HOOVER®
Deluxe Upright
Cleaner
Read this manual before
operating the cleaner
Thank you for selecting a HOOVER®product.
This cleaner was inspected and packaged carefully before being shipped from the
factory. If you should happen to need assistance during assembly or operation call
1-800-944-9200 for an automated referral of authorized service outlet
locations (U.S. only) or
1-330-499-9499 to speak with a representative in our Consumer
Response Center or
Visit us online at www.hoover.comto find the service outlet nearest you
(click on the “Service” button).
PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE
Owner’s Manual
ENGLISH ➜pp.1-14
ESPAÑOL ➜pág 15-22
FRANÇAIS ➜p. 23-30

2
Fill in and retain
The model and serial number are located on the bottom of the cleaner.
For your personal records, please enter the COMPLETE model and serial number
in the spaces provided and retain this information.
Your cleaner is model_________________________________________
and has serial number_________________________________________
It is suggested that you attach your sales receipt to this owner’s manual.
Verification of date of purchase may be required for warranty service of your
HOOVER product.
Save!
Index
Assembling Cleaner..........................3-7
Cleaning Effectiveness
Per Amp Rating ..................................13
HowTo Use
Cleaner Description ..........................7
Cleaning Tools ..................................9
Embedded Dirt FINDER™ feature....8
Upright Cleaner..............................7-8
If You Have a Problem ........................25
Clearing Blockages ........................14
Important Safeguards ..........................2
Maintenance
Authorized Service..........................13
Lubrication ......................................13
Replacing Belt ................................12
Replacing Brush Roll......................12
Replacing ‘ D i rt FINDER’B a t t e ry..10-11
Replacing Headlight........................11
Replacing Filter Bag........................10
Replacing Final Filter......................11
Warranty ..............................................27
Important Safeguards
When using an electrical appliance, always follow
basic precautions, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
Warning:To reduce the risk of fire, electric shock, or injury:
•Do not use outdoors or on wet surfaces.
•Close supervision is necessary when any appliance is used by or near ch i l d r e n .
Do not allow vacuum cleaner to be used as a toy or to run unattended at any time.
•Keep hair,loose cl o t h i n g ,f i n ge rs ,feet and all parts of body aw ay from openings,
rotating agitator and other moving part s . Do not operate cleaner in bare feet or
when wearing open toe shoes or sandals.
•Do not pick up anything that is burning or smoking,s u ch as cigarettes,m a t ch e s ,or
hot ashes.
•Do not use to pick up flammable or combu s t i ble liquids such as gasoline or use in
areas where they may be present.
•Avoid picking up hard ,sharp objects with the cl e a n e r.T h ey may damage the cleaner
and the bag .
•Do not use without dust bag or filters in place.C h a n ge bag frequently when picking
up very fine materials such as pow d e r.
•Use extra care when cleaning on stairs .
•Do not put any object into openings. Do not use with any opening bl o ck e d ;keep
free of dust,l i n t , h a i r,or anything that may reduce air flow.
•Do not pull or carry by cord ,use cord as a handle,close door on cord or pull cord
a round sharp edges or corners .Do not run appliance over cord .Keep cord aw ay
f rom heated surfaces.
•A lw ays disconnect cord from electrical outlet before servicing the cl e a n e r.
•Unplug cleaner when not in use.Turn off all controls before unplugg i n g .
•Do not unplug by pulling on cord . To unplug,grasp the plug,not the cord .N ever
handle plug or appliance with wet hands.
• The use of an extension cord is not recommended.
•Do not use with damaged cord or plug.If appliance is not working as it should,has
been dro p p e d ,d a m age d ,left outdoors ,or dropped into water,take it to a Hoover
Fa c t o ry Service Center or Au t h o r i zed Hoover Warranty Service Dealer (Depot).
•Use vacuum cleaner only for its intended use as described in the instructions.
Use only attachments recommended by The Hoover Company ;o t h e rs may cause
hazards.
Save these instructions!
© 1995, 1998 The Hoover Company
www.hoover.com

3
1. Assembling cleaner
It is extremely important to
read and follow all the
instruction steps in order.
The assembled cleaner will look like this drawing.
If you need assistance with any step of the assembly, call
1-800-944-9200 for an automated
referral of authorized service outlet
locations (U.S. only) or
1-330-499-9499 to speak with a
representative in our Consumer
Response Center or
Visit us online at www.hoover.com to find the
service outlet nearest you (click on the “Service” button).
This cleaner is intended for household use.
Side mounted hose trademark of The Hoover Company
Carton contents
Remove all parts from carton and
identify each item shown.
Note that some of the items are
shipped together in the sealed
bag with the owner’s manual.
A.Upper handle
B.Lower handle
C.Cord
D.Bag compartment and tool
storage
E.Bracket
F.Embedded Dirt FINDER™ battery
(some models only)
G. Extra belt (some models only)
H. Cleaner base and hose
I. Handle bolt and nut packet
(One extra nut included)
J. Paper bag (some models
come with 2 bags, others
have additional bags.)
K.Cleaning tools and extension wand
1-1
ABC
E
F
G
H
IJ
K
D

4
Step 1 Assemble
handle
Note: The white switch lock
above the ON/OFF switch, aids
in assembly of your cleaner.
Assembly can be continued if the
switch lock is missing. However,
do not remove the switch lock
until assembly is completed.
Align upper handle and lower
handle as shown. Place upper (C) and lower (D) handle parts on a flat surface,
aligning rod sections (B). With hands on sides of parts, push
them together firmly until they “click” and rod sections lock
together.
*Be careful not to press against rod (B) extending from the
lower handle shown in Fig. 1-3. Do not push handle
together with hands on ends of handle parts.
Step 2 Attach cord
With side marked “UP” visible, insert
large rectangular end of cord into
pocket in bottom of handle.
Make sure rectangular end is
pushed down into the handle as far
as possible.
Slide cord protector (E) toward
upper handle.
Rotate cord protector (E) on cord
until you see its arrow (F). With arrow on cord protector (E)
pointing toward arrow on upper
handle (G), press groove (H) in
cord protector into slot (I) in
upper handle.
Step 3 Attach handle
Note location of tapered rails (J) on
bracket (K) and on lower handle. With printed side of bracket (K) facing up, slide rails on bracket
onto rails (J) on lower handle until
bracket snaps past the lock tab (L).
J
KK
J
L
1-2
1-3 1-4 1-5
1-7 1-8
A
BC
D
E
E
FG
E
HI
Pull cord tight.
Press cord into place at each of the
three notches indicated.
Do not plug cleaner in until
assembly is totally complete.
1-6

5
N
M
Pull bracket toward bottom of handle
slightly to make sure bracket is
locked in place.
Make sure hole in bracket aligns
with hole in handle.
With ON/OFF switch to the front,
place assembled handle down onto
extension on cleaner base.
Rock handle side to side while
pushing down firmly. Extra pushing
effort may be required.
Push bolt into hole (N) on lower front
of handle.
If bolt will not go through hole
easily , check the following:
• the bracket is properly
positioned (Fig. 1-9)
•the handle is pushed down
completely (Fig. 1-10)
Place nut in recessed area (O) at
back of handle. Hold nut in place
while tightening bolt securely with a
screw driver.
Only one nut is needed on this
model. The extra nut is not required
but has been provided for your
convenience.
O
P
T
R
S
Q
1-9 1-10 1-11
1-12 1-14
1-15 1-16 1-17
Pull bag door latch forward and
remove door. Set bag door aside. Slide large tab (P) on bottom of bag
housing into slot between the brack-
et (Q) and the lower handle.
Note round opening and hooks (R)
on back of bag compartment.
Place opening over dirt tube (S) and
align hooks with slots in handle.
Push very firmly at (T) to snap
hooks into handle.
Pull on bag compartment to make
sure it is completely snapped to
handle.
Step 5 Install Embedded Dirt FINDER™ battery
(Some models only)
Press in at area indicated on battery
holder and remove holder. Connect battery to proper polarity
snaps. Place battery in holder.
Snap battery holder back into place.
Continued ➜
1-13
Step 4 Attach bag compartment

6
Step 6 Attach paper bag
Align opening in paper bag with dirt
tube (S) inside bag compartment. Push paper bag firmly onto tube.
Tuck top and bottom of paper bag
into bag compartment.
To replace bag door, insert the 2 tabs
on bottom of bag door into the 2 slots
onbag compartment.
Make sure all edges of paper bag
are completely inside the bag
compartment.
Close door.
Pull switch lock (U) above ON/OFF
switch (V) straight out.
Dispose of lock.
Note: If lock has come off during
assembly make sure switch is in
the OFF position (down) before
plugging cord into electrical
outlet.
Step 7 Position tools
Raise handle to upright position.
Bring hose toward front of cleaner
and stretch hose over hose rack.
Push opposite hose end firmly into
rear “cup” in rack.
Note: Hose end must be firmly
connected to tool rack when
cleaning floors.
Position wand,with smaller diameter
end down, at side of cleaner as
shown.
Open tool cover.
Position dusting brush (X),
furniture nozzle (Y), and crevice
tool (Z), into tool storage area
as shown.
XAA
BB
Y
Z
U
V
The extra belt (AA) and one extra
paper bag (BB) can be stored on
the back of the cleaner handle as
shown.
CAUTION:When cleaner is turned
on, the agitator will continue to
rotate when cleaner handle is in
upright position. Avoid tipping
cleaner or setting it on furniture,
fringed area rugs, or carpeted
stairs during tool use.
Fill out and return the product
registration card included with
your cleaner.
1-18 1-19 1-20
1-21
1-22 1-23
1-24 1-25
S

7
2. How to use The assembled cleaner will look like the
drawing.
1. Handle
2. ON/OFF switch
3. Cord hooks: wrap cord around
hooks for storage. The top hook can
be rotated right or left for easy cord
release.
4. Embedded Dirt FINDER™ sensitivity
switch*
5. ‘Dirt FINDER’display*
6. Furniture nozzle
7. Dusting brush
8. Crevice tool
9. Tool cover
10. Bag door latch
11. Bag door
12. Final filter door*
13. Stair cleaning handle
14. Hood
15. Carpet height control
16. Soft Guard™protector: provides
extra protection for your fine furniture.
17. Headlight
18. Hose
19. Extension wand
20. Extra belt* storage
21. Extra bag* storage
22. Handle release lever
*some models only
ON-OFF switch
To turn cleaner ON, push switch (A) up.
To turn cleaner OFF, push switch down.
Note: To reduce the risk of electric shock,
this appliance has a polarized plug (one
blade is wider than the other). This plug
will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit,
contact a qualified electrician to install the
proper outlet. Do not change the plug in
any way.
To insure that the filter bag is inflated, plug
cord into electrical outlet and turn cleaner
ON. With handle in upright position, pull
back on handle until front of cleaner (B) is
lifted off the carpet.
Hose end must be firmly pushed into “cup”
in tool rack for maximum suction on floors.
Handle positions
The handle of your cleaner has three
positions; upright for storage and when
using cleaning tools; operating for
general operation on carpet and floors;
low for reaching under low furniture. Step
on handle release lever to lower handle.
Transporting cleaner
To move your cleaner from room to
room, put handle in upright position, tilt
cleaner back on rear wheels, and push
forward (A).
The cleaner can also be moved by
lifting it as shown in (B)
2-1
2-2 2-3 2-4
Cleaner description
A
BA
B
Operate cleaner only at voltage specified on data plate on bottom of cleaner.
This cleaner is intended for household use.
1
2
3
3
3
5
67
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
4

8
Edge cleaning
Special edge groomers are provided on
both sides of the front of the cleaner
to help remove dirt in carpet near
baseboards and furniture.
Guide either side of the cleaner parallel
to edge of carpet or furniture.
Cleaning lightweight
flexible rugs
Stand on one end of rug and move
cleaner toward other end or edge.
Before reaching edge, push down on
handle. This will lift up the nozzle (front
of cleaner) and will prevent rug from
clinging to cleaner.
Continue to lift front of cleaner so that
when you have reached the edge, it is
completely off the rug. Move cleaner
back to start again, lower front of
cleaner, and use only forward strokes.
Stair cleaning
Astair cleaning handle has been
designed for ease in using your cleaner
on stairs.
With handle in operating position, place
fingers under edge of stair cleaning
handle and guide cleaner with other
hand on upper handle.
As an alternative, you may use the hose
and furniture nozzle for stair cleaning.
When using cleaning tools, the
agitator will continue to rotate.
CAUTION:To avoid personal injury or
unnecessary wear to carpet, and to
prevent the cleaner from falling, use
extra care if cleaner is placed on
stairs.
Embedded DirtFINDER™
feature (some models only)
With red and green lights (A), the ‘Dirt
FINDER’ system alerts the user to areas
of carpet that may need more cleaning
attention. It is able to sense when a larger
amount of dirt particles, especially
embedded dirt, are removed.
To let you know that the ‘Dirt FINDER’
feature is ready and the battery is good,
the red light will come on when the cleaner
is first turned ON. After a few seconds, the
red light will go off and the green light will
come on. Cleaning may then begin.(If
neither red nor the green light comes on,
the battery may need to be replaced.
See “Maintenance” section.)
The green light will remain on throughout
cleaning except when the detector senses
that a larger amount of dirt is being
picked up; then the red light will come on.
When the red light is on, you should take
additional cleaning strokes in the area
until it changes to green.
• The red light may seldom come on
during cleaning. This means that your
cleaner is picking up primarily fine surface
dust and lint which the system may not
detect, or that the carpet is generally
clean. To increase the feature’s
sensitivity to dirt, set the switch (B) to
the “Hi” position.
• At other times, the red light may stay on
for a considerable amount of time. This
means that the carpet contains a high
level of dirt which is being removed by
the cleaner. To decrease the feature’s
sensitivity to dirt set the switch to
“Reg.”(regular) position.
Carpet height adjust-
ment
When it is necessary to raise and lower the
front of the cleaner (A) for various carpet
pile heights, slide the carpet height control
(B) to the correct setting.
For ease in sliding the control, the handle
should be in the upright position.
The front of the cleaner will not move
into the adjusted position until the handle
is lowered to the operating position.
When using hose and tools, slide the
control to the Cleaning Tools setting.
Return the control to the correct setting
when cleaning floors. Do not leave the
control in the CleaningTools setting
when cleaning floors.
Place end of hose firmly into tool rack for
peak performance when cleaning carpets.
For maximum cleaning perfo r m a n c e,
the following carpet height settings are
recommended.
• Setting 1: for all types of carpet.
• Higher Settings:*for very deep pile
carpet where easier pushing effort is
desired, while maintaining good cleaning
performance.
• Setting 5: for hose and cleaning tool
use only.
*Note: If the cleaner is difficult to push,
slide the control to the next higher setting.
A
B
2-5
2-6 2-7
2-8 2-9 2-10
AB

9
Cleaning tools
Tools allow you to clean surfaces above
the floor and reach hard to clean areas.
Use tools with the cleaner handle in
upright position.
CAUTION: Agitator continues to rotate
while cleaner handle is in upright
position. Avoid tipping cleaner or
setting it on furniture, fringed area
rugs, or carpeted stairs during tool use.
How to clean tools
To clean the hose, wipe off dirt with a
cloth dampened in a liquid detergent.
Rinse with a damp cloth.
Cleaning tools may be washed in warm
water with a detergent. Rinse and air
dry before using.
A. Move carpet height
control
Slide carpet height control to the
CleaningTools setting to divert suction
to the hose and cleaning tools.
Return control to floor settings when
tool use is complete.
2-12
2-13 2-14
2-11
AB
CD
B. Select proper cleaning
tool
A. Dusting brush may be used for
carved furniture, table tops, books,
lamps, lighting fixtures, venetian blinds,
baseboards, shutters, and registers.
B. Furniture nozzle may be used
for upholstered furniture, draperies,
tapestries, mattresses, clothing,
automobile interiors, and carpeted stairs.
C. Crevice tool may be used in tight
spaces, corners and along edges in such
places as dresser drawers, upholstered
furniture, stairs, and baseboards.
D.Wand is used to give extra length
to your hose. Attach it to any of the
above tools.
C. Attach wand and
tools
The tools are attached to the hose or the
wand in the same manner.
Push tool firmly onto hose; twist tool
slightly to tighten or loosen connection.
How to attach tool
cover
The tool cover is designed with a
“break-away” feature which allows it to
snap off if it is pushed open too far. To
reattach, align hinges of cover with slots
on front of tool storage area. Press
cover back into place.
3. Maintenance
Familiarize yourself with these home
maintenance tasks as proper use and
care of your cleaner will ensure contin-
ued cleaning effectiveness.
Filter bag
When to replace
Check filter bag from time to time. It is
recommended that you change the filter
bag when dirt reaches the dotted line.
If more dirt than this accumulates, your
cleaner may not operate effectively.
NOTE: Check and change the filter bag
frequently when using cleaner on new
carpet due to rapid accumulation of
carpet fluff.
CAUTION: Very fine materials, such
as face powder, cornstarch, fireplace
ashes or fireplace soot, may seal the
paper bag and may cause it to burst
even though it is only partially full of
dirt. When cleaner is used to remove
material of this nature, change the
filter bag often.
Continued ➜

10
Where to buy
Filter bags may be purchased from your
local Authorized Hoover Dealer (Depot),
Leading Retailers, from Hoover Factory
Service Centers, using the order form
packed with your cleaner, or through
The Hoover Company online at
www.hoover.com
When ordering bags, be sure to give
the model number of your cleaner.
What to buy
If your cleaner was originally equipped
with a micro filtration bag, it is important
to use only Genuine HOOVER®Allergen
Filtration Type Z disposable bags in
order to maintain the original cleaning
effectiveness of your cleaner.
Regular HOOVER®Type Z disposable
filter bags also fit your cleaner.
To assure that your cleaner operates at
peak performance, it is imperative that
you use only genuine HOOVER filter
bags distributed by The Hoover
Company. HOOVER bags can be
identified by these trademarks –
3-1 3-2
3-3 3-4 3-5
Changing filter bag
Disconnect cleaner from electrical outlet.
Removing and installing filter
bag
Align opening in new filter bag with dirt
tube (B) inside bag compartment. Push
bag collar (A) firmly onto tube.
Fold top of bag down under top of bag
compartment.
®
Replacing bag door
To replace bag door, lift up lower edge of
filter bag. Insert the 2 tabs (C) on bottom
of bag door into the 2 slots on bag
compartment.
Make sure all edges of filter bag are
com p l etelyinside the bag compartmen t .
Close door.
Embedded Dirt FINDER™
battery (Some models only)
The battery is located in a holder inside
the beg compartment behind the filter
bag (A).
What to buy
The ‘Dirt FINDER’ system operates on a
regular 9-volt alkaline battery available at
your favorite retailer.
When to replace
Depending on cleaner usage, the
battery will need replacement every
12 months.
If neither the red nor green light comes
on when the cleaner is turned on or in
use, the battery should be replaced.
How to replace
Removing battery holder
Open and remove bag door as described
for Fig. 2-16. Gently push top of filter bag
aside.
Press in at area indicated on battery
holder and remove battery.
Removing bag door
Pull bag door latch forward and remove
door from cleaner.
Grasp bag collar and pull collar from tube.
Note: Do not clean out old bag and
reuse. Discard used bag.
A
C
A
B

11
3-6 3-7
3-8 3-9
3-11 3-12
3-10
Install new battery
Remove old battery and connect new one
to proper polarity snaps.
Reposition holder and door
Place battery in holder. Snap battery
holder back into place.
Replace bag door as for Fig. 2-18.
Reposition door
Place tabs (B) on door into slot in lower
front of cleaner. Close door.
Should you want to replace this filter,
ask for HOOVER part No. 38766017.
Headlight
What to buy
This cleaner uses a 12 volt, wedge base type 912 bulb, Hoover part No. 27313-101
How to replace
Disconnect cleaner from electrical
outlet.
Removing hood
Using a Phillips head screwdriver,
remove the 4 hood screws (A) and lift off
carpet height control (B).
Lift hood off cleaner base just enough to
access the bulb.
Final filter (some models)
The final filter assists in the filtration process to return clean air to the room.
How to clean
Disconnect cleaner from electrical
outlet.
Removing door
To remove this filter when it becomes
dirty, depress door latch and remove
door.
A
A
A
A
B
B
Removing filter
Lift out filter (A) and hand wash it in
cold water with mild detergent.
Let filter air dry and reposition it on
the front of the cleaner. Make sure
the white colored side of filter faces
outward.
Installing bulb and reposition-
ing hood
Pull old bulb straight out of socket.
Push new bulb straight into socket until
locked in place
Excessive force is not required.
Reposition hood, carpet adjustment
control and the 4 screws. Tighten
screws securely.

12
3-15 3-16
3-19
3-17
3-18
Positioning belt over pulley
With lettering on outside of belt and
positioned as shown in box on (C),
slide new belt over motor pulley (B).
Positioning belt over brush
roll
Insert brush roll through belt and place
belt in belt guide (D) on brush roll.
Installing brush roll
Grasp brush roll firmly and fit it into position
by first sliding end opposite the belt into
the rectangular slot (E) on side of cleaner.
Pull other side of brush roll (F) into place.
Turn brush roll making sure belt is not
pinched between brush roll and cleaner
base.
Replacing bottom plate
Reposition bottom plate and 4 Phillips
head screws. Tighten screws securely.
Agitator brush roll
replacement
3-13 3-14
Belt replacement
The belt on your HOOVER cleaner
causes the agitator to rotate and is
important for the effective operation of
the cleaner. The belt is located under
the bottom plate of the cleaner and
should be checked from time to time
to be sure it is in good condition.
When to replace
To check belt, remove bottom plate as
shown in “How to replace.” Replace
belt if it is stretched, cut or broken.
What to buy
One extra belt has been provided with
your cleaner.
To assure effective operation, use only
genuine HOOVER belts with your
cleaner. When purchasing a new belt,
ask for Hoover part No. 38528-027.
How to replace
Removing bottom plate
Disconnect cleaner from electrical
outlet.
Place handle in low position and turn
cleaner over.
Remove the 4 screws as shown with a
Phillips screw driver.
Lift off bottom plate (A).
Removing used belt
Remove agitator brush roll and
used belt.
Discard used belt.
A
C
DE
F
B
When to replace
Disconnect cleaner from electrical
outlet
When brush roll brushes are worn, it
should be replaced.
To check condition of brushes, move
edge of a card across bottom plate
while turning brush roll. To maintain
cleaning effectiveness, replace brush
roll if brushes do not touch card.
What to buy
When purchasing a new brush roll, as
for Hoover part No. 48414-061.
How to replace
Disconnect cleaner from electrical
outlet.
1. Remove bottom plate, belt and brush
roll following directions for Fig. 3-13
and 3-14.
2. Discard old brush roll
3. Continue following the directions for
“Belt replacement” starting with
Fig. 3-15 to reposition belt, new
brush roll and bottom plate.

13
3-20
Edge groomer
replacement
When to replace
The edge groomers, located on both
sides of the front of the cleaner, should
be replaced when they no longer extend
past the surface of the bottom plate.
What to buy
When purchasing edge groomers, ask
for HOOVER part No. 39511004.
Replacing edge groomers
Disconnect cleaner from electrical
outlet.
Remove bottom plate as described in
Fig.3-13.
Lift off both old edge groomers and slide
new edge groomers into position as
shown.
Reposition bottom plate and secure with
4 Phillips head screws (Fig 3-18).
Lubrication
The motor is equipped with bearings
which contain sufficient lubrication for
the life of the motor. The addition of
lubricant could cause damage. Do not
add lubricant to motor bearings.
The agitator is equipped with two ball
bearings that should be lubricated
periodically by a Hoover Factory
Service Center or an Authorized Hoover
Warranty Service Dealer (Depot).
Cleaning Effective-
ness Per Amp Rating
This is not an Amp rating. Amps do not
measure dirt removal, only the amount of
electricity used. Cleaning Effectiveness
Per Amp is determined by dividing this
model’s Cleaning Effectiveness*by
its Amps.
*Cleaning Effectiveness is the percent
value obtained from dividing:
(a) the geometric mean of the amount of
embedded carpet dirt removed in
testing under ASTM Test Method
F608-89, by
(b) the value 29 (the geometric mean of
the midpoints of the % dirt pickup
scales selected by Hoover as a
reference for its rating system).
Service
To obtain approved HOOVER service
and genuine HOOVER parts, locate
the nearest Hoover Factory Service
Center or Authorized Hoover
Warranty Service Dealer (Depot) by:
• checking the Yellow Pages
under “Vacuum Cleaners -
Household” OR -
•checking the list of Factory
Service Centers provided
with this cleaner OR -
• calling 1-800-944-9200 for an
automated referral of authorized
service outlet locations
(U.S. only) OR -
•checking the Service section of
The Hoover Company on-line at
www.hoover.com
Do not send your cleaner to The
Hoover Company in North Canton for
service, this will only result in delay.
If further assistance is needed, contact
The Hoover Company Consumer
Response Center, North Canton,
Ohio 44720, Phone: [phone].
In Canada, contact Hoover Canada,
Burlington, Ontario L7R 4A8,
Phone: [phone].
Always identify your cleaner by the
complete model number when
requesting information or ordering
parts. (The model number appears
on the bottom of the cleaner.)
4. If you have a
problem
If a minor problem occurs, it usually
can be solved quite easily when the
cause is found by using the check list
below.
Problem:Cleaner won’t run
Possible cause
Possible solution
• Not firmly plugged in
•Plug unit in firmly
• No voltage in wall plug
•Check fuse or breaker
• Blown fuse/tripped breaker
•Replace fuse/reset breaker
Problem: Cleaner won’t pick up
Possible cause
Possible solution
• Broken or worn belt
•Replace belt
• Brush roll brushes worn
•Replace brush roll
• Filter bag full
•Change filter bag
• Incorrect carpet height setting
•Move carpet height control to type of
carpet being cleaned
• Hose end not secure in tool rack
•Push hose end firmly into “cup” in
tool rack
Problem: Cleaning tools won’t pick up
Possible cause
Possible solution
• Hose clogged
•Clear blockage (see “Clearing
blockages section)
• Incorrect setting
•Move carpet height control to
“Cleaning Tools”
Problem: Cleaner hard to push
Possible cause
Possible solution
• Incorrect carpet height setting
•Move carpet height control to a
higher setting
Continued ➜

14
Clearing blockages
Remove large items from surfaces before
vacuuming to prevent blockages and to
maintain cleaning effectiveness of your
cleaner.
Refer to the following steps to check for
blockages continuing with each step
until the blockage is found.
A. If a blockage occurs during tool use:
Turn cleaner OFF and disconnect it
from the electrical outlet.
1. Look into end of hose for blockage and
remove any blockage.
Full One Year
Warranty
(Domestic Use)
Your HOOVER®appliance is warranted
in normal household use, in accordance
with the Owner’s Manual against original
defects in material and workmanship for
a period of one full year from date of
purchase. This warranty provides, at no
cost to you, all labor and parts to place
this appliance in correct operating
condition during the warranted period.
This warranty applies when the
appliance is purchased in the United
States including its territories and
possessions, or in Canada or from a
U.S. Military Exchange. Appliances
purchased elsewhere are covered by a
limited one year warranty which covers
the cost of parts only. This warranty
does not apply if the appliance is used
in a commercial or rental application.
Warranty service can only be obtained
by presenting the appliance to one of
the following Authorized Warranty
Service outlets. Proof of purchase will
be required before service is rendered.
1. Hoover Factory Service Centers
2. Hoover Authorized Warranty
Service Dealers (Depots)
For an automated referral of
authorized service outlets in the
U.S.A., phone [phone] OR
visit The Hoover Company on-line at
www.hoover.com
This warranty does not cover pick up,
delivery, or house calls; however, if you
mail your appliance to a Hoover Factory
Service Center for warranty service,
transportation will be paid one way.
While this warranty gives you specific
legal rights, you may also have other
rights which vary from state to state
(or province).
If further assistance is needed, or if
there are questions concerning this
warranty or the availability of warranty
service outlets, write or phone the
Consumer Response Center, The
Hoover Company, 101 East Maple St.,
North Canton, Ohio 44720.
Phone [phone].
In Canada, contact Hoover Canada,
Burlington, Ontario, L7R 4A8.
Phone [phone]
4-1
4-3
4-2
Removing duct cover
2. Remove hood and lift off carpet
height control as shown for Fig. 2-26.
CAUTION: Do not turn cleaner ON
while it is disassembled.
Remove 4 Phillips head screws and lift
off duct cover.
Checking hose and replacing
hood
3. Look for blockages in the hose and
around the cleaner base at the hose
opening. Remove any blockages.
4. Reposition duct cover and 4 screws.
Tighten screws securely.
5. Reposition hood and carpet height
control. Replace screws and tighten
securely.
B. If a blockage occurs during floor
cleaning:
Turn cleaner OFF and disconnect it
from electrical outlet.
1. Turn cleaner to expose underside.
Remove bottom plate and brush roll as
shown for Fig. 3-13 and 3-14.
Checking under bottom plate
2. Carefully remove any blockage from
brush roll cavity.
If a blockage is not found and a
problem persists, contact your Hoover
Factory Service Center or Authorized
Warranty Service Dealer (Depot).
