HOTOWELL HTW-MT06 Series User manual

Programmable Multi-Stage Smart Thermostat
Reference No.: HTW-MT06 Series
- 1 - Version 2020-1.0
Installation and Operation Manual
Max. 2H2C conventional System or Max. 3H/2C Heap Pump System
5+1+1 weekly Pro rammable, smart wifi application
****************************************************
This thermostat is compatible with the following systems:
• Gas, oil, Propane or electric furnace
• entral air conditioner
• Geo Thermal / Hot water system with or without pump
• Heat only/ ool only/Auto/Emer/Off modes configurable
• entral heating and cooling system
• Heat pump with auxiliary/backup heat
• Forced Air / In-Floor Radiant / Radiator system
Power Supply
AC/DC24V±10%
Terminal Load
1.0A(Inductive) per terminal, 3.0A ( esistance) per terminal
Set Point Temp. Ran e
42ºF to 122ºF (5ºC to 50ºC).
Accuracy
+/- 1ºF or +/- 0.5ºC.
Dimensions
4.33” L*4.33‘’ W* 1‘’ D /110x110x25.5mm
Color
White/Black/S.S Brush panel optional
Installation Hole Distance Wall Mounted or 2.36”/62±5mm(Europe,China,Japan) or
3.37”/86±3mm(USA, Italy)
Wire Diameter for Terminals 2*1.5mm
² or 1*2.5mm ²
Identify System Type
Features
Specification
SAVE ABOUT 25% ON HVA ENERGY
Save
money without compromising your comfort with features like flexible
weekly programmable scheduling and remote WiFi control.
EASY TO ONNE T TO WIFI
Easy guide in the manual to connect to WiFi
FLEXIBLE MOUNTED TYPE
Wall Mounted or 2.36”/62±5mm(Europe, hina,Japan) or 3.37”/86±3mm(USA,
Italy), easy to install.
SMART HOME OMPATIBLE
ompatible with smart home platforms Amazon Alexa, the Google Assista
nt,
Tuya Smart Life.
SAVE ABOUT 25% ON HVA ENERGY
Permanent Hold/Temporary Hold/Using Programming Schedule/Hold Until
Menu.
MULTIPLY THERMOSTAT ONTROL
Easy management for schools and light commercial applications.
Smart Scene/Group ontrol available.
OTHER FEATURES
 Device Sharing, Languages/Time synchronizes according to time zone.
 ºF or º configurable.
 Negative Black Screen, black lightness configurable.
 Fan switch ON and AUTO onfigurable.
 Air Filter change Indicator, Temperature calibration.
 Touch Screen Keypad, Easy operation friendly.
 Built-in compressor protection.

Programmable Multi-Stage Smart Thermostat
Reference No.: HTW-MT06 Series
- 2 - Version 2020-1.0
Display
Dimensions

Programmable Multi-Stage Smart Thermostat
Reference No.: HTW-MT06 Series
- 3 - Version 2020-1.0
Tip: Taking a picture with a camera or smartphone can help you not only remember how wires are connected to the
terminals, but can also ensure that you label your wires correctly.
Remove Old Thermostat
1.Turn Off the Power
or
To ensure the power to your heating and cooling system has been turned off, try to turn on heating or cooling by changing the
temperature on your old thermostat
2. Remove the old thermostat cover
Remove the old thermostat’s front cover from the wall base. Some covers pull off easily, while others may need to be
removed by prying the cover off with a screwdriver.
3. Label wires
Using your screwdriver, carefully unscrew one wire at a time from the terminal block and attach the corresponding wire label
sticker.
Please note that not all terminals may be used, and that there’s no standard color code for thermostat wires, so your wire
colors may vary.
For your reference, we’ve included a terminal label reference chart as below to help you connect the wires in your old
thermostat to your new thermostat in case you get stuck.
Terminal labeling reference chart
If your current terminal has the followin letter Label the wires with the followin letters Terminal function
C C 24V Power (Cooling)
H, , 5, 5 H 24V Power (Heating)
C C 24V (Common) from Equipment Transformer
W, W1, 4 W Heating elay
Y, Y1 Y Cooling elay
G G Fan elay
O O eversing Valve
(for heat pump applications energized in Cool mode)
B B eversing Valve
(for heat pump applications energized in Heat mode)
Installation

Programmable Multi-Stage Smart Thermostat
Reference No.: HTW-MT06 Series
- 4 - Version 2020-1.0
Tip: Worried about having your wires falling into your wall?
Keep the wires secure by wrapping them around a pencil.
4. Identify jumper wire
On your old thermostat, if… Then, on your new thermostat…
Terminal C and H are connected with a jumper wire Leave the jumper wire in its place
There’s only one wire ( C, H, or 5) coming out of the wall Leave the jumper wire in its place
Terminal C and H (or 5 or 5) are NOT connected by a jumper wire
emove the jumper wire between C and H
For terminal Y and W:
If you have a heat pump with reversing valve, connect Y and W with a jumper wire on your new thermostat.
5.Remove old thermostat base
With all of your wires disconnected and properly labeled, you may now safely remove the thermostat base from your wall.
Mounting and Wiring Your New Thermostat
1. Remove the mounting plate by CW direction rotating the LCD part and Open the insulating cover.
2.Install new thermostat base
Mount your new thermostat base using screws. Drill holes and insert wall anchors to secure the thermostat base to the
wall, if necessary.
3.Connect wires to corresponding terminal blocks
Match each labeled wire to it’s corresponding terminal on the mounted thermostat base. Insert each labeled wire into the hole of
it’s matching terminal, and using the screwdriver, tighten the screw on the terminal block securely.
4.Fasten body of thermostat and the whole mounting plate by CCW direction rotating back.
5.Turn on power
Turn on your power at the source.
Congratulations!
You’ve completed the thermostat installation process
Identify and label each wire
IGNORE WIRE COLORS:
Use terminal screw desi
gnations
to identify wires.

Programmable Multi-Stage Smart Thermostat
Reference No.: HTW-MT06 Series
- 5 - Version 2020-1.0
Check Thermostat Operation
Fan operation
If your system does not have a G terminal connection, ignore this step.
Press Fan button to select the Fan between Auto and On.
Move FAN switch to ON position, the blower should begin to operate.
Move FAN switch to AUTO position, the blower should work according to its heating/cooling demand.
Working Mode Operation
Press and hold F to set the thermostat working mode in Permanent Hold, Using Schedule or Temporary Hold. These
functions will appear on the screen.
Permanent Hold =Manual Mode. In this mode, press   to set temperature manually.
Temporary Hold. when you change the temperature setting to a different temperature and it stays at that setting until the next
schedule change
Using Schedule. 5+1+1 four periods daily programmable
Holiday Mode. hanges temperature setting for a designated number of days.
Real Time Setting
Press and hold F for 5 sec. till the min of time flashes; press   to set to set your minute.
Then press F switch to the “hour” and “week day” setting respectively, press   to set the values.
Programmable Schedule Setting
After the above time setting, touch the icon F week day”1 2 3 4 5” will show along the top of the screen.
press   to set the time for the 1st period(Awake). Press the icon F then use the   arrows to set the temp. for the 1st
period. Repeat this process for periods 2-4. Default values set as below:
Schedule Period Time
Set-Points
Heat Cool
Wake
6:00 Am 72℉(22°C) 72℉(22°C)
Leave
8:00 Am 72℉(22°C) 72℉(22°C)
Return
11:30 Am 72℉(22°C) 72℉(22°C)
Sleep
01:30 Am 72℉(22°C) 72℉(22°C)
System Mode Operation
Press M to select the mode AUTO, OOL,HEAT,OFF,EMER.
HEAT — Thermostat controls the heating system.
OFF — Both heating and cooling systems are off.
OOL — Thermostat controls the cooling system.
AUTO — Thermostat automatically changes between heating and cooling operation, depending on indoor temperature.
EMER — Emergency heat cycles to maintain temperature.

Programmable Multi-Stage Smart Thermostat
Reference No.: HTW-MT06 Series
- 6 - Version 2020-1.0
Press and hold button 5 seconds to enter into Installer Set-Up Process(ISU), press   to configure values and press
button again to switch to next parameter. Save and Exit ISU by pressing F/M or wait for 3 seconds.
Parameter items and default value set as below:
Item Function Setting Value and Options Default
Value
1 Temperature calibration -7 to -1° (-13 to -2
℉ ) -5
2 Auto mode switching differential 0 to 5° (0 to -9
℉ ) 03
3
℉ or ° 0=° 1= ℉ 1
4 Filter change reminder 0--5 (month) 03
5 Min. Set Temp. 5 to 15° (41 to 59
℉ ) 05
6 Max. Set Temp. 15 to 45° (59 to 113
℉ ) 45
7 12/24 hours format 0=12h 1=24h 1
8
O/B Reverse Valve 0=O/B terminal energizes in cooling
1= O/B terminal energizes in heating 1
9
Heat Pump/ onventional System 0=Heat Pump System
1= onventional System 0
A Date (month) Select number of current calendar month (1-12) 01
B Date (day) Select number of current calendar date (1-31) 1
C Dead band Temp. 1 to 5° (2 to 9
℉ ) 1
D Standby Backlight Brightness 3 -- 99 (Brightness) 10
E Delay setting for output 1--5 minute 01
F Fan output ( Heat) 0
： Without Fan 1: With Fan 01
 Always turn off power at the main power source by removing the fuse, or switching the circuit breaker to the off position before installing,
removing, cleaning, or servicing this thermostat.
 Use this thermostat only as described in this manual. Read all of the information in this manual before installing this thermostat.
 Use a professional personnel / installer to install this thermostat.
 This is a 24VA /24VD low-voltage thermostat, do not install on voltages higher than 30 Vac.
 ALL wiring must conform to local and national building and electrical codes and ordinances.
 Do not short (jumper) across terminals on the gas valve or at the system control to test installation. This will damage the thermostat and
void the warranty.
 Do not switch the system to cool if the temperature is below 50ºF (10º ). This may damage the air conditioning system.
 hange the Air Filter when the Filter hange Icon begins blinking.
 Products are warranted for 2 full year (checking and repairing services) from the
date of purchase which products are not being damaged by any man-made
factors.
 Service out of the warranty period may incur an extra charge.
 ore details please contact with Hotowell directly.
Installer Set-Up Process
Important Safety Information
Warranty

Programmable Multi-Stage Smart Thermostat
Reference No.: HTW-MT06 Series
- 7 - Version 2020-1.0
Use your smart phone or tablet PC to scan the QR code below or Search “SMART LIFE” in the app store
/Google play to download and install APP .
 Open “SMART LIFE” application, click “Allow” on the pop up notification dialog(fig 2.1)
 Press “register” button on the register page(fig2.2)
 Select your region and type in your phone No. or email (fig 2.3) then you may get a verification code.
Type in your password and confirm (fig 2.4) to complete your registration.
 If you already have an account, please just log in.
On the thermostat
During power off status, press and hold the arrow icon for 8 sec until the connecting icon appears on
the thermostat screen and flashes once a sec.
Wifi Connection
Step 1- Download and Install APP
Step 2- Registe you account
For ios system For Android system
fig 2.1 fig 2.2 fig 2.3 fig 2.4
Step 3- Connect App with The mostat
App Icon

Programmable Multi-Stage Smart Thermostat
Reference No.: HTW-MT06 Series
- 8 - Version 2020-1.0
On the App
 Press the “+” on the upper right corner of the page (see Fig 3.1) or “Add Device” to add “The mostat”.
 Click “Confirm indicator rapidly blink” (Fig 3.2) then select your network and back to your App to enter the
password of your wireless router(Fig.3.3) and confirm.
 The App will connect with the thermostat successfully. The connecting process takes 5~90 sec, the
thermostat name can be editable once connected.(Fig.4.4)
***If the the mostat has al eady been connected unde above steps, please igno e this p ocess.***
This SMART LIFE App is only supported on 2.4GHz Wi-Fi channels.
If the router does not be supported, or the wi-fi signal is weak or thermostat can not be connected as above
steps, please try this AP mode connection process.
On the thermostat
 During power off status, press and hold the arrow icon for 8 sec until the connecting
icon
appears on the thermostat screen and flashes once a sec.
 press and hold the arrow icon for 8 sec again, the icon will flash once per 3 sec.(fig 4.1)
indicates connecting from normal router mode.
Indicates connecting from AP mode.
On the App
 Click “Confirm indicator slowly blink” (fig 4.1) then select your network and back to your app to enter the
password of your wireless router (fig 4.2) and confirm. The app will go into the page(fig 4.3)
 Press “Connect now” to select the wifi signal Smart life-XXXX from the thermostat(fig 4.3).
 This AP mode connection process may typically take approx. 5~90 seconds to complete.
 The thermostat name can be edited after connection (fig 4.4).
fig 3.1 fig 3.2 fig 3.3 fig 3.4
Alte native AP mode Connection

Programmable Multi-Stage Smart Thermostat
Reference No.: HTW-MT06 Series
- 9 - Version 2020-1.0
App Icons Functions
Switch thermostat power On or Off
Working ode Selection: Permanent Hold/Temporary Hold/Using Schedule/Holiday Hold.
System ode Selection: Auto/ Cool/Heat/Emer/Off.
Set the device name, location, create group and etc.
When thermostat runs in programmable mode, click the setting symbol (at the bottom of the page) to switch
to the schedule page, where you can simply configure the weekly programmable schedule up to 4 periods each
day. Once your schedule has been set, click on SAVE and the app will send the programming to your
thermostat and confirm the schedule has been saved.
fig 4.1 fig 4.2 fig 4.3 fig 4.4
Ope ation Icons on APP
P og ammable Schedule Setting

Programmable Multi-Stage Smart Thermostat
Reference No.: HTW-MT06 Series
- 10 - Version 2020-1.0
 Press the menu button as fig 6.1, then click “Create Group”. Select all the rooms you want and
confirm.(fig 6.2 and fig 6.3), edit the group name or ungroup as fig 6.3
 Group Control allows to control all thermostats(+∞ units) configuration in the group at the same time.
 ethod 1: Click “Share with Familay” as fig 4.4.
 ethod 2: Click “Profile”>”Sent”>”Add”>Switch on the device>”Share with New ember”>Type in the
telephone number you would like to share with.
 ethod 3:Home page of the device> enu(as fig 6.1)>”Device Sharing”>”Add”>>Type in the telephone
number you would like to share with.
Click “Profile”>”Integration”>Select amazon echo/Google Home/IFTTT>”Use Now”
Details as below fig 7.1 and 7.2.
G oup Cont ol and Info. Modify
fig 6.1 fig 6.2 fig 6.3
Sha e The mostat with Othe s
fig 7.1
Wo k with 3 d pa ty Echo Cont ol
fig 7.2

Programmable Multi-Stage Smart Thermostat
Reference No.: HTW-MT06 Series
- 11 - Version 2020-1.0
 This process is to customize your own personal scenes to suit your needs, for example, set your home
temperature automatically when you come back home.
 There are 4 scenes in default setting, and can be added/deleted at will.
 Here set an example of a specific scene: “leave home for holiday” and turn on the thermostat when
temperature lower than 5°C
 Scenes(fig 8.1)>+>Enter a name for the scene(fig 8.2)>Add a condition(Below 5°C as fig 8.3)>Add a Task(fig
8.4)>Save
No. If… Then…
1 Power is on but without display.  Check if the terminals between LCD panel and
Relay/Power odule is loosen.
2 Without output but display works.  Use a new LCD panel or new Relay/Power
odule for Replacement
3 Room Temp. on display is not correct  Do temperature calibration in parameter in ISU
4 Heating system does not respond
 Set the mode to heating by press-ing the
button.
 ake sure the temperature is set above the
room temperature.
 ake sure “heat on” icon shows on the display.
 Wait 5 minutes for the system to respond.
5 The or Increase/Decrease button
doesn’t work
 ake sure keypad is unlocked.
 Check that thermostat is on.
Notice: Hotowell reserves all the right for the final explanation. The manual is subject to change without further notice.
Customize Scene
fig 8.1 fig 8.2 fig 8.3 fig 8.4
T ouble Shooting
