Hored RD-S800QCPE User manual

RD-S800QCPE
User Manual

.RD-S800QCPE is a 5G wireless bridge developed by HORED. The
maximum wireless speed is 300Mbps, and the farthest transmission
distance is 5KM, more suitable for long-distance environment.
Point-to-point wireless internet transmission help you save lots of
wire network cost. Support PoE power supply, it makes the installation
more simple and quick.
1.1Package Contents
Wireless bridge………….. 2pcs （a pair）
POE power adapter……… 2pcs
Stainless steel retainer……2pcs
Quick Installation Guide ...1pcs
1. Introduction

1.2 Indicator description
1.3Interface Description
HORED bridge interface description is as follows,
specific please in kind prevail!.
Reset button.: Press and hold for 5-10 seconds to reset the
system.
LAN1 port: near the network port of the reset button, is
Power indicator
Steady light indicates normal power supply;
Off indicates no power supply.
LAN1
Steady light indicates that the port network
connectionis normal.
Off indicates the network is not connected.
Flashing indicates data transmission;
LAN2
Signal strength
indicator
The more lights that are lit, the stronger the
signal is.

thePoE power input port for connecting to the PoE port of
the PoE power adapter.
LAN2 port, RJ45 port, can be used to connect switches.
Chapter 2 Configure Connections

2.1 Method one: Automatic connection (default)
A pair of bridges in the same box is configured by default at
the factory and can be used after plugging in. No configuration is
required.
Applicable to a simple environment, only a pair of bridges
around, point to point.
2.2 Method two: Manual connection
When the application environment is complex, there are
multiple bridges around, or if point-to-multipoint connections
are used, manual connection is required.
(1)Connect the PC and the network cable directly, configure the
PC as the IP address of the network segment 192.168.248.x and

the corresponding subnet mask:
⑵ Open a browser, enter http://192.168.248.1 in the address bar
and press Enter to log in to the web management interface. To
ensure a good user experience, it is recommended to use the
latest version of Chrome // Firefox browser:
⑶ In the pop-up login screen, enter the user name and
password (default is admin), and click "Sign in" button

⑷The interface will be showed as below after you login successfully.
⑸Configure the connection

Chapter3 Cautions
3.1 Installation Notes
Fengrunda wireless bridge installation should pay attention to the
following two points
Height
In the course of wireless transmission, obstacles such as trees, tall
buildings, and large-scale reinforced buildings will weaken wireless
signals. To improve the wireless transmission performance and
prevent the signal from being blocked, please ensure that there is
no obstruction in the line of sight between the wireless CPEs during
installation.
Direction
When installing a CPE device, adjust its front panel orientation to
ensure that the receiving device is within its signal coverage. You

can use Google Maps, GPS, and other tools, combined with the
horizontal lobe width of the CPE device to roughly determine the
orientation of the CPE.
3.2 Configuration instructions
The pairing IDs of the master and slave must be the same. The
default is consistent and does not need to be changed.
For example, point to point use scenarios in elevators,
different elevator bridges recommended to use a different ID;
In a point to multipoint scenario, the ID number of each slave
needs to be consistent with the master.
In a one-to-many scenario, the number of clients allowed to
access the master must be adjusted. By default, only one
client is allowed to access.
The channel of the master and slave must be the same, the
default is the same without change;
The wireless passwords of the master and slave must be

consistent. The default is the same and no change is needed.
The main bridge signal indicator on the slave side is on,
indicating that the bridge is successful.
During the manual configuration process, you can use the
Quick Installation or the Manual Scan feature to facilitate
configuration and connection.
When the bridge access network exists in the DHCP server,
the IP address is automatically obtained. The new
management IP can be queried from the DHCP server.

CPU
Qualcomm Industrial Chipset
Flash
8Mbyte
DDR
64MB DDR2
Frequency
5.15~5.25GHz、5.735~5.835GHz
Wireless
Standards
802.11a/n
Wireless Speeds
Up to 300Mbps
Transmission
Power
MAX 20dBm
Maximum
transmission
distance
5KM(point to point)
Stable bandwidth up to 90M (no interference
environment)
Multi-port
transmission
Support 2 ports above; Default setting point to
point
Chapter4 Product Specification

receive sensitivity
Up to -97dBm
Port
2 10/100M adaptive LAN ports, LAN1 support
24V PoE power supply
Button
reset (long press 5-10 seconds to restore
default setting)
LED
Radio signal: all bright signal best
LAN indicator light: the bright represents the
connection; the deputies are not connected; the
flicker represents the data transmission;
Power indicator light: on behalf of the system
on the electricity; the failure to represent the
power;
Antenna
Built-in 5G directional dual polarized antenna,
gain: 14 dBi
Horizontal angle: 40 degrees; vertical angle 30
degrees
Power
Consumption
﹤5W
Dimensions
200mm * 110mm * 61mm

Environment
Operating Temperature: : -30°C~55°C
Storage Temperature: : -40℃～70℃
Operating Humidity: 10% ~ 90%RH non
condensation
Storage Humidity: 5% ~ 90%RH non
condensing
Support power on at -40℃
The leading provider of data transmission products and services
Shenzhen Fengrunda Technology Co.,Ltd.
