HORNER APG OCS NX Series User manual

MAN0779-04 14 JUN 2006 PAGE 1
Product and Installation
1 INTRODUCTION
The Horner NX Series OCS is a cost effective family of high performance all-in-one controllers. The NX
features an advanced control engine, operator interface, local and remote I/O capabilities (including built-in
HSC and PWM for specific models), and a variety of communications options. The NX is extremely versatile,
adept at a variety of factory automation functions. The NX can be used to perform advanced machine control,
factory machine monitoring, RTU-type functions, and much more.
2 SPECIFICATIONS
Table 1 – NX Series OCS Specifications
NX220 NX221 NX222 NX250 NX251 NX252
Input Voltage 10 to 32 VDC
Screen Type 128x64 LCD Backlit, monochrome 240x128 LCD Backlit, monochrome
LCD Backlighting Green, Red, or Off (selectable) Green or Off (selectable)
Keypad / LEDs 20 keys (10 fn keys) plus 10 LEDs 24 keys (10 fn keys) plus 10 LEDs
Keypad Type Tactile Dome (1 million operations) plus defeatable Audible feedback
Application
Memory: Graphics 1 M byte
Control Memory 256K Ladder Memory plus 32KB Register Space
Control Scan Rate 0.1mS / K Ladder Logic (typical)*
I/O Interfaces Plastic SmartStack I/O – 4 modules maximum
Fiber Optic Expansion (FOX) I/O – 5 bases maximum
CsCAN Network Port – 252 SmartStix I/O maximum
Built-in High Speed
Counter / PWM No No
Yes - >1MHz
max TTL or
24vdc level No No
Yes - >1MHz
max TTL or
24vdc level
Built-in PWM
Outputs No No Yes
24vdc level No No
Yes
24vdc level
Portable Memory Compact FLASH (CF) slot (up to 2GB)
Battery Replaceable 3V Lithium battery – 4.5 years (off) lifetime
Ethernet Ports No 10/100MHz No 10/100MHz
Serial Ports 1 shared port (RS-232 DE-9S** & RS-232/485 RJ45) – software selectable
1 dedicated port (RS-232/485/422 on a 10-pin terminal strip)
Power
Requirements
(without I/O)
Steady State Current: 400mA @24VDC
Inrush Current: 28A for 1ms @24VDC
Temperature &
Humidity 32 - 122°F (0 - 50°C), 5 to 95% Non-condensing
UL
CE Please refer to Compliance Table located at
http://www.heapg.com/Support/compliance.htm
Environment Designed for installation in a NEMA 12 environment. Optional mounting kit HE-ACC006
allows mounting in a NEMA 4/4X or IP65 environment.
* Total ladder scan is impacted by several factors – logic, I/O, screen and communications update.
** Denotes 9-pin, 2-row, socket. The term DB9 is widely (but erroneously) used to specify a 9-pin RS-232 connector. The
correct specifier is either a DE-9S (socket) or a DE-9P (plug).
OCS NX Series Want More Information?
To download the NX User
Manual (MAN0781), refer to
Technical Support in this
document.

PAGE 2 14 JUN 2006 MAN0779-04
Product and Installation
3 INSTALLATION PROCEDURE
3.1 Overview of Required Steps
1. Per the specifications of Figure 1 and Figure 2 – carefully prepare the panel cutout. Make sure the
corners of the cutout are square and free from burrs.
2. Place the OCS in the panel cutout. Secure the unit as shown in Figure 3 using the four (4) supplied
mounting clamps. Figure 4shows the possible clamping locations (10 possible), and the locations
recommended for most applications. For NEMA 4/4X washdown applications, the optional
accessory kit HE-ACC006 is required. This kit includes six additional mounting clips so that all
mounting locations can be secured to provide an optimum seal against leaking.
3. As a final step prior to commissioning, carefully remove the protective, plastic sheet from the front of
the unit. The protective, transparent sheet is used to protect the display window.
3.2 Dimensions
Figure 1 – Dimensions for the NX (NX25x is shown but dimensions apply to all NX Models)
(Left figure shows side-view of NX with 4 SmartStack Modules attached.)
(Right figure shows front view.)
001NX003
CAUTION: Remove the plastic sheet slowly, from corner to corner, so as not to stretch
the NX keypad/display overlay.

MAN0779-04 14 JUN 2006 PAGE 3
Product and Installation
3.3 Panel Cut-Out
Figure 2 – Panel Cut-Out for the NX
Figure 3 – Four Standard Mounting Clips
Figure 4 shows locations for four standard mounting clips and also six additional clips contained in optional
accessory kit HE-ACC006, which is required for NEMA 4/4X or IP65 washdown applications.
202.50mm
(8.0376”)
131.00mm
(5.1614”)
001NX001

PAGE 4 14 JUN 2006 MAN0779-04
Product and Installation
Figure 4 – Locations for 10 Mounting Clips for Optimum Seal Against Leaking
(Extra Clips required for NEMA 4/4X or IP65 washdown applications.)
3.4 Ports, Connectors and Wiring
Figure 5 shows the locations of the most common connectors used during installation.
Figure 5 – Overview of NX Connectors
SWM SWC
CF
SHIELDRXDGND
TXD
TX-TX+ RX+ RX-
RX+ TX+
TX- 0V RXD
TXD
RX- +5V
CN1 PORT 1
0V
+24V
MIN. 9V dc.
MAX. 35V dc.
TX
RXC
TXC
TXM
RXM
I/O PORT
OUT1
IN2
IN1IN2
EXT
IN1
OUT2 EXT
TTL 0V
OUT1
OUT2 24V
LAN
SMARTSTACK
FBD
TRC
FDB
RDY
RDB
RUN
MJ1
F
I
B
E
R
V-
CAN_L
SHIELD CAN_H V+
CSCAN FOR CONNECTION DETAILS TO
MODULES ( NET2) SEE THE
PROFIBUS (NET1) AND COMMS
ASSOCIATED USER MANUAL
1
NET1 NET2
RX
KEY
Standard clip locations
Additional clip locations
RX+ TX+
TX- 0V RXD
TXD
RX- +5V
PORT MJ1
0V
+24V
001NX002-R2
SWM SWC
CF
SHIELDRXDGND
TXD
TX-TX+ RX+ RX-
RX+ TX+
TX- 0V RXD
TXD
RX- +5V
CN1 PORT 1
0V
+24V
MIN. 9V dc.
MAX. 35V dc.
TX
RXC
TXC
TXM
RXM
I/O PORT
OUT1
IN2
IN1IN2
EXT
IN1
OUT2 EXT
TTL 0V
OUT1
OUT2 24V
LAN
SMARTSTACK
FBD
TRC
FDB
RDY
RDB
RUN
MJ1
F
I
B
E
R
V-
CAN_L SHIELD CAN_H
V+
CSCAN FOR CONNECTION DETAILS TO
MODULE S (NET2) SEE THE
PROFIBUS (NET1) AND COMMS
ASSOCIATED USER MANUAL
1
NET1 NET2
RX
Note: This is
Port MJ1’s
pin-out.
SHIELD
RXD
GND
TXD
TX-TX+ RX+ RX-
CN1 PORT 1
OUT1
IN2
IN1IN2
EXT
IN1
OUT2 EXT
TTL 0V
OUT1
OUT2 24V
I/O PORT
V-
CAN_L
SHIELD CAN_H
V+
CSCAN
NET1
Primary
Power
(Physically located
on bottom of unit.)
Serial Ports
(MJ1, CN1, Port 1)
See Table 4 for
functions.
CAN connector used in
CsCAN Network.
RX+ TX+
TX- 0V RXD
TXD
RX- +5V
PORT MJ1
0V
+24V
001NX002-R2
SWM SWC
CF
SHIELDRXDGND
TXD
TX-TX+ RX+ RX-
RX+ TX+
TX- 0V RXD
TXD
RX- +5V
CN1 PORT 1
0V
+24V
MIN. 9V dc.
MAX. 35V dc.
TX
RXC
TXC
TXM
RXM
I/O PORT
OUT1
IN2
IN1IN2
EXT
IN1
OUT2 EXT
TTL 0V
OUT1
OUT2 24V
LAN
SMARTSTACK
FBD
TRC
FDB
RDY
RDB
RUN
MJ1
F
I
B
E
R
V-
CAN_L SHIELD CAN_H
V+
CSCAN FOR CONNECTION DETAILS TO
MODULE S (NET2) SEE THE
PROFIBUS (NET1) AND COMMS
ASSOCIATED USER MANUAL
1
NET1 NET2
RX
Note: This is
Port MJ1’s
pin-out.
SHIELD
RXD
GND
TXD
TX-TX+ RX+ RX-
CN1 PORT 1
OUT1
IN2
IN1IN2
EXT
IN1
OUT2 EXT
TTL 0V
OUT1
OUT2 24V
I/O PORT
V-
CAN_L
SHIELD CAN_H
V+
CSCAN
NET1
Primary
Power
Use for HSC I/O. For
best performance, use
separate supply and
isolated ground.
Use to
provide
power for
unit.

MAN0779-04 14 JUN 2006 PAGE 5
Product and Installation
3.4.1 Primary Power Port
Table 2 – Primary Power Port Pins
Pin Signal Description
1 Frame Ground
2 0V
Input power supply ground
3 +24V
Input power supply ground voltage
Figure 6 - Power Connector (Primary Power Port)
Figure 7 - As viewed looking at the NX
001NX002
PIN 1
PIN 2
PIN 3
+
-
9-36vdc
supply
Wiring to be run through the ferrite
twice (one loop).
Note: The included ferrite
must be installed as
shown to maintain CE
levels of noise immunity.
-
+ Supplied
ferrite
+
-

PAGE 6 14 JUN 2006 MAN0779-04
Product and Installation
3.4.2 CAN Network Port and Wiring
See the latest edition of Horner’s CAN Networks Manual (MAN0799) by referring to the website location
listed Section 6: Technical Support in this document.
Note: To optimize CAN network reliability in electrically noisy environments, the V- CAN Ground needs to be
isolated from the primary input power supply ground.
3.4.3 RS-232/ RS-485 Programming Ports and Wiring
The NX features two active serial ports, accessible through three connectors. Port 1 and MJ1 share internal
OCS circuitry. These two ports can NOT be used simultaneously. Port CN1 has independent circuitry, and
can be used simultaneously to either Port 1 or MJ1.
Note: In certain applications, both Port 1 and MJ1 can be used, but the OCS application program must select
the port which is active at any given time. Table 4 shows the three port connectors and the functions
supported by each.
Table 4 – Serial Ports and Functions (Port 1, MJ1 and CN1)
Port Connector RS-232 RS-422 RS-485 Cscape
Programming
Full
Modem
Support ASCII RTU
Slave RTU Master 3rd Party Protocols
Port 1 DE-9S* x x x x x x x
MJ1 RJ45 x x x x ** x x x x
CN1 10-pin
Terminal x x x ** x x x x
* Denotes 9-pin, 2-row, socket. The term DB9 is widely (but erroneously) used to specify a 9-pin RS-232
connector. The correct specifier is either a DE-9S (socket) or a DE-9P (plug).
** Does not support handshaking.
a. PORT 1 – 9-pin D-subminiature Jack
Figure 8– PORT 1 RS-2323 Port DE-9S Connector.
Table 5– PORT 1 RS-232 Port Pins
Pin Signal Description Dir
1 DCD Always high Out
2 RXD Received Data Out
3 TXD Transmitted Data In
4 DTR Data Terminal Ready In
5 GND Ground -
6 DSR Data Set Ready Out
7 RTS Request to Send In
8 CTS Clear to Send Out
9 RI Ring Indicate Out
Pin 1
Pin 9
Note: The term DB9 is
widely (but erroneously)
used to specify a 9-pin
RS-232 connector. The
correct specifier is either
a DE-9S (socket) or a
DE-9P (plug).

MAN0779-04 14 JUN 2006 PAGE 7
Product and Installation
Figure 9 –Programming Cable (9-pin)
b. MJ1 Modular Jack
Figure 10 – Serial Port MJ1 RJ-45 Jack
Table 6 – MJ1 Serial Pins
Pin Signal Direction
1 RX+ IN
2 RX- IN
3 TX+ OUT
4 TX- OUT
5 +5V OUT
6 0V -
7 RXD IN
8 TXD OUT
1 2 3 4 5 6 7 8
DE-9P
MALE
SHIELDED MULTI-CONDUCTOR
15.24 METERS MAX
(50 FEET MAX)
9-PIN PC
1 DCD
2 RXD
3 TXD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
OCS
RS-232
DCD 1
RXD 2
TXD 3
DTR 4
GND 5
DSR 6
RTS 7
CTS 8
RI 9
DE-9S
FEMALE
Note: For baud rates greater than 9600 baud, a shorter cable may be required.
Note: See Table 4 for a list
of serial port functions.

PAGE 8 14 JUN 2006 MAN0779-04
Product and Installation
c. CN1 10-pin Terminal Header
Figure 11 – CN1 Serial Terminal Connector
Table 7 – CN1 Pins (Black Connector)
Pin Signal Direction
1 TX+ OUT
2 TX- OUT
3 RX+ IN
4 RX- IN
5 TXD OUT
6 GND -
7 RXD IN
8 SHIELD -
9 +5V OUT
10 N/C -
3.5 I/O Port for Built-in High Speed Communications (HSC)
Figure 12 – I/O Port (HSC) Terminal Connector
Table 8 – I/O Port Pins (HSC) (Orange Connector)
Pin Signal Description
1 TTL In1 HSC 1 / 5 V Input 1 (See Note*)
2 TTL In2 HSC 2 / 5 V Input 2 (See Note*)
3 TTL In3 HSC 3 / 5 V Input 3 (See Note*)
4 In3 HSC 3 / 24 V Input 3 (See Note*)
5 0 V Ground
(For best performance, use separate
supply and isolated ground.)
6 In1 HSC 1 / 24 V Input 1 (See Note*)
7 In2 HSC 2 / 24 V Input 2 (See Note*)
8 Out1 Output 1 / PWM 1
9 Out2 Output 2 / PWM 2
10 +24 V Power for Outputs
Note* - Depending on the output of the application, use
5 V (e.g., TTL In1) or 24 V (e.g., In1) per channel.
Note: See Table 4 for a list
of serial port functions.
001NX008
001NX008
Want More Information on NX HSC and PWM?
Download the NX User Manual (MAN0781) and
refer to the Built-in HSC chapter, which covers
configuration, wiring, and other pertinent topics.
See Technical Support for our website address.

MAN0779-04 14 JUN 2006 PAGE 9
Product and Installation
3.6 NX DIP Switches
Table 9 – NX DIP Switches
Port Connector Description DIP Switch Positions
MJ1 RX BIAS SWM-1 ON and SWM-3 ON
MJ1 TERMINATION SWM-2 ON
MJ1 HALF-DUPLEX SWM-4 ON and SWC-4 ON
CN1 RX BIAS SWC-1 ON and SWC-3 ON
CN1
RS-485
TERMINATION SWC-2 ON
Figure 13 – DIP Switches (Switches Shown here in OFF Position)
4 SAFETY
When found on the product, the following symbols specify:
Warning: Consult user documentation. Warning: Electrical Shock Hazard.
WARNING: To avoid the risk of electric shock or burns, always connect the safety (or earth)
ground before making any other connections.
WARNING: To reduce the risk of fire, electrical shock, or physical injury it is strongly
recommended to fuse the voltage measurement inputs. Be sure to locate fuses as close to the
source as possible.
WARNING: Replace fuse with the same type and rating to provide protection against risk of
fire and shock hazards.
WARNING: In the event of repeated failure, do not replace the fuse again as a repeated failure
indicates a defective condition that will not clear by replacing the fuse.
WARNING: Only qualified electrical personnel familiar with the construction and operation of
this equipment and the hazards involved should install, adjust, operate, or service this
equipment. Read and understand this manual and other applicable manuals in their entirety
before proceeding. Failure to observe this precaution could result in severe bodily injury or
loss of life.
4 3 2 1
ON
SWM
4 3 2 1
ON
SWC

PAGE 10 14 JUN 2006 MAN0779-04
Product and Installation
For detailed installation and a handy checklist that covers panel box layout requirements and minimum
clearances, refer to the hardware manual of the controller you are using. (See the Additional References
section in this document.)
• All applicable codes and standards need to be followed in the installation of this product.
• For I/O wiring (discrete), use the following wire type or equivalent: Belden 9918, 18 AWG or larger.
Adhere to the following safety precautions whenever any type of connection is made to the module.
• Connect the green safety (earth) ground first before making any other connections.
• When connecting to electric circuits or pulse-initiating equipment, open their related breakers. Do not
make connections to live power lines.
• Make connections to the module first; then connect to the circuit to be monitored.
• Route power wires in a safe manner in accordance with good practice and local codes.
• Wear proper personal protective equipment including safety glasses and insulated gloves when
making connections to power circuits.
• Ensure hands, shoes, and floor are dry before making any connection to a power line.
• Make sure the unit is turned OFF before making connection to terminals. Make sure all circuits are
de-energized before making connections.
• Before each use, inspect all cables for breaks or cracks in the insulation. Replace immediately if
defective.
5 ADDITIONAL REFERENCES
The following information serves as a general listing of Horner controller products and other references of
interest and their corresponding manuals numbers. Visit our website listed in the Technical Support section
to obtain user documentation and updates.
Note: This list is not intended for users to determine which products are appropriate for their application;
controller products differ in the features that they support. If assistance is required, see the Technical
Support section in this document.
Controller Manual Number
XLE Series (e.g., HE-XExxx) MAN0805
QX Series (e.g., HE-QXxxx) MAN0798
NX Series (e.g., HE-NXxxx) MAN0781
LX Series (e.g., LX-xxx; also covers RCS116) MAN0755
Color Touch OCS (e.g., OCSxxx) MAN0465
OCS (Operator Control Station) (e.g., OCS1xx / 2xx; Graphic OCS250)
Remote Control Station (e.g., RCS2x0) MAN0227
MiniOCS (e.g., HE500OCSxxx, HE500RCSxxx) MAN0305
Other Useful References
CAN Networks MAN0799
Cscape Programming and Reference MAN0313
Wiring Accessories and Spare Parts Manual MAN0347
6 TECHNICAL SUPPORT
For assistance and manual updates, contact Technical Support at the following locations:
North America:
[phone]
www.heapg.com
email: [email protected]
Europe:
(+) 353-21-4321-266
www.horner-apg.com
email: [email protected]
