not change the plug in any way.
! WARNING: Do not leave vacuum unattended when it is plugged in and/or operating.
Unplug unit when not in use.
Honeywell handheld dry vacuum cleaner
4.5 Peak HP, 1.5 Gallon Tank *
* Gallons relate to the size of the tank, not the capacity for material or water.
CARTON CONTENT

5
As you open the carton, make sure the following is inside:
Vacuum motor and tank
Hose
Crevice tool
Brush
Upholstery tool
Wands (2)
Shoulder strap
Some of these items are packed inside the tank. If parts are missing, contact our
Customer Service Department. Do not return your vacuum to the store you purchased it
from.
For technical assistance or service parts, contact Customer Service Department at:
Producteers Inc.
811 Overhills Drive, Suite 101
Old Hickory TN 37138
[e-mail]
Phone: [phone] Monday –Friday, 8:00 to 5:00, Central Time
1. Vacuum head
2. Tank
3. Clamp
4. Hand tube
5. On/off switch
6. Post-filter
7. Power cord
8. Hook for power cord
9. Slot for tube storage
10. Hose
11. HEPA filter
12. Filter cleaning button
13. Hand grip to empty tank
14. Latch for post filter
15. Crevice tool
16. Upholstery tool
17. Shoulder strap
18. Wands (2)
19. Brush tool
CUSTOMER SERVICE
OVERVIEW
Figure 1

6
When servicing of double-insulated appliances note that in a double-insulated appliance, two
systems of insulation are provided instead of grounding. No grounding means is provided on a
double-insulated appliance, nor should a means for grounding be added to the appliance.
Servicing a double-insulated appliance requires extreme care and knowledge of the system,
and should be done only be qualified service personnel. Replacement parts for a double-
insulated appliance must be identical to the parts they replace.
! WARNING: Inadequate extension cords can be dangerous.
When using where an extension cord is necessary, a 2-conductor grounding cord must be used
for safety as well as cord and plug must be of watertight construction. This will also prevent
overheating and a loss of power. Do not use any AWG smaller than 16ga. Use AWG 14 ga for
25-50ft. and 12 ga for 50+ft.
Before using appliance, inspect power cord for loose or exposed wires and damaged insulation.
Make any needed repairs or replacements before using your appliance.
Inadequate extension cords can be dangerous!
NOTE: STATIC SHOCKS ARE COMMON IN DRY AREAS OR WHEN THE RELATIVE
HUMIDITY OF AIR IS LOW. THIS IS ONLY TEMPORARY AND DOES NOT AFFECT THE
USE. TO REDUCE THE FREQUENCY OF STATIC SHOCKS IN YOUR HOME, THE BEST
REMEDY IS TO ADD MOISTURE TO THE AIR WITH A CONSOLE OR INSTALLED
HUMIDIFIER.
1. Read the IMPORTANT SAFETY INSTRUCTIONS section of this manual thoroughly before
setting up and using this vacuum cleaner.
GROUNDING INSTRUCTIONS
EXTENSION CORDS
SET UP INSTRUCTIONS

7
2. Be sure the switch, Figure 1 (5), is in the off position. 0= off I= on
3. Be sure the power cord is not plugged into an electrical outlet.
4. See Figure 2. Remove vacuum head (A) from tank (B) by pulling gently on the lower part of
the clamps (C) on the vacuum head.
5. Remove any accessories that may have been packed inside the tank.
6. Attach the vacuum head to the tank. Be sure that vacuum head is securely clamped to the
tank.
7. See Figure 3. Insert hose adaptor (A) into the intake port and turn handle (D) clockwise until
locked. To remove the hose, turn handle (D) counter clockwise until unlocked and pull the
hose adaptor (A) out.
8. See Figure 4. Adjust the suction power by moving the sliding valve (A) back and forth with
your finger tip. The suction power is highest when the sliding valve is closed and lowest
when all open.
9. Attach crevice tool, upholstery tool or brush tool to the hand tube.
Figure 2
Figure 3
Figure 4

8
°
! ATTENTION: A HEPA filter is highly recommended when vacuuming dry materials.
1. Check to see that on/off switch, Figure 1 (5), is off (0).
2. Plug the power cord into an electrical outlet.
3. Start vacuum by turning switch on (I).
4. This vacuum cleaner is equipped with a filter which can collect fine dust, including cold
ashes from fireplaces. Ashes must be cold. Do not attempt to vacuum hot or warm
ash. Maximum temperature of the ashes should not be warmer than 104°F / 40°C.
5. This dry vacuum cleaner is also equipped with a post-filter to catch dust in the exhaust
air.
6. Figures 5 and 6. Use Filter Cleaning System to maintain performance before and after
each use. When working with fine dust or cold ash, the filters can get clogged,
decreasing the performance of the vacuum as well as the life of the filters. To operate
the Filter Cleaning System:
a. Turn the switch on (I).
b. See Figure 5. Place the end of the hose in the palm of your hand (A) or on a flat
solid surface or in the holder for hand tube (B). This will close the air flow and
build up pressure in the tank to clean the filter. Sliding valve must be closed.
c. See Figure 6. Push the filter cleaning button, Figure 1 (12), 5 times fast.
Figure 5
VACUUMING DRY MATERIAL
Figure 6

9
NOTE: THE SLIDING VALVE MUST BE CLOSED TO OPERATE THE FILTER CLEANING
SYSTEM.
NOTE that this vacuum cleaner has a built in thermal overload protector to protect the motor
from high temperatures. This can occur under heavy use. If the motor temperature shuts off
during operation, turn the switch off and allow the motor to cool for 5 minutes. Turn switch on
and resume operation.
7. When the tank needs to be emptied, see Figures 7,8:
a. Find an appropriate waste bin outside for disposal of material in the tank.
b. Turn switch off (0) and unplug power cord.
c. Detach hose from suction inlet.
d. Remove vacuum head from the tank by pulling gently on the lower part of the
clamps on the side of the vacuum head.
e. Place the vacuum head on a flat surface, resting on 2 rear legs and one front leg.
See Figure 7.
f. Empty the tank into the bin. Note the tank is equipped with a hand grip, Figure 1
(13), at the bottom for convenience.
g. Clean the post filter. See Figure 11 for instructions.
h. Attach vacuum head to tank, ensuring they are securely clamped together.
i. Insert hose into suction inlet.
! WARNING: Wear protection mask when the tank needs to be emptied.
Figure 8
Hand grip in
bottom, rear.
Figure 7
Legs

10
HEPA Filter
1. Suction performance can be maintained with the Filter Cleaning System. Eventually
filters will need to be washed or become worn and need to be replaced. To clean or
replace the filter:
a. Turn switch off (0) and unplug power cord from the electrical outlet.
b. Remove hose from suction inlet. (See Figure 3)
c. Remove head from the tank by pulling gently on the clamps on the vacuum head,
turn the head upside down.
d. See Figure 9. Remove the 4 screws fixing the filter frame to the head.
e. See Figure 10. Remove the filter frame (A) and the filter (B).
f. Insert a new filter into the filter frame and place it on the head. Use only filters
from model FSM1 to insure that you have a genuine replacement filter. To
purchase a FSM1 Filter Kit. See instruction for ordering filter kit below.
g. Insert the 4 screws. Do not over tighten the screws. Use an appropriate screw
driver.
h. Check to insure that the filter is properly in place and there is a proper seal
between the head and filter frame.
i. Attach head to the tank, ensuring they are securely clamped together.
Use only replacement filters from a FSM1 Filter Kit. This kit contains a HEPA filter and a
post filter. To order a FSM1 Filter Kit, contact Customer Service at 866-814-4103 or
[e-mail].
Never machine wash or machine dry filters.
Post Filter
2. The post filter ensures that very fine dust does not escape when using the filter cleaning
button.
3. See Figure 11. To clean or replace the post filter move the latch (A) down by pushing the
button. Take out the filter (B).
Figure 9
Figure 10
FILTER CLEANING AND REPLACEMENT
Figure 11

11
4. Clean the post filter (B) outside by blowing air backwards through it and/or shaking it
rapidly up and down.
1. Store vacuum cleaner above freezing temperature, 32°F / 0°C.
2. See Figure 12.
a. Place the hand tube in the holder for hand tube (A)
b. The crevice tool / brush tool can be stored on the machine (B)
c. Place cord on cord hook (C)
WARNING:When not in use: disconnect the power cord from the electrical outlet.
Repair or service of electrical components such as cord or motor, must only be carried out by an
authorized service center.
Vacuum cleaner does not
start:
Check to see that the plug is correctly inserted in the
electrical outlet and that there is power at receptacle.
A circuit breaker may have tripped. Check the circuit breaker
box.
The cord or plug may be damaged. Call the Customer
Service Department to get the nearest authorized service
center.
Motor stops:
A thermal overload protector will shut off the motor if the
motor temperature is too high. If this occurs, turn the switch
AFTER USE, STORAGE
TROUBLE SHOOTING
Figure 12

12
off. Wait 5 minutes for the motor to cool. Turn switch on and
resume operation.
Suction power is reduced:
The tank may be full and needs to be emptied. See Figure 7.
The wands, hose and nozzles may be clogged and need to
be cleaned.
Any of the above may be damaged and need to be replaced.
The filter may be clogged. Use the Filter Cleaning System,
Figure 5 and 6, to maintain suction performance.
Replace the filter or make sure the filter is installed properly.
The hose connection is loose and need to be tightened.
Static shocks:
If the environment is too dry, add moisture to air. If possible,
use a humidifier.
In case the relative humidity of air is low, please note that this
situation will not have any effect on use of the vacuum
cleaner.
Warranty covers:
This vacuum cleaner is warranted for one (1) year. This warranty includes spare parts and labor
costs, and covers manufacturing and material defects that may occur during normal domestic
use. This warranty does not include normal wear and tear.
Service under this warranty will only be performed with proof that the defect occurred within the
warranty period and that the vacuum cleaner was purchased as a new product. Proof will be a
cash register receipt with date and product type.
Warranty does not cover:
Normal wear and tear of accessories and filters.
Defects or damage occurring as a direct or indirect result of incorrect use - such as the
vacuuming of rubble, or carpet deodorant powder (read safety warnings and
instructions)
Abuse due to failure to follow instructions in the user manual.
Incorrect or poor configuration, i.e. setting up or improper connection, fire-damage, fire,
lightning strike or unusual voltage fluctuations or any other electrical disturbances.
Electrical disturbances include a defective circuit breaker or defective electrical
installations on the supply grid.
Warranty becomes void:
If a failure is caused by the use of non-original filters.
If the model, item or any identity number is removed from the vacuum cleaner.
If the vacuum cleaner has been repaired by a non-authorized dealer.
If the machine has been used for commercial purpose.
WARRANTY

13
! WARNING: If any of the motor housing parts should become detached or broken,
operations should be discontinued immediately to avoid personal injury. Repairs should
be made before reuse.
NOTE: For technical assistance, contact our Customer Service Department.
The Honeywell Trademark is used under license from Honeywell International Inc. Honeywell
International Inc. makes no representations or warranties with respect to this product.
This product is manufactured by Producteers.

14
______________________________________________
Manual del usuario
Aspiradora en seco
Modelo: HWS200

15
Antes de usar el aparato por primera vez, asegúrese de leer completamente este
manual y téngalo siempre a mano.
La aspiradora debe usarse como producto multipropósito doméstico/familiar, correspondiente a
la descripción dada en estas notas de operación y seguridad.
No se debe usar la aspiradora para fines comerciales o profesionales.
Cualquier uso más allá de este no se considera adecuado. El fabricante no es responsable por
ninguna pérdida.
! ATENCIÓN!: REVISE LA SECCIÓN "INSTRUCCIONES DE SEGURIDAD
IMPORTANTES" ANTES DE USAR LA ASPIRADORA. CONSERVE
ESTAS INSTRUCCIONES PARA FUTURAS CONSULTAS.
! PELIGRO!: No utilice nunca este aparato en presencia de materiales o vapores
inflamables, ya que los dispositivos eléctricos producen arcos o
chispas que podrían provocar un incendio o una explosión.
NUNCA DEJE EL APARATO ENCENDIDO SIN SUPERVISIÓN!
! ADVERTENCIA!: NO utilice esta aspiradora para aspirar restos de pintura con plomo,
ya que esto puede provocar que se dispersen partículas finas de
plomo en el aire. Esta aspiradora no es apta para la limpieza de
pintura con plomo en virtud del reglamento 40 CFR, parte 745, de la
EPA (Agencia para la protección del medio ambiente).
! ADVERTENCIA!: No utilice esta aspiradora para succionar agua u otros líquidos.
INSTRUCCIONES DE SEGURIDAD IMPORTANTES
PROPÓSITO Y USO
ESTIMADO CLIENTE

16
Cuando se utiliza un aparato eléctrico, se deben tomar siempre ciertas precauciones
básicas, incluyendo las que se describen a continuación:
LEA LAS INSTRUCCIONES EN SU TOTALIDAD ANTES DE USAR ESTA ASPIRADORA.
! ADVERTENCIA! –PARA REDUCIR EL RIESGO DE INCENDIO, DESCARGA ELÉCTRICA
Y LESIONS:
Utilice la aspiradora únicamente según las indicaciones de este manual. Utilice solo los
accesorios recomendados por el fabricante.
1. No utilice la aspiradora para recoger material en combustión o incandescente, como
cigarrillos, cerillas o cenizas calientes.
2. Nunca sumerja el aparato, el cable de alimentación o el enchufe en agua, ya que esto
podría provocar una descarga eléctrica. Cuando utilice el aparato, asegúrese de que el
cable de alimentación y, en su caso, el cable de extensión no estén en contacto con agua.
3. No utilice la aspiradora para recoger objetos punzantes, como agujas o trozos de cristal.
4. Antes de utilizar el aparato, asegúrese de que los filtros estén instalados y colocados
correctamente.
5. ADVERTENCIA: NO utilice esta aspiradora para aspirar restos de pintura con plomo, ya
que esto puede provocar que se dispersen partículas finas de plomo en el aire. Esta
aspiradora no es apta para la limpieza de pintura con plomo en virtud del reglamento 40
CFR, parte 745, de la EPA (Agencia para la protección del medio ambiente).
6. Nunca utilice la aspiradora para aspirar los siguientes materiales: gases explosivos o
combustibles, líquidos y partículas de polvo (partículas de polvo reactivas), partículas de
polvo de metal reactivas (como aluminio, magnesio o zinc) en combinación con
detergentes altamente ácidos o alcalinos, disolventes no diluidos, muy ácidos o alcalinos,
u orgánicos, tales como la gasolina, diluyente de pintura, acetona, aceite de calefacción
y materiales similares.
7. Riesgo de incendio: No utilice la aspiradora para recoger objetos en combustión o
incandescentes.
8. No utilice la aspiradora para aspirar líquidos inflamables o combustibles, como gasolina
o partículas de polvo reactivas, ni en las zonas en que estos puedan estar presentes.
9. No utilice la aspiradora para pulverizar líquidos inflamables, como pinturas con base de
aceite, barniz, detergentes domésticos, etc.
10. No utilice la aspiradora para aspirar materiales tóxicos, cancerígenos, combustibles o
peligrosos, como amianto, arsénico, bario, berilio, plomo, pesticidas u otros materiales
que puedan poner en riesgo su salud.
11. Si va a utilizar la aspiradora para recoger hollín, cemento, yeso o polvo de yeso,
asegúrese de que el filtro HEPA esté instalado y utilice el sistema de limpieza de filtros,
ya que se trata de partículas muy finas.
12. Para evitar la combustión espontánea, vacíe el depósito después de cada uso.
13. NOTA: Si el ambiente es muy seco, se puede producir una descarga electrostática. Esto
no afectará al funcionamiento de la aspiradora. Para reducir la carga de electricidad
estática, aumente el nivel de humedad del aire con una consola o un humidificador.
14. Apague todos los interruptores antes de desenchufar el cable de alimentación.

17
15. MANTÉNGASE ALERTA y utilice el sentido común. No use la aspiradora si se encuentra
bajo la influencia de drogas, alcohol o medicamentos o si está cansado o le cuesta
concentrarse.
16. Una vez terminado el trabajo de limpieza recoja el cable de alimentación, ya que podría
tropezar con él.
17. Tenga especial cuidado cuando utilice la aspiradora en escaleras o sobre una escalera
de mano.
18. Mantenga la ropa, las manos, el cabello y las demás partes del cuerpo alejados de las
aberturas y las partes móviles.
19. No coloque ningún objeto en las aberturas. No use la aspiradora si alguna de las aberturas
está bloqueada. Mantenga las aberturas libres de polvo, pelusa, pelo y cualquier otra cosa
que pueda reducir el flujo de aire.
20. No toque el enchufe ni el aparato con las manos mojadas.
21. No permita que se use como un juguete. Preste especial atención cuando el aparato sea
utilizado por niños o cerca de estos.
22. Mantenga el material de embalaje fuera del alcance de los niños, ya que podrían sufrir un
accidente por asfixia.
23. No utilice la aspiradora si el cable de alimentación o el enchufe están dañados. Si el
aparato no funciona correctamente, se ha caído, dañado, dejado a la intemperie o
sumergido en agua, póngase en contacto con un centro de servicio técnico autorizado o
un electricista cualificado para obtener ayuda. No utilice el aparato hasta que se haya
llevado a cabo la reparación.
24. No desconecte el aparato tirando del cable de alimentación. Para desenchufar, tire del
enchufe, no del cable.
25. No tire del cable para mover la aspiradora, no use el cable como asa, no pille el cable con
la puerta ni haga pasar el cable por bordes o esquinas afilados. Tenga cuidado de no
pisar el cable con la aspiradora. Mantenga el cable alejado de las superficies calientes.
26. No deje el aparato enchufado sin supervisión. Desenchúfelo de la toma de corriente
cuando no esté en uso y antes de realizar cualquier tarea de mantenimiento. Conecte el
aparato a una toma de corriente con las características adecuadas.
27. No utilice el aparato en exteriores ni en superficies húmedas.
28. Realice los trabajos de mantenimiento de acuerdo con las instrucciones.
29. Use una mascarilla de protección cuando vacíe la aspiradora de polvo fino.
30. Este aparato está dotado de doble aislamiento. Use solo piezas de repuesto idénticas a
las originales. Consulte la sección INSTRUCCIONES DE CONEXIÓN A TIERRA para
obtener información acerca de la reparación de electrodomésticos con doble aislamiento.
Desenchufe el aparato antes de conectar la manguera y las boquillas.
CONSERVE ESTAS INSTRUCCIONES
¡ADVERTENCIA! - Para reducir el riesgo de descarga eléctrica, este aparato dispone de un
enchufe polarizado (una clavija más ancha que la otra). El enchufe está diseñado para
encajar en una toma de corriente polarizada en una sola posición. Si el enchufe no encaja

18
en la toma de corriente, pruebe en la posición contraria. Si aún así no encaja, póngase en
contacto con un electricista cualificado para que instale una toma adecuada. No modifique
el enchufe de ninguna forma.
¡ADVERTENCIA! –No deje la aspiradora desatendida mientras está enchufada y/o en
funcionamiento. Desenchufe el aparato cuando no esté en uso.
Aspiradora de mano en seco Honeywell
Pico HP 4,5; depósito de 5,6 litros *
* La cantidad de litros hace referencia al tamaño del depósito, no a la capacidad para
almacenar material o agua.
Cuando abra la caja, asegúrese de que contiene lo siguiente:
Motor y depósito
Manguera
Boquilla para esquinas
Cepillo
Boquilla para tapicería
Tubos (2)
Bandolera
Algunos de estos artículos vienen embalados en el interior del depósito. Si falta
alguna pieza, póngase en contacto con nuestro Departamento de atención al
cliente. No devuelva la aspiradora a la tienda donde la compró.
Para obtener asistencia técnica o solicitar piezas de repuesto, póngase en contacto con el
Departamento de atención al cliente:
Producteers Inc.
811 Overhills Drive, Suite 101
Old Hickory TN 37138
[e-mail]
Línea gratuita: 866-814-4103 Lunes – viernes, 8:00AM a 5:00PM, hora central
CONTENIDO DE LA CAJA
SERVICIO AL CLIENTE

19
20. Cabeza de la aspiradora
21. Depósito
22. Cierre
23. Empuñadura
24. Interruptor de encendido/apagado
25. Filtro posterior
26. Cable de alimentación
27. Gancho para el cable de alimentación
28. Ranura para guardar el tubo
29. Manguera
30. Filtro HEPA
31. Botón de limpieza de filtro
32. Asa para vaciar el depósito
33. Trampilla del filtro posterior
34. Tubos (2)
35. Boquilla para esquinas
36. Upholstery tool
37. Shoulder strap
38. Brush tool
Cuando tenga que reparar un electrodoméstico con doble aislamiento, tenga en cuenta que estos
aparatos disponen de dos sistemas de aislamiento en lugar de una conexión a tierra. No debe
añadirse una conexión a tierra a los electrodomésticos con doble aislamiento. La reparación de
electrodomésticos con doble aislamiento requiere extremo cuidado y un gran conocimiento del
sistema, y solo debe llevarla a cabo personal técnico cualificado. Las piezas de repuesto de un
electrodoméstico con doble aislamiento deben ser idénticas a las piezas originales.
¡ADVERTENCIA! - El uso de un cable de extensión inadecuado puede resultar peligroso.
INFORMACIÓN GENERAL
REPARACIÓN DE ELECTRODOMÉSTICOS CON DOBLE
AISLAMIENTO
CABLES DE EXTENSIÓN
Figura 1

20
Cuando sea necesario, use un cable de extensión de 2 hilos con toma de tierra para garantizar
la seguridad. Asegúrese de que tanto el cable como el enchufe sean de construcción hermética.
Esto evitará además el sobrecalentamiento y la pérdida de potencia. No utilice un cable con un
calibre menor de 16 AWG. Utilice un cable de calibre 14 AWG para una extensión de 7,5 a 15
metros y de calibre 12 AWG para una extensión de más de 15 metros.
Antes de utilizar el aparato, inspeccione el cable de alimentación para asegurarse de que no
haya cables sueltos o desnudos o daños en el aislamiento.
Realice las reparaciones y sustituciones necesarias antes de utilizar el aparato.
El uso de un cable de extensión inadecuado puede resultar peligroso.
NOTA: LAS DESCARGAS ELECTROESTÁTICAS SON HABITUALES EN ZONAS SECAS O
CUANDO LA HUMEDAD RELATIVA
DEL AIRE ES BAJA. ÉSTE ES UN FENÓMENO TEMPORAL Y NO AFECTA AL
FUNCIONAMIENTO DEL APARATO. PARA REDUCIR LA FRECUENCIA DE LAS
DESCARGAS ELECTROESTÁTICAS EN EL HOGAR, LA MEJOR OPCIÓN ES AUMENTAR
EL NIVEL DE HUMEDAD DEL AIRE CON UNA CONSOLA O UN HUMIDIFICADOR.
10. Lea atentamente la sección INSTRUCCIONES DE SEGURIDAD IMPORTANTES de este
manual antes de montar y utilizar la aspiradora.
11. Compruebe que el interruptor, figura 1 (5), se encuentre en la posición de apagado. 0=
apagado, I= encendido
12. Asegúrese de que el cable no esté conectado a la toma de corriente.
13. Consulte la figura 2. Separe la cabeza de la aspiradora (A) del depósito (B) tirando
suavemente de la parte inferior de los cierres (C) situados en la cabeza.
14. Retire los accesorios embalados en el interior del depósito.
15. Una la cabeza de la aspiradora al depósito. Asegúrese de que la cabeza esté sujeta
firmemente al depósito.
16. Consulte la figura 3. Inserte el adaptador de la manguera (A) en el orificio de entrada y gire
el conector (D) hacia la derecha hasta bloquearlo. Para retirar la manguera, gire el conector
(D) hacia la izquierda hasta desbloquearlo y tire del adaptador de la manguera (A).
Figura 2
INSTRUCCIONES DE MONTAJE
