Horizon Hobby Blade Inductrix Switch Air BNF User manual

Instruction Manual
Bedienungsanleitung
Manuel d’utilisation
Manuale di Istruzioni
RTF

2
EN
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before
operating. Failure to operate the product correctly can result in damage to the product, personal property and
cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic
mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage
to the product or other property. This product is not intended for use by children without direct adult supervision. Do
not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon
Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow
all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid
damage or serious injury.
The following terms are used throughout the product literature to indicate various levels of potential harm when
operating this product:
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage,
and serious injury OR create a high probability of superficial injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a
possibility of serious injury.
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no
possibility of injury.
• Always keep a safe distance in all directions around
your model to avoid collisions or injury. This model is
controlled by a radio signal subject to interference from
many sources outside your control. Interference can
cause momentary loss of control.
• Always operate your model in open spaces away from
full-size vehicles, traffic and people.
• Always carefully follow the directions and warnings for
this and any optional support equipment
(chargers, rechargeable battery packs, etc.).
• Always keep all chemicals, small parts and anything
electrical out of the reach of children.
• Always avoid water exposure to all equipment not
specifically designed and protected for this purpose.
Moisture causes damage to electronics.
• Never place any portion of the model in your mouth as it
could cause serious injury or even death.
• Never operate your model with low transmitter
batteries.
• Always keep aircraft in sight and under control.
• Always move the throttle fully down at rotor strike.
• Always use fully charged batteries.
• Always keep transmitter powered on while aircraft is
powered.
• Always remove batteries before disassembly
• Always keep moving parts clean.
• Always keep parts dry.
• Always let parts cool after use before touching.
• Always remove batteries after use.
• Never operate aircraft with damaged wiring.
• Never touch moving parts.
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon
Hobby, LLC. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product.
Meaning of Special Language
Safety Precautions and Warnings
Age Recommendation: Not for children under 14 years. This is not a toy.
USB Charging Warnings
The Battery Charger (EFLC1008) included with your hovercraft
has been designed to safely charge the Li-Po battery.
WARNING: Failure to exercise caution while using this
product and comply with the following warnings could
result in product malfunction, electrical issues, excessive heat,
FIRE, and ultimately injury and property damage.
• NEVER LEAVE CHARGING BATTERIES UNATTENDED.
• NEVER CHARGE BATTERIES OVERNIGHT.
• Never attempt to charge dead, damaged or wet battery packs.
• Never attempt to charge a battery pack containing different
types of batteries.
• Never allow children under 14 years of age to charge battery
packs.
• Never charge batteries in extremely hot or cold places or place
in direct sunlight.
• Never charge a battery if the cable has been pinched or
shorted.
• Never connect the charger if the power cable has been
pinched or shorted.

3EN
RTF: BLH8300 BNF: BLH8380
Airframe – Blade®Inductrix® Switch Air (BLH8300) Included Included
Motors – 6mm Brushed, (BLH8521) Installed Installed
On-board Electronics – Main control board, SAFE®(BLH9802) Installed Installed
Battery – 150mAh 1S 3.7V 25C Li-Po (EFLB1501S25) Included Included
Charger – 1S USB Li-Po Charger, 3.7V (EFLC1008) Included Included
Transmitter – MLP4DSM 2.4GHz, 4 CH Transmitter, BCMX2 (EFLH1064B) Included Required
Components
Specifications
Table of Contents
Wingspan 13.98 in (35.5cm)
Propeller Diameter 1.81 in (30mm)
Flying Weight .95 oz (27 g)
To register your product online,visit www.bladehelis.com
Components ....................................................................3
Specifications..................................................................3
Box Contents ...................................................................4
First Flight Preparation.....................................................4
Flying Checklist ...............................................................4
Battery Charging..............................................................4
Installing the Transmitter Batteries...................................5
Installing the Flight Battery ..............................................5
SAFE Technology .............................................................5
Transmitter and Receiver Binding.....................................6
LED Codes.......................................................................7
Transmitter Control ..........................................................7
Understanding the Primary Flight Controls .......................8
Flying the Switch™ Quadcopter ......................................9
Switching from Quadcopter Operation to
Air Wing Operation...........................................................9
Air Mode Operation (Beginner Mode)................................9
Air Mode Operation (Expert Mode)..................................12
Hovercraft Operation......................................................13
Post-Flight Inspection and Maintenance Checklist..........14
Troubleshooting Guide ...................................................14
Exploded View ...............................................................15
Replacement Parts.........................................................15
Optional Parts................................................................15
Limited Warranty ...........................................................16
Warranty and Service Contact Information .....................17
FCC Information.............................................................17
IC Information ...............................................................17
Compliance Information for the European Union.............17
• Never attempt to dismantle the charger or use a damaged
charger.
• Always use only rechargeable batteries designed for use with
this type of charger.
• Always inspect the battery before charging.
• Always keep the battery away from any material that could
be affected by heat.
• Always monitor the charging area and have a fire
extinguisher available at all times.
• Always end the charging process if the battery becomes
hot to the touch or starts to change form (swell) during the
charge process.
• Always connect the positive leads (+) and negative leads (–)
correctly.
• Always disconnect the battery after charging, and let the
charger cool between charges.
• Always charge in a well-ventilated area.
• Always terminate all processes and contact Horizon Hobby if
the product malfunctions.
• Charge only rechargeable batteries. Charging non-
rechargeable batteries may cause the batteries to burst,
resulting in injury to persons and/or damage to property.
• The USB outlet shall be installed near the equipment and
shall be easily accessible.
CAUTION: Always ensure the battery you are charging
meets the specifications of this charger. Not doing
so can result in excessive heat and other related product
malfunctions, which can lead to user injury or property damage.
Please contact Horizon Hobby or an authorized retailer with
compatibility questions.
CAUTION: If at any time during the charge process the
battery pack becomes hot or begins to puff, disconnect
the battery immediately and discontinue the charge process as
batteries can cause fi re, collateral damage and injuries.

4
EN
NOTICE: Charge only batteries that are cool to the touch
and are not damaged. Look at the battery to make sure it
is not damaged e.g., swollen, bent, broken or punctured.
1. Insert the charger into a USB port.
2. Properly connect the battery to the charger.
3. Always disconnect the flight battery from the charger immediately upon completion of charging.
CAUTION: Only use chargers specifically designed to charge the included Li-Po battery. Failure to do so could result
in fire, causing injury or property damage.
CAUTION: Never exceed the recommended charge rate.
LED Indications
When you make the connection successfully, the LED on the charger turns solid red, indicating charging has begun.
Charging a fully discharged (not over-discharged) 150mAh battery takes approximately 30 minutes. The light goes out
when the charge is complete.
CHARGING (Solid Red)
MAX CHARGE (OFF)
CAUTION: Once charging is complete, immediately remove the battery. Never leave a battery connected to the charger.
Battery Charging
First Flight Preparation
• Remove and inspect contents
• Begin charging the flight battery
• Install the flight battery in the quadcopter
(once it has been fully charged)
• Familiarize yourself with the controls
• Find a suitable area for flying
Flying Checklist
❏Always turn the transmitter on first
❏Plug the flight battery into the lead from the control unit
❏Allow the control unit to initialize and arm properly
❏Fly the model
❏Land the model
❏Unplug the flight battery from the 5-in-1 control unit
❏Always turn the transmitter off last
• Blade®Inductrix®Switch Air
• 3.7V 25C 150mAh 1S Li-Po Battery
• 1S USB Li-Po Charger
• MLP4DSM Transmitter (RTF only)
• 4 AA Batteries (RTF only)
Box Contents

5EN
Revolutionary SAFE®(Sensor Assisted Flight Envelope) technology uses an innovative combination of multi-axis sensors and
software that allows model aircraft to know its position relative to the horizon. This spatial awareness is utilized to create a
controlled flight envelope the aircraft can use to maintain a safe region of bank and pitch angles so you can fly more safely.
Far beyond stability, this level of protection offers multiple modes so the pilot can choose to develop his or her skills with a
greater degree of security and flight control that always feels crisp and responsive.
SAFE technology delivers:
• Flight envelope protection you can enable at the flip of a switch.
• Multiple modes let you adapt SAFE technology to your skill level instantly.
Best of all, sophisticated SAFE technology doesn’t require any work to enjoy. Every aircraft with SAFE installed is ready to use
and optimized to offer the best possible flight experience.
FlySAFERC.com
Technology
®
1. Lower the throttle to the lowest setting.
2. Power on the transmitter.
3. Install the battery by sliding it into the battery mounting slot below the control unit. Slide the battery into the slots
with the label facing upward so that the battery key molded into the battery end-cap comes in contact with
the key on the battery slot.
4. Connect the battery cable to the control unit.
5. Place the craft on a flat surface and leave the craft still until the LED on the control unit indicates one of the following
flight modes:
Solid white: Air mode
Solid blue: Multirotor mode
Solid green: Hovercraft mode (1 stick)
Solid amber: Hovercraft mode (2 stick)
CAUTION: Always disconnect the Li-Po battery from the aircraft when not flying to avoid over-discharging the
battery. Batteries discharged to a voltage lower than the lowest approved voltage may become damaged,
resulting in loss of performance and potential fire when batteries are charged.
Installing the Transmitter Batteries
Replace the transmitter batteries when the power LED flashes and the
transmitter beeps.
CAUTION: NEVER remove the transmitter batteries while the model
is powered on. Loss of model control, damage, or injury may occur.
CAUTION: Risk of explosion if battery is replaced by an incorrect
type. Dispose of used batteries according to national regulations.
CAUTION: If using rechargeable batteries, charge only
rechargeable batteries. Charging non-rechargeable batteries may
cause the batteries to burst, resulting in injury to persons and/or damage
to property.
Installing the Flight Battery
12 3
4

6
EN
MLP4DSM Binding Procedure
1. Disconnect the flight battery from the quadcopter.
2. Center all trims on your transmitter.
3. Power off the transmitter and move the throttle stick to the down/off position.
4. Connect the flight battery in the quadcopter. The LED on the control unit flashes after 5 seconds.
5. When the blue light is flashing, push in and hold down the left stick* while powering on the transmitter
(you will hear a ‘click’).
6. Release the left stick. The transmitter will beep and the power LED will blink.
7. The quadcopter is bound when all of the LEDs on the aircraft turn solid.
8. Disconnect the flight battery and power the transmitter off.
* The trigger switch may also be used for the binding procedure.
If you encounter problems, obey binding instructions and refer to the troubleshooting guide for other instructions.
If needed, contact the appropriate Horizon Product Support office. For a list of compatible DSM®transmitters, please
visit www.bindnfly.com.
RTF
Your RTF transmitter comes prebound to the model. If you need to re-bind, follow the directions below.
Transmitter and Receiver Binding
CAUTION: When using a Futaba®transmitter with a Spektrum™ DSM2®/DSMX ®module, you must reverse the
throttle channel and re-bind. Refer to your Spektrum module manual for binding and failsafe instructions.
Refer to your Futaba transmitter manual for instructions on reversing the throttle channel.
If you are using a computer transmitter, set the model type to “Acro” or “Airplane” mode. In the channel input menu, set
channel 6 (Aux1) to a momentary switch such as the bind button ( I) and channel 5 (Gear) to a 3-position switch (switch
B). In the Servo Setup menu, reverse channel 6 (Aux1).
Bind the quadcopter to your transmitter following the Transmitter and Receiver Binding directions below.
General Binding Procedure
1. Disconnect the flight battery from the quadcopter.
2. Center all trims on your transmitter.
3. Power off the transmitter and fully lower the throttle.
4. Connect the flight battery in the quadcopter.All of the LEDs on the aircraft will flash rapidly, indicating the aircraft has
entered bind mode.
5. Put the transmitter into bind mode while powering on the transmitter.
6. Release the bind button/switch after 2–3 seconds. The quadcopter is bound when all of the LEDs on the aircraft
turn solid.
7. Disconnect the flight battery and power the transmitter off.

7EN
RTF
Transmitter Control
ABCDE F
Mode 1 Aileron (Left/Right)
Throttle (Up/Down)
Throttle
Trim
Aileron
Trim
Rudder
Trim
Elevator
Trim
Rudder (Left/Right)
Elevator (Up/Down)
Mode 2 Aileron (Left/Right)
Elevator (Up/Down)
Elevator
Trim
Aileron
Trim
Rudder
Trim
Throttle
Trim
Rudder (Left/Right)
Throttle (Up/Down)
Mode
selection
• Bind
• Long press:
Arm/Disarm
D
E
F
Power LED indicator
C
B
A
On/Off Switch
When pressed down, trim buttons make a sound that increases or decreases in pitch at each pressing. The middle or
neutral trim position is heard as a middle tone in the pitch range of the sounds. The end of the control range is sounded
by a series of beeps.
M
se
LED Codes
Equipment LED Color LED Status Operation
Flight control LED on
the control board, RGB
Red Solid Position 2; Quadcopter AS3X mode
Purple Solid Position 1; Quadcopter Horizon mode
Blue Solid Position 0; Quadcopter Stability mode
Green Solid IDX Switch mode 1
Amber Solid IDX Switch mode 2
White Solid Air mode
Green Blinks for 1 second at power ON Battery voltage check; Full
Orange Blinks for 1 second at power ON Battery voltage check; Middle
Red Blinks for 1 second at power ON Battery voltage check; Low
Blue Blinking rapidly Bind mode
Blue Blinking slowly 2.4GHz signal lost, Low voltage warning
Front LEDs White
Blinking rapidly Bind mode
Solid Arm
Blinking slowly Disarm
Blinking slowly 2.4GHz signal lost, Low voltage warning
Rear LEDs Red
Blinking rapidly Bind mode
Solid Arm / Disarm
Blinking slowly 2.4GHz signal lost, Low voltage warning

8
EN
Understanding the Primary Flight Controls
If you are not familiar with the controls of your Inductrix®Switch Air wing and quadcopter, take a few minutes to
familiarize yourself with them before attempting your first flight.
Quadcopter Operation
To selct Quadcopter mode, with the aircraft and transmitter powered on and bound, press both
sticks to the outside bottom corners for 3 seconds.
Quadcopter Flight Modes
Change flight modes by pushing down on the right stick. Ensure the flight mode switch is in the
desired position before flying.
• In Stability mode (switch position 0), the controls provide a minimum bank angle. This mode is
shown by the flight control LEDs on the quadcopter glowing solid blue.
• Agility mode (switch position 2) is shown by the flight control LEDs on the quadcopter glowing
solid red.
Elevator
ForwardElevator up Elevator down Backward
Left Side View Left Side View
Rudder
Rudder left Rudder right
Nose Yaws
RightNose Yaws Left
Throttle
Throttle down
Throttle up
Left Side View
Top View Top View
Left Side View
Descend
Climb
Aileron
Aileron left Left Aileron right Right
Rear ViewRear View

9EN
Takeo
Increase the throttle until the model is approximately 2 ft. (600mm) off the ground and check the trim so the model
flies as desired. Once the trim is adjusted, begin flying the model.
Typical flight times for the included battery range from 3 to 4 minutes.
Low Voltage Cuto (LVC)
LVC decreases the power to the motors when the battery voltage gets low. When the motor power decreases and the
front and rear FC LEDs flash red, land the aircraft immediately and recharge the flight battery.
LVC does not prevent the battery from over-discharge during storage.
NOTICE: Repeated flying to LVC will damage the battery.
Landing
To land, slowly decrease the throttle while in a low-level hover. After landing, hold the arm/disarm switch until the
motors have stopped, then remove the battery. Fully charge your battery before storing it. During storage, make sure the
battery charge does not fall below 3V per cell.
Flying the Switch™Quadcopter
Throttle
Throttle down
Throttle up
Left Side View
Left Side View
Descend
Climb
Switching from Quadcopter Operation to Air Wing Operation
To switch from quadcopter operation to air wing operation, slide the two rear fans down out of the clips on the main
frame and slide them into the clips at the rear of the wing base plate. Seat the main frame into the slot in the wing with
the two front fans attached ensuring the fans click into their respective openings in the wing.
To select Air Mode, press both sticks to the outside upper corners for 3 seconds. The flight
mode LED will glow solid white to indicate Air mode.
Select flight modes by pushing down on the right stick. Ensure the flight mode switch is in the
desired position before flying.
• Beginner mode (switch position 0); The Aileron and Rudder controls are combined on the right
stick to simplify flight controls for new users.
• Expert Mode (Switch position 2); Standard fixed-wing flight controls for more experienced
pilots.
Air Mode
Air Mode Operation (Beginner mode)

10
EN
Elevator
Forward
Elevator down
Elevator up
Backward
Left Side View
Left Side View
Nose Yaws Left
Top View
Aileron and Rudder - Right Stick
Right Stick to left
Left
Rear View

11 EN
Right
Rear View
Nose Yaws Right
Top View
Aileron and Rudder - Right Stick (continued)
Right Stick to right

12
EN
Elevator
Forward
Elevator up
Elevator down Backward
Left Side View
Left Side View
Aileron right
Right
Rear View
Aileron
Aileron left
Left
Rear View
Throttle
Throttle down
Throttle up
Left Side View
Left Side View
Descend
Climb
Air Mode Operation (Expert mode)

13 EN
Rudder
Rudder left
Rudder right
Nose Yaws Right
Nose Yaws Left
Top View
Top View
Sold Separately
BLH9806
Foam skirt
BLH9805
Base plate
Hovercra Operation
The hovercraft base plate (BLH9805) and foam skirt (BLH9806) are not
included with this product and are sold separately. Please refer to the manual
for the Inductrix Switch (BLH9800) for operation in the two hovercraft modes;
single-stick or two-stick mode.

14
EN
Post-Flight Inspection and Maintenance Checklist
√
Cleaning Make sure the battery is not connected before cleaning. Remove dust and debris with a soft brush or
a dry, lint-free cloth.
Motors Replace the motor when the model will not fly steady or veers off when doing a climb out.
Wiring Make sure the wiring does not block moving parts. Replace damaged wiring and loose connectors.
Fasteners
Make sure there are no loose screws, other fasteners or connectors. Do not over-tighten metal
screws in plastic parts. Tighten screws so the parts are mated together, then turn the screw only
1/8th of a turn more.
Propellers Make sure there is no damage to the propellers or other parts that move at high speed. Damage to
these parts includes cracks, burrs, chips or scratches. Replace damaged parts before flying.
Troubleshooting Guide
Problem Possible Cause Solution
Quadcopter control response is
inconsistent or requires extra trim
to neutralize movement.
Aircraft not initialized on a level surface. Disconnect the flight battery, center the control
trim and re-initialize the quadcopter.
Battery not correctly placed in
battery slot. Adjust battery position so quadcopter balances in the center of the frame.
Quadcopter will not respond to
throttle.
Throttle too high and/or throttle trim is
too high. Reset controls with the throttle stick and throttle trim at the lowest setting.
Quadcopter moved during initialization. Disconnect the flight battery and re-initialize the quadcopter while keeping the quadcopter
from moving.
Throttle channel is reversed. Disconnect flight battery, reverse the throttle channel on the transmitter,
recconnect flight battery.
Quadcopter does not function
and smells burnt after connecting
the flight battery.
Flight battery connected with the wrong
polarity. Replace the 5-in-1 board. Connect the flight battery noting proper polarity.
Quadcopter has reduced flight
time or is underpowered.
Flight battery charge is low. Completely recharge the flight battery.
Inadequate power to flight battery charger. Use a different USB power source for the
charger.
Flight battery is damaged. Replace the flight battery and follow the flight
battery instructions.
Flight conditions might be too cold. Make sure the battery is warm (room
temperature) before use.
LED on receiver flashes rapidly
and aircraft will not respond to
transmitter (during binding).
Transmitter too near aircraft during
binding process.
Power off the transmitter. Move the transmitter
a larger distance from the aircraft. Disconnect
and reconnect the flight battery to the aircraft.
Follow the binding instructions.
Bind switch or button was not held while
transmitter was powered on. Power off transmitter and repeat bind process.
Aircraft or transmitter is too close to large
metal object, wireless source or another
transmitter.
Move aircraft and transmitter to another
location and attempt binding again.
LED on the receiver flashes
rapidly and the quadcopter will
not respond to the transmitter
(after binding).
Less than a 5-second wait between
first powering on the transmitter and
connecting the flight battery to the
quadcopter.
Leave the transmitter powered on. Disconnect
and reconnect the flight battery to the
quadcopter.
The quadcopter is bound to a different
model memory (ModelMatch™
transmitters only).
Select the correct model memory on the
transmitter. Disconnect and reconnect the flight
battery to the quadcopter.
Flight battery or transmitter battery charge
is too low. Replace or recharge batteries.
Aircraft or transmitter is too close to
large metal object, wireless source or
another transmitter.
Move aircraft and transmitter to another
location and attempt connecting again.
Crashes immediately upon lift-off Propellers in wrong locations or
incorrect flight mode selected. Ensure propeller direction and motor direction are correct.

15 EN
Exploded View
Replacement Parts
Optional Parts
3
5
9
9
10
11
Air Wing Assembly Quadcopter Assembly
7
2
2
8
8
4
4
1
1
6
1
1
Part # Description
1 BLH8521 Pro Motor Set (4)
2 BLH8705 Propeller Set, White (4)
3 BLH9807 Canopy, Red
4 BLH9803 Duct Set (2)
5 BLH9802 Control Board
6 BLH08301 Replacement Wing
Part # Description
7 BLH9804 Main Frame
8 BLH9801 Propeller Set (4)
9 EFLB1501S25 3.7V 150mAh 1S 25C LiPo
10 EFLC1008 1S USB LiPo charger, 350mAh
11 EFLH1064/B Blade MLP4DSM 4CH transmitter,
2.4GHz: BMCX2, 120SR
Part # Description
BLH8302 LED Nav light set: Inductrix Switch Air
BLH7840 USB: Multi Rotor Programmer
EFLB2001S45 3.7V 200mAh 1S 45C LiPo
Part # Description
BLH8852 Camera with OSD
BLH9809 Canopy option set (blue) with props

16
EN
Limited Warranty
What this Warranty Covers
Horizon Hobby, LLC, (Horizon) warrants to the original purchaser
that the product purchased (the "Product") will be free from
defects in materials and workmanship at the date of purchase.
What is Not Covered
This warranty is not transferable and does not cover (i) cosmetic
damage, (ii) damage due to acts of God, accident, misuse,
abuse, negligence, commercial use, or due to improper use,
installation, operation or maintenance, (iii) modification of or to
any part of the Product, (iv) attempted service by anyone other
than a Horizon Hobby authorized service center, (v) Product not
purchased from an authorized Horizon dealer, or (vi) Product not
compliant with applicable technical regulations.
OTHER THAN THE EXPRESS WARRANTY ABOVE, HORIZON
MAKES NO OTHER WARRANTY OR REPRESENTATION, AND
HEREBY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES,
INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES
OF NON-INFRINGEMENT, MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE. THE PURCHASER ACKNOWLEDGES
THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT
WILL SUITABLY MEET THE REQUIREMENTS OF THE
PURCHASER’S INTENDED USE.
Purchaser’s Remedy
Horizon’s sole obligation and purchaser’s sole and exclusive
remedy shall be that Horizon will, at its option, either (i)
service, or (ii) replace, any Product determined by Horizon to
be defective. Horizon reserves the right to inspect any and all
Product(s) involved in a warranty claim. Service or replacement
decisions are at the sole discretion of Horizon. Proof of purchase
is required for all warranty claims. SERVICE OR REPLACEMENT
AS PROVIDED UNDER THIS WARRANTY IS THE PURCHASER’S
SOLE AND EXCLUSIVE REMEDY.
Limitation of Liability
HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT,
INCIDENTAL OR CONSEQUENTIAL DAMAGES, LOSS OF
PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY
WAY, REGARDLESS OF WHETHER SUCH CLAIM IS BASED IN
CONTRACT, WARRANTY, TORT, NEGLIGENCE, STRICT LIABILITY
OR ANY OTHER THEORY OF LIABILITY, EVEN IF HORIZON HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Further, in no event shall the liability of Horizon exceed the
individual price of the Product on which liability is asserted.
As Horizon has no control over use, setup, final assembly,
modification or misuse, no liability shall be assumed nor
accepted for any resulting damage or injury. By the act of use,
setup or assembly, the user accepts all resulting liability. If you
as the purchaser or user are not prepared to accept the liability
associated with the use of the Product, purchaser is advised to
return the Product immediately in new and unused condition to
the place of purchase.
Law
These terms are governed by Illinois law (without regard to
conflict of law principals). This warranty gives you specific legal
rights, and you may also have other rights which vary from state
to state. Horizon reserves the right to change or modify this
warranty at any time without notice.
WARRANTY SERVICES
Questions, Assistance, and Services
Your local hobby store and/or place of purchase cannot provide
warranty support or service. Once assembly, setup or use of the
Product has been started, you must contact your local distributor
or Horizon directly. This will enable Horizon to better answer your
questions and service you in the event that you may need any
assistance. For questions or assistance, please visit our website
at www.horizonhobby.com, submit a Product Support Inquiry, or
call the toll free telephone number referenced in the Warranty
and Service Contact Information section to speak with a Product
Support representative.
Inspection or Services
If this Product needs to be inspected or serviced and is
compliant in the country you live and use the Product in,
please use the Horizon Online Service Request submission
process found on our website or call Horizon to obtain a Return
Merchandise Authorization (RMA) number. Pack the Product
securely using a shipping carton. Please note that original boxes
may be included, but are not designed to withstand the rigors
of shipping without additional protection. Ship via a carrier that
provides tracking and insurance for lost or damaged parcels, as
Horizon is not responsible for merchandise until it arrives and is
accepted at our facility. An Online Service Request is available at
http://www.horizonhobby.com/content/_service-center_render-
service-center. If you do not have internet access, please
contact Horizon Product Support to obtain a RMA number along
with instructions for submitting your product for service. When
calling Horizon, you will be asked to provide your complete
name, street address, email address and phone number where
you can be reached during business hours. When sending
product into Horizon, please include your RMA number, a list
of the included items, and a brief summary of the problem. A
copy of your original sales receipt must be included for warranty
consideration. Be sure your name, address, and RMA number
are clearly written on the outside of the shipping carton.
NOTICE: Do not ship LiPo batteries to Horizon. If you
have any issue with a LiPo battery, please contact the
appropriate Horizon Product Support office.
Warranty Requirements
For Warranty consideration, you must include your
original sales receipt verifying the proof-of-purchase
date. Provided warranty conditions have been met, your
Product will be serviced or replaced free of charge. Service or
replacement decisions are at the sole discretion of Horizon.
Non-Warranty Service
Should your service not be covered by warranty, service
will be completed and payment will be required without
notification or estimate of the expense unless the
expense exceeds 50% of the retail purchase cost. By
submitting the item for service you are agreeing to payment of
the service without notification. Service estimates are available
upon request. You must include this request with your item
submitted for service. Non-warranty service estimates will be
billed a minimum of ½ hour of labor. In addition you will be billed
for return freight. Horizon accepts money orders and cashier’s
checks, as well as Visa, MasterCard, American Express, and
Discover cards. By submitting any item to Horizon for service,
you are agreeing to Horizon’s Terms and Conditions found on
our website http://www.horizonhobby.com/content/_service-
center_render-service-center.
ATTENTION: Horizon service is limited to Product
compliant in the country of use and ownership. If
received, a non-compliant Product will not be serviced.
Further, the sender will be responsible for arranging
return shipment of the un-serviced Product, through
a carrier of the sender’s choice and at the sender’s
expense. Horizon will hold non-compliant Product for a
period of 60 days from notification, after which it will be
discarded.
10/2015

17 EN
Warranty and Service Contact Information
FCC Information
FCC ID (Transmitter): BRWDXMTX10
FCC ID (Aircraft): BRWBLH9706
Supplier’s Declaration of Conformity
Blade Inductrix Switch Air | BLH8380
This device complies with part 15 of the
FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any
interference received, including interference that may
cause undesired operation.
CAUTION: Changes or modifications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This product contains a radio transmitter with wireless
technology which has been tested and found to be
compliant with the applicable regulations governing a radio
transmitter in the 2.400GHz to 2.4835GHz frequency range.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
Horizon Hobby, LLC
4105 Fieldstone Rd.
Champaign, IL 61822
Email: [e-mail]
Web: HorizonHobby.com
IC Information
IC: CAN ICES-3 (B)/NMB-3(B)
IC (Transmitter): 6175A-BRWDXMT
IC (Aircraft): 6157A-BLH9706
This device complies with Industry Canada license-exempt
RSS standard(s). Operation is subject to the following two
conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference, including interference
that may cause undesired operation of the device.
Country of
Purchase Horizon Hobby Contact Information Address
United States of
America
Horizon Service Center
(Repairs and Repair Requests)
servicecenter.horizonhobby.com/
RequestForm/
2904 Research Rd
Champaign, Illinois 61822 USA
Horizon Product Support
(Product Technical Assistance)
[e-mail]
877-504-0233
Sales [e-mail]
800-338-4639
European Union Horizon Technischer Service [e-mail] Hanskampring 9
D 22885 Barsbüttel, Germany
Sales: Horizon Hobby GmbH [phone]

18
EN
EU Compliance Statement:
BLH8300: Horizon Hobby, LLC hereby declares
that this product is in compliance with the
essential requirements and other relevant
provisions of the RED and EMC Directives.
BLH8380: Horizon Hobby, LLC hereby declares that this
product is in compliance with the essential requirements and
other relevant provisions of the RED and EMC Directives.
A copy of the EU Declaration of Conformity is available online at:
http://www.horizonhobby.com/content/support-render-
compliance.
Compliance Information for the European Union
Instructions for disposal of WEEE by users in the European Union
This product must not be disposed of with other waste. Instead, it is the user’s responsibility to dispose of their
waste equipment by handing it over to a designated collections point for the recycling of waste electrical and
electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will
help to conserve natural resources and make sure that it is recycled in a manner that protects human health and
the environment. For more information about where you can drop off your waste equipment for recycling, please
contact your local city office, your household waste disposal service or where you purchased the product.

©2019 Horizon Hobby, LLC.
Blade, the Blade logo, Inductrix, BNF and Bind-N-Fly logo, E-flite, SAFE, the SAFE logo, DSM, DSM2, DSMX, ModelMatch
and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is
used with permission of Bachmann Industries, Inc. Futaba is a registered trademark of Futaba Denshi Kogyo Kabushiki
Kaisha Corporation of Japan. All other trademarks, service marks or logos are property of their respective owners.
Created 12/18 60431.1 BLH8300 / BLH8380
