1. Overview
The Hornettek Phantom MP-2020 is a powerful portable High Definition Multimedia Player.
A perfect Home Entertainment System addition with High Definition 1080i HDMI for playing
and recording HD Movies, Video, Photos & Music. Play, Record & transfer files by adding any
USB external storage subsystem, in addition you can stream and transfer files through built-in
Ethernet connection or by Wireless LAN by adding USB Wi-Fi 802.11g / n adapter.
The USB 2.0 interface offers high speed data transfer rates up to 480Mbit/sec. The Phantom
MP-2020 can be directly connected to a TV & Hi-Fi speakers w/ Fiber Optic Output capability,
or to a Computer and also directly connect to HDMI VGA monitor. Includes user-friendly
Remote Control with step-by-step menu to direct you to your multimedia preferences.
Supports NTSC & PAL formats.
Designed to give you the ultimate Home Entertainment System experience with its attractive
Brushed Black Aluminum finish. The Phantom MP-2020 is compact and durable. Made of
light weight aluminum, the Phantom is easily portable for you to take with you wherever you go.
2. Features:
☆Full-HD 1080P video play back on your TV system
☆2.5-inches HDD can be easily install into Phantom unit
☆Browse photo with background music playing
☆Stream and transfer files through Ethernet and USB 2.0 Host port
☆Support various multimedia formats
☆Equipped with a High Definition Multimedia Interface Connector (HDMI)
☆Support both NTSC and PAL video out
☆Play file from USB storage device
☆Direct connection to TV & HI-FI speakers & Fiber Optical Output
☆Support Multi Language Subtitle
☆Support Dolby and DTS decode
☆BT download available and file sharing on LAN
☆Power Adapter, 100-240 VAC(47Hz~63Hz), 12V/2A output
☆Dimension: 145mm(L)* 139mm(W)* 380mm(H)
☆OS support: Windows ME / 2000 / XP/VISTA
MAC OS 9.x or above
Linux kernel 2.4.1.0 or above

Rev. No. 1.4
Model Name:
Phantom Issue Date Sep 22, 2009
Doc. No. Intellectual Property of Premiertek, LLC City of Industry, CA. Page 3of 7
3. Specification:
Composite Out Supported
Video Output HDMI 1.3 Out Supported up to 1920*1080p
Audio Out L/R Supported
Audio Output SPDIF(Optical) Supported
File Transfer Port USB 2.0 port 2 Ports
Exterior
Interfaces
Ethernet 10/100Mbps RJ-45 Supported
Optional
Interface Wireless LAN W-LAN
Wi-Fi 802.11g / n Supported
Requires - USB Wi-Fi 802.11g/n adapter
MPEG-1 MPG/MPEG/DAT up to 1080p
MPEG-2 MPG/MPEG/VOB/ISO/IFO/TS/
TP/M2TS up to 1080p
MPEG-4 MP4/AVI/MOV support up to
1080p
DivX/XviD 3/4/5/6 AVI/MKV support up to 1080p
H.264, AVC TS/AVI/MKV/MOV/M2TS
support up to 1080p
WMV9 WMV support up to 1080p
Real Video 8/9/10 RM/RMVB support up to 720p
Video Decoding
FLV FLV support up to 1080p
WMA Supported
MP3 Supported
Real Audio (RA) Supported
Audio Decoding
Dolby & DTS Supported(Not Pass through)
JPEG Supported
BMP Supported
Multimedia
Support
Picture Format
PNG Supported

Rev. No. 1.4
Model Name:
Phantom Issue Date Sep 22, 2009
Doc. No. Intellectual Property of Premiertek, LLC City of Industry, CA. Page 4of 7
4. Package Contents:
■Multimedia box Unit x 1
■DC Power Adapter x 1
■AV Cable x 1
■USB Cable x1
■Remote Control x1
■User Manual x1
■Screw Package
■HDMI Cable (Optional)
5. Assembly Viewing:
Front
Back

Rev. No. 1.4
Model Name:
Phantom Issue Date Sep 22, 2009
Doc. No. Intellectual Property of Premiertek, LLC City of Industry, CA. Page 5of 7
Remote Control
1. POWER 9. STOP 17. TITLE 25. Navigation
2. Display 10. PLAY 18. HOME 26. RETURN
3. Audio 11. PREV 19. TV SYSTEM 27. PAUSE
4 Number Buttons 12. SLOW 20. SUBTITLE 28. NEXT
5. GOTO 13. Option 21.MENU 29. FR/FF
6. Setup 14. REPEAT 22. VOL + / - 30. CONFIRM
7. Enter / ZOOM 15. ANGLE 23. MUTE 31. CM SKIP
8. Browser 16. EJECT 24.REPLAY 32. SELECT
33. COPY
24
33
3
20
31
17
1
5
13
1
5
2
27
9
10
11
7
8
18
23
19
22
6
28
25
26
29
30
32
21
12
14
16
4

Rev. No. 1.4
Model Name:
Phantom Issue Date Sep 22, 2009
Doc. No. Intellectual Property of Premiertek, LLC City of Industry, CA. Page 6of 7
6. Agency Approvals: FCC/CE Compliant
RoHS certified
7. Supported Operating Systems:
Windows 7 ---------------------------------Window Native Driver
Win-Vista ---------------------------------Window Native Driver
Win-XP ------------------------------------Window Native Driver
Win2000 ---------------------------------- Window Native Driver
Win-ME -----------------------------------Window Native Driver
MAC OS 9.0 and later ------------------ Mac Native Driver support
Linux with Kernel 2.4.1.0 or above ---- Linux Native Driver Support
8. Physical Specifications:
WEIGHT:
Gross Package Weight --------------- 2.5 lbs.
Net Gross Weight ---------------- 1.2 lbs.
DIMENSIONS:
Package Dimensions --------------- 17cm (W) x 13.5cm (H) x 16.6 (D)
