Hotpoint Ariston ARMXXL 105 User manual

GB
1
English,1
Contents
Installation, 2-3
Unpacking and levelling
Connecting the electricity and water supplies
The first wash cycle
Technical data
Description of the washer-dryer and
starting a wash cycle, 4-5
Control panel
Indicator lights
Starting a wash cycle
Wash cycles,
Table of wash cycles
Personalisation, 7
Setting the temperature
Setting the drying cycle
Functions
Detergents and laundry, 8
Detergent dispenser drawer
Bleach cycle
reparing the laundry
Garments requiring special care
Load balancing system
Precautions and tips, 9
General safety
Disposal
Opening the porthole door manually
Care and maintenance, 10
Cutting off the water or electricity supply
Cleaning the washer-dryer
Cleaning the detergent dispenser drawer
Caring for the door and drum of your appliance
Cleaning the pump
Checking the water inlet hose
Troubleshooting, 11
Service, 12
GB
ARMXXL 105
Instructions for use
WASHER DRYER
ÁÚËÃÀÐÑÊÈ,25
BGRO
Românã,13
CIS
Ðóññêèé,37
GR
ÅËËÇÍÉÊÁ,49

2
GB
A
Installation
 This instruction manual should be kept in a safe
place for future reference. If the washer-dryer is sold,
transferred or moved, make sure that the instruction
manual remains with the machine so that the new
owner is able to familiarise himself/herself with its
operation and features.
 Read these instructions carefully: they contain vital
information relating to the safe installation and
operation of the appliance.
Unpacking and levelling
Unpacking
1. Remove the washer-dryer from its packaging.
2. Make sure that the washer-dryer has not been
damaged during the transportation process. If it has
been damaged, contact the retailer and do not
proceed any further with the installation process.
3. Remove the 4
protective screws (used
during transportation) and
the rubber washer with
the corresponding
spacer, located on the
rear part of the appliance
(see figure).
4. Close off the holes using the plastic plugs provided.
5. Keep all the parts in a safe place: you will need
them again if the washer-dryer needs to be moved to
another location.
 ackaging materials should not be used as toys for
children.
Levelling
1. Install the washer-dryer on a flat sturdy floor,
without resting it up against walls, furniture cabinets
or anything else.
2. If the floor is not
perfectly level, compen-
sate for any unevenness
by tightening or loosening
the adjustable front feet
(see figure); the angle of
inclination, measured in
relation to the worktop,
must not exceed 2°.
Levelling the machine correctly will provide it with
stability, help to avoid vibrations and excessive noise
and prevent it from shifting while it is operating. If it is
placed on carpet or a rug, adjust the feet in such a
way as to allow a sufficient ventilation space
underneath the washer-dryer.
Connecting the electricity and water
supplies
Connecting the water inlet hose
1. Insert seal A into the
end of the inlet hose and
screw the latter onto a
cold water tap with a 3/4
gas threaded opening
(see figure).
Before performing the
connection, allow the
water to run freely until it
is perfectly clear.
2. Connect the inlet hose
to the washer-dryer by
screwing it onto the
corresponding water inlet
of the appliance, which is
situated on the top right-
hand side of the rear part
of the appliance (see
figure).
3. Make sure that the hose is not folded over or bent.
 The water pressure at the tap must fall within the
values indicated in the Technical details table (see
next page).
 If the inlet hose is not long enough, contact a
specialised shop or an authorised technician.
 Never use second-hand hoses.
 Use the ones supplied with the machine.

GB
3
Technical data
Model ARMXXL 105
Dimensions
width 59.5 cm
height 85 cm
depth 53,5 cm
Capacity from 1 to 7 kg for the wash programme;
from 1 to 5 kg for the drying programme
Electrical
connections
please refer to the technical data plate
fixed to the machine
Wat e r
connections
maximum pressure 1 M a (10 bar)
minimum pressure 0.05 M a (0.5 bar)
drum capacity 52 litres
Spin speed up to 1000 rotations per minute
Energy rated
programmes
according to
EN 50229
Wash: programme 6; temperature 60°C;
using a load of 7 kg.
Drying: first drying cycle performed with a
2 kg load, by selecting the dryness level.
The second drying cycle is performed with a
5 kg load, by selecting the dryness level.
This appliance conforms to the following
EC Directives:
- 89/336/EEC dated 03/05/89
(Electromagnetic Compatibility) and
subsequent modifications
- 2006/95/EC (Low Voltage)
- 2002/96/EC
65 - 100 cm
Connecting the drain hose
Connect the drain hose,
without bending it, to a
drainage duct or a wall
drain located at a height
between 65 and 100 cm
from the floor;
alternatively, rest it on
the side of a washbasin
or bathtub, fastening the
duct supplied to the tap
(see figure). The free end
of the hose should not
be underwater.
 We advise against the use of hose extensions; if it is
absolutely necessary, the extension must have the
same diameter as the original hose and must not
exceed 150 cm in length.
Electrical connections
Before plugging the appliance into the electricity
socket, make sure that:
 the socket is earthed and complies with all
applicable laws;
 the socket is able to withstand the maximum power
load of the appliance as indicated in the Technical
data table (see opposite);
 the power supply voltage falls within the values
indicated in the Technical data table (see opposite);
 the socket is compatible with the plug of the
washer-dryer. If this is not the case, replace the
socket or the plug.
 The washer-dryer must not be installed outdoors,
even in covered areas. It is extremely dangerous to
leave the appliance exposed to rain, storms and other
weather conditions.
 When the washer-dryer has been installed, the
electricity socket must be within easy reach.
 Do not use extension cords or multiple sockets.
 The cable should not be bent or compressed.
 The power supply cable must only be replaced by
authorised technicians.
Warning! The company shall not be held responsible
in the event that these regulations are not respected.
The first wash cycle
Once the appliance has been installed, and before
you use it for the first time, run a wash cycle with
detergent and no laundry, using the wash cycle 1.

4
GB
Detergent dispenser drawer: used to dispense
detergents and washing additives (see Detergents
and laundry).
There is a key which provides a summary of the
available wash cycles inside the detergent dispenser
drawer; this may be consulted at any time.
ON/OFF button: switches the washer-dryer on and
off.
WASH CYCLE knob: programmes the wash cycles.
During the wash cycle, the knob does not move.
FUNCTION buttons with indicator light: used to
select the available functions. The indicator light
corresponding to the selected function will remain lit.
TEMPERATURE knob: sets the temperature or the
cold wash cycle (see Personalisation).
DRYING knob: used to set the desired drying
programme (see Personalisation).
WASH CYCLE PROGRESS/DELAY TIMER
indicator light s: used to monitor the progress of the
wash cycle.
The illuminated indicator light shows which phase is in
progress.
If the Delay Timer function has been set, the time
remaining until the wash cycle starts will be indicated
(see next page).
DOOR LOCKED indicator light: indicates whether
the door may be opened or not (see next page).
START/PAUSE button with indicator light: starts or
temporarily interrupts the wash cycles.
N.B. To pause the wash cycle in progress, press this
button; the corresponding indicator light will flash
orange, while the indicator light for the current wash
cycle phase will remain lit in a fixed manner. If the
DOOR LOCKED indicator light is switched off, the
door may be opened.
To start the wash cycle from the point at which it was
interrupted, press this button again.
Description of the washer-dryer and
starting a wash cycle
TEMPERATURE
knob
Detergent dispenser drawer
WASH CYCLE PROGRESS/
DELAY TIMER
indicator lights
FUNCTION
buttons with
indicator lights
ON/OFF button
DRYING
knob
DOOR
LOCKED
indicator light
START/PAUSE
button with indicator
light
Control panel
WASH CYCLE
knob

GB
5
Indicator lights
The indicator lights provide important information.
This is what they can tell you:
Delayed start
If the DELAY TIMER function has been activated (see
Personalisation), after the wash cycle has been
started the indicator light corresponding to the
selected delay period will begin to flash:
As time passes, the remaining delay will be displayed
and the corresponding indicator light will flash:
Once the set delay has elapsed, the flashing indicator
light will switch off and the selected wash cycle will
begin.
Wash cycle phase indicator lights
Once the desired wash cycle has been selected and has
begun, the indicator lights switch on one by one to
indicate which phase of the cycle is currently in progress.
Note: during the "Drain" phase, the indicator light
corresponding to the "Spin" cycle phase will illuminate.
Function buttons and corresponding indicator lights
When a function is selected, the corresponding
indicator light will illuminate.
If the selected function is not compatible with the
programmed wash cycle, the corresponding indicator
light will flash and the function will not be activated.
If a function which is incompatible with another
function selected previously, only the most recent
selection will remain active.
Door locked indicator light
If this indicator light is on, the appliance door is locked
to prevent it from being opened accidentally; to avoid
any damage, wait for the indicator light to switch off
before you open the appliance door.
N.B. If the DELAY TIMER function is activated, the door
cannot be opened; pause the machine by pressing the
START/ AUSE button if you wish to open it.
 If the START/ AUSE indicator light (orange) flashes
rapidly at the same time as the function indicator
light, this indicates a problem has occurred (see
Troubleshooting).
Starting a wash cycle
1. Switch the washer-dryer on by pressing the ON/OFF button. All indicator lights will switch on for a few
seconds, then they will switch off and the START/ AUSE indicator light will pulse.
2. Load the laundry and close the door.
3. Set the WASH CYCLE knob to the desired programme.
4. Set the washing temperature (see Personalisation).
5. Set the drying cycle if necessary (see Personalisation).
6. Measure out the detergent and washing additives (see Detergents and laundry).
7. Select the desired functions.
8. Start the wash cycle by pressing the START/ AUSE button and the corresponding indicator light will remain lit
in a fixed manner, in green. To cancel the set wash cycle, pause the machine by pressing the START/ AUSE
button and select a new cycle.
9. At the end of the wash cycle the indicator light will switch on. The DOOR LOCKED indicator light will switch
off, indicating that the door may be opened. Take out your laundry and leave the appliance door ajar to make
sure the drum dries completely. Switch the washer-dryer off by pressing the ON/OFF button.
Wash
Rinse
Spin
Dry
End of wash cycle
Note: as soon as a drying
level or time period has been
set, this indicator light
illuminates to indicate that
the selected wash cycle will
be followed by a drying
phase.

GB
Specials wash cycles
Sanitizing cycle (wash cycle 6). A high-temperature hygienic wash cycle (over 60°C) which requires the use of bleach.
our the bleach, the detergent and the additives into the relevant compartments (see paragraph entitled
Detergent dispenser drawer).
Goodnigt cycle (wash cycle 7). This is a silent cycle which can be run at night, when the electricity prices are lower. The
wash cycle is designed for cottons and synthetics. At the end of the cycle the machine stops while there is still water in
the drum; to spin and drain the laundry press the START/ AUSE button; alternatively the machine will perform the spin
cycle and drain the water automatically after 8 hours.
Baby cycle (wash cycle 8). This wash cycle can be used to remove the soiling typically caused by babies, while ensuring
that all detergent is removed from nappies in order to prevent the delicate skin of babies from suffering allergies. The
cycle has been designed to reduce the amount of bacteria by using a greater quantity of water and optimising the effect
of special disinfecting additives added to the detergent.
At the end of the wash cycle, the machine will slowly rotate the drum to prevent the formation of creases; to end the cycle
press the START/ AUSE button.
Mix 30(wash cycle 4) this wash cycle was designed to wash lightly soiled garments quickly: it lasts just 30 minutes and
therefore saves both energy and time. By selecting this wash cycle (5 at 30°C), it is possible to wash different fabrics
together (except for wool and silk items), with a maximum load of 3 kg.
Mix 15(wash cycle 5) this wash cycle was designed to wash lightly soiled garments quickly: it lasts just 15 minutes and
therefore saves both energy and time. By selecting this wash cycle (5 at 30°C), it is possible to wash different fabrics
together (except for wool and silk items), with a maximum load of 1.5 kg.
Wash cycles
The information contained in the table is intended as a guide only.
For all Test Instit tes:
1) Test wash cycle in compliance with reg lation EN 50229: set wash cycle 6 with a temperat re of 60°C.
2) Long wash cycle for cottons: set wash cycle 1 with a temperat re of 40°C.
3) Short wash cycle for cottons: set wash cycle 2 with a temperat re of 40°C.
Wash cycles
Table of wash cycles
Description of the wash cycle
Max.
temp.
(°C)
Max.
speed
(rpm)
Drying
Detergents Max.
load
(kg)
Cycle
d ration
Bleach Wash Fabric
softener
Specials cycles
Sanitizing cycle: Extremely soiled whites. 90° 1000 llll 7170
Sanitizing cycle (1): Heavily soiled whites and resistant colours. 60° 1000 l-ll 7 153
7Goodnigt cycle: Lightly soiled delicate colours. 40° 1000 l-ll 4290
8Baby cycle: Heavily soiled delicate colours. 40° 800 l-ll 2118
9Silk/C rtains: For garments in silk and viscose, lingerie. 30° 0 - - ll 155
10 Wool: For wool, cashmere, etc. 40° 800 l-ll1,5 55
Daily wash cycles
1Cotton: Heavily soiled whites and resistant colours. 60° 1000 llll 7 122
1Cotton (2): Heavily soiled whites and delicate colours. 40° 1000 llll 7115
2Colo red Cottons (3): Lightly soiled whites and delicate colours. 40° 1000 llll 785
3Synthetics resistents: Heavily soiled resistant colours. 60° 800 l-ll 385
3Synthetics resistents: Lightly soiled resistant colours. 40° 800 l-ll 370
4Mix 30':To refresh lightly soiled garments quickly (not suitable for wool,
silk and clothes which require washing by hand). 30° 800 l-ll 330
5Mix 15': To refresh lightly soiled garments quickly (not suitable for wool,
silk and clothes which require washing by hand). 30° 800 l-ll1,5 15
Partials wash cycles
ARinse -1000 l- - l736
BSpin -1000 l- - - 716
CDrain no spin -0- - - - 72
Drying cycles
11 Cotton drying - - l- - - 5-
12 Synthetics drying - - l- - - 3-
13 Wool drying - - l- - - 1,5 -

GB
7
Setting the temperature
Turn the TEM ERATURE knob to set the wash temperature (see Table of wash cycles).
The temperature may be lowered, or even set to a cold wash ( ).
The washer-dryer will automatically prevent you from selecting a temperature which is higher than the maximum
value set for each wash cycle.
Setting the drying cycle
Turn the DRYING knob to set the desired drying type.
Two options are available:
A - Based on time: from 40 to 180 minutes.
B - Based on the how damp the clothes are once they have
been dried:
ron : slightly damp clothes, easy to iron.
Hanger : dry clothes to put away.
Cupboard : very dry clothes, recommended for towelling
and bathrobes.
If your laundry load to be washed and dried is much greater than the maximum stated load (see adjacent table),
perform the wash cycle, and when the cycle is complete, divide the garments into groups and put some of them
back in the drum. At this point, follow the instructions provided for a "Drying only" cycle. Repeat this procedure
for the remainder of the load.
N.B: When the drying is complete there is a cooling period, even though the DRYING knob is in the position.
Drying only
Turn the WASH CYCLE knob to one of the drying settings (11-12-13) according to the type of fabric, then select
the desired drying duration using the DRYING knob.
Functions
The various wash functions available with this washer-dryer will help to achieve the desired results, every time.
To activate the functions:
1. ress the button corresponding to the desired function;
2. the function is enabled when the corresponding indicator light is illuminated.
Note: If the indicator light flashes rapidly, this signals that this particular function may not be selected in
conjunction with the selected wash cycle.
Delay timer
This timer delays the start time of the wash cycle by up to 9 hours.
ress the button repeatedly until the indicator light corresponding to the desired delay time switches on. The fifth time
the button is pressed, the function will be disabled.
N.B. Once you have pressed the START/ AUSE button, the delay time may only be decreased if you wish to modify it.
This option is enabled with all programmes.
Extra rinse
By selecting this function, the efficiency of the rinse is increased and optimal detergent removal is guaranteed. It is
particularly useful for sensitive skin.
 This function may not be used in conjunction with wash cycles 4, 5, 11, 12, 13, B, C.
Super Wash
Because a greater quantity of water is used in the initial phase of the cycle, and because of the increased cycle
duration, this function offers a high-performance wash.
 This function may not be used in conjunction with wash cycles 4, 5, 6, 9, 10, 11, 12, 13, A, B, C.
1000-500
By selecting this function, reduces the spin speed.
 This function may not be used in conjunction with wash cycles 9, C, 11, 12, 13.
Personalisation
Fabric
type
Load type Max.
load
(kg)
C pboard
dry
Henger
dry
Iron
dry
Cotton Clothing of different
sizes, Terry towels 5 180 170 160
Synthe-
tics Sheets, Shirts, yjamas,
socks, etc. 3 180 170 160
Wool Knitwear, ullovers, etc. 1,5 150 140 130
Table of Drying times (guideline values)

8
GB
Detergents and laundry
Detergent dispenser drawer
Good washing results also depend on the correct
dose of detergent: adding too much detergent will not
necessarily result in a more efficient wash, and may in
fact cause build up on the inside of your appliance
and contribute to environmental pollution.
 Do not use hand washing detergents because these
create too much foam.
Open the detergent
dispenser drawer and
pour in the detergent or
washing additive, as
follows.
compartment 1: Pre-wash detergent (powder)
Before pouring in the detergent, make sure that extra
compartment 4 has been removed.
compartment 2: Detergent for the wash cycle
(powder or liquid)
Liquid detergent should only be poured in immediately
prior to the start of the wash cycle.
compartment 3: Additives (fabric softeners, etc.)
The fabric softener should not overflow the grid.
extra compartment 4: Bleach
Bleach cycle
Bleaching may only be performed in conjunction with
wash cycles 1, 2, .
our the bleach into extra compartment 4; pour the
detergent and softener into the corresponding
compartments, then select one of the
abovementioned wash cycles.
This option is recommended only for very soiled
cotton garments.
Preparing the laundry
 Divide the laundry according to:
- the type of fabric/the symbol on the label
- the colours: separate coloured garments from
whites.
 Empty all garment pockets and check the buttons.
 Do not exceed the listed values, which refer to the
weight of the laundry when dry:
Durable fabrics: max. 7 kg
Synthetic fabrics: max. 3 kg
Delicate fabrics: max. 2 kg
Wool: max. 1.5 kg
MAX
1
2
4
3
How much does your laundry weigh?
1 sheet 400-500 g
1 pillow case 150-200 g
1 tablecloth 400-500 g
1 bathrobe 900-1200 g
1 towel 150-250 g
Garments requiring special care
Silk: use special wash cycle 9 to wash all silk
garments. We recommend the use of special
detergent which has been designed to wash delicate
clothes.
Curtains: these should be folded and placed inside
the bag provided. Use wash cycle 9.
Wool: Hotpoint/Ariston is the only washer-dryer
manufacturer to have been awarded the prestigious
Woolmark latinum Care endorsement (M.0508) by
the Woolmark Company, which means that all
woollen garments may be washed in the washer-
dryer, even those which state hand wash only
on the label. Wash cycle 10 therefore offers complete
peace of mind when washing woollen garments in the
washer-dryer (max. load 1.5 kg) and guarantees
optimal performance.
Load balancing system
Before every spin cycle, to avoid excessive vibrations
and to distribute the load in a uniform manner, the
drum rotates continuously at a speed which is slightly
greater than the washing rotation speed. If, after
several attempts, the load is not balanced correctly,
the machine spins at a reduced spin speed. If the
load is excessively unbalanced, the washer-dryer
performs the distribution process instead of spinning.
To encourage improved load distribution and balance,
we recommend small and large garments are mixed
in the load.
Anti-crease
This function interrupts the wash programme, and the
washing is left to soak in water before the appliance
is drained.
It can only be used with programme 9 (Silk/Curtains)
and helps to prevent the formation of creases.
To complete the cycle press the START/ AUSE
button.

GB
9
Precautions and tips
 This washer-dryer was designed and constructed in
accordance with international safety regulations. The
following information is provided for safety reasons
and must therefore be read carefully.
General safety
 This appliance was designed for domestic use only.
 The washer-dryer must only be used by adults, in
accordance with the instructions provided in this manual.
 Do not touch the machine when barefoot or with
wet or damp hands or feet.
 Do not pull on the power supply cable when
unplugging the appliance from the electricity
socket. Hold the plug and pull.
 Do not open the detergent dispenser drawer while
the machine is in operation.
 Do not touch the drained water as it may reach
extremely high temperatures.
 Never force the porthole door. This could damage
the safety lock mechanism designed to prevent
accidental opening.
 If the appliance breaks down, do not under any
circumstances access the internal mechanisms in
an attempt to repair it yourself.
 Always keep children well away from the appliance
while it is operating.
 The door can become quite hot during the wash cycle.
 If the appliance has to be moved, work in a group
of two or three people and handle it with the utmost
care. Never try to do this alone, because the
appliance is very heavy.
 Before loading laundry into the washer-dryer, make
sure the drum is empty.
 During the drying phase, the door tends to get
quite hot.
 Do not use the appliance to dry clothes that have
been washed with flammable solvents (e.g.
trichlorethylene).
 Do not use the appliance to dry foam rubber or
similar elastomers.
 Make sure that the water tap is turned on during
the drying cycles.
Disposal
 Disposing of the packaging materials: observe local
regulations so that the packaging may be re-used.
 The European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment, requires that
old household electrical appliances must not be
disposed of in the normal unsorted municipal waste
stream. Old appliances must be collected
Opening the porthole door manually
In the event that it is not possible to open the
porthole door due to a powercut, and if you wish to
remove the laundry, proceed as follows:
1. remove the plug from
the electrical socket.
2. make sure the water
level inside the machine is
lower than the door
opening; if it is not, remove
excess water using the
drain hose, collecting it in a
bucket as indicated in the
figure.
3. using a screwdriver,
remove the cover panel on
the lower front part of the
washer-dryer (see figure).
4. pull outwards using the tab as indicated in the
figure, until the plastic tie-rod is freed from its stop
position; pull downwards and open the door at the
same time.
5. reposition the panel, making sure the hooks are
securely in place before you push it onto the
appliance.
20
separately in order to optimise the recovery and
recycling of the materials they contain and reduce
the impact on human health and the environment.
The crossed out "wheeled bin" symbol on the
product reminds you of your obligation, that when
you dispose of the appliance it must be separately
collected.
Consumers should contact their local authority or
retailer for information concerning the correct
disposal of their old appliance.

10
GB
Care and maintenance
Cutting off the water and electricity
supplies
 Turn off the water tap after every wash cycle. This
will limit wear on the hydraulic system inside the
washer-dryer and help to prevent leaks.
 Unplug the washer-dryer when cleaning it and
during all maintenance work.
Cleaning the washer-dryer
The outer parts and rubber components of the
appliance can be cleaned using a soft cloth soaked
in lukewarm soapy water. Do not use solvents or
abrasives.
Cleaning the detergent dispenser
drawer
Remove the dispenser
by raising it and pulling it
out (see figure).
Wash it under running
water; this operation
should be repeated
frequently.
Caring for the door and drum of your
appliance
 Always leave the porthole door ajar in order to
prevent unpleasant odours from forming.
Cleaning the pump
The washer-dryer is fitted with a self-cleaning pump
which does not require any maintenance. Sometimes,
small items (such as coins or buttons) may fall into the
pre-chamber which protects the pump, situated in its
bottom part.
 Make sure the wash cycle has finished and unplug
the appliance.
To access the pre-chamber:
1. using a screwdriver,
remove the cover panel
on the lower front part of
the washer-dryer (see
figure);
2. unscrew the lid by
rotating it anti-clockwise
(see figure): a little water
may trickle out. This is
perfectly normal;
3. clean the inside thoroughly;
4. screw the lid back on;
5. reposition the panel, making sure the hooks are
securely in place before you push it onto the
appliance.
Checking the water inlet hose
Check the inlet hose at least once a year. If there are
any cracks, it should be replaced immediately: during
the wash cycles, water pressure is very strong and a
cracked hose could easily split open.
 Never use second-hand hoses.
1
2

GB
11
Troubleshooting
Your washer-dryer could fail to work. Before contacting the Technical Assistance Centre (see Assistance), make
sure that the problem cannot be not solved easily using the following list.
Problem:
The washer-dryer does not
switch on.
The wash cycle does not start.
The washer-dryer does not take
in water (the indicator light for
the first wash cycle stage
flashes rapidly).
The washer-dryer continuously
takes in and drains water.
The washer-dryer does not drain
or spin.
The washer-dryer vibrates a lot
during the spin cycle.
The washer-dryer leaks.
The START/PAUSE indicator light
(orange) and the function
indicator lights flash rapidly.
There is too much foam.
The washer-dryer does not dry.
Possible causes / Solutions:
 The appliance is not plugged into the socket fully, or is not making contact.
 There is no power in the house.
 The washer-dryer door is not closed properly.
 The ON/OFF button has not been pressed.
 The START/ AUSE button has not been pressed.
 The water tap has not been opened.
 A delayed start has been set (see Personalisation).
 The water inlet hose is not connected to the tap.
 The hose is bent.
 The water tap has not been opened.
 There is no water supply in the house.
 The pressure is too low.
 The START/ AUSE button has not been pressed.
 The drain hose is not fitted at a height between 65 and 100 cm from
the floor (see  nstallation).
 The free end of the hose is under water (see  nstallation).
 The wall drainage system is not fitted with a breather pipe.
If the problem persists even after these checks, turn off the water tap,
switch the appliance off and contact the Assistance Service. If the
dwelling is on one of the upper floors of a building, there may be problems
relating to water drainage, causing the washer-dryer to fill with water and
drain continuously. Special anti-draining valves are available in shops and
help to avoid this inconvenience.
 The wash cycle does not include draining: some wash cycles require
the drain phase to be started manually.
 The ANTI-CREASE function has been activated: To complete the wash
cycle, press the START/ AUSE button (Personalisation).
 The drain hose is bent (see  nstallation).
 The drainage duct is clogged.
 The drum was not unlocked correctly during installation (see  nstallation).
 The washer-dryer is not level (see  nstallation).
 The washer-dryer is trapped between cabinets and walls (see  nstallation).
 The water inlet hose is not screwed on properly (see  nstallation).
 The detergent dispenser drawer is blocked (for cleaning instructions, see
Care and maintenance).
 The drain hose is not fixed properly (see  nstallation).
 Switch off the machine and unplug it, wait for approximately 1 minute
and then switch it back on again.
If the problem persists, contact the Technical Assistance Service.
 The detergent is not suitable for machine washing (it should display the
text for washer-dryers or hand and machine wash, or the like).
 Too much detergent was used.
 The appliance is not plugged into the socket, or not enough to make contact.
 There has been a power failure.
 The appliance door is not shut properly.
 A delayed start has been set.
 The DRYING knob is on the setting.

12
GB
Service
Before calling for Assistance:
Check whether you can solve the problem alone (see Troubleshooting);
 Restart the programme to check whether the problem has been solved;
 If this is not the case, contact an authorised Technical Assistance Centre using the telephone number
provided on the guarantee certificate.
Always request the assistance of authorised technicians.
Have the following information to hand:
 the type of problem;
 the appliance model (Mod.);
 the serial number (S/N).
This information can be found on the data plate applied to the rear of the washer-dryer, and can also be
found on the front of the appliance by opening the door.

13
RO
Românã
Sumar
Instalare, 14-15
Despachetare ºi punere la nivel
Racorduri hidraulice ºi electrice
Primul ciclu de spãlare
Date tehnice
Descrierea maºinii de spãlat ºi activarea
unui program, 16-1
Panoul de control
Indicatoare luminoase
Activarea unui program
Programe, 18
Tabel de programe
Personalizare, 19
Reglarea temperaturii
Alegerea programului de uscare
Funcþii
Detergenþi ºi rufe albe, 20
Compartimentul pentru detergenþi
Ciclu de albire
Pregãtirea rufelor
Articole delicate
istemul de echilibrare a încãrcãturii
Precauþii ºi sfaturi, 21
Norme de protecþie ºi siguranþã generale
Aruncarea reziduurilor
Deschiderea manualã a uºii
Întreþinere ºi curãþare, 22
Întreruperea alimentãrii cu apã ºi curent electric
Curãþarea maºinii de spãlat
Curãþarea compartimentului pentru detergent
Îngrijirea uºii ºi a tamburului
Curãþarea pompei
Controlarea furtunului de alimentare cu apã
Anomalii ºi remedii, 23
Asistenþã, 24
RO
ARMXXL 105
Instrucþiuni de folosire
MAªINÃ DE SPÃLAT ªI USCAT

14
RO
A
Instalare
 Este important sã pãstraþi acest manual pentru a-l
putea consulta în orice moment. În caz de vânzare,
de cesiune sau de schimbare a locuinþei, acesta
trebuie sã rãmânã împreunã cu maºina de spãlat
pentru a informa noul proprietar cu privire la
funcþionare ºi la respectivele avertismente.
 Citiþi cu atenþie instrucþiunile: veþi gãsi informaþii
importante cu privire la instalare, la folosire ºi la
siguranþã.
Despachetare ºi punere la nivel
Despachetare
1. coaterea din ambalaj a maºinii de spãlat.
2. Controlaþi ca maºina de spãlat sã nu fi fost
deterioratã în timpul transportului. Dacã este
deterioratã nu o conectaþi ºi luaþi legãtura cu
vânzãtorul.
3. coateþi cele 4
ºuruburi de protecþie
pentru transport ºi
cauciucul cu respectivul
distanþier, situate în
partea posterioarã
(a se vedea figura).
4. Închideþi orificiile cu dopurile din plastic aflate în
dotare.
5. Pãstraþi toate piesele: pentru cazul în care
maºina de spãlat va trebui sã fie transportatã,
piesele vor trebui montante din nou.
 Ambalajele nu sunt jucãrii pentru copii!
Punere la nivel
1. Instalaþi maºina de spãlat pe o suprafaþã planã ºi
rigidã, fãrã a o sprijini de ziduri, mobilã sau altceva.
2. Dacã podeaua nu este
perfect orizontalã,
compensaþi
neregularitãþile
deºurubând sau
înºurubând picioruºele
anterioare (a se vedea
figura); unghiul de
înclinare, mãsurat pe
planul de lucru, nu trebuie
sã depãºeascã 2°.
O nivelare precisã conferã stabilitate maºinii ºi evitã
vibraþii, zgomote ºi deplasãri pe timpul funcþionãrii.
În cazul mochetelor sau a unui covor, reglaþi
picioruºele astfel încât sã menþineþi sub maºina de
spãlat un spaþiu suficient pentru ventilare.
Racorduri hidraulice ºi electrice
Racordarea furtunului de alimentare cu apã
1. Introduceþi garnitura A
în extremitatea tubului de
alimentare ºi înºurubaþi-l
la un robinet de apã rece
cu gura filetatã (a se
vedea figura).
Înainte de conectare,
lãsaþi apa sã curgã pânã
când nu a devine
limpede.
2. Conectaþi tubul de
alimentare la maºina de
spãlat, înºurubându-l la
sursa de apã respectivã,
amplasatã în partea
posterioarã, sus în
dreapta (a se vedea
figura).
3. Fiþi atenþi ca furtunul sã nu fie nici pliat nici îndoit.
 Presiunea apei de la robinet trebuie sã fie cuprinsã
în valorile din tabelul Date tehnice (a se vedea
pagina alãturatã).
 Dacã lungimea furtunului de alimentare nu este
suficientã, adresaþi-vã unui magazin specializat sau
unui instalator autorizat.
 Nu folosiþi niciodatã tuburi folosite deja.
 Utilizaþi tuburile furnizate împreunã cu maºina.

15
RO
65 - 100 cm
Conectarea furtunului de golire
Conectaþi furtunul de
golire - fãrã a-l îndoi - la
canalizare sau la
racordul de golire
prevãzut pe perete, la o
înãlþime de 65 - 100 cm
de sol;
prijiniþi-l de marginea
cãzii sau chiuvetei ºi
racordaþi ºina de ghidare
din dotare la robinet (a
se vedea figura).
Capãtul liber al
furtunului de golire nu
trebuie sã rãmânã
cufundat în apã.
 Nu se recomandã folosirea furtunurilor
prelungitoare; dacã este indispensabil, acestea
trebuie sã aibã acelaºi diametru ca ºi furtunul
original ºi nu trebuie sã depãºeascã 150 cm
lungime.
Racordarea electricã
Înainte de a introduce stecherul în prizã, asiguraþi-vã ca:
 priza sã fie cu împãmântare ºi conform
prevederilor legale;
 priza sã poatã suporta sarcina maximã de putere
a maºinii, indicatã în tabelul Date Tehnice
(a se vedea alãturi);
 tensiunea de alimentare sã fie cuprinsã în valorile
indicate în tabelul Date Tehnice (a se vedea
alãturi);
 priza sã fie compatibilã cu stecherul maºinii de
spãlat. În caz contrar înlocuiþi stecherul.
 Maºina de spãlat nu trebuie instalatã afarã, nici
chiar în cazul în care spaþiul este adãpostit,
deoarece este foarte periculoasã expunerea maºinii
la ploi ºi furtuni.
 Dupã instalarea maºinii de spãlat, priza de curent
trebuie sã fie uºor accesibilã.
 Nu folosiþi prelungitoare ºi prize multiple.
 Cablul nu trebuie sã fie îndoit sau comprimat.
 Cablul de alimentare trebuie sã fie înlocuit doar de
tehnicieni autorizaþi ai centrului de service ce apare
scris pe certificatul de garantie emis de producator.
Atenþie! Producãtorul îºi declinã orice
responsabilitate în cazul în care aceste norme nu se
respectã.
Primul ciclu de spãlare
Dupã instalare, înainte de folosire, efectuaþi un ciclu
de spãlare cu detergent ºi fãrã rufe, selectând
programul 1.
Date tehnice
Model ARMXXL 105
Dimensiuni
lãrgime: 59,5 cm
înãlþime: 85 cm
profunzime: 53,5 cm
Capacitate De l 1 l 7 kg pentru spãl re
De l 1 l 5 kg pentru usc re
Legãturi electrice vezi etichet cu c r cteristicile tehnice,
plic tã pe m ºinã
Legãturi hidrice
presiune m ximã: 1 MP (10 b ri)
presiune minimã: 0,05 MP (0,5 b ri)
c p cit te cuvei: 52 litri
Turaþia de
centrifugare pânã l 1000 de rot þii pe minut
Programe de control
în baza normei
EN 0229
Spãlare: progr mul 6; temper tur
60°C; efectu tã cu 7 kg de rufe.
Uscare: prim usc re se efectue zã cu
2 kg de rufe ºi selectorul de USCARE în
poziþi ;
dou usc re se efectue zã cu kg de
rufe ºi selectorul de USCARE în
poziþi .
Acest p r t este conform cu
urmãto rele Directive Comunit re:e
- 89/336/CEE din d t de 03/05/89
(Comp tibilit te Electrom gneticã) ºi
modificãri succesive
- 2006/95/CE (Tensiuni Jo se)
- 2002/96/CE
Zgomot
(dB(A) re 1 pW)
Spãl re: 66
Tur þie de centrifug re: 76

16
RO
Sertarul detergenþilor: pentru a introduce
detergenþi sau aditivi (a se vedea Detergenþi ºi rufe
albe).
În interiorul sertarului pentru detergenþi este
amplasat un suport pe care se aflã schema
programelor.
Tasta PORNIRE/OPRIRE: pentru a porni ºi opri
maºina.
elector PROGRAME: pentru a selecta programele.
Pe durata desfãºurãrii programului selectorul rãmâne
în aceeaºi poziþie.
Taste cu led FUNCÞII: pentru a selecta funcþiile
disponibile. Indicatorul corespunzãtor funcþiei alese
va rãmâne aprins.
elector USCARE: pentru a regla uscarea doritã
(a se vedea Personalizare).
elector TEMPERATURÃ: pentru a selecta temperatu-
ra sau spãlarea la rece (a se vedea Personalizare).
Indicatoare DESFêURARE CICLU/PORNIRE
ÎNTÂRZIATÃ: pentru a putea urmãri avansarea
programului de spãlare.
Indicatorul aprins aratã faza în curs de desfãºurare.
Dacã a fost selectatã funcþia Pornire întârziatã, va
fi indicat timpul care lipseºte pânã la pornirea
programului (a se vedea pag. alãturatã).
Indicator UªÃ BLOCATÃ: pentru a înþelege dacã uºa
se poate deschide sau nu (a se vedea pag.
alãturatã).
Tastã cu led START/PAUZÃ: pentru a activa / opri
momentan programele.
N.B.: pentru a întrerupe momentan un ciclu apãsaþi
aceastã tastã; ledul se va aprinde intermitent
(culoare portocalie) în timp ce ledul corespunzãtor
fazei în curs de desfãºurare va rãmâne aprins. Dacã
indicatorul UªÃ BLOCATà este stins, atunci uºa
se poate deschide.
Pentru a continua spãlarea, de unde a fost
întreruptã, apãsaþi din nou tasta.
Descrierea maºinii de spãlat ºi
activarea unui program
elector
TEMPERATURÃ
Sertarul detergenþilor
Indicatoare
DESFêURARE CICLU/
PORNIRE ÎNTÂRZIATÃ
Taste cu led
FUNCÞII
Tasta
PORNIRE/OPRIRE
elector
USCARE
Indicator
UªÃ
BLOCATÃ
Tastã cu led
START/PAUZÃ
Panoul de control
elector
PROGRAME

17
RO
Indicatoare luminoase
Ledurile furnizeazã informaþii importante.
Iatã ce indicã:
Pornire întârziatã
Dacã a fost activatã funcþia Pornire întârziatã (a se
vedea Personalizare), dupã activarea programului, se
va aprinde intermitent ledul corespunzãtor
întârzieriiselectate:
Cu trecerea timpului, se va vizualiza întârzierea
restantã, prin aprinderea intermitentã a ledului
respectiv.
La expirarea întârzierii selectate, indicatorul luminos
se va stinge ºi programul selectat va intra în
funcþiune.
Indicatoare de fazã
Dupã alegerea ºi activarea ciclului dorit, indicatoarele
luminoase se vor aprinde unul dupã altul, ceea ce vã
indicã starea de avansare a programului:
Notã: în timpul fazei de Evacuare se va aprinde
indicatorul corespunzãtor cu Centrifugã.
Tastele de funcþii ºi ledurile corespunzãtoare
Alegerea unei funcþii implicã aprinderea ledului
corespunzãtor.
Dacã funcþia selectatã nu este compatibilã cu
programul ales, ledul corespunzãtor se va aprinde
intermitent iar funcþia nu se va activa.
În cazul în care va fi selectatã o funcþie
incompatibilã cu alta selectatã anterior, se va activa
doar ultima funcþie aleasã.
Indicator uºã blocatã:
Indicatorul luminos aprins indicã faptul cã uºa este
blocatã, ceea ce evitã deschiderea accidentalã;
pentru a evita orice daunã, este necesar sã se
aºtepte stingerea ledului, înainte de a deschide uºa.
N.B.: dacã funcþia Pornire întârziatã este activã,
uºa nu se poate deschide; pentru a o deschide,
apãsaþi tasta TART/PAUZÃ pentru a întrerupe
momentan programarea.
 Aprinderea intermitentã rapidã a indicatorului
TART/PAUZÃ (culoare portocalie) concomitent cu
un alt led indicã apariþia unei anomalii (a se vedea
Ano alii ºi re edii).
Activarea unui program
1.Porniþi maºina de spãlat apãsând pe tasta PORNIRE/OPRIRE. Toate indicatoarele se aprind câteva secunde,
apoi se sting; indicatorul TART/PAUZÃ se va aprinde intermitent.
2. Introduceþi rufele ºi închideþi uºa.
3. electaþi programul dorit cu ajutorul selectorului de PROGRAME.
4. Reglaþi temperatura de spãlare (a se vedea Personalizare).
5. electaþi uscarea dacã este necesar (a se vedea Personalizare).
6. Adãugaþi detergentul ºi aditivii (a se vedea Detergenþi ºi rufe).
7. Alegeþi funcþiile dorite.
8. Activaþi programul apãsând tasta TART/PAUZÃ; indicatorul luminos se va aprinde (culoare verde).
Pentru a anula un ciclu selectat, apãsaþi tasta TART/PAUZÃ pentru a întrerupe momentan ciclul ºi alegeþi un
nou program.
9. La încheierea programului, indicatorul luminos se va aprinde. Indicatorul UªÃ BLOCATà se va stinge,
ceea ce vã aratã cã uºa poate fi deschisã. coateþi rufele ºi lãsaþi uºa întredeschisã pentru a se putea usca
cuva si tamburul.
Opriti maºina de spãlat apãsând pe tasta PORNIRE/OPRIRE.
pãlare
Clãtire
Centrifugã
Uscare
fârºit pãlare
Notã: Imediat dupã alegerea
unui nivel sau a unei durate
de uscare, acest indicator
se va aprinde, ceea ce vã
aratã cã ciclul de spãlare
selectat va fi urmat de o
fazã de uscare.

18
RO
Programe speciale
STERILIZARE (programul 6). Un program de igienizare la temperaturã ridicatã, care presupune folosirea
decolorantului (temperatura este peste 60°C).
Pentru a decolora rufele, turnaþi decolorantul, detergentul ºi
aditivii în sertarele corespunzãtoare (a se vedea paragraful Co parti entul pentru detergenþi).
CICLU DE SPALARE NOCTURNA (programul 7). Este un ciclu cu zgomot redus, care vã permite folosirea
maºinii pe timp de noapte. Programul a fost conceput pentru articolele sintetice ºi din bumbac. La încheierea
ciclului, maºina se opreºte cu apã în cuvã; pentru a stoarce rufele ºi a goli apa apãsaþi tasta TART/PAUZÃ,
daca nu, dupã 8 ore maºina comandã automat stoarcerea ºi evacuarea apei.
CICLU BABY (programul 8). Programul îndepãrteazã eficient atât mizeria care pãteazã în mod obiºnuit hainele
copiilor cât ºi detergentul, în scopul de a evita apariþia unor alergii pe pielea delicatã a celor mici. Ciclul a fost
conceput pentru a diminua încãrcarea bacterianã prin folosirea unei cantitãþi de apã mai mari ºi prin optimizarea
aditivilor speciali de igienizare, adãugati la detergent.
La încheierea ciclului de spãlare, maºina efectueazã o rotaþie lentã a cuvei, pentru a limita ºifonarea; pentru a
termina ciclul, apãsaþi tasta TART/PAUZÃ.
MI 30' (programul 4) a fost studiat pentru a spãla articolele puþin murdare, în mod rapid: dureazã doar 30 de
minute ceea ce economiseºte energie ºi timp. electând programul (4 la 30°C) este posibilã spãlarea
articolelor din materiale diferite (excluse lâna ºi mãtasea) cu o greutate maximã de 3 kg.
MI 15' (programul 5) a fost studiat pentru a spãla articolele foarte puþin murdare, în mod rapid: dureazã doar 15
de minute ceea ce economiseºte energie ºi timp. electând programul (5 la 30°C) este posibilã spãlarea
articolelor din materiale diferite (excluse lâna ºi mãtasea) cu o greutate maximã de 1,5 kg.
Programe
Datele specificate în tabel au valoare indicativã.
Pentru toate Instituþiile de Testare:
1) Programul de control conform normei EN 50229: selectaþi programul 6 ºi temperatura de 60°C.
2) Program pentru bumbac, prelungit: selectaþi programul 1 ºi temperatura de 40°C.
3) Program pentru bumbac, rapid: selectaþi programul 2 ºi temperatura de 40°C.
Tabel de programe
Programe
Detergenþi
Descrierea Programului Temp.
max.
(°C)
Viteza max.
(rotaþii pe
minut) Decolorant Spãlare Balsam
rufe
Uscare Sarcina
Max.
(Kg)
Durata ciclului de
spãlare
Programe Speciale
6 STERILIZARE: Rufe albe foarte murdare. 90°1000 ••••7170
6 STERILIZARE (1):Albe ºi colorate rezistente foarte
murdare. 60°1000 - •••7153
7 CICLU DE SPÃLARE NOCTURNÃ:Colorate
delicate puþin murdare. 40°800 - •••4290
8 CICLU BABY: Colorate delicate foarte murdare. 40°800 - •••2118
9 MÃTASE /PERDELE: Pentru articolele din
mãtase, viscozã, lenjerie. 30°0 - ••-155
10 LÂNÃ Pentru articole din lânã, caºmir. 40°800 - •••1,5 55
Programe zilnice
1 RUFE ALBE BUMBAC: Albe ºi colorate rezistente
foarte murdare. 60°1000 ••••7 122
1 RUFE ALBE BUMBAC (2): Albe ºi colorate delicate
foarte murdare. 40°1000 ••••7 115
2 COLORATE BUMBAC (3): Albe puþin murdare
ºi colorate delicate. 40°1000 ••••7 85
3 SINTETICE REZISTENTE: Colorate rezistente
foarte murdare. 60°800 - •••3 85
3 SINTETICE DELICATE: Colorate rezistente
puþin murdare. 40°800 - •••3 70
4 MIX 30’: Pentru a spãla rapid articolele puþin
murdare (nu este indicat pentru lânã, mãtase ºi
articole de spãlat cu mâna).
30°800 - •••3 30
5 MIX 15': Pentru a împrospãta rapid articolele
puþin murdare (nu este indicat pentru lânã,
mãtase ºi articole de spãlat cu mâna).
30°800 - •••1,5 15
Programe parþiale
A C ÃTIRE - 1000 - -
••7 36
B CENTRIFUGARE - 1000 - - -
•7 16
C EVACUARE - 0 - - - - 7 2
Programe de uscare
11 USCARE Bumbac - - - - -
•5 -
12 USCARE Sintetice - - - - -
•3 -
13 USCARE Lânã - - - - -
•1,5 -

19
RO
Reglarea temperaturii
Rotind selectorul de TEMPERATURÃ se fixeazã temperatura de spãlare (a se vedea Tabelul progra elor).
Temperatura poate fi redusã pânã la spãlarea la rece ( ).
Maºina va împiedica în mod automat de a alege o temperaturã mai mare decât maxima admisã pentru fiecare program.
Alegerea programului de uscare
Rotind selectorul U CARE se determinã modalitatea de
uscare doritã. unt prevãzute douã posibilitãþi:
A - În funcþie de duratã: de la 40 la 180 de minute.
B - În funcþie de umiditatea rufelor:
Cãlcare : rufe puþin umede, uºor de cãlcat.
Uscate : rufe uscate de pus în dulap.
Dulap : rufe foarte uscate, indicatã pentru prosoape ºi
halate de baie.
Dacã, în mod excepþional, cantitatea de rufe de spãlat ºi uscat este superioarã cantitãþii maxime prevãzute (vezi
tabelul progra elor), efectuaþi spãlarea, iar la terminarea programului, împãrþiþi cantitatea de rufe în mai multe pãrþi ºi
uscaþi-le separat.
Urmaþi apoi instrucþiunile prevãzute pentru efectuare programului Doar uscare.
Repetaþi aceleaºi operaþiuni pentru rufele rãmase.
N.B: Dupã încheierea programului de uscare, maºina va efectua o rãcire, chiar dacã selectorul de U CARE este
adus în poziþia .
Doar uscare
Rotiþi selectorul de PROGRAME într-una din poziþiile de uscare (11-12-13) disponibile, în funcþie de tipul de
material; selectaþi apoi modalitatea de uscare doritã, cu ajutorul selectorului de U CARE.
Funcþii
Diferitele funcþii de spãlare prevãzute pentru maºina de spãlat, permit obþinerea unor rufe curate ºi albe, dupã dorinþã.
Pentru a activa funcþiile:
1. apãsaþi tasta corespunzãtoare funcþiei dorite;
2. aprinderea ledului respectiv indicã activarea funcþiei.
Notã: emnalul luminos intermitent, rapid, indicã faptul cã funcþia respectivã nu este compatibilã cu programul ales.
Pornirea întârziatã
Întârzie pornirea maºinii cu pânã la 9 de ore.
Apãsaþi de mai multe ori pânã la aprinderea butonului cu întârzierea doritã. La a cincea apãsare a tastei, funcþia se
va dezactiva.
N.B.: Dupã apãsarea tastei TART/PAUZÃ, se va putea modifica întârzierea doar diminuând-o.
e poate activa pe toate programele.
Clãtire suplimentarã
electând aceastã opþiune, clãtirea va fi mai eficientã, ceea ce asigurã eliminarea totalã a detergentului din
rufe. Este recomandatã cu precãdere persoanelor cu pielea sensibilã.
Nu poate fi activatã pe programele 4, 5, 11, 12, 13, B, C.
Super spãlare
Mulþumitã utilizãrii unei cantitãþi mai mari de apã în faza iniþialã a ciclului ºi duratei de timp îndelungate,
aceastã funcþie garanteazã o spãlare de mare performanþã.
Nu poate fi activatã pe programele 4, 5, 6, 9, 10, 11, 12, 13, A, B, C.
1000-500
Apãsând aceastã tastã se reduce viteza de stoarcere.
Nu poate fi activatã pe programele 9, C, 11, 12, 13.
Personalizare
Tipul
þesãturii
Tipul sarcinii Sarcinã
max (kg)
Dulap Uscate Cãlcare
Bumb c Rufe de diverse dimensiuni,
Proso pe din bumb c eponj t 5 180 170 160
Sintetice Ce rº f, Cãmãºi, Pij m le,
ºosete, ecc. 3 180 170 160
Lânã 1,5 150 140 130
Tabel Duratã Uscare (valori indicative)

20
RO
Detergenþi ºi rufe albe
Compartimentul pentru detergenþi
Un rezultat bun la spãlare depinde ºi de dozarea
corectã a detergentului: excesul de detergent nu
garanteazã o spãlare mai eficientã, ci contribuie la
deteriorarea pãrþilor interne ale maºinii de spãlat ºi
la poluarea mediului înconjurãtor.
 Nu introduceþi în maºinã detergenþii pentru
spãlarea manualã deoarece formeazã prea multã
spumã.
Deschideþi
compartimentul pentru
detergenþi ºi introduceþi
detergentul sau aditivul
dupã cum urmeazã:
compartiment 1: Detergent pentru prespãlare
(sub formã de praf)
Înainte de a adãuga detergentul verificaþi ca sertarul
adiþional 4 sã nu fie introdus.
compartiment 2: Detergent pentru spãlare
(sub formã de praf sau lichid)
Detergentul lichid trebuie vãrsat doar înainte de pornire.
compartiment 3: Aditivi
(soluþie de înmuiat, balsam rufe etc.)
oluþia de înmuiat nu trebuie sã iasã deasupra
grãtarului.
compartiment adiþional 4: Decolorant (Inãlbitor)
Ciclu de albire
Albirea poate fi efectuatã numai cu programele 1,2,6.
Turnaþi decolorantul în compartimentul adiþional 4, iar
detergentul ºi balsamul de rufe în compartimentele
corespunzãtoare, apoi alegeþi unul din ciclurile descrise
mai sus. Este indicat numai pentru articole din bumbac
foarte murdare.
Pregãtirea rufelor
 ortaþi rufele în funcþie de:
- tipul de material / simbolul de pe etichetã.
- culori: separaþi rufele colorate de cele albe.
 Goliþi buzunarele ºi controlaþi nasturii.
 Nu depãºiþi valorile indicate, referitoare la
greutatea rufelor uscate:
Þesãturi rezistente: max 7 kg
Materiale sintetice: max 3 kg
Þesãturi delicate: max 2 kg
Lânã: max 1,5 kg
MAX
12
4
3
Cât cântãresc rufele?
1 cearceaf 400-500 g.
1 faþã de pernã 150-200 g.
1 faþã de masã 400-500 g.
1 halat de baie 900-1.200 g.
1 prosop 150-250 g.
Articole delicate
Mãtase: utilizaþi programul special 9 pentru spãlarea
articolelor din mãtase. e recomandã folosirea unui
detergent special pentru articole delicate.
Perdele: împãturiþi-le ºi aºezaþi-le într-o faþã de pernã
sau într-un sac de tip plasã. Utilizaþi programul 9.
Lânã: Hotpoint/Ariston este unica maºinã de spãlat
recunoscutã de Woolmark Company, care i-a acordat
Woolmark Platinum Care (M.0508), ca garanþie a
calitãþii de spãlare cu maºina a tuturor articolelor de
lânã, inclusiv a celor care au pe etichetã menþiunea a
se spãla manual . Cu programul 10 puteþi deci
spãla la maºinã, în cea mai mare siguranþã, toate
articolele din lânã (max. 1,5 kg) cu garanþia de a
obþine cele mai performante rezultate.
Sistemul de echilibrare a încãrcãturii
Pentru a evita trepidaþiile excesive, înainte de
stoarcere, cuva maºinii va distribui cantitatea de rufe
în mod uniform, centrifuga efectuând câteva rotaþii la
o vitezã mai mare decât viteza de spãlare. Dacã,
dupã numeroase încercãri, maºina nu reuºeºte sã
echilibreze greutatea, stoarcerea rufelor se va face
la o vitezã mai micã decât cea prevãzutã în program.
Dacã instabilitatea este prea mare, maºina va
distribui greutatea în locul centrifugei. Pentru a
favoriza o mai bunã repartizare a rufelor ºi
echilibrarea corectã a maºinii, se recomandã sã
introduceþi în maºinã atât articole mari cât ºi mici.
Antiºifonare
Aceastã funcþie întrerupe programul de spãlare
menþinând rufele la înmuiat în apã înainte de golirea
maºinii.
Poate fi activatã numai cu programul 9 (Mãtase/
Perdele) ºi serveºte la evitarea formãrii pliurilor.
Pentru a termina ciclul, apãsaþi tasta TART/
PAUZÃ.
