Dallmeier Ddz5200hd series User manual

008316 | REV. 1.0.0 | 2021-04-13

COMMISSIONING

DDZ5200HD Outdoor Series

The reproduction, distribution and utilization of this document as well as the

communication of its contents to others without express authorization is prohibited.

Oenders will be held liable for the payment of damages.

The manufacturer accepts no liability for damage to property or pecuniary damages

arising due to minor defects of the product or documentation, e.g. print or spelling errors,

and for those not caused by intention or gross negligence of the manufacturer.

Figures in this document may dier from the actual product.

Specications subject to change without notice. Errors and misprints excepted.

All trademarks identied by ® are registered trademarks of Dallmeier.

All trademarks identied by * are trademarks or registered trademarks of the following owners:

Google and Google Chrome of Google Inc. headquartered in Mountain View, California, USA;

JavaScript of Oracle Corporation (and/or its aliates) headquartered in Redwood Shores, California, USA;

Microsoft, Internet Explorer, Microsoft Edge and Windows of Microsoft Corporation headquartered in Redmond,

Washington, USA;

Mozilla and Firefox of Mozilla Foundation headquartered in Mountain View, California, USA.

Third-party trademarks are named for information purposes only.

Dallmeier respects the intellectual property of third parties and always attempts to ensure the complete identication of

third-party trademarks and indication of the respective holder of rights.

In case that protected rights are not indicated separately, this circumstance is no reason to assume that the respective

trademark is unprotected.

This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (https://www.openssl.org)

and cryptographic software written by Eric Young (ea[email protected]).

Contents

1 Validity 6

2 Documents 6

This Document 7

Other Applicable Documents

Product Specication

The product specication contains detailed technical data, features and

characteristics of the device.

The target audience of the document is trained system integrators (installa-

tion contractors of video security/surveillance systems).

Conguration

The document entitled “Conguration” contains detailed information con-

cerning the conguration of the device.

The target audience of the document is trained system integrators (installa-

tion contractors of video security/surveillance systems).

3 Typographical Conventions

This document may contain various warning words and symbols that indi-

cate potential sources of danger:

DANGER

DANGER indicates a hazardous situation which, if not avoided, will result

in death or serious injury.

WARNING

WARNING indicates a hazardous situation which, if not avoided, could

result in death or serious injury.

CAUTION

CAUTION indicates a hazardous situation which, if not avoided, could

result in minor or moderate injury.

NOTICE

NOTICE addresses practices not related to physical injury and indicates

measures to prevent device and/or property damage due to improper

installation, assembly, wiring, operation, conguration or maintenance of

the device.

For reasons of clarity and readability, various text formatting elements and

types of emphasis are used in this documentation:

Instructions are indicated by arrows (➡).

➡Always carry out instructions one after the other in the sequence de-

scribed.

“Expressions” in quotation marks usually refer to individual components of

the device (housing parts, mounting elements, connections/interfaces, etc.)

or to control elements of the device’s web-based graphical user interface

(menu items, buttons, etc.).

Paragraphs in italics provide information on basic principles, special

features and ecient procedure as well as general recommendations.

4 Approvals/Certications

The following approvals/certications were valid for the device at the time

of this document’s compilation:

• CE (tested according to DIN EN 50130-4:2011, EN 55032:2015)

• FCC

• RCM

Visit www.dallmeier.com for possible updates.

Information for Users in the United States of America (USA)

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment.

This equipment generates, uses, and can radiate radio frequency energ

and, if not installed and used in accordance with the instruction manual,

may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interfer-

ence at his own expense.

5 Safety Instructions

Only use the device if it is in technically perfect condition, according to its

intended purpose, in a safety and hazard conscious manner and in accor-

dance with the following safety instructions:

• Qualied Personnel

The mounting, connection, commissioning and conguration of the

device may only be carried out by qualied personnel.

This also applies to the maintenance, inspection and repair of the device

in compliance with the locally applicable regulations (regional and

country-specic legal requirements and standards), such as the DIN VDE

0701-0702 series of standards (VDE 0701-0702: “Inspection after repair,

modication of electrical appliances – Periodic inspection on electrical

appliances – General requirements for electrical safety”).

• Regulations

The use of video and audio security/surveillance systems is, in general,

strictly regulated.

Before using the device, inform yourself about the currently valid laws

and regulations regarding data, worker and environmental protection

and ensure compliance with them.

• Opening the Device

The device may only be opened by qualied personnel in a voltage-free

state for commissioning, inspection, maintenance and repair (ensure

adequate ESD protection when working on the open device).

• System Components

Only use internal components that have been tested and approved by

Dallmeier. Inappropriate internal components may cause malfunctions,

damage and data loss and may result in the loss of warranty.

• Modications to the Device

Do not make any modications to the hardware or software of the device

that have not been tested and approved by Dallmeier.

Inappropriate modications (e.g. unapproved paintwork or housing add-

ons) may cause malfunctions, damage and data loss and may result in

the loss of warranty.

• Condensation

If the device is brought from a cold to a warm environment, resulting

condensation may cause malfunctions and damage. In this case, wait

until the device has reached room temperature (up to 8 hours) before

commissioning.

• Operating Conditions

Unfavorable operating conditions may shorten the lifetime of the device,

may cause malfunctions, damage and data loss and may result in the loss

of warranty.

Before using the device, observe the specications given in the technical

data, the operating condition requirements and the maintenance instruc-

tions.

• Earthing/Grounding & Equipotential Bonding

For the safety of persons (protection against dangerous contact voltages)

and devices (protection against over-voltages) as well as for the immunity

of information and communication technolog equipment to electro-

magnetic interferences (EMI), all protective measures, which are specied

by the currently applicable DIN, VDE and ISO standards and which provide

for a standard-compliant earthing/grounding and a correct equipotential

bonding of electrical and electronic devices, are mandatory and must be

fullled by all means.

• Lightning Storms

To avoid damage to the device by electrical surge during lightning storms,

all protective measures, which are specied by the currently applicable

DIN, VDE and ISO standards and which provide for a standard-compliant

lightning protection equipotential bonding, are mandatory and must be

fullled by all means.

• Foreign Bodies in the Device

If objects or liquids get into the device, immediately interrupt the power

supply to the device (e.g. switch o the corresponding circuit breaker or

disable the PoE feature on the corresponding Ethernet port of your PSE).

Contact the sales partner responsible for your area.

• Burnt Smell from the Device

If you notice burnt smell or a formation of smoke coming from the device,

immediately interrupt the power supply to the device (e.g. switch o the

corresponding circuit breaker or disable the PoE feature on the corre-

sponding Ethernet port of your PSE).

Contact the sales partner responsible for your area.

• Disposal of the Device

Do not dispose waste electrical and electronic equipment into the house-

hold trash.

Interrupt the power supply to the device (e.g. switch o the correspond-

ing circuit breaker or disable the PoE feature on the corresponding Ether-

net port of your PSE).

Remove all connected peripherals.

Return the device to the sales partner responsible for your area.

6 General Notes

Warranty

The terms and conditions valid at the time the contract was signed shall

apply.

Scope of Delivery

The standard scope of delivery includes:

• 1× Pair of gloves for a better grip during mounting (or removal) of the

device and to avoid ngerprints on the device (especially on the

polycarbonate dome bubble)

• 1× Flexible rubber sleeve (bellows) for sealing the cable entry

• 1× Hexagon socket screw key (wrench size 5)

• Product documentation

The scope of delivery may dier depending on the ordered equipment,

device variant or country of destination.

NOTICE

Possible damage to the surface coating of the polycarbonate dome bubble

as well as reduced image quality due to ngerprints

➡Do not touch the polycarbonate dome bubble with bare ngers.

Instead, always use the supplied pair of gloves to prevent a reduction

in image quality due to ngerprints and to protect the surface coating

of the dome bubble from possible damage caused by sweat and grease

deposits.

Transportation and Packaging

Store the original packaging for later transportation.

Dallmeier is not responsible for any damage resulting from unprofessional

or improper transportation.

The device should only be shipped in the original packaging.

If the original packaging is no longer available, ensure that the used packag-

ing suciently protects the device against damage, moisture, heat and cold.

Appropriate Use

The cameras of the DDZ5200HD Outdoor series are high-resolution and

high-speed PTZ dome network cameras with 20× or 32× optical zoom, ex-

cellent low-light performance, fast-reacting autofocus as well as a powerful

pan/tilt/zoom mechanism for comprehensive IP-based video surveillance of

areas and objects in outdoor environments.

The cameras described in this document are designed for quick and easy

mounting on wall and ceiling brackets with Mountera® Quick-Lock System

and, depending on requirements, can either be powered by an external

48V DC power supply unit or operated with Power over Ethernet* (PoE+,

IEEE 802.3at).

Built into IP69-rated weather-proof enclosures and featuring an integrated

fan/heater system*, the cameras of the DDZ5200HD Outdoor series are

suitable for residential, public, commercial and industrial use in both indoor

and outdoor areas during the day and at night (24/7/365 continuous opera-

tion).

* No fan/heater support if operated with Power over Ethernet.

The cameras of the DDZ5200HD Outdoor series are designed exclusively

for hanging installations on ceilings or walls (optionally available

Mountera® bracket required).

Operation

➡Observe the following notes for operating the device:

• If the device or the cables connected to the device are located near

sources with strong radiation (e.g. radio transmitters, magnetic

elds), the video image may be distorted.

• The device is equipped with Automatic Gain Control (AGC).

In low-light conditions the image may be altered (e.g. noise).

This is not a malfunction.

• The video image quality depends on the lighting conditions and the

used monitor.

• The accuracy of the Automatic White Balance (AWB) algorithm

depends on the used lighting.

Mixed light (consisting of articial light and daylight) may cause color

distortions (inaccurate color reproduction).

• Poor lighting can lead to an incorrect white balance.

Formation of Condensation

Condensation forms mainly due to temperature or pressure uctuations.

If the device is transported between locations with high temperature dif-

ferences, condensation may form on the outside of the housing as well as

inside the device. In this case, wait until the temperature of the device will

have slowly adapted to the ambient temperature prior to commissioning.

Pressure Equalization Element

The device is equipped with a pressure equalization element.

Pressure equalization elements are used to prevent the formation of con-

densation in sealed enclosures, where humidity normally cannot escape to

the outside.

Fig. 1: Pressure equalization element

The built-in pressure equalization element of the device continuously equal-

izes the internal pressure of the device to the ambient pressure. Thus, the

temperature and humidity dierence between the housing interior and the

ambient air is balanced, and hence the formation of condensation is largely

prevented.

Condensation Inside the Housing

Despite the built-in pressure equalization element, a sudden drop in tem-

perature (e.g. based on heavy showers or thunderstorms) may temporarily

cause water vapor (moisture) inside the housing, resulting in condensation

on the inner surface of the bubble as well as on the front glass element of

the camera lens.

In this case, activate the integrated heater manually via the WebCong user

interface of the camera until all components are free of condensation again.

However, note that the built-in heater cannot be activated if the internal

housing temperature has exceeded +60°C (140°F).

Condensation on the Outside of the Housing

Condensation on the outside of the housing may form temporarily – usually

in the early morning when the humidity level is high, as the ambient air is

warming faster than the outer surface of the housing.

This results in condensation on the outer surface of the polycarbonate bub-

ble (like dew on the grass).

This phenomenon is due to physical reasons and, therefore, does not consti-

tute a defect.

7 Requirements

Operating Mode and Ambient Conditions

The device is designed for 24/7/365 continuous operation in both indoor

and outdoor environments.

However, the device may only be installed and operated under suitable

ambient conditions.

NOTICE

Damage to the device due to unfavorable ambient conditions

Use of the device under unfavorable ambient conditions may shorten the

lifetime of the device and may cause malfunction or damage to the device.

➡Do not install and operate the device in environments with

• a large amount of dust and dirt,

• water or oil vapors (e.g. in a kitchen),

• exposure to direct sunlight for a longer period of time,

• high heat radiation (e.g. generated by a radiator),

• unsuitable ambient temperatures or unfavorable relative humidity

levels (observe the product specication of your device),

• nearby strong radiation sources (e.g. radio transmitters, magnetic

elds),

• a corrosive atmosphere, such as indoor swimming pools with a high

concentration of chlorides, or in industrial areas with the presence of

aggressive elements (gases, vapors, solvents, chemicals, etc.),

• areas of explosive hazard due to ammable material (gas, vapor,

mist or dust),

• poor air circulation or heat dissipation (e.g. in insuciently dimen-

sioned cavities).

Other manuals for DDZ5200HD Series

This manual suits for next models

Table of contents

Other dallmeier Outdoor Camera manuals

dallmeier

dallmeier PANOMERA S4 User manual

dallmeier

dallmeier DDZ5200HD Series User manual

Popular Outdoor Camera manuals by other brands

Abode

Abode Outdoor Smart Camera user guide

Honeywell

Honeywell HC70WB8R2 Quick installation guide

Monacor

Monacor INC-4212BV quick guide

nest

nest Nest Hello Pro Installation & Configuration Guide

Mobotix

Mobotix B016 Quick install

SkyLink

SkyLink WC-520 user manual

Oncam

Oncam Evolution 180 Series quick start guide

RedLINK

RedLINK Argus PT Ultra quick start guide

Sercomm

Sercomm SCE2R0-29 Setup guide
