Hoshizaki KM-1300SAH User manual

NO: 71191
KM-1300SAH
KM-1300SWH
KM-1300SRH
KM-1300SAH3
KM-1300SWH3
KM-1300SRH3
MODEL
PARTS LIST
HOSHIZAKI
STACKABLE CRESCENT CUBER
ISSUED: SEPT.12,2001
REVISED: FEB.13,2003

2
HA
KM-1300SAH L-0 May2001
M-0 Jan., 2002
M-1 Feb., 2002
M-2 May2002
N-0 Dec., 2002
KM-1300SAH3 L-0 May2001
M-0 Dec., 2001
M-1 Feb., 2002
M-2 July2002
KM-1300SWH L-0 June 2001
M-0 Dec., 2001
M-1 March 2002
M-2 April 2002
M-3 June 2002
N-0 Dec., 2002
KM-1300SWH3 L-0 June 2001
M-0 April 2002
M-1 June 2002
N-0 Dec., 2002
KM-1300SRH L-0 May2001
M-0 Dec., 2001
M-1 April 2002
M-2 May2002
N-0 Dec., 2002
KM-1300SRH3 L-0 May2001
M-0 Dec., 2001
M-1 Feb., 2002
M-2 May2002
N-0 Dec., 2002

3
HA MATERIAL ABBREVIATIONS
ALUMINUM
AL = Aluminum
COPPER
CU = Copper
PLASTIC
ABS = Acrylonitritrile -butadiene - styrene
AC = Polyacetal
EVA = Ethylene vinyl acetate
PA = Polyamide = Nylon
PC = Polycarbonate
PE = Polyethylene
PES = Polyester
PETP = Polyethylene terephthalate = Tetlon
PP = Polypropylene
PS = Polystyrene
PTFE = Polytetrafluoroethylene = Teflon
PUR = Polyurethane
PVC = Polyvinyl chloride
RUBBER
VN = Vinyl Nitrile
EPDM = EP rubber
NBR = Nitrile butadiene rubber
NR = Natural rubber
NP = Neoprene
SI.R = Silicone rubber
SY.R = Syntheticrubber
EPH = Epichlorohydrin
STEEL
GS = Galvanized steel
SS = Stainless steel
PS = Plated steel
PAS = Primed steel
AUXILIARY CODE
Ex.1 K-0Parts are the same as in the preceding (Note) - = Part deleted.
year. x = Part deleted and replaced
"K" is the tenth in alphabetical order with "I" by "o" (interchangeable)
skipped. So, "K" indicates "2000". part.
Ex.2 L-0 o = New part for "x" in the
"L" is the next in alphabetical same auxiliary code.
order. So, "L" indicates "2001".
Ex.3 L-1Each time a part is changed non-interchangeably
in a year, this number advances.

4
HA
KM-1300SAH,KM-1300SAH3 A.ICE CUBERASSEMBLY L-0, M-0, M-1, M-2, N-0

5
HA
MODEL: KM-1300SAH TITLE:A. ICE CUBER ASSEMBLY
INDEX
NO. DESCRIPTION MATERIAL
OR MODEL PART
NUMBER REQUIRED NUMBER
NUMBER L-0 M-0 M-1-
M10267B
M10667E-
M-2
N-0
B REFRIGERATION CIRCUIT - 1A0207A01 1 1 x1
- 1A0207A05 o1 1 1
C WATER CIRCUIT - 105109A04 1 1 1 1 1
D CONTROL BOX ASSEMBLY - 2A2287A01 1 1 1 -
- 2A2522A01 1 1
T2 SCREW Zinc, 4X8 7P31-0408 3 3 3 3 3
E LABEL LOCATION - 2A2227A01 1 1 1 - 1
- 2A2529A01 1 1
1 EVAPORATOR CASE - 1A0603G01 1 1 1 1 1
2 CONTROL BOX COVER GS 3A0174-01 1 1 1 -
GS 3A2386-01 1 1
T2 SCREW Zinc, 4X8 7P31-0408 3 3 3 3 3
3 SQUARE WASHER BRASS 433537-02 1 1 1 1 1
4 SCREW - GROUNDING BRASS 433304-02 1 1 1 1 1
5 BUSHING SR-34-2 420472-05 1 1 1 1 1
6 JUNCTION BOX COVER GS 433410-01 1 1 1 1 1
T2 SCREW Zinc, 4X8 7P31-0408 1 1 1 1 1
7 BULB HOLDER ABS 328919-01 1 1 1 1 1
T2 SCREW SS, 4X16 7P32-0416 2 2 2 2 2
8 SPACER PE 443545-01 1 1 1 2 2
9 BULB HOLDER (C) ABS 216340G01 1 1 1 1 1
TRUSS HEAD SCREW SS, 4X12 7C32-0412 2 2 2 2 2
10 CAPILLARY RING EP RUBBER 425307-01 1 1 1 1 1
11 SPACER ABS 439727-01 1 1 1 1 1
12 BULB HOLDER (D) GS 328742-01 1 1 1 1 1

6
HA
MODEL: KM-1300SAH TITLE:A. ICE CUBER ASSEMBLY
INDEX
NO. DESCRIPTION MATERIAL
OR MODEL PART
NUMBER REQUIRED NUMBER
NUMBER L-0 M-0 M-1 M-2 N-0
13 FRONT PANEL - BRACKET SS 323903-01 1 1 1 1 1
T2 SCREW SS 7P32-0412 3 3 3 3 3
14 SPACER ABS 324321-01 1 1 1 1 1
15 TOP INSULATION ABS, PE 324216G01 1 1 1 1 1
16 FRONT INSULATION ABS, PE 324215G01 1 1 1 1 1
17 THUMBSCREW ABS, SS 415949G01 1 1 1 1 1
18 SIDE PANEL (R) SS 2A2226G01 1 1 1 1 1
19 TOP PANEL - 2A2255-01 1 1 1 1 1
TRUSS HEAD SCREW SS, 4X8 7C32-0408 3 3 3 3 3
20 LOUVER B ABS 1A0548-01 4 4 4 4 4
21 PUSH RETAINER - 4A2414-01 12 12 12 12 12
22 FRONT PANEL (A) SS 2A2224-02 1 1 1 1 1
TRUSS HEAD SCREW SS, 4X16 7C32-0416 2 2 2 2 2
23 AIR FILTER B - 2A2063G01 4 4 4 4 4
24 GASKET L=1219 4A0808L02 1 1 1 1 1

7
HA
MODEL: KM-1300SAH3 TITLE:A. ICE CUBER ASSEMBLY
INDEX
NO. DESCRIPTION MATERIAL
OR MODEL PART
NUMBER REQUIRED NUMBER
NUMBER L-0 M-0 M-1 M-2 N-0
B REFRIGERATION CIRCUIT - 1A0207A02 1 1 x1
- 1A0207A06 o1 1 1
C WATER CIRCUIT - 105109A04 1 1 1 1 1
D CONTROL BOX ASSEMBLY - 2A1122A03 1 1 1 -
- 2A2527A01 1 1
T2 SCREW Zinc, 4X8 7P31-0408 3 3 3 3 3
E LABEL LOCATION - 2A1049A02 1 1 1 -
- 2A2529A02 1 1
FTRANSFORMER BOX ASSEMBLY - 3A1102A01 1 1 1 1 1
HEX HEAD BOLT W/WASHER 5X10 7B0130510 4 4 4 4 4
1 EVAPORATOR CASE - 1A0603G01 1 1 1 1 1
2 CONTROL BOX COVER GS 3A0174-01 1 1 1 -
GS 3A2386-01 1 1
T2 SCREW Zinc, 4X8 7P31-0408 3 3 3 3 3
3 SQUARE WASHER BRASS 433537-02 1 1 1 1 1
4 SCREW - GROUNDING BRASS 433304-02 1 1 1 1 1
5 BUSHING SR-34-2 420472-05 1 1 1 1 1
6 JUNCTION BOX COVER GS 433410-01 1 1 1 1 1
T2 SCREW Zinc, 4X8 7P31-0408 1 1 1 1 1
7 BULB HOLDER ABS 328919-01 1 1 1 1 1
8 SPACER PE 443545-01 1 1 1 2 2
9 BULB HOLDER (C) ABS 216340G01 1 1 1 1 1
TRUSS HEAD SCREW SS, 4X12 7C32-0412 2 2 2 2 2
10 CAPILLARY RING EP RUBBER 425307-01 1 1 1 1 1
11 SPACER ABS 439727-01 1 1 1 1 1
12 BULB HOLDER (D) GS 328742-01 1 1 1 1 1
T2 SCREW SS, 4X16 7P32-0416 2 2 2 2 2

8
HA
MODEL: KM-1300SAH3 TITLE:A. ICE CUBER ASSEMBLY
INDEX
NO. DESCRIPTION MATERIAL
OR MODEL PART
NUMBER REQUIRED NUMBER
NUMBER L-0 M-0 M-1 M-2 N-0
13 FRONT PANEL - BRACKET SS 323903-01 1 1 1 1 1
T2 SCREW SS 7P32-0412 3 3 3 3 3
14 SPACER ABS 324321-01 1 1 1 1 1
15 TOP INSULATION ABS, PE 324216G01 1 1 1 1 1
16 FRONT INSULATION ABS, PE 324215G01 1 1 1 1 1
17 THUMBSCREW ABS, SS 415949G01 1 1 1 1 1
18 SIDE PANEL (R) SS 2A2226G01 1 1 1 1 1
19 TOP PANEL - 2A2255-01 1 1 1 1 1
TRUSS HEAD SCREW SS, 4X8 7C32-0408 3 3 3 3 3
20 LOUVER B ABS 1A0548-01 4 4 4 4 4
21 PUSH RETAINER - 4A2414-01 12 12 12 12 12
22 FRONT PANEL (A) SS 2A2224-02 1 1 1 1 1
TRUSS HEAD SCREW SS, 4X16 7C32-0416 2 2 2 2 2
23 AIR FILTER B - 2A2063G01 4 4 4 4 4
24 GASKET L=1219 4A0808L02 1 1 1 1 1

9
HA
KM-1300SWH, KM-1300SWH3 A. ICE CUBER ASSEMBLY L-0, M-0, M-1, M-2, M-3, N-0

10
HA
MODEL: KM-1300SWH TITLE:A. ICE CUBER ASSEMBLY
INDEX
NO. DESCRIPTION MATERIAL
OR MODEL PART
NUMBER REQUIRED NUMBER
NUMBER L-0 M-0 M-1 M-2 M-3 N-0
B REFRIGERATION CIRCUIT - 1A0259A01 1 1 x1
- 1A0259A04 o1 -
- 1A0682A01 1 1 1
C WATER CIRCUIT - 105109A04 1 1 1 1 1 1
D CONTROL BOX ASSEMBLY - 2A2287A01 1 1 1 1 -
- 2A2552A01 1 1
T2 SCREW 4X8 7P31-0408 3 3 3 3 3 3
E LABEL LOCATION - 2A2228A01 1 1 1 -
- 2A2228A03 1 -
- 2A2530A01 1 1
1 EVAPORATOR CASE - 1A0603G02 1 1 1 -
- 1A0603G09 1 1 1
2 CONTROL BOX COVER GS 3A0174-01 1 1 1 1 -
GS 3A2386-01 1 1
T2 SCREW 4X8 7P31-0408 3 3 3 3 3 3
3 SQUARE WASHER BRASS 433537-02 1 1 1 1 1 1
4 SCREW - GROUNDING BRASS 433304-02 1 1 1 1 1 1
5 BUSHING SR-30-1 420472-05 1 1 1 1 1 1
6 JUNCTION BOX COVER GS 433410-01 1 1 1 1 1 1
T2 SCREW 4X8 7P31-0408 1 1 1 1 1 1
7 BULB HOLDER ABS 328919-01 1 1 1 1 1 1
T2 SCREW 4X16, SS 7P32-0416 2 2 2 2 2 2
8 SPACER PE 443545-01 1 1 1 1 2 2
9 BULB HOLDER (C) ABS 216340G01 1 1 1 1 1 1
TRUSS HEAD SCREW 4X12, SS 7C32-0412 2 2 2 2 2 2
10 CAPILLARY RING EP RUBBER 425307-01 1 1 1 1 1 1
11 SPACER ABS 439727-01 1 1 1 1 1 1
12 BULB HOLDER (D) GS 328742-01 1 1 1 1 1 1
