Hornby 4-6-2 REBUILT WEST COUNTRY CLASS Manual

4-6-2 REBUILT WEST COUNTRY CLASS &
4-6-2 REBUILT BATTLE OF BRITAIN CLASS
LOCOMOTIVE & TENDER
Operating and Maintenance Instructions
Hornby Hobbies Limited, Westwood, Margate, Kent CT9 4JX, United Kingdom
INS-00003 1006 Printed in China
General
Please read right through these instructions,
particularly the Safety Notes on page 4.
Hornby locomotives are precision built and, if treated
with care, will give many years of good service. This
Hornby locomotive is produced to super detail standard
and therefore incorporate delicate, protruding detail and
many small parts. Care should be taken to avoid
damage when handling the model especially the valve
gear, coupling rods and the small detail parts of the
locomotive body.
This locomotive should not be operated on track
curves of less than 438mm radius, which is Hornby
2nd radius track.
The five-pole electric motor of the locomotive is
designed to be operated from a variable 12 volts,
DC power supply only. This should be obtained by
using a suitable Power Controller operated from the
normal domestic mains electricity supply.
NEVER CONNECT A LOCOMOTIVE DIRECTLY TO
THE MAINS ELECTRICITY SUPPLY.
The locomotive will normally draw a current of between
·2 and ·4 amp depending upon the track configuration and
whether or not gradients are included. There will
be a current surge on starting the locomotive.
Running Hints
If a locomotive ceases to respond normally to the
power controller, or runs badly, check that the
following are in order:
• All electrical connections are correctly made and
the wall power socket is switched “ON”.
• The power connecting clip is correctly inserted into
a suitable section of track.
• All track sections are correctly fitted together and
all fishplates (rail-joiners) are fitting tightly onto
adjoining metal rails.
• All locomotive wheels are correctly positioned on
the track rails.
• The tender drawbar pin is making contact with the
contacts on the locomotive drawbar and the upper
contacts of the drawbar are making contact with
the drawbar pin plate of the tender (if applicable).
• The direction control switch on the train controller
is set to operate in one direction or the other, and
not in the central “OFF” position.
DCC Ready – contact your specialist dealer for advice.
Routine Maintenance
Track Cleaning – In normal use, model railway layouts
will eventually accumulate a blackish deposit on the
running surfaces of the rails, and some of this will be
transferred onto the locomotive’s pick-up wheels.
The 12 volt DC supply is collected from the track
through the wheels on one side of the locomotive and
returned through the wheels on the other side. If the
deposit is allowed to build up, it will have the following
adverse effects:
• The driving wheels will not be able to achieve
maximum traction
• There will be a reduction in the power reaching the
locomotive motor
It is therefore essential that the track and wheels are
kept clean. This can be done by wiping the surfaces
with a clean, non-fluffy cloth. More stubborn deposits
can be removed by using the Hornby Track Cleaning
Rubber, reference R8087, which can be obtained from
Hornby Service Dealers.
Motor – The locomotive is fitted with a sealed, long-
life, 5-pole motor which requires no maintenance.
After a considerable amount of use the motor may
require replacement and this should be carried out by
a Hornby Service Dealer.
Chassis – The locomotive chassis may, from time to
time, pick up fluff, fabric fibres and pet hairs which can
become entangled in the gears and around axles. For
this reason, it is not advisable to run the locomotive on
track which is laid on a carpet. It is important to check
regularly and remove any such debris with the aid of
small tweezers.
Lubrication – Although the locomotive was lubricated
during manufacture, the lubricant can sometimes dry
out in storage. Lubrication should be carried out at
approximately 6-monthly intervals, or every 100 hours
of running. Instructions for carrying out lubrication
procedures are given in section 1 on page 2.
Locomotive Bodywork – Locomotive and tender
bodies are overall spray painted and the rest of the
decoration is applied by a printed process, not transfers.
Safety Notes
14
Television Suppression
Your Hornby locomotive incorporates radio and television interference suppressors. Should interference be
experienced despite these precautions, it may be due to close proximity of the model railway layout to receivers,
aerials, or their “downlines”. In this case, move the layout further away from aerials and receivers.
It is most important that track and wheels be kept absolutely clean.
Spare Parts and Service
Spare parts packs can be obtained from Hornby Service Dealers who are also able to offer a repair service.
IMPORTANT
• The protective 2-part EPS pack is designed to prevent damage during product
removal. Remove the bands found at either end of the pack. Lift off the upper
half of the pack, exposing the locomotive for easy access.
• This locomotive is made to exacting fine scale standards and therefore
necessarily incorporates small, delicate, protruding parts – handle with care.
• Before using the model, read through the Operating and Maintenance
Instructions in this leaflet.
• This locomotive is not suitable for children under
3 years of age because of small parts which can
present a choking hazard. Some components have
functional sharp edges and points – handle with care.
• This locomotive is intended for indoor use only.
• The transformer is not a toy. It is a “Transformer for
Toys”. Before use, check that the transformer is the
correct voltage for your mains electricity supply.
This locomotive is only to be used with the recom-
mended transformer. The transformer should be
examined regularly for damage to the casing, plug
pins and cables. In the event of such damage, the
set should not be used until the transformer is
replaced with a new Hornby recommended unit.
Never attempt to open the transformer yourself.
• This locomotive must not be connected to more
than the recommended number of power supplies.
The output terminals of the transformer must not be
connected directly, or indirectly, to the output of any
other AC circuit derived from a transformer or mains
power supply.
• Before cleaning any part, disconnect the transformer
from the mains electricity supply. Do not use liquid
for cleaning.
• Please retain these details and the address for future
reference.
12V

32
Fig. 2Fig. 1 Fig. 3
Lubrication
IMPORTANT – Only apply small single drops of light machine oil to the places indicated in red. This is best achieved by
making a simple oil “dropper” as illustrated in Fig.1. Insert a straightened paper clip into a cork and use a bottle cap as
a container for the oil. A small drop of oil can then be picked up by the dropper and applied in exactly the right place.
Immediately wipe off any excess oil, especially from the locomotive and tender bodies. Only lubricate moving parts.
Apply one drop of oil to each of the valve gear
and connecting rod pivot points indicated in red
in Fig.2, on both sides of the locomotive.
Apply one drop of oil to the gear and each
of the axle bearings indicated in red.
(See Fig.3).
Accessories The chain guard, vacpipes and articulated coupling cannot
be fitted if the front coupling is to be used when running the locomotive.
Fig.8
Fig.7
DCC Ready
Fig.10
Fig.4
To remove the locomotive body
Important: If your model is fitted with a speedometer cable, detach this first from the left hand rear driving wheel
(Fig.7). Keep screw and spacer safe until the body is replaced.
Turn the locomotive upside down and remove the screw beneath the bogie. (Fig.8). Turn the locomotive right way up
and ease the front end of the chassis downward from the body. When the front of the chassis is clear of the body, pull
the chassis forward to disengage the rear chassis lugs from the rear of the body. (Fig.9).
Fig.5
Alternative pony truck wheels (flanged).
Fig.6
Fig.9
When re-assembling, make sure
the rear chassis lugs are located
into the slots inside the rear of
the body as shown in Fig.10.
Ease body back into place and
replace the chassis fixing screw
and bogie assembly.
