Horton S User guide

Servicing Instructions
Juego de Reparación
Instructions d’entretien
Minor Seal Kit Servicing Instructions for Type
S and HT/S Fan Drives
Juego de Reparación de Sellos Menores
Instrucciones de Servicio Para los Embragues
de Ventilador Tipo S y HT/S
Kit de joints Instructions d’entretien pour les
entraînements de ventilateur des types S et
HT/S
When unpacking your product, remove all components and inspect them
to ensure that no damage occurred during shipping. If any components
are missing or damaged, contact Horton, Inc. at 1-800-621-1320 imme-
diately. Do not return the product to the retailer or point of purchase.

© 2021 Horton Holding, Inc. All rights reserved.
Committed to Your Ideal Airow Solution
Horton®is the premium provider of engine cooling solutions worldwide.
Our culture of innovation delivers high-performance products that last
and services that help you meet your commitments. Trust Horton to help
your products last longer, run quieter and consume less fuel.
www.hortonww.com
Horton is IATF 16949, ISO 14001 and ISO 9001 certied.
ENGLISH
Introduction 3
Pre-Installation 4
Fan Clutch and air chamber removal 6
Seal Kit 8
O-ring, face seal and System Sentry®8
Cartridge Assembly 12
Clutch Assembly 15
Form #22502-H-0521 EN
2

Read this manual carefully, making use of its explanations. This
manual describes the correct inspection, service, and repair pro-
cedures for Type S and HT/S fan drives. Following the instructions
carefully will provide the safest and most trouble-free operation.
We are using the following special notices to give warning of pos-
sible safety-related problems which could cause serious injury, and
provides information to help prevent damage to equipment.
Danger is used to indicate the presence of a hazard which will
cause severe personal injury, death, or substantial property dama-
ge if the warning is ignored.
Denotes that a potential hazard exists and indicates procedures
that must be followed exactly to either eliminate or reduce the ha-
zard, and to avoid serious personal injury, or prevent future safety
problems with the vehicle.
Caution is used to indicate the presence of a hazard which will or
can cause minor personal injury or property damage if the warning
is ignored.
NOTE
Advises of operation, procedure, or instruction that is inserted for
correct service providing greater owner satisfaction. A note can
also provide information that will make service quicker and easier.
Introduction
WARNING
CAUTION
DANGER
3

Pre-Installation
You must follow your company safety practices, which should
adhere to or be better than Federal or State approved shop safety
practices and procedures. Be sure that you understand all the
procedures and instructions before you begin work on this unit.
NOTE
Parts replacement and/or repair of your Horton fan drive should
be performed only by the Horton Factory or an authorized Horton
Distributor or Dealer to keep your warranty coverage intact
during the warranty period.
NOTE
In the following sections, an O-Ring is used for the Piston Fric-
tion Disc if you have purchased a Minor Seal Kit. The PolarExtre-
meTM Seal Kit contains a D-Ring for the Piston Friction Disc.
4

5

1. Verify the fan drive model and that correct replacement parts
t this model.
2. Remove the fan drive from the engine. Lay the fan drive
assembly in a vise and clamp the Journal Bracket tight.
3. Remove the Torx®Socket Head Cap Screws from the Air
Chamber.
NOTE
Applying a small amount of air pressure to the fan drive air
inlet will aid in removal of the Air Chamber Assembly from the
fan drive.
Apply air pressure slowly so that the Air Chamber will not pop
off quickly, resulting in serious personal injury.
4. Slide the Air Chamber Assembly off the Piston Friction Disc.
5. Examine the inside of the Air Chamber for signs of dirt and
foreign material. The Air Chamber should be clean and dry.
If not, a problem may exist in the vehicle air system and must
be corrected before the fan drive is reinstalled.
WARNING
Fan drive and air chamber removal
6

7

1. Remove the O-ring from the Air Chamber and clean the O-ring
contact surfaces.
2. Inspect the Face Seal for signs of wear that may indicate dirt
exists in the air system.
If dirt or oil exists in the air system, the air system must be
cleaned and dried before the fan drive is reinstalled.
3. Remove the Piston Friction Disc and clean the splines of both
the Piston Friction Disc and the Splined Hub.
4. Check the System Sentry®for visual signs of melting. If your
fan drive is not equipped with a System Sentry®, Horton
recommends that the Piston Friction Disc is replaced with a
System Sentry®PFD for proper, safe operation.
NOTE
If for any reason, excessive heat is building up in the fan drive,
the System Sentry® will release and create an air open air passa-
ge. This shuts down the system to prevent any further damage.
5. When replacing the System Sentry®be sure to loosen it in
the correct direction. It is a left hand thread and needs to be
turned clockwise for removal.
CAUTION
Minor seal kit and PolarExtreme seal kit
O (D)-ring, face seal and System Sentry®
8

9

NOTE
Your System Sentry® may have an Allen head or a Torx® head.
The glove box Torx® head tool (part number 994365) was desig-
ned with a 30 and 40 Torx® end. The 30 Torx® end will work in the
removal and installation of the 3/16 Allen head System Sentry®.
The 40 Torx® end will work in the removal and installation of the
40 Torx®System Sentry® or lock-up bolts. The System Sentry®
has left hand threads.
Do not replace the System Sentry® with a straight plug. The Pis-
ton Friction Disc is balanced and anything other than the Horton
System Sentry® will upset the balance and could void warranty.
6. Install the new System Sentry®.
7. Using the small brush supplied in the repair kit, apply an even
coating of spline lubricant (also supplied in the repair kit) to
both splined areas of the Piston Friction Disc and Hub.
8. Install the Piston Friction Disc.
9. Replace the Face Seal and tighten the Face Seal to 50 In. Lbs.
[5.7 Nm] torque.
NOTE
If the Face Seal is round (NOT HEX. SHAPE) it is considered an
obsolete part and a new Air Chamber, with a threaded Face Seal
must be used to replace it.
10. Lubricate the new O-ring and O-ring contact surfaces with the
fresh O-ring lubricant supplied in the kit; then, install the new
O-ring into the Air Chamber.
WARNING
10

11

11. Remove the O-ring from the Piston Friction Disc and clean the
O-ring contact surfaces.
12. Lubricate the new D (O)-ring and D (O)-ring contact surfaces
with the fresh lubricant supplied in the kit; then, install the
new D (O)-ring onto the Piston Friction Disc.
NOTE
The entire tube of the lubricant should be used when lubrica-
ting the new D (O)-rings and D (O)-ring contact surfaces. Extra
lubricant may be placed in the bottom of the Air Chamber. A
slight amount of lubricant will be needed for the O-rings on the
Cartridge Assembly.
WARNING
Fan drive and air chamber removal
Cartridge Assembly
Wear safe eye protection when removing Retaining Rings to pre-
vent serious eye injury.
1. Remove the Retaining Ring.
2. Remove the Cartridge Assembly and, if applicable, the U-cup.
Clean the Journal Bracket bore if necessary.
The Cartridge Assembly shown in Step 2 is an older style brass
Cartridge. The new Cartridge Assembly does not use the U-cup
Seal. Make sure you DISCARD the U-cup Seal upon installation
of this new style Cartridge.
CAUTION
12

13

3. Apply O-ring lubricant to the outside O-rings of the new Car-
tridge and install the new Cartridge Assembly into the Journal
Bracket; then, reinstall the Retaining Rings to hold the new
Cartridge Assembly in tight.
The Retaining Ring must be fully seated in the retaining ring
groove to keep the Cartridge Assembly from moving. Also, the
Retaining Ring is beveled. The curved side must be installed
facing the Cartridge.
4. Clean both the Carbon Tip of the Cartridge Assembly and also
the Face Seal of the Air Chamber Assembly to make sure they
are free of lubricants and dust.
CAUTION
14

All fan drive components must be cleaned and free of all rust
and foreign material prior to reassembly. Extreme care must be
exercised when replacing the Air Chamber to avoid damage to
the O-rings.
1. Install the Air Chamber onto the Piston Friction Disc.
2. Install the new Torx®Socket Head Cap Screws by alternately
and evenly tightening to 180 In. Lbs. [20.3 N•m] torque.
3. Install the Umbrella Check Valve into the Air Chamber bleed
hole by pressing it into place with your thumb.
4. Apply 90 to 120 PSI of clean air to the air inlet of the fan drive
to check for proper engagement of the Piston Friction Disc
and friction material.
If a problem exists, it must be corrected prior to mounting the
fan drive onto the vehicle. If the problem is not corrected, the
fan drive will fail prematurely.
CAUTION
Clutch reassembly
CAUTION
15

© 2021 Horton Holding, Inc. Todos los derechos reservados.
Nuestro compromiso: soluciones de  ujo de aire
Horton®es el proveedor líder a nivel mundial de soluciones de
refrigeración de motores. Nuestra cultura de innovación logra productos
duraderos de alto rendimiento y servicios que le ayudan a cumplir con sus
compromisos. Confíe en Horton, sus productos durarán más, funcionarán
de manera mas silenciosa y consumirán menos combustible.
www.hortonww.com
Horton cuenta con las certicaciones IATF 16949, ISO 14001, e ISO 9001.
ESPAÑOL
Introducción 17
Instalación previa 18
Extracción del embrague y de la
cámera de aire 20
Juego menor de sellado 22
 O-rings,sellodesupercieyfusible
térmico System Sentry®22
Conjunto del cartucho 26
Reensamblado del embrague 29
Form #22502-H-0521 ES
16

Lea detenidamente este manual; asegúrese de aplicar todas las
explicaciones. Este manual describe los procedimientos correctos
para inspeccionar, mantener y reparar los embragues de ventilador
tipo S y HT/S. Seguir cuidadosamente las instrucciones proporcio-
nará un funcionamiento seguro y sin problemas.
Horton utiliza los siguientes avisos especiales para advertir sobre
posibles problemas de seguridad que podrían producir heridas de
gravedad y para proporcionar información para prevenir daños al
equipo.
Se utiliza para indicar la presencia de un peligro que podría produ-
cir heridas graves, mortales o daños serios a la propiedad.
Se utiliza para indicar la presencia de un peligro potencial y para
indicar exactamente los procedimientos que deben seguirse para
eliminar o reducir el peligro y para evitar heridas personales graves,
o prevenir futuros problemas de seguridad relacionados con el
vehículo.
Introducción
ADVERTENCIA
PELIGRO
17

Se utiliza para indicar la presencia de un peligro que puede o
podría producir heridas personales leves o daño a la propiedad.
NOTA
Se utiliza para dar sugerencias relacionadas con la operación,
procedimiento o instrucción para el mantenimiento correcto, lo
cual brinda al propietario mayor satisfacción. Una nota también
puede proporcionar información que hará más fácil y más rápido el
mantenimiento.
PRECAUCIÓN
Instalación previa
Se deben seguir las normas de seguridad de la compañía, las cua-
les deben ser iguales o mejores que las normas establecidas por
el gobierno federal o estatal para talleres de reparación. Asegúrese
de entender todas las instrucciones y procedimientos de instalaci-
ón antes de comenzar a trabajar con esta unidad.
18

NOTA
La reparación o cambio de piezas del embrague de ventilador
Horton durante el periodo de garantia, debe ser realizada sólo por
la Fábrica Horton o por un concesionario o distribuidor Horton, a
n de no anular la garantía.
NOTA
En las siguientes secciones un anillo “O” (O ring) se utiliza en el
pistón del disco de fricción si usted ha comprado un kit menor de
sellado. El PolarExtreme kit de sellado contiene un anillo “D” (D
ring) para el pistón del disco de fricción.
19

1. Verique el modelo de embrague y que los repuestos sean
adecuados para el mismo.
2. Desmonte el embrague del motor. Póngalo en un tornillo de
banco y apriételo por el soporte del muñón.
3. Retire los tornillos Torx®de la cámara del aire.
NOTA
Aplicar una pequeña presión de aire a la entrada de aire del em-
brague ayuda a la extracción de la cámara del aire del embrague.
La presión de aire debe aplicarse lentamente para que la cámara
no salte repentinamente y cause heridas graves.
4. Quite la cámara de aire del disco de fricción del pistón.
5. Examine el interior de la cámara para vericar que no haya
indicios de suciedad o materias extrañas. La cámara siempre
debe estar limpia y seca, si no lo está, puede haber una falla
en el sistema del aire del vehículo que debe repararse antes
de reinstalar el embrague.
Extracción del embrague de la
cámera del aire
ADVERTENCIA
20
