Hoselink L330 User manual

Solar Garden Globe | Decorative |
20LED | RADIANCE User Manual
MODEL: L330
MODEL: L330
For more information visit
hoselink.com.au
or call
1300 900 617
Cultivating Connections
youtube.com/hoselink
Cultivating Connections
Solar Garden Globe | Decorative |
20LED | RADIANCE
User ManualUser Manual

Kit Contents
1 x Ground spike 1 x Globe
2 x Extension poles 1 x Pin
When first removed from the box the light will need to be
turned on. This is done using the included pin to activate
the light (A). On the base of the light you will find a sticker
of a blue arrow indicating the location of the pin hole (B).
Insert the pin into the hole, press down to engage power
button and hold for 3 seconds to activate light (C).
The light is now on, and will automatically come on at dusk and
turn off at dawn. Once the light is activated you can remove the
arrow sticker. If you want to fully deactivate the light, Insert the
pin, again pressing down and holding for 3 seconds. The light
will then flash twice indicating it is deactivated.
Product Installation - Option 1
With the ground spike.
STEP 1 Find a suitable location
Solar lights need access to direct sunlight for optimum
results; preferably 6-8 hours per day.
STEP 2 Assemble the ground spike
Assemble the ground spike and extension pole
components by screwing them together, then thread
into the base of the light and push the spike into the
ground. The middle spike component can be removed
to adjust the height as preferred.
Product Installation – Option 2
Using the light as a pendant.
STEP 1 Remove the spike by unscrewing it from the light.
STEP 2 With a screwdriver, remove the screw at the base
of the light.
STEP 3 Flip the light and thread the screw into the inlet
located in the centre of the light.
STEP 4 To hang, tie a knot around the screw using wire or string.
Make sure you hang the light with the top facing up,
otherwise the solar panel will not get charged. The top is
the opposite side to where the spike attaches.
Specifications
NOTE: if the light does not turn on, this could be
due to the battery not being charged. Leave out in
direct sunlight for 6–8 hours and try again.
Solar panel 5.5V / 0.77W
LED Lumens 52
Water Proof Rating IP65
Lithium Battery 800mAh / 3.7V
Light Temperature 3000 k
Charge Time 8 hours
A B C
