Hotpoint RN328HSA Manual

®
RN328H – Hotpoint Standard Range Hood
5-1/2
29-7/8
17-1/2
12
1-3/8" Typ.
8-5/16" Typ.
Center line
of hood
1-1/4
1-1/4
Optional top power
supply connection
1-1/8" Typ.
7-3/4
10
3-1/4
1/2
Rear power
supply connection
1-3/8" Typ.
8-5/16" Typ.
Center line
of hood
1-1/4
1-1/4
Optional power
supply connection
1-1/8" Typ.
7-3/4
5-3/4
WB02X9381 replacement grease filter and WB02X10700 replacement charcoal
filter are available for additional cost. Call toll-free 800.626.2002.
JXHC1 Cord Kit: Allows a receptacle in the cabinet over the range to accommodate
either an over-the-range microwave oven or a standard hood.
Installation Information: Before installing, consult installation instructions,
packed with product, for current dimensional data.
Model JN327
Center
line of hood
1-1/4
1-1/4
Optional power
supply connection
Exhaust outlet
1-1/8" Typ.
7-3/4
1-3/8" Typ.
8-1/4" Typ.
Dimensions (in inches)
KW Rating
120V 2.5
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center® service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
Specification Created 1/04
430300

®
Specification Created 1/04
430300
Features and Benefits
• Non-Vented – Effectively filters smoke and vapors through the hoods filtration system.
• Cooktop light – Provides light to illuminate cooking surface below hood.
• Removable carbon filter – Odor absorbing activated charcoal filter can be easily replaced.
• Round ducting – Hood is designed to fit standard round duct work.
• Model RN328HSA – Silver metallic
RN328H – Hotpoint Standard Range Hood
RN328SHSA
