horsch Terrano 5 FM User manual

Operating Instructions
Read carefully prior to starting up!
Keep operating instructions in a safe place!
Art.: 80270207 en
Issue: 04/2013
Terrano 5/6/7 FM

EC Declaration of Conformity
exchangeable equipment
(RL 2006/42/EC)
The manufacturer HORSCH Maschinen GmbH
Sitzenhof 1
D-92421 Schwandorf
hereby declares, that the product,
Designation of machine: Heavy Universal Cultivator
Machine type: Terrano 5 FM from serial no. 34431397
Terrano 6 FM from serial no. 34441410
Terrano 7 FM from serial no. 34471285
this declaration refers to, conforms with all relevant fundamental health and safety requirements
of the EC directive 2006/42/EC.
For proper implementation of the heath and safety requirements mentioned in the EC-directive,
the following standards and technical speci󰘰cations have been used:
EN 894-4 11-2010
EN 1853 02-2010
EN ISO 4413 04-2011
EN ISO 4254-1 05-2011
EN ISO 12100 03-2011
Schwandorf, 20.06.2013 Person responsible for documentation:
Place and date Gerhard Muck
____________________ ____________________
M. Horsch P. Horsch
(CEO) (Development and Engineering)

Operating instructions: 04/2013 80270207 Terrano 5/6/7 FM en
I hereby con󰘰rm receipt of the operating instructions for the above mentioned machine.
I have been instructed by a HORSCH service technician or authorised dealer in the operation and
functions of the machine, as well as in the safety requirements.
........................................................................
Name of the service technician
Machine Registration
No warranty claims will be accepted if this machine registration form is
not returned !
I am aware that a warranty claim will only be valid if this form has been fully completed, signed and
returned to HORSCH Maschinen GmbH, or has been given to the Service Technician, immediately
after 󰘰rst instruction.
................................................................... ........................................................................
Place, date of 󰘰rst instruction Buyer’s signature
Dealer
Name: ............................................................
Street: ............................................................
Postal code: ...................................................
Place: .............................................................
Tel.: ................................................................
Fax:.................................................................
E-mail: ...........................................................
Customer No. : ...............................................
Customer
Name: ............................................................
Street: ............................................................
Postal code: ...................................................
Place: .............................................................
Tel.: ................................................................
Fax:.................................................................
E-mail: ...........................................................
Customer No. : ...............................................
.
Type of machine:............................................
Serial number: ................................................
Delivery date: .................................................
To
HORSCH Maschinen GmbH
Postfach 10 38
D-92401 Schwandorf
Fax: [phone] / 41364
Demonstration machine – initial use
Demonstration machine - relocation
Demonstration machine 󰘰nal sale - use
New machine 󰘰nal sale – initial use
Customer‘s machine - relocation

- Translation of the Original Operating Instructions -
Machine Identication
The corresponding data is to be entered into the list below upon
receiving the machine:
Serial number: ..................................................
Machine type: ...................................................
Year of construction: ........................................
Initial installation: ..............................................
Fittings: .............................................................
..........................................................................
..........................................................................
..........................................................................
Publication date of Operation Manual: 04/2013
Latest change: 04/2018
Address of Retailer: Name: ......................................................................
Road: ......................................................................
Town/City: ......................................................................
Tel.: ......................................................................
Customer No.:
Retailer: ......................................................................
Address of HORSCH: HORSCH Maschinen GmbH
92421 Schwandorf, Sitzenhof 1
92401 Schwandorf, Postbox 1038
Tel.: [phone] / 7143-0
Fax: [phone]
E-mail: [email protected]
Customer No.:
HORSCH: ......................................................................

2
Table of contents
Introduction.................................................4
Foreword ......................................................4
Warranty claims............................................4
Intended use.................................................5
Consequential damage...............................5
Authorised operators ....................................6
Protective clothing ........................................6
Information regarding safety.....................7
Safety symbols .............................................7
Operational safety ......................................10
Road tra󰘲c safety.......................................10
Accident prevention....................................10
Hitching / unhitching .................................10
Pressure accumulator.............................11
Changing implements...............................11
In operation...............................................11
Service and maintenance...........................11
Delivery.......................................................12
Installation ..................................................12
Transport ....................................................12
Technical data...........................................13
Design and working principle .................14
Overview.....................................................14
Lighting.......................................................15
Hydraulic system ........................................15
Hydraulics - Undercarriage and Tailgate....16
Adapting the hose connection ....................17
TerraGrip Tines ..........................................17
MulchMix Coulters......................................18
Disc levelling...............................................19
Packer ........................................................20
Setting/Operation .....................................21
Hitching and unhitching the machine..........21
Hitching.....................................................21
Connecting the hydraulic system..............21
Folding......................................................22
Parking the machine.................................22
Unhitching.................................................22
Depth setting ..............................................22
Traction intensi󰘰er ....................................25
Use without packer ...................................25
Brake system..............................................26
Air brake system.......................................27
Hydraulic brake.........................................28
Optional equipment..................................29
Additional support wheels...........................29
Harrow........................................................30
Rear drawbar..............................................30
Maintenance and Servicing .....................31
Cleaning .....................................................31
Maintenance periods ..................................31
Storage.......................................................31
Service........................................................32
Lubricating machine ...................................32
Hygiene...................................................32
Maintenance overview Terrano FM............33
Lubrication points .....................................34
Coulter arrangement...................................35

3

4
Introduction
Foreword
Before operating the machine, read and strictly
comply with the operating instructions. In doing
so, you will avoid accidents, reduce repair costs
and downtime and increase the reliability and
service life of your machine. Pay attention to
the safety notices!
HORSCH will not assume liability for any dam-
age or malfunctions resulting from failure to
comply with the operating instructions.
These operating instructions will assist you in
getting to know your machine and in using it
correctly for its intended purposes. First you
are given general instructions in handling the
machine. This is followed by chapters on care,
description, adjustment and maintenance.
The operating instructions must be read and
observed by everyone authorised to work on or
with the machine, e.g.
¾operation (including preparation, fault recti󰘰-
cation during work and servicing)
¾Maintenance (maintenance and inspection)
¾transport
Together with the operating instructions, you
also receive a spare parts list and a machine
registration form. Field service technicians
will instruct you in the operation and care of
your machine. After this you should return the
machine registration form to HORSCH. This
con󰘰rms your formal acceptance receipt of the
machine. The warranty period starts with the
date of delivery.
We reserve the right to alter illustrations as
well as technical data and weights contained in
these operating instructions for the purpose of
improving the machine.
Warranty claims
Warranty claim forms must be submitted through
your local HORSCH dealer to the HORSCH
Service Department in Schwandorf.
Only claims, which have been correctly complet-
ed and submitted no later than four weeks after
the defect occurred, can be processed.
Please return damaged components cleaned
and emptied to HORSCH within 4 weeks to-
gether with a warranty claim form and precise
fault description.
Parts deliveries without used parts request.
Please keep such parts for 6 weeks, until a de-
cision has been made on the action to be taken.
Warranty repairs, which are to be carried out
by a third-party company, or which are expect-
ed to take longer than 10 working hours, must
be agreed upon in advance with the Customer
Service Department.

5
Intended use
The machine has been built in accordance with
latest technical standards and generally accept-
ed safety regulations. However, risks of injury to
the operator or third parties and impairment of
the machine or other tangible assets can occur
during use.
The machine must only be operated for its in-
tended use if in a technically perfect condition,
whilst being aware of safety and risks and in
strict compliance with the operating instructions!
Faults, particularly those which impair safety,
must be remedied immediately.
The machine must only be operated, serviced
and repaired by persons who are familiar with
it and have been made aware of the dangers
involved.
Genuine spare parts and accessories from
HORSCH have been specially designed for this
machine. Spare parts and accessories which
are not delivered by us, have not been tested
or approved by us.
Installation or use of non-original HORSCH
products may have a detrimental effect on
speci󰘰c design features of the machine and
impair the safety of machine operators and the
machine itself.
HORSCH will not assume liability whatsoever for
damage resulting from the use of non-original
parts and accessories.
The machine is intended for normal use in soil
cultivation in agricultural applications. Any other
use or use beyond these limits is considered as
unintended.
HORSCH will not assume liability whatsoever
for damage resulting from unintended use. The
risk will be borne solely by the user.
The respective accident prevention regulations
and other generally recognised safety-related,
occupational medical and road tra󰘲c regulations
are to be adhered to.
Intended use also includes the strict compliance
with the operating instructions and adherence to
the operating, maintenance and repair instruc-
tions speci󰘰ed by the manufacturer.
Consequential damage
The machine has been manufactured by
HORSCH with great care. However, damage
can also occur when used for purposes for which
it is not intended.
¾Damage caused by external in󰘱uences.
¾Inappropriate or incorrectly adapted rotary,
working and travel speeds.
¾Inappropriate or incorrect attachment or set-
ting of the equipment
¾Failure to comply with the operating instruc-
tions.
¾No or inadequate care and maintenance.
¾Missing, worn or broken cultivation tools.
You should therefore check the correct function
and setting of the machine before each use.
Compensation claims for damages which have
not been caused by the machine, are excluded.
This also includes that any liability for conse-
quential damages caused by travel and operat-
ing faults, is excluded.

6
Authorised operators
Only those persons who have been authorised
and instructed by the operator may operate the
machine. Operators must be at least 16 years
of age.
The operator must hold a valid driving licence.
He is responsible for third parties in the oper-
ating area.
The person in charge must
¾make the operating instructions available to
the operator.
¾Ensure that the operator has read and under-
stood the operating instructions.
The operating instructions are a component part
of the machine.
Protective clothing
For operation and maintenance you need:
¾snug 󰘰tting clothing.
¾safety gloves and goggles to protect against
dirt and sharp edged machine parts.
In these operating instructions
The operating instructions distinguish between
three di󰘯erent types of warning and safety instruc-
tions. The following graphic symbols are used:
important notes!
if there is a risk of injury!
if there is a risk to life and limb!
It is important that all the safety instructions
contained in these operating instructions and
all the warning signs on the machine are read
thoroughly.
Ensure that the warning signs are legible and
replace signs that are missing or damaged.
These instructions must be followed in order
to prevent accidents. Inform other users of the
warnings and safety instructions.
Do not carry out any operations which may a󰘯ect
the safe use of the machine.

7
Information regarding
safety
The following warnings and safety instructions ap-
ply to all sections in these operating instructions.
Safety symbols
On the machine
Watch out for 󰘱uids spraying out
under high pressure, follow the
operating instructions
00380133
Never reach into areas where there
is a risk of crushing, as long as parts
could still be moving!
00380134
No passengers are allowed to ride
on the machine!
00380054
Read and adhere to the operating
instructions before starting up the
machine!
00380055
Stay clear of swinging area of re-
tractable and extendible machine
parts!
00380135
Switch the engine o󰘯 and pull out
the key before starting maintenance
and repair work.
00380294
Do not climb on rotatable parts.
Use mounting steps provided for
this purpose.
00380299
The accumulator is charged with
gas or oil pressure. Dismantle and
repair only in strict compliance with
the instructions in the technical
manual.
00380252

8
It is only permitted to remain in the
danger zone if the safety support
is in place
00380953
It is only permitted to remain in the
danger zone when the lifting cylin-
der safety device is applied.
00380896
When hitching up the drill and when
operating the hydraulic system, no
persons should be between the
machines.
00380145
alle Verladehacken ed Sept 03
DatumEnt w.DateinameZeichnungsnummerMaschine Zeichnung
00380880
00380880
Loading hook; attach lifting tackle (chains, ropes,
etc.) here when performing loading work.
alle Aufkleber ed 113700340358
Ent w.DateinameMaschine Zeichnung JJKWZeichnungsnummer
00380359
Retighten the wheel nuts / wheel bolts after
50 km or 10 hours. Retighten every day - see
maintenance overview.
sw aufkleber ed 12 1400380972
Ent w.DateinameMaschine Zeichnung JJKWZeichnungsnummer
00380972
Do not insert any clips during use.

9
00385488
300
1:1
2B09141
30 x 60 mm
00385488
5 mm
2011-12-02
schwarz
CX4
do
Auftrag:
Maßstab:
Erstelldatum:
Farben:
Prog.Version:
Bearbeiter:
Artikel:
Format:
Freigabe:
gepr. Sachb.:
geprüft:
Radius:
00385488
Tighten with the appropriate torque.
00385489
510
1:1
2B09140
30 x 60 mm
00385489
5 mm
2011-12-02
schwarz
CX4
do
Auftrag:
Maßstab:
Erstelldatum:
Farben:
Prog.Version:
Bearbeiter:
Artikel:
Format:
Freigabe:
gepr. Sachb.:
geprüft:
Radius:
Hydr_Funktionen ed Sept 03
DatumEntw.DateinameZeichnungsnummerMaschine Zeichnung
00380165
00380165
The colour marking of the hydraulic function
corresponds with the colour marking on the
hydraulic hose (Lift - Fold - Bout markers - Cul-
tivation tools).
00380165
ed Nov 06
DatumEnt w.DateinameZeichnungsnummerMaschine Zeichnung
Aufkleber 00110681 - 7
00110681 00110682
00110683 00110684
00110685 00110686
00110687
ed Nov 06
DatumEnt w.DateinameZeichnungsnummerMaschine Zeichnung
Aufkleber 00110681 - 7
00110681 00110682
00110683 00110684
00110685 00110686
00110687
ed Nov 06
DatumE nt w.DateinameZeichnungsnummerMaschine Zeichnung
Aufkleber 00110681 - 7
00110681 00110682
00110683 00110684
00110685 00110686
00110687
Hydraulic valve block
Machine up / down
Folding / unfolding the machine
Identication marks on hydraulic hoses
The symbol is always found on the hose requir-
ing pressure to bring the machine to transport
position (raising, folding, etc.).
00385489

10
Accident prevention
In addition to the operating instructions, it is
important to observe the accident prevention
regulations speci󰘰ed by agricultural trade as-
sociations!
Hitching / unhitching
There is risk of injury to persons when hitching/
unhitching the machine to / from the drawbar of
the tractor.
¾Secure the machine against rolling away.
¾Take special care when reversing the tractor.
Never stand between tractor and machine.
¾Only park the machine on a 󰘰rm and level
surface. Before unhitching the machine, lower
it to the ground.
On the hydraulic system
¾Do not connect hydraulic hoses to the tractor,
before both hydraulic systems on machine
and tractor are de-pressurised.
¾Check all lines, hoses and screwed con-
nections regularly for leaks and any visible
external damage!
¾Only use appropriate aids when checking for
leaks. Repair any damage immediately! Oil
sprays can cause injuries and 󰘰re!
¾In the case of injury, contact a doctor imme-
diately!
The hydraulic spool valves on the trac-
tor must be secured or locked when not
in use or when the machine is in trans-
port position, in order to prevent acci-
dents caused by unintended hydraulic
movements or movements caused by
persons other than the operator (chil-
dren, passengers).
Operational safety
The machine must only be put into operation
after receiving instructions by employees of the
authorized dealer or a HORSCH employee. The
machine registration form has to be completed
and returned to HORSCH.
All protective features and safety equipment,
such as detachable protective devices, must be
correctly in place and reliably functioning before
the machine is put into operation.
¾Check and tighten nuts and screws at regular
intervals.
¾Check tyre pressure regularly.
¾In case of malfunctions stop and secure the
machine immediately!
Road trafc safety
The valid road tra󰘲c regulations are to be ob-
served when travelling on public roads, paths
and areas.
Do not exceed the max. permissible widths
and attach light system, warning and protective
devices.
Also observe transport height depending on the
coupled machine!
Do not exceed the permissible axle loads, tyre
carrying capacities and total weights, in order
to ensure su󰘲cient steering and braking capa-
bilities. Handling is a󰘯ected by the connected
equipment. It is important to take into account
the large overhang and the centrifugal mass of
the implement, particularly when cornering.
Clean all soil o󰘯 the machine before driving on
public roads.
Passengers are strictly forbidden to ride on the
machine!
When transporting along public roads pay
attention to the permissible top speed spec-
ied in the type approval.
Always match the travel speed to the road
conditions to avoid accidents and damage
to the undercarriage.
Consider personal abilities, carriageway,
trafc, sight and weather conditions.

11
Operation of the hydraulic system re-
quires utmost attention. Operating er-
rors can cause damage to man and
machine.
Hydraulic connectors are marked with symbols,
to prevent operating errors.
Pressure accumulator
The hydraulic system is equipped with
a pressure accumulators.
It requires extreme care in handling
to avoid accidents.
Do not open or work (welding, drilling) on
pressure accumulators. Even when empty, the
accumulator is still preloaded by gas pressure.
Always de-pressurize the pressure accumulator
before starting work on the hydraulic system.
The pressure gauge should not indicate any
pressure.
The pressure gauge reading should drop to 0
bar. Only then may work be carried out on the
hydraulic system.
Changing implements
¾Secure the machine against unintended roll-
ing away!
¾Secure lifted frame parts, under which you will
be working, with suitable supports!
¾Caution! Danger of injury caused by protrud-
ing parts (harrow, tines, share)!
¾Do not use the packer tyres or other rotating
parts to climb onto the machine. These could
start to rotate and you could fall and be seri-
ously injured.
In operation
¾Check the area around the machine (for chil-
dren!) before setting o󰘯 and starting operation
of the machine. Ensure su󰘲cient visibility!
¾Do not remove any of the mandatory and
supplied protective devices.
¾Stay clear of the operating range of hydrauli-
cally operated parts.
¾Only use ascending aids and steps when
machine is at standstill. Passengers are not al-
lowed to ride on the machine during operation!
Service and maintenance
¾Ensure that regular tests and inspections are
always carried out to schedule, as speci󰘰ed
in the operating instructions.
¾Prior to performing maintenance and servicing
work, ensure that the machine is positioned
on 󰘰rm, level ground and that it is properly
secured against rolling away.
¾De-pressurise the hydraulic system and lower
or support the implement.
¾After cleaning, check all hydraulic lines for
leaks and loose connections.
¾Check for cha󰘰ng and signs of other damage.
Remedy any faults immediately!
¾Retighten screwed connections which had
been loosened during servicing and mainte-
nance work.
Do not wash new machines with a
steam-jet or high-pressure cleaner. The
paint takes approx. 3 months to cure
and could thus be damaged if this time
has not yet expired.

12
Higher danger of accident during in-
stallation and maintenance. Before
performing any installation and mainte-
nance work make yourself familiar with
the machine and read the operating
instructions.
Depending on scope of equipment
¾Take loosely delivered parts o󰘯 the machine.
¾Check all important screw connections!
¾Lubricate all grease nipples!
¾Check air pressure in tyres!
¾Check all hydraulic connections and hoses
for correct fastening and function.
¾Immediately rectify any occurring damage or
have it corrected!
Transport
Depending on country speci󰘰c regulations and
working width the equipment can be transported
on public roads, either attached to a tractor or
on a trailer or low loader.
¾The permissible dimensions and weights for
transport must be complied with.
¾The tractor must be big enough, so that
su󰘲cient steering and braking abilities are
assured.
¾If the machine is hitched up in two-point mode,
the tractor link arms must be blocked against
swinging sideways.
¾For road transport the piston rods must be
󰘰lled up with spacers and the machine must
be lowered on these spacers.
¾On a trailer or low loader the machine must
be secured with tensioning straps or other
means.
¾Attach lifting tackle only at the specially
marked points.
Transport / installation
Higher danger of accident during initial instal-
lation. Please pay attention to the notes in the
corresponding chapters.
Delivery
The machine with implements is normally de-
livered completely assembled on a low loader.
If parts or modules had to be disassembled for
transportation purposes, these will be assem-
bled by our distributor or 󰘰eld engineer in situ.
Depending on the design of the low loader the
machine can be unloaded with a tractor, or
needs to lifted o󰘯 with suitable lifting gear (forklift
truck or crane).
Su󰘲cient load bearing capacity of lifting gear
and lifting tackle must therefore be assured.
Lifting and lashing points are identi󰘰ed by labels.
When using other lifting points pay careful at-
tention to the centre of gravity and the weight
distribution. These points must, in any case, only
be on the frame of the machine.
Installation
Instruction of the operator and initial installation
of the machine will be carried out by our service
engineers or distributors.
Any anticipating use of the machine is
prohibited!
The machine can only be released for opera-
tion after the instruction session conducted by
our service engineer / distributor and after the
operating instructions have been read.

13
Technical data
Terrano FM 5 FM 6 FM 7 FM
Working width (m) 4.8 5.9 7.0
Length (m)*up to 9.65 up to 9.65 up to 9.65
Transport height (m) 3.3 3.85 4.0
Transport width (m) 3.0 3.0 3.0
Weight (with Double RollFlex) (kg) 6,050 6,800 7,900
Number of tines 17 21 25
Coulter spacing (cm) 112 112 112
Tine spacing (cm) 28 28 28
Tyres (undercarriage): 405/70 - 24 405/70 - 24 405/70 - 24
Tyre front support wheel 380/55 - 17 380/55 - 17 380/55 - 17
Recommended. tractor power (kW) 150 - 220 175 - 265 220 - 290
Control unit 2 (3 with hydr. depth
setting)
2 (3 with hydr. depth
setting)
2 (3 with hydr. depth
setting)
Bl
(Benennung)
(Zeichnungsnummer) Blatt
Datum Name
Bearb.
Gepr.
Norm
Name
Datum
Änderung
Index
Lfd. Nr. Stück Benennung
Maßstab:
WerkstoffDIN Rohmaß
Urheberschutz: Für diese technische Unterlage
behalten wir uns alle Rechte vor.
Werkstück-
kanten
DIN 6784
Gewicht (kg):
3D
A1
Bemaßungen in mm
24.03.2011 Gottschalk
Terrano 6 FM 2011
34004400
9798,451 kg
Allgemein-
toleranz
© Horsch Maschinen GmbH
Änderungen sind untersagt
Landwirtschaft aus Leidenschaft
HORSCH Maschinen GmbH
Sitzenhof 1
92421 Schwandorf
www.horsch.com
3339 (3290 Scharspitzen gedreht 90° )
2800
Zul. Gesamtgewicht ( kg ): 7950
Zul. Stützlast ( kg ): 800
Zul. Achslast hinten ( kg ): 7150
Anzahl der Schare: 21
Schar / Strich Abstand ( m ): 1,12 / 0,28
Anzahl der Scharreihen: 4
Fahrwerk Rad: 405/ 70- 24 /ø1,20m /2
Stützräder / Durchmesser Rad: 15.0/ 55- 17 /ø0,90m /2
Hyd. Ansteuerung: 2 x doppelwirkend
Mechanische Anhängung vorn: Zugpendel/ Kugelkopf
9131
3146 (3090 Scharspitzen gedreht 90° )
3731
392
O
870
825 1075
725 725
280
1120
O
550
9131 (ohne Zughaken, ohne Striegel)
750
1940
2990
3085
1180
O
9650
O 380
Terrano 6 FM
* depending on equipment
24.03.2011 Gottschalk Terrano 6 FM 2011
34004400
9798,451 kg
Bl
(Benennung)
(Zeichnungsnummer) Blatt
Datum Name
Bearb.
Gepr.
Norm
Name
Datum
Änderung
Index
Lfd. Nr. Stück Benennung
Maßstab:
Werkstoff
Maschinen
DIN Rohmaß
C A D - Zeichnung
Änderungen am Reißbrett sind
u n t e r s a g t
Urheberschutz: Für diese technische Unterlage
behalten wir uns alle Rechte vor.
Werkstück-
kanten
DIN 6784
Allgemein-
toleranz
HORSCH Maschinen GmbH
Sitzenhof 1
92421 Schwandorf
Gewicht (kg):
3-D
A1
Bemaßungen in mm
3459 (3405 Scharspitzen gedreht 90° )
2810
2998
Zul. Gesamtgewicht ( kg ): 6500
Stützlast ( kg ): 1000
Achslast hinten ( kg ): 5500
Anzahl der Schare: 21
Schar / Strich Abstand ( m ): 1,12 / 0,28
Anzahl der Scharreihen: 4
Fahrwerk Rad: 405/ 70- 24 /ø1,20m /2
Stützräder / Durchmesser Rad: 15.0/ 55- 17 /ø0,90m /2
Hyd. Ansteuerung: 2 x doppelwirkend
Mechanische Anhängung vorn: Zugpendel/ Unterlenker
8914
3141 (3090 Scharspitzen gedreht 90° )
3847
388
O
1178
O
894
825 1075
725 725
280
1120
O
550
O 380
2520
8566 (ohne Zughaken)
750
2100

14
Design and working principle
Overview
2
3
8
5
1
97
10
64
Terrano 6 FM
1 Lighting
2 Packer
3 Spade discs
4 Setting disc levelling
5 Tines
6 Hydraulic depth setting (packer)
7 Undercarriage
8 Support wheel
9 Two-point hitching
10 Hose bracket
The Terrano FM is a universal cultivator with
central undercarriage and is most suitable for
shallow and deep tillage.
The four-beam superstructure enables intensive
mixing, which remains unobstructive, because
of the 28 cm groove spacing.
The central undercarriage enables very tight
turning at the headland and has excellent travel
characteristics on the road.
The depth is set via packer and front support
wheels or, in case of severe conditions, also via
the central chassis.

15
Lighting
Alle angehängten Beleuchtung Beleucht.skf ed Feb 04
1
2
3
4
5
6
7
12
3
4
5
67
R
L
1 - 7
DatumEnt w.DateinameZeichnungsnummerMaschine Zeichnung
1
12
3
4
5
67
2
3
7
5
4 6
April 02
Lighting equipment
1.7-pin plug
2.Distribution box
3.Lighting tine guard right
4.Lighting tine guard left
5.Rear-light, right
6.Rear-light, left
7.7-pin socket (rear drawbar)
Plug and cable assignment
No. Design. Colour Function
1. L yellow Indicator left
2. 54 g - - - - - -
3. 31 white Earth
4. R green Indicator right
5. 58 R brown Rear light right
6. 54 red Brake light
7. 58 L black Rear-light left
Check lighting equipment at regular
intervals, to prevent other road users
being endangered through negligence!
Hydraulic system
The hydraulic system is under high
pressure. Hydraulic oil escaping under
pressure can penetrate the skin and
cause serious injuries. In the case of
injury, contact a doctor immediately!
Operation of the hydraulic system re-
quires very careful attention. Operating
errors can cause damage to man and
machine.
The hydraulic system is equipped with
a pressure accumulator.
This requires highest caution when
handling, in order to avoid accidents.
Do not open or work (welding, drilling)
on the pressure accumulator. Even
after being emptied, the accumulator is
still preloaded by gas pressure.
Always depressurize the pressure ac-
cumulator before starting work on the
hydraulic system. The pressure gauge
should not indicate any pressure.
The pressure gauge reading should
drop to 0 bar. Only then may work be
carried out on the hydraulic system.

16
Hydraulics - Undercarriage and Tailgate
1
terrano fm Hub, Klapp, ed 131634441200
2
Ent w.DateinameMaschine Zeichnung JJKWZeichnungsnummer
12
14 13
8
10
9
9
8
7
5
6
54
H1S1SB
B
A
SA MA S2 H2
3
4
15
11 11
Hydraulics Terrano FM
1 Control unit
2 Hydraulic coupling
3 Valve block traction booster
4 Shut-o󰘯 valve
5 Pressure valve
6 Lock valve
7 Pressure gauge
8 Pressure accumulator
9 One-way restrictor
10 Hydraulic cylinder traction booster
11 Double load retaining valve
12 Hydraulic cylinder lift/lower
13 Shut-o󰘯 valve
14 Restrictor
15 Hydraulic cylinder wings
