Hoover HTC 9 AA Troubleshooting guide

APROGRAMME/TEMPERATURE SELECTOR
B SPIN SPEED SELECTOR
C1PRE-WASH
C2 EASY IRON
C3SUPER FAST
C4EXTRA RINSE
GDOOR LOCK LAMP
HSTART/STOP KEY
pCONTROL POSITION INDICATOR
SSTOP/END OF CYCLE LAMP
V TIME REMAINING OR PROGRAMME PHASE LAMPS
P
R
WASHING MACHINE HTC 9 AA
A
V
G
H
p
p
S
B C2C3C4C1

Table of programmes mod. HTC 9 AA
230 V. /
50 Hz.
175 W. 340 W. 30 W. 1950 W. 2200 W. 10 A. 0,05-0,8
Mpa
54 L. 1,04 Kw/h.
Mains
voltage
Wash
power
rating
Spin
power
rating
Pump
motor
power
rating
Heating
element
power rating
Max.
power
input
Mains fuse
amp. rating
Water
pressure
Water
consumption
* prog.
EN 60456
Energy
consumption
* prog.
EN 60456
* Programme as per EN 60456
Technical data mod. HTC 9 AA
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
900
900
900
900
900
800
800
800
800
800
800
900
400
800
800
800
800
800
800
800
•
•
•
•
•
•
•
•
•
•
programme
whites
* fast coloureds
fast coloureds
delicate coloureds
delicate coloureds
fast coloureds
fast coloureds
delicate coloureds
delicate coloureds
delicate coloureds
rinse
spin
empty
delicates
woolmark woollens
woolmark woollens
hand wash 30º
sport 30º
AA 40 40º
express 44
express 29
programme for
aprox.
time
min.
160
150
90
90
90
90
85
85
80
80
25
9
4
70
50
50
50
150
160
44
30
5,5
5,5
5,5
5,5
5,5
2,0
2,0
2,0
2,0
2,0
1,5
1,0
1,0
2,0
2,0
2,0
3,5
2,0
Máx.
temp.
setting
ºC
90º
60º
40º
30º
15º
60º
50º
40º
30º
15º
40
30
15
30
30
40
40
40
Máx.
spin
speed
Máx.
load
kg III
Washing powder load Option keys C
COTTONS
MIXED /SYNTH.
SPECIF.
PROGR.
DELICAT.
SPECIALS
PR

PREPARING THE WASH CYCLE
1.- Once the washing is loaded, ensure that the drum doors are properly closed.
2.- Add detergent and additives, not exceeding the maximum level indicator.
• detergent for pre-wash I
• detergent for wash programme II
• bleach
• fabric conditioner
SELECTING THE DESIRED PROGRAMMES AND OPTIONS
3.- Turn the programme selector (A) to the desired programme.
4.- Press the key or keys for any options desired (C1, C2, C3, C4).
C1 pre-wash key
This is useful for heavily soiled washing. This adds a short additional wash before the main
wash. The key can be activated only in Cottons, Mixed and Synthetics programmes. To
activate this option, always press the key before pressing the start key (H).
C2 easy iron key
This function helps reduce creasing, depending on the programme selected and the type
of fabric washed. This works as follows:
Mixed,Synthetics. Intermediate spins during rinses are eliminated, the final spin is a gentle
spin.
Delicates. Intermediate spins during rinses are eliminated and the machine stops before
the final spin, which is a gentle spin.
Hand wash, Woollens ,Cotton, and AA40. The machine stops before the final spin.
Rinses. Intermediate spins during rinses are eliminated, the final spin is a gentle spin.
To complete the wash cycle in the Delicates , Hand wash , AA40, Cotton, and Woollens
programmes, press the Easy Iron key again: the machine will empty and perform the
required spin.
To empty machine of water with no spin, cancel the ongoing programme and select the
Empty programme.
C3 super fast key
When this key is engaged programme times are cut by as much as 50 minutes, depending
on the wash programme and temperature selected. The key can be activated only in Cottons,
Synthetics and Mixed programmes.
C4 extra rinse key
The electronic system engaged by this key activates a new special rinse cycle. More water
and a combination of drum rotation movements ensure that washing is perfectly rinsed.
The key can be activated in Cottons, Mixed, Synthetics, Delicates, Rinse, Sportswear and
AA40 programmes.
5.- Select spin speed if required (B)
B spin selector
Use this control to select the maximum spin speed within the range for the model of washing
machine in question and the programme selected (see programme table). The control can
be turned in both directions. Spin speed may be selected at any time during the
programme.

07-04 / 46001669 / EN
6.- Once you have selected the desired options, press the START key (H). The washing machine
will start up and one of the time remaining or programme phase lamps (V) will come on. This
lamp indicates approximately how much time is left before the wash programme is completed
(or wash cycle phase): it will change as the programme progresses. Make sure that the stop/end
of cycle lamp is flashing before pressing the start key (H). If it remains on continuously, turn
the programme selector to OFF and re-set it to the desired programme.
To cancel an option after setting, just press the option key again (the indicator lamp will
go out).
To change or cancel a programme once the programme selected has started, proceed as
follows:
-Hold down the start key (H) until the stop/end of cycle lamp is burning steadily. The
programme has been cancelled, and another may be selected.
- Select the new programme.
-Press the start key (H) again until one of the time remaining or programme phase lamps
lights up.
- The machine will then run the new programme selected.
Programme Pause
To pause the wash programme so that more washing can be added, proceed as follows:
-Hold down the start key (H) until the option key lamps begin to flash and the time remaining
or programme phase lamp lights up.
-When the Door Lock lamp goes out (after approx. 2 minutes), open the door and put the
additional washing into the drum.
- Close the drum door and the lid properly.
- Press the start key (H), the time remaining or programme phase lamp will light up and
the machine will continue with the programme.
When the programme is completed the Stop/End of cycle lamp (S) will come on and the time
remaining or programme phase and Door Lock lamps (V and G) will go out.
For your own safety, set the programme selector to OFF before opening the washing-
machine lid and the drum doors to remove the washing.
