Host Host0902pm User manual

Planetary Mixer

Instruction manual

Model:

HOST0902PM

HOST0903PM

HOST0904PM

Read this instruction

manual carefully

before use

HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 1HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 1 2022/8/17 17:36:082022/8/17 17:36:08

Safety Instructions

THE PLANETARY MIXER IS A DANGEROUS APPLIANCE

AND MUST ONLY BE USED BY TRAINED PERSONNEL IN

ACCORDANCE WITH THESE INSTRUCTIONS.

• Position on a flat, stable surface.

• A service agent/qualified technician should carry out

installation and any repairs if required. Do not remove any

components on this product.

• Consult Local and National Standards to comply with the

following:

- Health and Safety at Work Legislation

- BS EN Codes of Practice

- Fire Precautions

- IEE Wiring Regulations

- Building Regulations

• Always stand BEHIND the safety guard when operating the

appliance.

• DO NOT place hands near the rotating attachments when in

use. This can result in severe injury.

• DO NOT remove food from the appliance until the mixing

attachments have come to a complete stop.

• DO NOT immerse the appliance in water.

• DO NOT attempt to mix items that this machine is not

designed for. This can damage the mixing attachments.

• DO NOT use with a damaged mixing attachment.

• DO NOT bypass the safety interlocks.

• Always switch off and disconnect the power supply to the

appliance when not in use.

• NEVER leave the appliance unattended when in use.

• The appliance is heavy. Take care when moving.

• This appliance must only be used in accordance with these

instructions and by persons competent to do so.

HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 2HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 2 2022/8/17 17:36:082022/8/17 17:36:08

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

• Keep all packaging away from children. Dispose of the

packaging in accordance to the regulations of local authorities.

• If the power cord is damaged, it must be replaced by a

recommended qualified technician in order to avoid a hazard.

• Never use accessories which are not recommended by the

manufacturer. They could pose a safety risk to the user and

might damage the appliance. Only use original parts and

accessories.

• HOST

recommend that this appliance should be periodically

tested (at least annually) by a Competent Person. Testing

should include, but not be limited to: Visual Inspection, Polarity

Test, Earth Continuity, Insulation Continuity and Functional

Testing.

• HOST recommend that this product is connected to a circuit

protected by an appropriate RCD (Residual Current Device).

Introduction

The HOST Planetary Mixer has been designed to mix a range of foodstuffs, varying from cream to dough.

Please take a few moments to carefully read through this manual. Correct maintenance and operation of

this machine will provide the best possible performance from your HOST product.

HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 3HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 3 2022/8/17 17:36:082022/8/17 17:36:08

Installation

• Ensure the location of the Planetary Mixer is capable of supporting its weight.

WARNING: The Planetary Mixer is very heavy, care

must be taken when moving it.

• If the appliance is intended to be positioned on a

worktop, please ensure it is secured in position

(for HOST0902PM, HOST0903PM).

Floor Standing only with mixer HOST0904PM! Do

not place it on any worktop due to its heavy weight.

In addition, it may vibrate intensely on the worktop

during use, fall from it and result in personal/property

damage.

HOST0904PM

Assembly

WARNING: The bowl must be attached and raised into position prior to starting the Planetary

Mixer.

• HOST accept no responsibility for any injury caused by incorrect assembly of this appliance.

Note: Ensure the feet are level to reduce vibration during operation.

• Remove the appliance from all packaging.

How to install the rubber feet

1. Remove all packaging from the appliance.

2. Remove the wooden pallet from the machine (Loosen

the four bolts at the bottom of the wooden pallet).

3. Take out the rubber feet from the bowl

4. Add the rubber feet to the feet of the machine.

Note: A minimum of two people should be used to

install the rubber feet.

Note: Once the rubber feet have been installed,

ensure the machine is stable.

Rubber feet

HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 4HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 4 2022/8/17 17:36:082022/8/17 17:36:08

The type of rubber feet

Rubber feet

Remove all packaging from the appliance.

Remove the wooden pallet from the machine

(Loosen the four bolts at the bottom of the

wooden pallet).

Take out the rubber feet from the bowl

Add the rubber feet to the feet of the machine.

Note: A minimum of two people should

Note: Once the rubber feet have been installed, ensure the machine is stable.

be used to install the rubber feet.

Fitting/Removing the Bowl

1. Turn Off the appliance.

2. Open the safety guard by turning it to the left

(HOST0902PM & HOST0903PM) or lifting it above the

mixer (HOST0904PM).

3. Lower the bowl with the bowl handle.

4. Release the locking catches either side of the bowl.

5. Lift the bowl. The bowl is held in place by two pins

securing the handles to the cradle and a hole at the

back of the appliance which houses the lug on the

bowl lip.

6. Reverse the procedure to fit the bowl.

Note: Ensure the handle is fully pushed back and the

bowl is completely raised or the mixer will not work.

Note: Regularly grease the bowl lift mechanism to

ensure smooth operation.

Bowl handle

Locking catchSecuring pins

HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 5HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 5 2022/8/17 17:36:092022/8/17 17:36:09

Changing the Mixer Attachment

1. Turn Off the appliance.

2. Open the safety guard by turning it to the left (HOST0902PM & HOST0903PM) or lifting it above the

mixer (HOST0904PM).

3. Lower the bowl with the bowl handle.

4. Push the mixer attachment up and to the left to release it.

5. Insert the desired attachment. Push up and to the right to lock it into place.

6. Raise the bowl.

HOST recommend the following uses for each attachment:

Spiral Dough

hook Heavy mixes dough, pie pastry etc. Suitable Gears: 1 Slow

Beater Firm mixes light pastry, cake/biscuit mix,

icings, fillings and mashed vegetables Suitable Gears: 1, 2 Medium

Whisk Light mixes whipped cream, mayonnaise,

egg whites, pancakes and soufflés Suitable Gears: 1, 2, 3 Fast

Layout of Controls

Gear lever

START button

STOP button

START button - Press to start the mixer.

STOP button - Press to stop the mixer. Twist clockwise to release and reset (HOST0904PM only).

GEAR LEVER - Use to adjust the speed of the mixer.

HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 6HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 6 2022/8/17 17:36:092022/8/17 17:36:09

Operation

• Note: Ensure that these instructions have been read thoroughly and the operation of the

appliance is fully understood before use.

• All personnel must be fully trained on the operation and safety precautions of the Planetary

Mixer.

Mixing

WARNING: Always ensure the appliance is turned off before placing hands in the mixing bowl.

1. Open the safety guard.

2. Fill the bowl.

3. Select the desired speed and close the guard.

• Note: HOST recommend that you start with the slowest speed and increase the speed

gradually as necessary.

• Ensure the safety guard is fully closed or the mixer will not work.

4. Press the START button to begin mixing.

Note: If the appliance is straining to mix then turn the appliance Off and remove some of the

contents of the bowl before restarting.

Mixing Capacity

Model Bowl Volume Max Flour Max Dough

HOST0902PM 9L 2kg 3.2kg

HOST0903PM 20L 5kg 8kg

HOST0904PM 29L 7.5kg 11.3kg

Changing Mixing Speed

Note: ALWAYS stop the mixer before attempting to change the mixing speed.

With the appliance turned Off:

1. Select the required gear using the gear change lever.

2. Restart the appliance.

HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 7HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 7 2022/8/17 17:36:092022/8/17 17:36:09

Overload Switch

The Overload switch is situated at the back of the machine

beside the cable entry (Note for HOST0902PM: The

Overload switch is on the base).

If the appliance becomes too hot the Overload switch will

stop the machine automatically. If this happens:

1. Turn Off the mixer.

2. Reduce the load in the mixing bowl.

3. Push the Overload switch back in to reset it.

4. Allow the appliance to cool for 20 minutes.

Overload

switch

Note:

• In the event of a power cut the Overload switch will cut in to prevent the appliance from

restarting automatically when power is restored.

• Always disconnect the Planetary Mixer from the mains powers supply when not in use.

Cleaning, Care & Maintenance

• Always turn off the mixer and disconnect from the power supply before cleaning.

• Use warm soapy water to clean the bowl and mixing attachments. Do not use abrasive cleaning

chemicals as these can leave harmful residues.

• Clean the exterior of the appliance with a damp cloth.

• Dry all parts thoroughly after cleaning.

• Do not use jet/pressure washers to clean the appliance.

• Clean the appliance regularly.

Troubleshooting

A qualified technician must carry out repairs if required.

Fault Probable Cause Solution

The appliance is

not working

The unit is not switched on Check the unit is plugged in correctly and

switched on

Plug or lead is damaged Replace plug or lead

Fuse in the plug has blown Replace the fuse

Mains power supply fault Check mains power supply

The Stop button not released

(HOST0904PM)

Turn button clockwise to release

The overload switch has activated See overload switch information in the

Operation section of this manual

Safety Guard not closed Close Safety Guard fully

Appliance not in gear Put in gear

Bowl not fully raised Ensure the Bowl lever is pushed back fully

HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 8HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 8 2022/8/17 17:36:092022/8/17 17:36:09

Fault Probable Cause Solution

Bowl will not fit

back in to place

Bowl pins or surrounding area

clogged with mix

Clean the appliance

The appliance is

overheating

The mixing bowl is overloaded Turn off the appliance and empty some of the

contents

The appliance has been operating

for too long

Turn off the appliance and allow to cool down

for 30 minutes

The appliance is

noisy

Bowl or mixing attachment not

correctly fitted

Remove and refit bowl/mixing attachment

Worn bearings/damaged gears Consult a qualified technician

Grease has dried up in the

gearbox

Consult a qualified technician

The mixing

attachment fails to

rotate properly

The belt has become loose Consult a qualified technician

Cannot select gear Gearing cogs misaligned Turn Off appliance and manually turn the whisk

attachment slightly. Select the gear again

Service

Should your appliance have a fault, please visit the Service section of the HOST website.

Technical Specifications

Model Voltage Power Current Dimensions

(H x W x D) (mm)

Weight

(kg)

Bowl

Volume

HOST0902PM 220-240V 50Hz 550W 1.8A 610 x 395 x 395 36 9L

HOST0903PM 220-240V 50Hz 1100W 4.7A 794 x 555 x 558 64 20L

HOST0904PM 220-240V 50Hz 1500W 6.5A 1142 x 579 × 611 160 29L

Due to our continuing program of research and development, the specifications herein are subject to

change without notice.

HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 9HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 9 2022/8/17 17:36:092022/8/17 17:36:09

Electrical Wiring (HOST0902PM / HOST0903PM)

The appliance is supplied with a 3 pin BS1363 plug and lead.

The plug is to be connected to a suitable mains socket.

The appliance is wired as follows:

• Live wire (coloured brown) to terminal marked L

• Neutral wire (coloured blue) to terminal marked N

• Earth wire (coloured green/yellow) to terminal marked E

This appliance must be earthed.

If in doubt consult a qualified electrician.

Electrical isolation points must be kept clear of any obstructions. In the event of any emergency

disconnection being required they must be readily accessible.

Electrical Wiring (HOST0904PM)

This appliance is supplied unplugged and requires hardwiring to a suitable electrical power supply with a

16 amp rated fuse.

This appliance is wired as follows:

• Live wire (coloured brown) to terminal marked L

• Neutral wire (coloured blue) to terminal marked N

• Earth wire (coloured green/yellow) to terminal marked E

This appliance must be earthed.

If in doubt consult a qualified electrician.

Electrical isolation points must be kept clear of any obstructions. In the event of any emergency

disconnection being required they must be readily accessible.

Connection to a suitable power supply should only be carried out by a qualified and competent

electrical engineer.

Compliance

The WEEE logo on this product or its documentation indicates that the product must not

be disposed of as household waste. To help prevent possible harm to human health and/

or the environment, the product must be disposed of in an approved and environmentally

safe recycling process. For further information on how to dispose of this product correctly,

contact the product supplier, or the local authority responsible for waste disposal in your

area.

HOST parts have undergone strict product testing in order to comply with regulatory

standards and specifications set by international, independent, and federal authorities.

photocopying, recording or otherwise, without the prior written permission of HOST.

Every effort is made to ensure all details are correct at the time of going to press, however, HOST reserve the right to change specifications

without notice.

HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 10HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 10 2022/8/17 17:36:092022/8/17 17:36:09

We {Host} of {Host House, Chepstow, NP16 6UP} hereby declare that the equipment is in conformity with the requirements of the

following Regulations:

Supply of Machinery (Safety) Regulations 2008

Electromagnetic Compatibility Regulations 2016

The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012

We hereby declare that:

Equipment Model number HOST0902PM 9 Ltr Planetary Mixer

HOST0903PM 20 Ltr Planetary Mixer

HOST0904PM 29 Ltr Planetary Mixer

is in conformity with the applicable requirements of the following documents

Ref. No.

Edition/date

BS EN 454

2014

BS EN 60204-1

2018

BS EN ISO 12100

2010

BS EN 55014-1

2017

BS EN 55014-2

2015

BS EN IEC 61000-3-2

2019

BS EN 61000-3-3

2013 +A1:2019

I hereby declare that the equipment named above has been designed to comply with the relevant sections of the above referenced

specifications and is in accordance with the requirements of the Regulations:

Signed by:

Full Name Jess Attree

Title: General Manager

Location: Chepstow, Great Britain

Date: 16th June 2022

UKCA Declaration of Conformity

DocuSign Envelope ID: DA4256D2-A1DE-4750-BC23-AF75CB542431

HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 11HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 11 2022/8/17 17:36:102022/8/17 17:36:10

HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_2022/08/17

www.host-appliances.com

HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 12HOST0902PM_HOST0903PM_HOST0904PM_EN_A5_v1_20220817.indb 12 2022/8/17 17:36:102022/8/17 17:36:10

This manual suits for next models

Table of contents
