Hoover SJ60DA/1 User manual

®
USER MANUAL

1 2
3 4
2
1
B
C
D
E
F
J*
I* L*
H*
K
A
G

5* 6
7* 8*
9
2
1

1
INSTRUCTIONS FOR SAFE USE
This appliance should only be used for domestic cleaning, as described
in this user guide. Please ensure that this guide is fully understood
before operating the appliance.
Always switch o and remove the charger from the socket before
cleaning the appliance or any maintenance task.
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with
the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
If the power cord is damaged stop using the appliance immediately.
To avoid a safety hazard, an authorised Hoover service engineer must
replace the power cord.
Battery Charging
Never touch the charger with wet hands.
Use only the original charger supplied with the appliance.
Check that your supply voltage is the same as that stated on the charger.
Before being charged the main product must be switched o.
Never charge the batteries in temperatures above 37°C or below 0°C.
Plug the charger delivered with this appliance into a suitable socket.
Do recharge the batteries with Adaptor*/Charging Base*. Occasionally
fully discharge the batteries to obtain maximum battery life.
It is normal for the charger to become warm to the touch when
charging.
Use only attachments, consumables or spares
recommended or supplied by Hoover.
Do frequently clean the dust bin and lter assembly when picking up
ne powder.
Do not pick up liquids, hard or sharp objects, matches, hot ashes,
cigarette
ends or other similar items.
Do not spray with or pick up ammable liquids, cleaning uids,
aerosols or their vapours.
GB

2
Do not continue to use your appliance or charger if it appears faulty.
Hoover service: To ensure the continued safe and ecient
operation of this appliance we recommend that any servicing or
repairs are only carried out by an authorised Hoover service engineer.
Do not use the appliance to clean animals or people.
Do not replace the batteries with non-rechargeable batteries.
Do not use your appliance outdoors or on any wet surface or for wet
pickup.
End of life battery removal
If the appliance is to be disposed of the batteries must rst be
removed. The appliance must be disconnected from the supply mains
when removing the battery. Dispose of the batteries safely. Run the
appliance until it stops because the batteries are fully discharged.
Used batteries should be taken to a recycling station and not disposed
of with household waste. To remove the batteries, please contact
the Hoover Customer Centre or proceed according to the following
instructions.
Remove dust container. Unscrew 3 screws and open the unit. Remove
motor assembly and disconnect the cables. Remove the batteries.’
NOTE: Should you experience any diculty in dismantling the unit or
for more detailed information on treatment, recovery and recycling of
this appliance, please contact your local city oce or your household
waste disposal service.
The Environment
The symbol on this appliance indicates that this appliance may not be treated as household
waste. Instead it must be handed over to the applicable collection point for the recycling of
electrical and electronic equipment. Disposal must be carried out in accordance with local
environmental regulations for waste disposal. For more detailed information about treatment,
recovery and recycling of this appliance, please contact your local city oce, your household
and waste disposal service or the shop where you purchased the appliance.
This appliance complies with the European Directives 2006/95/EC, 2004/108/EC and 2011/65/EU.
HOOVER Limited, Pentrebach, Merthyr Tydl, Mid Glamorgan, CF48 4TU, UK
GB

3
FEATURES
STORAGE/CHARGING
MOUNT CHARGING BASE *
TOOLS REQUIRED: SCREWDRIVER AND DRILL
CHARGING/STORAGE BASE
Designed to sit in the charging base on a at surface or mount vertically. [1]
For tidy storage wrap excess cord on the back of the charging base and exit either side or bottom.
TO WALL MOUNT
1. Place the Measure* on the mounting surface vertically. Mark the centres of the holes.
2. Move the Measure* then drill 4.8mm holes.
3. Fit wall plug.
4. Insert the Rawlplugs into the holes, and adjust the screws height to ensure Charging Base is xed rmly to the mounting surface.
UNIT STORAGE
1. Hold the unit by the handle and push rmly down onto the charging base.
2. Be sure that the red light is on to indicate charging.
3. Other storage methods are hanging the unit up using the storage hook, or adjusting the Nozzle [3] to allow the unit to stand
upright. [2]
CHARGING
NOTE: Use only the Charging Base*/Adaptor* with your cleaner to recharge.
IMPORTANT: BEFORE FIRST USE, CHARGE YOUR CLEANER FOR AT LEAST 24 HOURS.
When charging the Cleaner power switch must be O.
Keep the charger plugged into Charging Socket at all times. It is normal for the charger to become warm to the touch when
charging.
If the operating time reduces after repeated use, let the cleaner run until it stops, then recharge for 24 hours and repeat this
monthly for best results.
IMPORTANT: Never charge the batteries in temperatures above 37°C or below 0°C.
HOW TO USE
TO USE: Remove cleaner from storage base, slide the power switch to the ON position. Empty and clean the unit and lter after
each use or when the unit becomes full.
A. On/O Switch
B. Charging Indicator
C. Dust Cup Release Button
D. Crevice Tool
E. Dust Cup
F. Nozzle
G. Storage Hook
H. Charging Base*
I. Dusting Brush*
J. Adaptor*
K. Charging Socket
L. Measure*
*certain models only
ATTACHMENTS
CREVICE TOOL
The crevice tool is used to clean corners and hard to reach areas and is stored on board the dust cup. To use, remove the crevice tool
from the dust cup [3] then t the crevice tool onto the nozzle to clean corners and hard to reach areas. [4]
DUSTING BRUSH*
The dusting brush is stored in the wall bracket. Fit the dusting brush onto the nozzle to clean keyboards and other delicate areas. [5]
DUST CONTAINER & FILTER: REMOVAL and REPLACEMENT
IMPORTANT: FOR BEST RESULTS CLEAN THE FILTER AFTER EACH USE
GB
Electrical requirements
This HOOVER appliance is supplied with a double insulated battery charger which is only suitable for insertion in a 230V (UK 240V)
socket outlet. Ensure that the Charging rating label matches your voltage supply.

4
YOUR GUARANTEE
The guarantee conditions for this appliance are as dened by our representative in the country in which it is sold. Details regarding
these conditions can be obtained from the dealer from whom the appliance was purchased. The bill of sale or receipt must be
produced when making any claim under the terms of this guarantee.
Subject to change without notice.
HOOVER spares and Consumables
Always replace parts with genuine HOOVER spares. These are available from your local HOOVER dealer or direct from HOOVER.
When ordering parts always quote your model number.
Cloth lter - T110 35601348
EPA Filter - T111 35601349
1. Depress the release button and remove dust cup assembly. [6]
2. Hold dust container over waste bin and gently remove Filter* or EPA Filter*. [7,8]
3. Empty dust container. Brush the dust and dirt o the Filter*/ EPA lter* or shake the lter inside the waste bin. [9]
4. The Filter* may be washed in warm soapy water, make sure the lter is completely dry before replacing in your cleaner.
5. The EPA Filter* should be washed in warm water only. Do not use any detergent, make sure the EPA lter* is completely dry
before replacing in your cleaner.
6. Replace the Filter*/EPA Filter* into the dust container and re-assemble the dust container to the cleaner.
End of product life battery disposal.
If the cleaner is to be disposed of the batteries should be removed. Used batteries should be taken to a recycling station and not
disposed with household waste.
IMPORTANT: Always fully discharge the batteries before removal.
Battery removal
Remove dust container. Unscrew 3 screws and open the unit. Remove motor assembly and disconnect the cables. Remove the
batteries.
NOTE: Should you experience any diculties in dismantling the unit or for more detailed information about treatment, recovery
and recycling of this product, please contact your local city oce, your household waste disposal service.
End of product life battery disposal.
If the cleaner is to be disposed of the batteries should be removed. Used batteries should be taken to a recycling station and not
disposed with household waste.
IMPORTANT: Always fully discharge the batteries before removal.
Battery removal
Remove dust container. Unscrew 3 screws and open the unit. Remove motor assembly and disconnect the cables. Remove the
batteries.
NOTE: Should you experience any diculties in dismantling the unit or for more detailed information about treatment, recovery
and recycling of this product, please contact your local city oce, your household waste disposal service.
GB
*certain models only
