Product Instruction Manual
DC TO AC Power Inverter
TO REDUCE THE RISK OF INJURY, USER MUST READ AND UNDERSTAND THIS INSTRUCTION MANUAL.

THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING THE OPERATION AND WARRANTY
OF THIS PRODUCT. PLEASE RETAIN FOR FURTURE REFERENCE.
TABLE OF CONTENTS
1. Important Safety Information
2. Introduction
3. Installation Guidelines
4. Using the inverter
5. Trouble shooting
6. Specifications

1. Important Safety Information
Incorrect installation or misuse of the inverter may result in danger to the user or hazardous
conditions. We urge you to pay special attention to all CAUTION and WARNING statements. CAUTION
statements identify conditions or practices that may result in damage to other equipment. WARNING
statements identify conditions that may result in personal injury or loss of life.
WARNING! Shock hazard. Keep away from children.
The inverter generates the same potentially lethal AC power as a normal household wall outlet.
Treat it with the same respect that you would like AC outlet.
Do not insert foreign objects into the inverter’s AC outlet, fan or vent openings.
Do not expose the inverter to water, rain, snow or spray.
Do not under any circumstances, connect the inverter to utility power AC distribution wiring.
WARNING! Heated surface.
The inverter’s housing may become uncomfortably warm, reaching 140℉(60℃)under extended
high power operation. Ensure at least 2 inches (5cm) of air space is maintained on all sides of the
inverter. During operation, keep away from materials that may be affected by high temperatures.
WARNING! Explosion hazard.
Do not use the inverter in the presence of flammable fumes or gases, such as in the bilge of a
gasoline powered boat, or near propane tanks. Do not use the inverter in an enclosure containing
automotive-type, lead-acid batteries. These batteries, unlike sealed batteries, vent explosive
hydrogen gas, which can be ignited by sparks from electrical connections.
When working on electrical equipment always ensure someone is nearby to help you in an
emergency.
CAUTION!
Do not connect live AC power to the inverter’s AC outlets. The inverter will be damaged even if it is
switched OFF.
Do not connect any AC load, which has its neutral conductor connected to ground, to the inverter.
Do not expose the inverter to temperatures exceeding 104℉(40℃).
CAUTION! Do not use inverter with the following equipment.
Small battery operated product such as rechargeable flashlights, some rechargeable shavers, and
night-lights that are plugged directly into and ac receptacle to recharge.
Certain battery chargers for battery packs used in hand powered tools. These chargers will have
warning labels stating that dangerous voltages are present at the charger’s battery terminals.
Connect inverter only to batteries with a 12V DC nominal output. A battery with 6V nominal output
will not supply enough voltage and a battery with 36V/48V nominal output will DAMAGE THE
INVERTER.

2. Introduction
Thank you for purchasing the power inverter. The inverter is a compact and highly portable power
inverter, the leader in the field of high frequency inverter design. From the 12V DC outlet in your vehicle
or boat, or directly from a dedicated 12V DC battery, or the solar power bank,
the inverter will efficiently and reliably power a wide variety of household AC products, such as TVs,
computers, VCRs, and includes automatic safety monitoring circuitry to protect the inverter, and your
battery, from inadvertent overload conditions.
Read this guide before installing or using the inverter and save it for future reference.
Safety Features
These advanced safety features are built into the inverter:
Electronic overload protection with automatic shutdown.
Built-in internal backup DC fuse provides added safety.
Low battery voltage protection with automatic shutdown.
Over temperature protection with automatic shutdown.
Output short circuit protection.
3. Installation Guidelines
Selecting a Suitable Location
For safe and optimum performance, install the inverter in a location that is …..
Dry. Do not expose to water drip or spray.
Cool. Operate only in ambient temperatures between 32℉(0℃)and 104℉(40℃). Keep away from
furnace heating vents or other heat producing equipment.
Well ventilated. Allow at least 2 inches (5cm) clearance above and on all sides of the unit for proper
cooling.
Safe. Do not install inverter in a compartment with batteries or
flammable liquids, such as gasoline, or explosive vapors.
Clean and free of dust and dirt. This is especially important if the inverter is used in a work
environment.
Using the DC Cable-Ring terminal
Due to limitations in the common 12V DC outlet in a vehicle or boat, the inverter should only be used to
supply AC power to products that require the rated continuous power or less. If your application requires
more than the rated power (but less than the rated continuous power) or has a high start-up surge, see
using the DC Cable-Clips.
1. Attach the ring type connector marked with red to the positive (+) DC terminal on the inverter and
attach the ring connector marked with black to the negative (-) DC terminal.
CAUTION! A reverse polarity connection (positive to negative) may damage the inverter. Damage
caused by a reverse polarity connection is not covered under warranty.
2. Tighten the nut on each DC terminal by hand until it is snug. Do not over tighten.
3. Insert the plug of this cable into the 12V DC outlet and switch the unit ON. See Section 4 if the
inverter does not operate properly after being connect.
4. When the inverter is not in use, unplug it from the 12V DC outlet to prevent slight discharge of the
Battery.

Using the Dc cable-Clips
By directly connecting the inverter to a 12V DC battery with DC Cable-Clips, you can operate products
with power requirements up to rated continuous output power. If you want to permanently connect the
inverter to a battery, please use Ring Terminals.
1. Follow steps 1 and 2 above (Using the DC Cable-Ring Terminal) to attach the ring type connectors.
2. Attach the black negative clip to negative (-) battery terminal.
3. Attach the red positive clip to the positive (+) battery terminal. Make sure both clips are securely
connected to the battery terminals, as a loose connection will cause excessive voltage drop and may
cause the cables to overheat resulting in equipment damage or fire.
4. Switch the inverter ON. See section 4 if the inverter does not operate properly after being connected.
5. When the inverter is not in use, disconnect the DC Cable-Clips from the battery.
4. Using the inverter
The inverter is capable of continuously powering most 120V AC products that use the rated
continuous output power or less. Its AC output waveform, called ”modified sine wave “ is designed to
function as wave shape of utility power.
The power, or “wattage”, rating of ac products is the average power they use. When many AC
products are first switched on, they initially consume more power than their power rating. TVs, monitors,
and electric motors are examples of products that have high “surge” requirements at start up. Although
the inverter can supply momentary surge power as high as surge power, occasionally some products
rated less than the rated continuous output power may exceed its surge capabilities and trigger its safety
overload shutdown feature. If this problem occurs when attempting to operate several AC products at the
same time ,try first switching on inverter with all AC products switched off ,then one by one switch each
on, starting with the high surge product first.
Indicators and Controls (See Figure 1)
The AC outlets are provided on one end of the inverter. Any combination of 120V AC product with a
total continuous power consumption of the continuous power or less may be plugged in.
The ON/OFF switch enables output AC power at the AC outlets when switched ON.
The green POWER light indicates AC power is present at the AC outlets and the inverter is operating
normally.
The red FAULT light indicates inverter shutdown caused by low or high voltage, overload or
excessive temperature.
Inverter operation
1. When properly connected to a 12V DC outlet or battery, turning the ON/OFF switch ON, will
illuminate the green POWER light, and AC power to the outlets.
2. Plug the AC product(s) you wish to operate onto the AC outlet(s) and switch them on, one at a time.
3. As the battery capacity is used up, battery voltage begins to fall. When the inverter senses that the
voltage at its DC input has dropped to 9.7~10.7V(19.4-21.4V), and audible alarm sounds. This allows
time for computers or other sensitive devices to be shut down.
4. If the audible alarm is ignored the inverter will automatically shut down when the battery voltage
drops to 9~10V(18-20V). This prevents battery damage from excessive discharge. After auto shut
down, the red FAULT light illuminates.

IMPORTANT: Vehicle batteries are designed to provide short periods of very high current needed
for engine starting. They are not intended for constant deep discharge. Regularly operating the
inverter shortens the life of the battery. Consider connecting the inverter to a separate deep
discharge type battery if you will be frequently running electrical products for long time.
5. If an AC product rated higher than the rated continuous power (or which draws excessive surge
power) is connected, the inverter will shut down .The red FAULT light will turn on.
6. If the inverter exceeds a safe operating temperature, due to insufficient ventilation or a high
temperature environment, it will automatically shut down. The red FAULT light will turn on and the audio
warning will sound.
7. Should a defective battery charging system cause the battery voltage to rise to dangerously high
levels, the inverter automatically shuts down.
CAUTION! Although the inverter incorporates protection against over-voltage, it may still be
damaged if the input voltage exceeds 16 volts.
8. The cooling fan is designed to operate only when the temperature is higher than 40℃.
9. In the event of an overload, low battery voltage or overheating, the inverter will automatically shut
down (See Section 4).
Battery Operating Time
Operating time will vary depending on the charge level of the battery, its capacity and the power level
drawn by the particular AC load.
When using the battery of the vehicle as a power source, it is strongly recommended to start the
vehicle every hour or two to recharge the battery before its capacity drops too low. The inverter can
operate while the engine is running, but the normal voltage drop that occurs during starting may trigger
the inverter’s low voltage shut down feature.
Because the inverter draws less than the no-load current draw with the ON/OFF switch in ON position
and with no AC products connected, it has minimal impact on battery operating times.
Interference with Electronic Equipment
Generally, most AC products operate with the inverter just as they would with household AC power.
Below is information concerning two possible exceptions.
Buzzing Sound in Audio Systems and Radios
Some inexpensive stereo systems, “boom boxes”, and AM-FM radios have inadequate internal power
supply filtering and “buzz” slightly when powered by the inverter. Generally, the only solution is an audio
product with a higher quality filter.
Television Interference
The inverter is shielded to minimize its interference with TV signal. However, with weak TV signals
interference may be visible in the form of lines scrolling across the screen. The following should minimize

or eliminate the problem:
Use an extension cord to increase the distance between the inverter and the TV, antenna and
cables.
Adjust the orientation of the inverter, television, antenna and cables.
Maximize TV signal strength by using a better antenna and use shielded antenna cable where
possible.
Try a different TV. Different models of televisions vary considerably in their susceptibility to inverter.
5. Troubleshooting
PROBLEM: AC product will not operate
Possible Cause
Suggested solution
Battery is defective.
Check battery and replace if
required.
Inverter has been connected
with reverse DC input polarity.
Check connection to battery. Probable inverter damage
has occurred. Have unit repaired(not covered by warranty)
Loose cable connections.
Check cables and connections. Tightens required
PROBLEM: Inverter will run some small loads, but not large ones.
Possible Cause
Suggested solution
Voltage drop across DC cables.
Shorten cables or use heavier cables.
PROBLEM: Measured inverter output is too low.
Possible Cause
Suggested solution
Standard ”average-reading” AC
voltmeter used to measure
output voltage, resulting in an
apparent reading 5 to 15 volts
too low.
Inverter’s “modified sine wave” output requires “true RM”
voltmeter, such as Fluke 87 series millimeters for accurate
measurement.
Battery voltage is too low.
Recharge battery.
PROBLEM: Alarm is sounding.
Possible Cause
Suggested solution
Low voltage shut down or
thermal shutdown has
occurred.
Shorten cables or use heavier cables. Recharge battery.
Allow unit to cool. Improve air circulation around unit.
Reduce load if continuous operation is required.
PROBLEM: Battery run time is less than expected.
Possible Cause
Suggested solution
AC product power consumption
is higher than rate.
Use a larger battery to make up for increased power
requirement
Battery is old or defective
Replace battery

Battery is not being properly
charged.
Many simple charges are unable to charge a battery fully.
Replace charger with better model such a TRUE
CHARGE smart charger.
Power dissipation in DC cables.
Use shorter/heavier DC cables.
PROBLEM: AC product will not operate, red FAULT light ON.
Possible Cause
Suggested solution
AC product(s) connected are
rated at more than the rated
continuous output power:
overload shutdown has
occurred.
Use product with a power rating less than the rated
continuous output power.
AC product is rated less than
rated continuous output power:
high starting surge has caused
overload shutdown.
Product exceeds inverter’s surge
capability. Use a product with starting surge power within
the inverter’s capability.
Battery is discharged (alarm is
sounding).
Recharge Battery.
Inverter has overheated due to
poor ventilation and has
caused over temperature
shutdown.
Switch inverter OFF and allow to cool for 15 minutes.
Clear blocked fan or remove objects covering unit. Locate
unit to a cooler environment. Reduce load if continuous
operation is required. Restart. Verify charging system is
properly regulated and battery is 12VDC nominal.
6. Specifications
AC output voltage (nominal):120V AC
DC input voltage range:
Nominal 12V:10V-15V
AC output frequency:60Hz±2Hz
AC output waveform: modified sine wave
Ambient operating temperature range:
12℉-130℉/-20℃-65℃
Low battery alarm trigger range:
Nominal 12V:9.7V-10.7V
Low battery shut down range:
Nominal 12V:9V-10V
High battery shut down range (nominal):15V
Specification subject to change without notice
Note: Please refer to the input voltage of the inverter panel to get the related protection data from the
instruction manual.
