Hornady 95907 User manual

Wireless
Hygrometer
FEATURES:
1. Touchscreen display shows temperature, humidity, and max/min values at the
base and remote units.
2. Temperature can be displayed in Fahrenheit or Celsius.
3. Maximum and minimum value can be easily reset.
4. Maximum and minimum value can be set to automatically reset every 24 hours.
5. Includes magnets, quick-connect bracket and screws for installing on wall.
6. Compatible with Hornady Square-Lok™ system.
OPERATION:
Begin by removing the battery cover from the base and remote unit and installing new
AAA batteries into both the base and remote units. It may take up to one minute for the
base and remote to connect after installing batteries.
A. REMOTE / BASE Button
• Press and release to toggle between displaying
the remote readings and base readings.
• Press and hold to manually initiate pairing
between the base and remote.
NOTE: Whenever batteries are placed in the
base unit, the base unit automatically initiates
the connection process with the remote, but it
must wait until the remote broadcasts a signal to
establish a connection. If replacing the batteries
in just the remote, a manual connection will be
needed. It is best to replace the batteries in the
base and remote at the same time.
B. °F / °C Button:
• Press to toggle between displaying temperature
in Fahrenheit or Celsius.
C. ALL TIME/24 HRs:
• Press and release to toggle between ALL TIME
and 24 HRs min/max interval.
i. ALL TIME: Displays the min/max readings until manually reset.
ii. 24 HRs: Displays the min/max readings over a 24 hour period. Automatically resets
every 24 hours.
• Hold down this button for 3 seconds to clear the recorded maximum and minimum value.
D. Signal Icon:
• The icon will blink when first establishing a connection.
• When the base and remote are connected, this icon remains on.
• Icon will blink approximately every 50 seconds when the base and remote update readings.
E. Comfort Icon:
• Displays general comfort levels based on humidity readings.
COMF – A comfortable humidity level is between 30% and 60%
WET – Any humidity level higher than 60%
DRY – Any humidity level less than 30%
Item No. 95907
DISPLAY BASE
D
E
C
B
A

10/202121HMC0069
P.O. Box 1848, Grand Island, Nebraska 68802-1848
308-382-1390 • 800-338-3220 • Fax: [phone]
Hornady.com/contact
QUICK CONNECT BRACKET:
The Hygrometer ships with two brackets to allow the
Hygrometer to be mounted to vertical surfaces.
To connect the hygrometer to the bracket, place the
hygrometer onto the bracket and rotate 90 degrees.
PROPER CARE:
1. Keep product clean. A buildup of dust could affect
the accuracy of the thermometer and hygrometer.
2. Do not drop as it may damage the sensitive
electronics.
3. For indoor use only. Keep away from water.
4. Replace batteries when the display begins to dim.
5. The touchscreen is designed to read a soft fingertip.
DO NOT use a fingernail or other hard object as it may damage the screen.
TROUBLESHOOTING:
If the touchscreen buttons are not working properly, please try the following steps:
1. Clean the screen with rubbing alcohol and a soft cloth.
2. Remove the batteries to reboot hygrometer.
SPECIFICATIONS:
1. Temperature range: -10 ~50° C (14-122° F)
2. Humidity range: 10% ~99%RH
3. Maximum read distance: 100 feet unobstructed
4. Measurement period: 50 second intervals
5. Power supply: Four AAA batteries total (not included).
Base Display requires two batteries and Remote Sensor requires two batteries.
6. Dimensions:
Base Display
76 x 63 x 15mm (3.0" x 2.5" x 0.6") | Net weight: 4.0 oz (113.4g)
Remote Sensor:
72 x 72 x 25mm (2.8" x 2.8" x 1.0") | Net weight: 1.6 oz (45.4g)
INCLUDED IN THE BOX:
a. Base Display Unit
b. Remote Unit
c. Twist-Lock Mount
Hornady Security®electronic components are covered by a one-year warranty from
the date of purchase. See Hornady.com for details.
Wall Mount
Square-Lok™
Mount
d. User manual
e. Wood Screws
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
