horiba LAQUA 2000 Series User manual

Instruction Manual
Benchtop pH/ORP/ION/Conductivity Meter
LAQUA-PH2000
LAQUA-ION2000
LAQUA-EC2000
LAQUA-PC2000

I
CODE:3200928090 - GZ0000657563
September, 2021 © 2021 HORIBA Advanced Techno Co., Ltd.
■ Preface
This manual describes the operation of the following instrument.
Be sure to read this manual before using the product to ensure proper and safe operation of
the product. Also, safely store the manual so it is readily available whenever necessary.
Product specifications and appearance as well as the contents of this manual are subject to
change without notice.
• Warranty and responsibility
HORIBA Advanced Techno Co., Ltd. warrants that the product shall be free from defects in
material and workmanship and agrees to repair or replace free of charge, at option of HORIBA
Advanced Techno Co., Ltd., any malfunctioned or damaged product attributable to
responsibility of HORIBA Advanced Techno Co., Ltd. for a period of three (3) years from the
delivery unless otherwise agreed in a written statement. In any one of the following cases,
none of the warranties set forth herein shall be extended:
• Any malfunction or damage attributable to improper operation
• Any malfunction attributable to repair or modification by any person not authorized by
HORIBA Advanced Techno Co., Ltd.
• Any malfunction or damage attributable to the use in an environment not specified in this
manual
• Any malfunction or damage attributable to violation of the instructions in this manual or
operations in the manner not specified in this manual
• Any malfunction or damage attributable to any cause or causes beyond the reasonable
control of HORIBA Advanced Techno Co., Ltd. such as natural disasters
• Any deterioration in appearance attributable to corrosion, rust and so on
• Replacement of consumables
HORIBA Advanced Techno Co., Ltd. SHALL NOT BE LIABLE FOR ANY DAMAGES
RESULTING FROM ANY MALFUNCTIONS OF THE PRODUCT, ANY ERASURE OF DATA,
OR ANY OTHER USES OF THE PRODUCT.
• Trademarks
• Microsoft, Windows, Windows Vista are registered trademarks or trademarks of Microsoft
Corporation in the United States and other countries.
• Other company names and brand names are either registered trademarks or trademarks of
the respective companies. (R), (TM) symbols may be omitted in this manual.
Brand: LAQUA
Series name: LAQUA 2000 Series Benchtop Water Quality Meters
Model: LAQUA-PH2000, LAQUA-ION2000, LAQUA-EC2000,
LAQUA-PC2000
Model description: pH/ORP/Ion/Conductivity Benchtop Meter
