Hopeland HL7202K8 User manual

HL7202K8 Handheld
Terminal User manual
Shenzhen Hopeland Technologies co. Ltd.

Welcome to be a customer of Hopeland.
Thank you for choosing the handheld
terminal HL7202K8 2P

Use this user manual
Thank you for choosing Hopeland technology multifunctional handheld terminal.
Based on the high technology and high standard of Hopeland technology, this
equipment provides you with high quality experience. This user manual is convenient
for you to understand the functional features and usage of this product.
Please read the instructions first
Before use, please read the safety precautions and user manual carefully to ensure
safety and normal use.
The description in the user manual is based on default parameter Settings.
The images and screen shots used in the manual may not look like the actual
product.
The manual may be slightly different from the product, and the latest version is
available at www.hopelandrfid.com
Available features and additional services may vary from product, software, or
service provider.
The format and information are based on Google's Android operating system.
Applications and their functions may vary by country, region, or hardware
specification.
The sound source, wallpaper and images provided in the terminal are licensed for
limited use between Hopeland technology and its owners. Extracting and using
these materials for commercial or other purposes would violate copyright law.
Hopeland shall not be liable for such copyright infringement by users.
There may be charges for sending and receiving information, uploading and
downloading, automatic synchronization or location-based services. To avoid extra
costs, choose the right mode of work.
Keep the user manual for future reference.
Please note the following tips before use:
Warning - a condition that may harm yourself or others.
Note - possible damage to this or other equipment.
Tips - comments, use tips, or other information.

Contents
1 Specification.......................................................................................................................................................... 1
2 Schematic diagram..............................................................................................................................................2
2.1 Structure appearance.............................................................................................................................. 2
2.2 Weight......................................................................................................................................................... 2
3 Instructions............................................................................................................................................................ 3
4 Demo Software instructions............................................................................................................................. 4
4.1 Android installation package(apk)...................................................................................................... 4
4.2 connection...............................................................................................................................................4
4.3 UHF............................................................................................................................................................... 5
4.4 Scan.............................................................................................................................................................. 8
4.5 Trigger function setting.......................................................................................................................... 8
4.6 Information Query................................................................................................................................. 10
5 Packing accessories and transportation and storage.............................................................................11
5.1 Package..................................................................................................................................................... 11
5.2 Storage environment............................................................................................................................ 11
6 Common failure analysis and solution........................................................................................................12
7 After-sale service............................................................................................................................................... 15

HL7202K8handhelduser manual
1 Specification
Product parameters
Functional Configurations
Major parameters
Basic functions
MCU
ATSAM4S4BA-MU
Keypad
Trigger Key, Power key, Work mode switch key, reset key
Indicator LED
Charging indicator, status indicator, Work mode indicator
V2.1+EDR
Connection range of 10m and above
Support communication
Audio
Support buzzer
Special functions
Barcode Engine
The professional scanning engine module supports
one-dimensional barcode and two-dimensional code scanning
2D: PDF417.QR Code, Hanxin .
DataMatrix(ECC200.ECC000,050;080.100.140) etc.
1D: Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E,
Codabar,Interleaved 2 of 5, ITF-6, ITF-14, ISBN, Code 93,
UCC/EAN-128,GS1 Databar, Matrix 2 of 5, Code 11, Industrial 2 of 5,
Standard 2 of 5,Plessey, MSI-Plessey etc.
UHF
Air Protocols :ISO/IEC18000-6B ,6C/ EPC Global C1Gen2
Work Mode: Fixed/hop frequency optional
Support RSSI
Output Power: 0dBm-24dBm adjustable
Physical interface
USB Type C
Support device charging function
Software
SDK
Provide secondary development documentation for Android
devices
Physical
Characteristics
Power Consumption
Standby time is greater than 72 hours and continuous working time
is greater than 8 hours
Temp.
Operating Temp.:-20℃～+70℃
Storage Temp.: -25℃～+75℃
Humidity
5%-95% (non condensing)
EMC
Comply with relevant national standards
Dust & Water Proof
IP53
Drop Spec.
1.5M Drop to concrete
Accessories
Battery
Non-replaceable and rechargeable battery, 5000mAh/3.7V
Work continuously for more than 8 hours. Support USB charging.
Meet GB/ T18287-2000 standard
Power Adapter
General purpose power adapter 5V, standard USB interface
Charging time is less than 4 hours
communication
cable
USB communication cable×1

HL7202K8handhelduser manual
2 Schematic diagram
2.1 Structure appearance
Figure 2-1 HL7202K8 Structure appearance
HL7202K8 Dimensions
176mm×130.4mm×83.5mm (without accessories)
2.2 Weight
About 400g（include battery）

HL7202K8handhelduser manual
3 Instructions
Function diagram
Introductions
Charging indicator
Display red when charging, full display green
status indicator
Flashing slowly: pairing
Constant: connected
Flashing fast: battery low
Work Mode indicator
Off: UHF mode
On: Scanning mode
In different working modes, press the same trigger button will perform
corresponding functions
Power button
Press and hold more than 2 seconds to turn on or turn off the device
Work mode switch key
Switch the working mode of the handheld (uhf mode and scanning mode),
and the working mode indicator will indicate the current working mode
reset key
will automatically reset when pressed
This handheld device cannot be used alone, it must be used with android
phone.
When using, connect the mobile phone to the handheld by , and control the
handheld device through the app.

HL7202K8handhelduser manual
4 Demo Software instructions
4.1 Android installation package (apk)
At present, handheld demo software version is V1.5.Demo software runs on Android
5.0 system, can be installed using CL7202G7 or CL7202G9.
4.2 connection
Take HL7202K8 -096464 as an example:
Open the software and check whether HL7202K8 -096464 exists in the parameter list
of connection. If it does not exist, turn on the android phone's function, click the
"search" button and the pairing interface will pop up. As shown in the figure below
Click HL7202K8 -096464 to enter the pairing connection. Return after the link is
successfully paired."HL7202K8 -096464" can be found in the list of connection
parameters. Select it and click "ok".

HL7202K8handhelduser manual
Once the link is successfully connected, it will prompt "open connection successfully"
and jump to UHF interface by default. At this point, you can click "version" to check the
baseband version of UHF and further confirm that the connection is successful.
4.3 UHF
Click the UHF icon to enter the UHF test interface

HL7202K8handhelduser manual
Interfaces of Read tag, write tag, lock tag, configuration
Baseband upgrade of UHF module

HL7202K8handhelduser manual
When upgrading, you need to hold down the power key
Query UHF version

HL7202K8handhelduser manual
4.4 Scan
Click the "barcode" icon to enter the scanning test interface. One-dimensional code
and two-dimensional code can be scanned respectively, as shown in the figure below:
4.5 Trigger function setting
The trigger button of handheld (K8) has the following functions: Press the trigger
button to start UHF tag reading test, stop reading immediately after releasing the trigger
button. Press and release the trigger button once to do barcode test. The UHF operating
instructions triggered by the trigger button (that is, how to read and what areas of data to
read) is set through the UHF configuration interface. To read tags or scan barcodes, switch
through MODE key of handheld (K8), and use status indicator to distinguish and identify.
Data obtained by trigger button of handheld (K8) can only be displayed by reading
tag interface or barcode interface of demo. Other interfaces do not display the obtained
data.
The following is an example of setting trigger button to read user data:
Open the uhf configuration interface, select the option of "custom read" in the
drop-down box of trigger execution instruction, and enter the instruction of reading
user data in the pop-up box, as shown in the figure below.

HL7202K8handhelduser manual
After confirm, click the "Set" button, and it will prompt that the Setting is successful. At
this point, the trigger execution instruction is set to read user data. As shown in the
figure below:
Open the interface of UHF tag reading, press the trigger button at this time, the
handheld starts to read tags, and the interface of tag reading will display the tag data.

HL7202K8handhelduser manual
4.6 Information Query
In order to query the current handheld serial number, software version and battery
information, the Demo software provides a query interface, as shown in the figure below:

HL7202K8handhelduser manual
5 Packing accessories and transportation and storage
5.1 Package
To facilitate future storage and transportation, the packing boxes and packing materials
should be properly stored after opening.
In the packing box, besides the handheld, it also includes the accessories for the use of
the products. Please confirm that the products and accessories are complete according
to the packing list of the products. If there is any nonconformity or damage, please
contact the after-sales service immediately.
The specific annex list is shown in table 5-1:
Table 5-1 accessories list
5.2 Storage environment
HL7202K8 handheld terminal should be stored in below conditions:
☆ Environment temperature: -20℃～+70℃
☆ Relative humidity: 5% RH～95%RH
No.
ITEM
QTY
UNIT
REMARK
1
Handheld terminal
1
pcs
Included
2
Charger
1
pcs
Included
3
USB cable
1
pcs
Included
4
Warranty card
1
pcs
Included
5
Certificate of approval
1
pcs
Included
6
Pin
1
pcs
Included

HL7202K8handhelduser manual
6 Common failure analysis and solution
Can't find another device
Make sure the wireless function is enabled.
Make sure that the device you want to connect to has wireless function enabled (if
necessary).
Make sure the distance between the device and another device is within range.
Safety precautions
To protect you and others from harm or protect your terminal from damage, please
read all the information below before using your terminal.
Warning
Avoid electric shock, fire and explosion
Do not use damaged power cord plugs or loose power outlets
Do not touch the power cord with wet hands or unplug the charger by pulling the cord
Do not bend or damage the power cord
Please use the special charger
Please avoid using the terminal in thunderstorm weather
Do not throw the battery or terminal into the fire.
Do not place the battery or terminal inside or attached to a heating device, such as
a microwave oven, oven or radiator. Overheating can cause a battery to explode.
Do not squeeze or puncture the battery. Do not subject the battery to external
high pressure, otherwise it may lead to internal short circuit and overheating.
Protect the terminal, battery and charger from damage
Avoid exposing terminals and batteries to extremely cold or extremely hot
temperatures.
Extreme temperatures can deform terminals, reduce charging capacity and
shorten terminal and battery life.
Prevent the battery from contacting metal objects, otherwise it may make the
positive and negative connection of the battery, causing temporary or permanent

HL7202K8handhelduser manual
damage to the battery.
Note: Please comply with all safety warnings and regulations when using terminals
in restricted areas
Close the terminal where it is not allowed
Comply with all restrictions on the use of terminals in a particular area.
Do not use terminals near other electronic devices
Most electronic devices use radio frequency signals, and your terminal may interfere
with other electronic devices.
Do not use terminals near hospitals or medical devices that may be interfered with
by radio frequency
If you personally use any medical equipment, please contact the equipment
manufacturer to ensure that your terminal can be used safely in radio frequency.
Close the terminal in the event of a possible explosion
Always operate according to regulations, instructions and signs in the case of
possible explosion.
Do not use terminals at gas stations (maintenance stations) or close to flammable,
chemical agents or explosion areas.
Do not store or carry flammable liquid, gas or explosive articles in a box with
terminal, terminal parts or accessories
Properly keep and use the terminal
Keep the terminal dry
Moisture and various liquids may damage terminal parts or electrical wiring.
When the terminal is wet, remove the battery. Dry the terminal with a towel.
Ensure battery and chargers reach maximum service life
The battery should not be charged continuously for more than a week.

HL7202K8handhelduser manual
Overcharging may shorten the battery life.
The battery will not discharge gradually after long-term placement and must be
recharged before use.
Please disconnect the power when the charger is idle.

HL7202K8handhelduser manual
7 After-sale service
Letter to Customers
Since our aim is to continuously improve our products for better user experience, we
may modify the product characteristics, composition and design of circuits without given
notifications. Thus the real product may be not in accordance with this manual. Generally,
we will provide timely amendments to this manual. If it ’ s not provided timely, please
consult our service department.
Shenzhen Hopeland Technologies Co., Ltd.
Tell: [phone]
Website: http://www.hopelandrfid.com
Address: Clou Buliding, Baoshen Road, Hi-tech Park North, Nanshan District, 518057, Shenzhen, China

FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment.
IC warning:
- English:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not cause interference, and (2)
This device must accept any interference, including interference that may cause undesired operation of
the device.
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitationestautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le brouillageest
susceptible d'encompromettre le fonctionnement.
This equipment complies with IC RF radiation exposure limits set forth for an uncontrolled environment.
« ce matériel est conforme aux limites d'exposition aux rayonnements rf de ic énoncés dans un autre
environnement.
