Hoover HWC 2335 User manual

HWC 2335
HWC 2336DL
Please read this instruction booklet carefully before using your Candy Wine CoolerPlease read this instruction booklet carefully before using your Candy Wine Cooler
NL
F
WIJNKOELER
Cave vin
GB WINE COOLER
ICANTINETTA
DWEINKUHLER
. .
SVE HANDBOK
NOR BRUKERVEILEDNING
DEN BRUGSVEJLEDNING
FIN KAYTTOOHJE
. . . .
EREFRIGERADOR DEVINO
SLO Vinskaomara
HBORHUTO
....
PL CHLODZIARKADO WINA
.
PT CAVEDEVINHOS

1
9. Temperature Sensor
8.
7. Interior Lamp
6. Wooden Shelves
5. Glass Door
4. Wine Rack
3. Levelling Leg
2. Cabinet
1. Operation and Display Panel
PARTS AND FEATURES
Electrical Control Assembly (at the back)
Thanks for your choice.
You are going to start a trip in a full taste and smell world, granting yourself.
With your new Wine Cellar you could explore the real meaning of a glass of
wine because.. in "Hoover Wine Cooler" veritas!
ENGLISH
1
2
3
4
5
6
7
8
9
8
9

Important Safety Instructions
Read all instructions before using the appliance.
Child entrapment and suffocation are not problems of the past. Junked or
abandoned appliances are still dangerous... even if theywill "just sit in
the garage a few days."
Never allow children to operate, playwith, or crawl inside the appliance.
Never clean appliance parts with flammable fluids. The fumes can create
a fire hazard or explosion.
Do not store or use gasoline or anyother flammable vapors and liquids
in the vicinityof this or anyother appliance. The fumes can create a
fire or explosion.
easilyclimb inside.
take off the door, leave the shelves in place, so that children maynot
Before you throw away your old wine cooler:
INSTALLATION INSTRUCTIONS
Before Using Your Wine Cooler
Clean the interior surface with lukewarm water using a soft cloth.
Before connecting the appliance to the power source, let it stand
upright for approximately2 hours. This will reduce the possibility
of a malfunction in the cooling system from handling during
transportation.
1 wine rack
1 Instruction manual
4 slide out shelves
Check to be sure the following parts are included:
Remove the exterior and interior packing, including protective foam on
door panels .
Installation of Your Wine Cooler
Place your appliance on a floor that is strong enough to support the
appliance when it is fullyloaded. To level your appliance, adjust the
legs at the front of the appliance.
2
Locate the appliance awayfrom direct sunlight and sources of heat
(stove, heater, radiator, etc.). Direct sunlight mayaffect the acrylic
coating and heat sources mayincrease electrical consumption.
Extreme cold ambient temperatures mayalso cause the appliance
not to perform properly.
Allow 5 inches of space between the back and sides of the appliance
which allows the proper air circulation to cool the compressor.
,

Plug the appliance into an exclusive properlyinstalled-grounded wall
outlet. Do not under anycircumstances cut or remove the third
(ground) prong from the power cord. Anyquestions concerning power
and or grounding should be directed toward a certified electrician or an
authorized HOOVER Products service center.
3
Avoid locating the appliance in moist areas. Too much moisture in
the air will cause frost to form quickly on the evaporator.
You must attach the door handle to the left hand side of the frame
before you start to use the wine cooler.
Improper use of the grounded plug can result in the risk of electrical
shock. If the power cord is damaged, have it replaced by an
authorized HOOVER Products service center.

Do not store food in wine cooler, as interior temperature may not get cool
enough to prevent spoilage. As a natural result of condensation, in summer
months or area of high humidity, the glass door may built up moisture on
the outside. Just wipe it away.
IMPORTANT SAFEGUARDS
It is recommended for best result you install the wine cooler in a place where
the ambient temperature is between 22-25 degree Celsius. If the ambient
temperature in above or below the recommended temperature, conditions may
cause the interior temperature to fluctuate. Recommended temperature ranges
for chilling wine.
OPERATING YOUR WINE COOLER
Before starting the wine cooler, ensure the cabinet is level. This will eliminate
any vibrations. This wine cooler is designed for climatic class N and to use at
temperature from 16 to 32 degree Celsius.
4
SETTING THE TEMPERATURE CONTROLS
Each cooling compartment of the wine cooler (upper & lower) are independently
controlled. To set the temperature:
1. Connect the power cord to a properly grounded outlet. The temperature
preset at factory of each compartment are:
12 C (54 F)-Upper Compartment
6 C (43 F)-Lower Compartment
2. Set the desired cooling temperature by pressing the button or which
are under the Upper Compartment/Lower Compartment program. When you
push the two buttons for the first time, the LCD readout will show the original
temperature set at previous time. The temperature that you desire to set will
increase 1 F or 1 C if you push the once, on the contra the temperature
will decrease 1 F or 1 C if you push the once.
Red wines: 15-18 C
Dry/White Wines 10-15 C
Rose Wines 9-10 C
Sparkling Wines 6-9 C
Beverage 3-6 C

Upper Compartment: The temperature setting can be adjusted from
10 C - 18 C (50 F - 64.4 F) ;
Lower Compartment: The temperature setting can be adjusted from
5C - 10 C (41.0 F - 50 F) .
The setting temperatures may fluctuate depending on whether the bottles are
located on the upper/middle or lower section.
3. To view the setting temperature, (anytime) press the corresponding or
button, the setting temperature will temporarily flash in the LCD display for 5
seconds.
Flashing LCD = Setting Temperature
Steady LCD = Cabinet Temperature
4. This unit has the option to display temperature in either Celsius or
Fahrenheit. To change the setting, press the button marks C/F
5. You can turn the interior lights on or off by pressing the button marked
symbol. The interior lights are LED lights which are low power(only
0.25W for each one) and low heat. They can be left on for long term.
The temperature inside the wine cooler will not be influenced.
6. Your wine cooler is designed with an Auto-Cycle defrost system. During
the Off-Cycle the refrigerated surface of the wine cooler (interior rear wall)
defrost automatically. The defrost water is channelled into a condensate
drain pan which is located at the back of the wine cooler on the top of the
compressor from where it evaporates.
Shelves
Shelving is wooden. To accommodate different size bottles, they
can be moved up or drown by sliding them out of the tracks. The shelves
are designed to accommodate the maximum amount of bottles.
Wine Rack
There is an additional wine rack at bottom section of the unit where you
can store up to 6 wine bottles. raccomanded for WHITE SPARKING WINE
5
(Champagne, Spumante, ...) This rack is removable for cleaning purpose.

6
NOTE:
When you use the wine cooler for the first time or restart the wine cooler
after it has been turned off for long time , there could be a few degrees
variance between the temperature you select and the one indicated on
the LCD readout. This is normal and it is due to the length of the activat-
ion time . Once the wine cooler is running for a few hours everything will
be back to normal.
Also, there is a 2 to 3 C variance between the top and bottom shelves of
each wine chiller. Therefore, If you have set the wine cellar for red wine
only and the temperature reads 16 C and you want to place a mix of white
and red wines, you should place the wine bottles on the bottom shelves
and the red wines on the top shelves.

CHANGING THE LED LIGHT
CARE AND MAINTENANCE
Note: All parts removed must be saved to do the replacement of the LED
light. Before removing the LED light, either unplug the refrigerator or
disconnect the electricity leading into the refrigerator at the main power
supply. Failure to do so could result in electrical shock or personal injury.
You should use the LED light which is permitted by the seller.
7
Be sure the wine cooler stays in the upright position during transportation.
Tape the doors shut.
Turn the levelling screws up to the base to avoid damage.
Securely tape down all loose items inside your wine cooler.
Remove all the bottles.
Moving Your Wine Cooler
Most power failures are corrected within a few hours and should not
affect the temperature of your wine cooler if you minimize the number
of times the door is opened. If the power is going to be off for a longer
period of time, you need to take the proper steps to protect your contents.
Power Failure
Maintenance of Your Wine Cooler
Unplug the wine cooler, and remove the bottles.
Wash the inside with a warm water and baking soda solution. The solution
should be about 2 tablespoons of baking soda to a quart of water.
Wooden shelves does not require cleaning.
The outside of the wine cooler should be cleaned with mild detergent and
warm water.
It may also be necessary to periodically wipe the bottom part of the storage
area, as the wine cooler is designed to retain humidity, and condensation
may collect there.
Cleaning Your Wine Cooler

The switch is in the "OFF" position.
The LED light has burned out(see maintenance section
for the replacement procedure).
The wine cooler is unplugged.
The home circuit breaker or fuse has tripped.
The wine cooler does not have the correct clearances.
The door gasket does not seal properly.
The temperature control is not set correctly.
The door is not closed completely.
The door is opened too often.
A large amount of warm wine has been added to the
wine cooler.
The room temperature is hotter than normal.
The wine cooler does not have the correct clearances.
The door gasket does not seal properly.
The door is not closed completely.
The door is opened too often.
External environment may require a higher setting.
Wine cooler is
not cold enough.
The circuit breaker tripped or blown fuse.
Wine cooler does
not operate.
PROBLEM
TROUBLESHOOTING GUIDE
You can solve many common wine cellar problems easily, saving you the
cost of a possible service call. Try the suggestions below to see if you can
solve the problem before calling the servicer.
Troubleshooting
POSSIBLE CAUSE
Not plugged in.
Check to be sure the temperature control setting.
Compressor turns
on and off frequently
The light does
not work.
8

Technical Specifications:
For detailed specifications, please refer to the nameplate at the back of the wine
Cellar. The specifications are subject to change without prior notice due to products
Improvement.
The shelves are out of position.
The gasket is dirty.
The wine cooler is not level.
The wine cooler is not level.
Contraction and expansion of the inside walls may
cause popping and crackling noises.
As each cycle ends, you may hear gurgling sounds
caused by the flow of refrigerant in your wine cooler.
The rattling noise may come from the flow of the
refrigerant,which is normal.
Check to assure that the wine cooler is level.
Vibrations.
The wine cooler
seems to make
too much noise.
The door will not
close properly.
9
