Honic HN-SB200F User manual
USER MANUAL
HN-SB200F
1080P AHD/HDCVI/TVI/960H Hybrid
Weatherproof Camera
WhatsApp: +86 18028341866
Important Notes
If there is ANY QUESTION of the camera, please contact
us, EACH camera has been tested before shipping.
1. Power supply, coaxial video cable and DVR are NOT
INCLUDED but REQUIRED.
2. Default mode: 1080P AHD video format.
3. Power on the camera, then switch to the
corresponding video format that your DVR support.
4. 1080P HD modes (TVI, AHD, CVI) DO NOT compatible
with 720P or 960P DVR, make sure your DVR is 1080P or
1080N DVR for 1080P mode.
5. At least DC 12V 1A power adapter is required. If
there is no video or IR Led is not working properly at
night, please use DC 12V 2A (or 3A) power adapter. It
depends on the power cable length and quality.
6. Peel off the protective film on the lens and glass
panel before installation, or else the night vision will be
very foggy.
Please read this user manual carefully to ensure
proper use of the product.
Product Description
The HN-SB200F is a high-definition camera designed
around a 1/2.7" Color 2.0 megapixel CMOS image
sensor, 14µ x 20pcs IR LEDs providing infrared capability
up to 65 feet, and a 3.6mm lens with wide angle field of
view of 90 degrees. Please read this user manual
carefully to ensure proper use of the product.
Notice Before Using
Default Mode: 1080P AHD Video Output.
If your DVR is TVI, CVI or Analog DVR, please switch the
corresponding video output mode by OSD joystick.
POWER ON the camera, switch the video output mode
by OSD joystick according to your DVR video type:
LEFT Push 5s to 960H mode for analog DVR.
RIGHT Push 5s to TVI mode for 1080P TVI DVR.
DOWN Push 5s to CVI mode for 1080P CVR.
UP Push 5s to AHD mode for 1080P (N) AHD
DVR.
Note: 5s means 5 seconds
Installation and Operation:
1. Unpacking and Handling
Each unit is shipped assembled and factory tested.
Ensure that all accessories are removed from the
container before discarding packing material.
OSD
Package includes
1x bullet camera
3x mounting screws and screw anchors
1x user manual
1x drill template
1x Allen wrench
2. Mechanical Inspection
Inspect the front and rear of the equipment for shipping
damage. Make sure the equipment is clean, and no
connectors are broken, damaged, or loose. If equipment
appears to be damaged or defective please contact us
for assistance.
3. Special Attention
(i) The installer must comply with electrical safety
standards. There must be sufficient space between
the camera's power supply and video line and any
high voltage equipment and/or cables.
(ii) To help ensure the camera's life and proper
operation do not point the camera towards the sun
or strong light.
(iii) Do not install the camera in an environment where
the temperature is too high or too low,
recommended operating temperature is 14F ~
122F.
(iv) Do not install the camera near a magnetic field or a
high-power motor.
(v) Only use a dry cloth to clean the camera. If there is
dirt that is difficult to remove, wipe gently with a
mild detergent. Never use strong or abrasive
detergents.
(vi) A 12V DC 1A or 2A power supply must be used. AC
power cannot be applied. AC power will damage
the camera and void warranty. Power supply output
voltage, current, voltage polarity and operating
temperature must match requirement of this
equipment.
(vii) Only qualified installers are allowed to install, test
and disassemble the camera.
(viii) Any change to the camera's lens will affect image
quality.
(ix) The camera is a low voltage product. If installed
outdoors, proper safety and lightening grounding
are required.
4. Wiring Connections
(i) Connect the power supply's DC plug to the
camera's power outlet.
(ii) Connect the camera to the DVR with a 75Ω coaxial
video cable.
(iii) Connect power supply's AC plug to a suitable AC
power outlet.
(iv) Adjust the lens direction according to the required
surveillance area and environment.
Setup OSD Menu
Press the OSD joystick to start the OSD menu in any
video output mode, OSD menu will show on monitor:
MAIN MENU
AE
AWB
DAY-NIGHT
IMAGE ENHANCE
VIDEO SETTING
LANGUAGE
FUNC
RESET
SAVE-EXIT
EXIT
OSD Functions and Options
MAIN MENU
AE
BRIGHTNESS
EXPOSURE
GLOBE
CENTRE
BLC
FLC
RETURN
AWB
MODE
ATW
MWB
RGAIN
BGAIN
Gray World (Not Valid)
RETURN
DAY-
NIGHT
MODE
AUTO
Day/Night Switch Sensitivity
COLOR
MONO (B/W)
RETURN
ENHANC
E
CONTRAST
AUTO/MANUAL
SHARPNESS
AUTO/MANUAL
SATURATE
AUTO/MANUAL
3DNR
AUTO/MANUAL
D-WDR
CLOSE/OPEN
RETURN
HD
AHD/CVI/TVI/CVBS
STANDARD
HD:1080P 30 FOR NTSC
HD:1080P 25 FOR PAL
VIDEO
SETTING
APPLY&REBOOT
RETURN
LANGUA
GE
ENGLISH, CHINESE, KOREAN, RUSSIAN, etc
FUNC
PRIVACY & MOTION (PLEASE CHECK BELOW)
RESET
SAVE-EXIT
EXIT
BLC (Back Light Compensation): In images where a
bright light source is behind the subject of interest, the
subject would normally appear in silhouette. BLC allows
the camera to adjust the exposure of the entire image
to properly expose the subject in the foreground.
FLC (Front Light Compensation): In images where a
bright light source is in front of the subject of interest,
the subject would normally not visible clearly. FLC
allows the camera to adjust the exposure of the entire
image to properly expose the subject in the
background.
ATW (Auto Tracking White Balance): White Balance
allows the camera to adjust the tone according to the
color temperature of the light source illuminating the
subject. It allows the operator to see objects as they
appear during daylight.
MWB (Manual White Balance): Adjust the red gain
and blue gain manually to produce white accurately
picture.
Day Night Mode:
a. AUTO: Provide color image at daytime and black
and white image at nighttime automatically by AGC
level.
GAIN DAY/NIGHT: Sensitivity from low to high.
GAIN NIGHT/DAY: Sensitivity from low to high.
b. Color: Provide color image both at daytime and
nighttime.
c. MONO=B/W: Provide black and white image both
at daytime and nighttime.
Contrast: Contrast is defined as the separation between
the darkest and brightest areas of the image. Increase
contrast and you increase the separation between dark
and bright, making shadows darker and highlights
brighter. Decrease contrast and you bring the shadows
up and the highlights down to make them closer to one
another.
Sharpness: Sharpness can be defined as edge contrast,
that is, the contrast along edges in a photo. When we
increase sharpness, we increase the contrast only
along/near edges in the photo while leaving smooth
areas of the image alone.
Saturate: Color gain means saturation, it is similar to
contrast, however instead of increasing the separation
between shadows and highlights, it increases the
separation between colors.
3DNR (Digital Noise Reduction): DNR is a technique
of removing image noise from a video signal by
applying a digital comb filter. It reduces the noise that
can be found in low light images and makes images
clearer. This type of filter is sometimes confused by
motion, resulting in blur trails.
Standard:
a. CVBS: PAL and NTSC, its NTSC in USA.
b. FHD modes: Choose 1080P 30 for NTSC system; its
NTSC in default.
D-WDR: Digital WDR (D-WDR) is a software-based
technique that optimizes image quality by adjusting the
gamma (γ) value to enhance dark areas.
FUNC:
Privacy: Apply a mask to an area you want to hide.
Useful in areas where a camera can see into areas that
are not relevant to security needs.
1. On/Off Optional.
2. Support up to 4 areas, position and size adjustable.
3. Mask support red, blue and green colors.
4. Mask transparency optional.
Motion: Monitor activity more efficient with this feature
by means of highlighting moving objects with outlined
box around the moving object.
1. On/Off Optional.
2. Support up to 4 areas, position and size adjustable.
3. Mask support red, blue and green colors.
4. Mask transparency optional.
Reset: If you need factory reset all the OSD menu
settings, choose reset option.
Save Exit: Make sure click SAVE EXIT for any setting
change if you need to keep the setting.
Exit: Leave the OSD menu.
Specifications
Model No.
HN-SB200F
Video Output Mode
AHD/CVI/TVI/CVBS
Camera
Image Sensor
1/2.7" CMOS Image Sensor
Image Resolution
1080P / 960H
Effective Pixels
1920*1080 in HD mode
TV System
PAL/NTSC
Electronic Shutter
Auto
S/N Ratio
≥50dB
Scanning System
Progressive Scan
Lens
Focus Length
3.6mm
Horizontal View Angle
90 Degrees
Lens Type
Fixed
Pixels
3 Mega Pixels
Night Vision
Infrared LED
14µ x 20pcs
Infrared Distance
65-100 Feet*
IR Status
Under 10 Lux by CDS
IR Power On
AGC Auto Control
Camera Features
Day/Night
YES
OSD Menu Language
YES
White Balance
AUTO / MANUAL
Gain Control
AUTO
Noise Reduction
3DNR
Picture Adjustment
YES
DWDR
YES
OSD Support
YES
UTC
YES (HD Mode Only)
General
Housing
Metal, IP66
Bracket
YES
IR Cut Filter
YES
Operation Temperature
14F ~ 122F RH95% Max
Storage Temperature
-4F ~ 140F RH95% Max
Power Source
DC12V±10%, 700mA
Dimension
157(W) x 70(H) x 66(D)mm
Weight
450g
*Stated maximum IR range is based on ideal conditions in
typical outdoor environment. Actual range and image
clarity depends on installation location, viewing area and
light reflection / absorption level of object.
Trouble Shooting
a. Night vision image very dark, could not see the
object clear
(i) Please check if the IR light is on. If the ambient light
from side is bright, then it may cause the camera
turn off the IR light, then you could not see the
object in dark area. Please adjust the camera
direction to turn on the infrared Led.
b. No picture or only black and white picture after
applying power
(ii) Check all plugs and cables are securely connected
to the proper connectors.
(iii) Ensure your power supply is providing the correct
voltage and current.
(iv) Ensure switch the camera video output mode to
correspond your DVR video type.
(v) Ensure your AHD DVR is 1080P or 1080N, CVI and
TVI DVR is 1080P.
c. The picture has ripples
(i) Check to see if the power supply is experiencing AC
ripple, if so a filter may be required.
(ii) Determine if the monitor is faulty.
(iii) Determine if other peripheral equipment is causing
ripple and if so make the necessary adjustments.
d. The picture appears smeared
(i) The power supply voltage level may be unstable,
therefore, try another power supply.
(ii) Ensure the cables are correctly connected and/or
the cables are of the correct impedance.
e. The picture background continuously changes
color
(i) A fluorescent lamp's magnetic field may cause color
roll, therefore, reduce the number of fluorescent
lamps or increase the distance between the camera
and the lamps.
(ii) Sometimes the environment light is just at a critical
point for day/night switch, please just wait a few
minutes.
Camera Dimensions (mm)
Frequently Asked Questions
Q: What else do I need to make it work?
A: This camera can output 1080P AHD, 1080P CVI,
1080P TVI and 960H signals, so you need:
1. One of 1080P(N) AHD DVR, 1080P CVI DVR, 1080P
TVI DVR or 960H analog DVR.
2. 12V DV power supply.
3. Coaxial video cable with BNC connector.
Q: Does this camera work with 720P DVR system?
A: No, the video signal is 2MP 1080P, it could not work
with 720P DVR.
Some batches of cameras could support 720P DVR,
please switch to CVBS mode, then go to OSD menu,
check VIDEO SETTING-STANDARD, if there is 720p, then
it could work, make sure select 720P 30 for NTSC.
Q: Will the OSD switch stay in same mode if camera
is powered off, or do you have to reset mode each
time you power it back up?
A: It will stay in the same output mode, do not need to
reset each time.
A: Why the color is black and white at daytime?
A: Make sure the camera video signal match your DVR.
First check the DVR signal type, then adjust the OSD
joystick to corresponding signal mode to make it match.
Make sure the camera and DVR are with same video
format, both NTSC or both PAL.
Q: Will this camera work with other brand DVRs?
A: Yes, it could work with most brand DVRs, please
make sure the DVR resolution and signal type is proper.
Q: I have an SDI system, is this compatible?
A: No.
Q: How to reset camera when accidentally change
NTSC to PAL and signal is gone
A: Change DVR from NTSC to PAL, the signal will be
back, then change the camera from PAL to NTSC by
OSD menu, then change the DVR from PAL to NTSC
back.
Q: Is there a way to turn off the IR? I have sufficient
light at night and would prefer that the IR not come
on at all.
A: There is NO switch to turn off the IR led, the light
sensor detect ambient light constantly and turn on/off
the IR led automatically.
If you have sufficient light at night and would prefer
color image, then press OSD joystick to start On-
Screen-Display, choose DAY/NIGHT and switch COLOR
mode, then it will be color image at night, but the IR
light will be on if the ambient light is not bright enough.
2 Ways to avoid the IR light:
1. Make the ambient light bright enough and the light
sensor could turn off IR led.
2. Stick opaque black material on the glass to hide the
IR light.
Q: Could I mount it behind window glass?
A: It is not recommended, window glass could reflect IR
light at night which will ruin the image completely.
If you must mount it behind window glass, please check
the QA just above this question.
Warranty and Customer Service
60-Day Money-Back Guarantee for Any Reason
You may return your undamaged product and
packaging within 60 days of purchase to receive a FULL
REFUND for any reason.
24-Month Warranty for Quality-Related Issues
Honic warrants this product against defects in
workmanship and material for a period of 2 years from
its original purchase date.
The warranty does not cover any incidental, accidental
or consequential damages arising from the use of or the
inability to use this product.
For any further question, please contact:
Tech Support Email: support@honictech.com
WhatsApp: +86 18028341866
Table of contents
