Hotpoint Aquarius Plus+ WD640P Operating and installation instructions

Information
Indesit Company Ltd
© 2007 Reg. Office: Peterborough PE2 9JB. Registered in London: 106725
Service
Hotpoint
Aquarius Plus+
Washer Dryers
Model Commercial
Code
WD640P 31130
WD640G 31131
WD640T 31129
WD645A 31132
with '3 phase' Motor
5407187 Issue 8 March 2007

2
SAFETY NOTES & GENERAL SERVICING ADVICE
1. This manual is NOT intended as a comprehensive repair/maintenance guide to the appliance.
2. It should ONLY be used by suitably qualified persons having technical competence applicable
product knowledge and suitable tools and test equipment.
3. Servicing of electrical appliances must be undertaken with the appliance disconnected (unplugged)
from the electrical supply.
4. Servicing must be preceded by Earth Continuity and Insulation Resistance checks.
5. Personal safety precautions must be taken to protect against accidents caused by sharp edges on
metal and plastic parts.
6. After servicing the appliance must be rechecked for Electrical Safety. In the case of appliances which
are connected to a water supply (i.e.: Washing Machines, Dishwashers & Food Centres etc.) checks
must be made for leaks from seals gaskets and pipe work and rectification carried out where
necessary.
7. It can be dangerous to attempt 'DIY' repairs / maintenance on complex equipment and the Company
recommends that any problem with the appliance is referred to its own Service Organisation.
8. Whilst the Company has endeavoured to ensure the accuracy of the data within this publication they
cannot hold themselves responsible for any inconvenience or loss occasioned by any error within.
9. This appliance is manufactured with a '3 phase' motor and uses a different type of power
module.
This power board is fitted with a large aluminium heat sink which remains live after the power
is disconnected.
Under no circumstances should the board be removed under the time shown below in Fig 1.
Alternative 'quick methods' of discharging the board SHOULD NOT be used or attempted !
IMPORTANT SAFETY NOTE
Risk of Electric Shock
The metal heatsink fitted on the
Power Module may hold an
electrical charge for a short period
after switching off the machine.
Allow 5 minutes after
disconnecting the machine from
the electrical supply before
commencing ANY work.

3
INDEX
Safety & Servicing Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Manufacturing Date Code Chart / Serial Number Explanation . . . . . . . . . . . . . . . . . . . . . . .4
Development History. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 9
Console Display, Controls, Demo Mode & Programmes. . . . . . . . . . . . . . . . . . . . . . . 10 - 16
Three Phase Power Module Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Three Phase Motor Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Wiring Details
Wiring Connections & Wiring Diagram - Before D.C. 40 . . . . . . . . . . . . . . . . . . . 19 - 20
Wiring Connections & Wiring Diagram - After D.C. 39, Before Date Code 45 . . 21 - 22
Wiring Connections & Wiring Diagram - After D.C. 46 . . . . . . . . . . . . . . . . . . . . 23 - 24
Wiring Connections & Wiring Diagram - After Serial No. 60508.0000. . . . . . . . . 25 - 26
Wiring Diagram Legend. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
EEProms & Diagnostics & Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 - 32
Dismantling Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 - 41
EEProms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

4
MANUFACTURING DATE CODE REFERENCE CHART
This example shows that the machine was manufactured in May 2003:
SERIAL NUMBER / INDUSTRIAL CODE EXPLANATION
1986 1987 1988 1989 1990 1991 1992 1993
1994 1995 1996 1997 1998 1999 2000 2001
2002 2003 2004 2005 2006 2007 2008 2009
Jan 01 13 25 37 49 61 73 85
Feb 02 14 26 38 50 62 74 86
March 03 15 27 39 51 63 75 87
April 04 16 28 40 52 64 76 88
Ma
y
05 17 29 41 53 65 77 89
June 06 18 30 42 54 66 78 90
Jul
y
07 19 31 43 55 67 79 91
Aug 08 20 32 44 56 68 80 92
Sept 09 21 33 45 57 69 81 93
Oct 10 22 34 46 58 70 82 94
No
v
11 23 35 47 59 71 83 95
Dec 12 24 36 48 60 72 84 96
Date Code 17 120054
Serial Number Example
3 10 02 0895
Four remaining digits = Build number that day 895th built
Third two digits = Day of manufacture 2nd of month
Second two digits = Month of manufacture October
First digit = Year of manufacture 2003
Industrial Code Example
37 24455 0010
Last four digits = 0000 original production.
Second five digits = COMMERCIAL CODE*
First two digits = Factory of origin
* Vital for correct model information and system identification
Other numbers denote major production changes

5
DEVELOPMENT HISTORY
September 2004 Aquarius Plus+ versions WD640 / WD645 enter full production.
Date Code 33
April 2005 Models WD640 & WD645
Date Code 40 Change to Cold Fill and deletion of heater box fluff filter.
On 25th April 2005 (Date Code 40), this range of washer dryers changed from
Hot and Cold Fill to Cold Fill only. Along with this change a modification was
made to the tumble dryer heater box assembly with the introduction of a
straight heating element, this to improve the air flow through the heater box.
This change enables the removal of the heater box fluff filter and deletion of the
flushing valve and hose. The thermistor, one-shot cut out and fan assembly are
not affected. The 4-way valve is replaced by a 3-way valve and the hot supply
hose is deleted.
A new file setting (EEPROM) is used for cold fill machines but the consumer
programmes remain the same for both Hot and Cold and Cold fill machines, the
changes to the heater box assembly does not effect the EEPROM file settings.
All parts that are affected with these changes are listed on Partfinder along with
a Special Notice.
October 2005 Models WD640 & WD645
Date Code 46 Change to 3.5 software along with a new PCB and programme settings file.
The dryer heater box connections J10 also changed with the introduction of the
new PCB. The fan motor connections move from J10 connector to a separate
connection on J16.
May 2006 Models WD640 & WD645
S/N 60508.0000 Re-introduction of flushing valve style heater box assembly.
On 8 May 2006 (Serial Number 60508.0000) the flushing valve and fluff filter
was re-introduced in production, along with spiral element, metal fan,
externally mounted dryer motor and thermal fuse cable which is attached to the
heater box upper casing in place of the one shot cut-out device.
A new file setting (EEPROM) was introduced for quality improvement during
this period. The Cotton fabric drying cycle heat default setting originally Low
Heat has changed to High Heat.

6
SPECIFICATIONS
Models Covered WD640, WD645 Washer Dryers
Colours P = Polar, G = Graphite, T = Sandstone, A = Aluminium
Country of Origin Great Britain
Electrical Supply 230 Volts AC @ 50Hz Fuse 13amp
Energy Energy Class: B
Washing Performance Class: A @ 40°C
Energy Consumption 1.02 kWh / Cycle @ 60°C Cotton
Water Consumption 55 litres @ 60°C Cotton
Wash Load 6 kg Cottons
Washing & Drying Load 5.0 kg Cottons
Spin Speed 1400 rpm maximum
Control PCB 220/230Volt 50/60Hz Type Merloni EVO 2
Wash Heater 1800 Watts @ 230 volts Resistance 30 Ω approx.
Dryer Heater 1200 Watts @ 230 volts Resistance 43 Ω approx.
Thermistor NTC - Wash Resistance: 20 KΩ@ 20°C
Thermistor NTC - Dryer Resistance: 26 KΩ@ 20°C
Water Supply Hot & Cold Valves - Coil Resistance 3.8 KΩ
Max Pressure = 1 Mpa (10bar)
Minimum Pressure = 0.05 Mpa (0.5bar)
Motor - Wash 3 Phase 230V 50Hz AC
Motor - Dryer Fan 230 Volt 50 Hz Resistance approx. 45 Ω
Pump 2 Pole Synchronous
220 / 240 Volt 25 Watt, Resistance = 165 Ω
Maximum Head 1.4 metres
Flow rate @ 0.9 metres / 30 Litres per minute
Door Lock P.T.C. Bimetallic - Time Delay approximately 2 minutes
Torque Settings Outer Drum = 8Nm
Upper Balance Weight = 18 Nm
Lower Balance Weight = 24 Nm
Heater Box to Drum = 12Nm
Heater Box Top to Bottom = 8Nm
Dimensions Height 850 mm Width 595 mm
Depth 600 mm Weight 66 kg. Packed approx. 69 kg

7
INSTALLATION
Unpacking
1. Unpack the washing machine.
2. Check whether the washing machine has
been damaged during transport. If this is
the case, do not install it.
Remove the polystyrene base
The vertical block part of the base (see below)
should have stayed intact when the base was
removed. If it has broken off and is still inside
the machine, carefully lay the machine on its
side, onto the polystyrene top cap and then
remove the block.
Warning:
Packaging materials are not childrens toys.
Remove the transit fixings
Follow these instructions to remove the TWO
transit fixings. IMPORTANT: Situated one either
side of the rear panel, both transit bolts
(complete with spacers) MUST be removed
before use.
Failure to do so may cause damage to the
machine!
1. Use a crosshead
screwdriver to
remove the plastic
cover.
Vertical block
polystyrene
base
For safety, replace both plastic covers over
the holes left by removing the two bolts.
Levelling
1. Install the washing machine on a flat sturdy
floor, without resting it up against walls,
cabinets etc.
2. Compensate for any unevenness by
tightening or loosening the adjustable front
feet. The angle of inclination, measured
according to the worktop must not
exceed 2°.
Levelling the appliance correctly will provide it
with stability and avoid any vibrations, noise
and shifting during operation. If it is placed on
a fitted or loose carpet, adjust the feet in such
a way as to allow enough room for ventilation
beneath the washing machine.
2. Unscrew the bolt
using a 13 mm
spanner.
3. STOP when 3
threads can be
seen.
4. Hold, slide and pull
to remove.
! It is important the
transit bolt and
spacer come out
intact
(see image left).

8
Connecting to the Water Supply
WARNINGS:
The temperature of the hot water supply
should ideally be 60°C and no higher than
70°C as this could cause damage to the
laundry and the machine. Applies to
products produced prior to D.C. 40.
Do not connect the machine to a single
outlet instantaneous water heater.
The hot and cold water pressure should be
between 3 and 150 psi (21 - 1034 kPa).
Incorrect pressures could lead to flooding.
The water supply taps should be accessible
when the machine is installed.
Before connecting the fill hoses, check that
water is running from the water supply taps
you will use for the machine.
Connect the washing machine to the water
supply using the fill hoses fitted to the
machine.
Do not use old hoses.
Hot & Cold Fill - Cold fill only from D.C. 40
1 Unclip the grey and blue fill hoses from the
back of the machine.
2 Connect the free end of the grey fill hose
to the HOT water supply (see Fig. 1).
Connect the free end of the blue fill hose
to the COLD water supply.
3 Turn on the water supply and check for
leaks. If there is a leak, turn off the water
supply, remove the connector and check
that the sealing washer is in place.
Refit the connector and tighten it.
Turn on the water supply.
4 When moving the machine into its final
position, make sure that the hoses are not
trapped or kinked.
Fig. 1 Fig. 2
If the fill hoses are too short:
Longer fill hoses are available. Remove the
existing fill hoses from the inlet valves on the
back of the machine and fit the new longer fill
hoses as shown above with the angled ends of
the hoses connected to the machine
(see Fig. 2).
If no hot water supply is available or the hot
water pressure is low, a cold fill adaptor
(Fig. 3) and fitting instructions are available.
Applies to products produced prior to D.C. 40.
Electrical Connections
Before plugging the appliance into the
mains socket, make sure that:
- the socket is earthed and in compliance
with the applicable law.
- the supply voltage is included within the
values indicated in the Specifications page.
- the socket is compatible with the washing
machines plug. If this is not the case,
replace the socket or the plug.
Location
! The washing machine should not be
installed in an outdoor environment, not
even when the area is sheltered, because it
may be very dangerous to leave it exposed
to rain and thunderstorms.
! When the washing machine is installed, the
mains socket must be within easy reach.
! Do not use extensions or multiple sockets.
! The power supply cable must never be bent
or dangerously compressed.
! The power supply cable must only be
replaced by an authorised engineer.

9
DRAINAGE CONNECTIONS
Take care when you remove the drain hose
from the clips on the back of the machine.
All machines are tested with water before they
leave the factory so a small amount of water
may still be in the hose.
Do not remove the hooked end support from
the GREY drainage hose when using any of
the drainage methods detailed below.
You may need to reposition it as required
along the drainage hose.
For drainage into a standard work top sink,
ensure the outlet pipe has a minimum
diameter of 32 mm. If the sink is inset, the front
edge of the basin must be less than 75 mm
from the front edge of the worktop, so that the
drain hose will hook securely into the sink.
Unclip the drainage hose from the back of the
machine and hook over into the sink. Make
sure that the sink is free of any obstructions
and that the sink plug can not fall into the sink,
preventing the water from draining away
freely. Pumped out water may be very hot.
We recommend one of the following drainage
methods:
Stand pipe Fig. 1 1 Make sure that the
standpipe has a
minimum diameter
of 38 mm.
2 Remove the
drainage hose from
the clips on the
back of the
machine.
3 Make sure that the
top of the standpipe
is positioned at
least 500 mm from
the floor (see
Fig.1).
Use the plumbing
indicator line label
on the back of the
machine as a
guide.
4 Place the drainage hose approximately
100 mm into the standpipe.
500 mm
Extending the drainage hose
If the GREY drainage hose is too short, a
longer drainage hose is available from our
Genuine Parts & Accessories Mail Order
Hotline.
WARNING!
The company denies all liability if and when
these warnings are not respected.
The first wash cycle
Once the appliance has been installed and
before you use it for the first time, run a
wash cycle without detergent and no
laundry, setting the 90°C programme
without a pre-wash cycle.
Under Sink
Waste System
Fig.2
Fig.3
1 Cut out the
membrane, bung or
blanking plug (see
Fig. 2).
2 Unclip the drainage
hose from the back
of the machine.
3 Move the hooked
end support along
the drainage hose
as required.
4 Attach the drainage
hose securely to
the under sink
drainage unit, using
a hose clip (see
Fig. 3).
5 Raise the hooked
end support uptoat
least 800 mm to
avoid water being
drawn back into the
machine.
cut
off
end
Hose clip

10
CONSOLE PANEL
On-Off / Selecting a Programme
The machine is switched on by pressing the 'On/Off' button for 3 seconds. All the indicator lights will
light up for a few seconds and the 'Door Locked' indicator light will flash once.
Turn the programme selector dial to the desired programme. Load the laundry and detergent.
Select the options you require.
Press the 'Start/Cancel' button for 3 seconds to start the programme.
To Stop or Change a Programme
Press the 'Start/Cancel' button for 3 seconds. Select 'Pump Out' on the programme selector dial.
When the machine has finished emptying, turn the programme selector dial to the new programme.
Press the 'Start/Cancel' button to start the programme.
If you cancel a hot wash programme, take care when removing the laundry, it might still be very hot.
Progress Indicator Lights
These will light up when you choose a programme, to indicate the progress of the selected
programme. When started, the first light in the cycle will stay lit and as the programme progresses,
successive lights will come on until the programme finishes.
Door Locked Indicator Light
The 'Door Locked' indicator light will come on two seconds after you press the 'Start/Cancel' button
and will stay lit throughout the both Wash and Drying programmes. A short time after the
programme has finished the indicator light will go out and you can then open the door.
Selected programmes will not start if the door is not closed properly, the 'Door Locked' indicator light
will flash to show this. Push the door shut until you hear the catch click.
Option
Buttons Door Locked
Indicator Light
Programme
Listing Progress Indicator
Lights
Variable
Temperature Variable
Spin Programme
Selector
Digital
Display
On/Off
Start/Cancel

11
Button Selection:
To select an option, press the button and you will see a light come on alongside the button.
Press again to cancel, and the light will go out.
Display Error Message
The display will show an message in the display if there is one of the following problems:
H20 A problem with the water supply. Check the taps are turned on and working.
door Please close the door properly.
F000 This indicates a machine fault - this is an Error Code.
The 'F' number will vary depending on the fault. Refer to Error Codes.
Options are selected by pressing the button and confirmed by illumination of the LED.
Drying High Heat
The original default setting was LOW heat. By selecting this allows HIGH heat for tumble drying.
From Serial Number 60612.0000 (Date Code 54), the Eeprom file settings changed. The default
setting is now HIGH heat and will be indicated on the option LED. If High heat is not required this
option must be deselected.
Reduced Creases
Changes wash action and slightly increases drum speed on cotton programmes and removes end
of wash spin with a reduced speed on final spin on synthetic programmes.
Available on programmes C, E, G, and Rinse and Spin programmes.
Rinse Hold
Clothes will be suspended in cold water at the end of the final rinse. To complete the programme,
press the button when the LED is flashing.
This option is not available on programmes A, H, L and Spin only.
Time Saver
Saves programme time by up to a third depending on programme selected and is achieved by
reducing wash run times.
This option is only available on programmes B, D, G and H.
Time Delay
This option can delay the start of your wash programme by up to 24 hours.
The display will show the delay you have chosen.
Each press of the option button will add a delay of one hour. If you press after 24 shows on the
display the machine will reset the time delay and show 'OFF' in the display, any press after this will
start counting again from one hour.
Variable Wash Temperature Control - Selected by Push Button
Enables a lower wash temperature and No Heat to be selected by pressing the button.
Note: The display defaults to the maximum temperature for the programme selected.
Variable Tumble Drying Time
Enables the required drying time to be chosen.

12
CONTROLS INFORMATION
A single control board located at the back of the machine contains all the circuitry to control the
machine and interfaces with the programme selector, option buttons and LEDs located on the
console panel. The control board has an access port to the rear of the machine to enable
programming and diagnostic checks to be carried out.
Programmes are selected by turning the rotary switch to one of the 16 positions a rotary switch.
Special options can be selected by pressing the appropriate buttons and the programme process
followed by LEDs.
The machine is switched on using the On/Off button and selected programmes started by pressing
the Start/ Cancel button.
AUTOMATIC FEATURES
Auto Half Load
Auto half load adjusts the amount of water in the wash load depending on the absorbency of
garments in the wash load.
Fabric Conditioner Dispensing
Dispensing of fabric conditioner is achieved by energising both the Pre-Wash and Main Wash
cold valves
Out of Balance Protection
The machine has an inbuilt feature to prevent spinning with an unbalanced load. A calculation
via the motor tacho and control board detects the current drawn by the motor during
distribution.
Before each spin, the controls senses the load within the drum and if the load is calculated to be
out of balance the machine will not automatically spin to the full speed.
There are two levels of out of balance, level 1 @ 480 grams and level 2 @ 1030 grams.
If the out of balance is below level 1 the machine will spin at full speed, if between level 1 and
level 2 the machine will spin at the reduced speed of 600 rpm and above level 2 spin at reduced
speed of 400 rpm. There are 15 attempts at level 1 with 57 attempts in total, this being the same
for both cotton and synthetic spins.
The wool spin has one level of out of balance @ 1.8Kg. The controls will make three attempts to
achieve a balance, if after three attempts a balance is not achieved; the spin is reduced to a
speed of 90 rpm.
DEMO MODE
To Activate
1. From the Default screen of a programme after switching the appliance on press both
'Start /Cancel' and 'On / Off' buttons together until 'd ON' appears in display.
2. Press the 'Start / Cancel' button only and t ES t appears in the screen. (Temp and Spin
symbols also appear.)
To Deactivate
1. Press the 'Start /Cancel' button until ALL the console LEDs illuminate.
2. Press both 'Start /Cancel' and 'On / Off' buttons together until 'd OFF' appears.
3. The Default screen returns and you can select a new programme.
Note: Default Screen
The default screen information displayed on these models is that of the programme currently
selected by the selector knob.

13
THE CONDENSER TUMBLE DRYING PROCESS
The drying process is by means of a closed air system driven by a circulating fan. Air is drawn
internally from the rear of the outer drum, passed over a heating element and returned to the front of
the drum via an inlet through the door seal. The warm air travels through the wash load collecting
moisture, the moist air then condenses on a stream of cold water running down the inner rear section
of the outer drum. The relatively dry air is then drawn back over the element to repeat the process.
The circulating fan, one shot cut-out or thermal fuse cable along with a thermistor to control the air
temperature are located in a heater box assembly attached to the top of the outer drum.
The airflow passes through a filter located within the air duct from the outer drum to the heater box
assembly. At the start of every drying program the filter is automatically cleaned by flushing water
through it by means of a fill valve wired in parallel with the hot fill valve for 5 seconds duration.
On products produced from April 2005, Date Code 40, the filter flushing hose was deleted.
On products produced from May 2006 (Serial No. 60508.0000), the flushing valve system was
re-introduced. See notes on Page 5.
The water supply for the condenser is by means of a direct feed from a cold inlet valve to the rear of
the outer drum and is pumped out approximately every 30 seconds.
The closed air system is sealed by a 'P' trap located within the dispenser inlet hose.
The hose is topped up with cold water every 8 minutes for a duration of 1 second.
There are two heat settings, high and low heat. The default setting is high heat, low heat is selected
by means of a push button on the console. The drying time is selected by means of a rotary switch
also located on the console. The drying times are followed by a 20 minute cool tumble.
Thermal Spin
A thermal spin on the High Heat setting is carried at the start of the of the drying process. The load
is pre-heated to approximately 50°C by the dryer heater with normal tumble action and pump out.
Thethermistorlocatedin the washheater willsense theload temperatureand when 50°Cis achieved
a 5 minute Spin profile will be carried out at full spin speed.
During thermal spin the out of balance detection will operate and maximum speed will only be
achieved depending on the out of balance condition.
On completion of the Thermal Spin, the tumble drying process will commence for the period of time
selected.
Thermal spin is NOT available when low heat is selected.
Warm Humid Air
Cold Dry Air
Warm Dry Air
Airflow Diagram

14
Flushing Valve Operation
During Rinse phase: 2 xs for 15 seconds
Drying Phase: 1 x before drying phase for 4 seconds
End cycle: After drying phase, during cool down phase
Valve Off for 118 seconds
Valve On for 2 seconds
Beginning of Drying Cycle
Wash valve: On for 1 second to put water into dispenser hose
Flushing valve: On for 4 seconds
Drain pump: On for 20 seconds
During Drying Cycle
Drain pump: On for 9 seconds and off for 21 seconds
Wash valve: On for 2 seconds and off for 510 seconds to put water into dispenser hose
Condenser valve: On continuously after thermo spin

15
DRYING
SETTING THE DRYING PROGRAMME
Independent Drying only Programme:
1. Remove the wet laundry and in the drum the dosing ball (if used) until the correct drying weight
load (see Drying Table below) is left in the drum.
Close the door until it clicks shut.
2. Turn the programme selector dial to Drying Programme M (see Programme Table overleaf).
3. Set the required drying time or autodry (see Drying Option below).
4. When all selections have been made press the Start/Cancel button. The door will lock.
5. A short time after the programme has finished the 'Door Locked' indicator light will go out and
the door can be opened.
Drying Option
•Timer Drying programmes:
Where you can select the length of the drying time suitable for your load.
Aquarius+- Press the Drying Times button twice and '3' will appear in the display, indicating 3
hours drying time.
- Each subsequent press of the Drying Times button will reduce the drying time
shown in the display in 30 minute increments until '1' (1 hour) is displayed.
- Pressing the Drying Times button again after '1' is displayed cancels the drying
programme, 'Off' will appear in the display, no drying programme is selected.
•Auto Drying programme 'Sensor Dry'
When selected the machine will automatically sense when the laundry is dry and switch off.
- Press the Drying Times button, 'Auto' will appear in the display.
Drying Table *For smaller loads reduce the drying time accordingly.
It is recommended that you separate your drying loads into similar fabric types, as this will increase
the drying efficiency.
Fabric Programme Dry Weight Load Heat Setting Time Setting*
(Approx.)
Cottons B, C, D, E & F
5 kg
4 kg
3 kg
2 kg
1 kg
max. 180 minutes
max. 153 minutes
max. 134 minutes
max. 106 minutes
max. 87 minutes
Synthetics G & K 3 kg 2 kg
1 kg
max. 120 minutes
max. 95 minutes
max. 70 minutes

16
PROGRAMME TABLE
ID Label Programme Type / Fabric Description Temp Max Load Approximate Soil Spin Aquarius + Recommended
(˚C) (kg) Programme Time Level Speed Available Options Detergent
(h : min)
APPrewash A cool temperature cycle to loosen stains before selecting 30 6 0 : 20 Heavy - Ariel Bio Liquid
Mixed a main wash programme.
B95 Hygienic For hard wearing heat resistant cotton and linen. 95 6 2 : 30 Norma l Max
Drying High Heat, Rinse Hold, Ariel Bio Powder /
White Cotton
Time Saver, Time Delay Tablets
C60 Superwash An intensive cleaning programme for heavily soiled har 60 5 2 : 2 0 Heavy Max
Drying High Heat, Reduce Creases,
Ariel Colour
Colourfast Cotton wearing fabrics.
Rinse
Time Delay
Hold, Time Delay
D60 Standard An intensive cleaning, energy ecient cycle using the 60 6 2 : 00 Normal Max
Drying High Heat, Rinse Hold, Ariel Colour
Colourfast Cotton (IEC 60456*) maximum load capacity.
Time Saver, Time Delay
E60 Fast Wash A fast cycle for lightly soiled heat resistant cotton & linen 60 5 1 : 00 Light Max
Drying High Heat, Reduce Creases,
Ariel Colour
Colourfast Cotton fabrics.
Time Delay
F60 Standard A less energy ecient intensive 40˚C cycle for more 40 6 1 : 45 Normal Max
Drying High Heat, Rinse Hold,
Ariel Colour
Non Colourfast Cotton stubbor n soiling.
Time Delay
G40 Man-made fibres A cycle designed to wash a variety of man-made bres 40 3 1:05 Normal 800
Reduce Creases, Rinse Hold, Ariel Colour
Coloured Synthetics & Acrylics and bre mixtures.
Time Saver, Time Delay
H40 Gold Woolmark Approved A special cycle for Hand Wash wool that will not shrink 40 1 0 : 45 Normal 600 Dreft
Handwash Wool your garments exclusively approved by Woolmark.
J40 - Machine Washable For silk garments labelled as machine washable. 30 3 0:55 Normal 8 00
Rinse
Time Delay
Time Delay
Time Delay
Time Delay
Time Delay
Hold, Time Delay
Dreft
Silk
K30 Fast Wash A very short refresh programme for lightly soiled mixed 30 3 0 : 30 Light 800 Ariel Colour Liquid
Mixed fabrics.
(not Wool/Silk/Handwash)
LHHandwash A gentle cycle for delicate items labelled as Hand Wash 25 4 0 : 5 0 Normal 400 Ariel Colour Liquid
.ylnosetacileD
(not Wool/Silk)
MDrying Aquarius +: 5/3 - - Special
Drying High Heat, Time Delay
-
Cottons (HIGH heat) temperatu
Select an auto drying programme and
choose the level of dryness you require.
re for the items you wish to dry.
Synthetics (LOW heat)
R&S -Rinse & Spin This partial programme completes two full rinses and then -3 0:25 - 800
Reduce Creases, Time Delay
-
Mixed a
nal spin.
nal spin.
slow spin.
Select the drying time and Hi/Lo
FS -Fast Spin This partial programme completes the maximum speed - 6 0:15 -Max -
Cotton
SS -Slow Spin This partial programme completes the intermediate speed - 3 0 : 10 - 800 -
Delicates
PO DPump Out This partial programme ensures the appliance is emptied -6 0:02 --- -
All of water.
2 Bath Towels
6 Shirts
6 Blouses
2 Set of Pyjamas
4 Items of Underwear
2 Pillow Cases
COTTON
=5kg =3kg
3Children’sDresses
5 Shirts
6 Blouses
2 Set of Pyjamas
4 Items of Underwear
SYNTHETIC
Two examples of maximum DRYING loads for different fabric:
2 Bath Towels
1 Hand Towel
6 Shirts
6 Blouses
1 Set of Pyjamas
4 Items of Underwear
COTTON
=6kg =3kg
2 Children’s Dresses
4 Shirts
4 Blouses
1 Set of Pyjamas
4 Items of Underwear
SYNTHETIC
Two examples of maximum WASH loads for different fabric:

17
THREE PHASE POWER MODULE LAYOUT
Auto Test
Connections
Live Heatsink
Warning !
Refer to
Safety Notes
EEPROM Identification
Production
EEPROM SERVICE
EEPROM
Note: only one of the eeproms
shown in the inset will be fitted

18
THREE PHASE MOTOR
These washing machines are equipped with three-phase motor.
Compared with the commutator motor there are no brushes and the stator is delta connected
internally (see diagram).
The three-phase motor has a thermoprotector that cuts in turning off the supply to the power part of
the electronic card and therefore to the motor.
The photo and diagram below give the connection diagram of the windings.
Motor Resistances
1-2 Motor Protector 0.0Ω
3-4 Winding 6.4Ω
3-5 Winding 6.4Ω
5-4 Winding 6.4Ω
6-7 Tacho 120Ω
Tacho
Tacho
Winding
Winding
Winding
Thermoprotector
Thermoprotector
Blank Receptacle

19
WIRING CONNECTIONS - Before Date Code 40

20
WIRING DIAGRAM - Before Date Code 40
5
4
3
2
1
21
21
1
OVERFLOW
N
L
12
1
14
11 16
1
5
R
R
TF
R
Test
14
3
1
2
23
4
1
2
34
C
34679
1
EMPTY
FULL
COMMON
GND
RX
SEN.COND
TG
12
R R
56
D
4
2
3
43 2
j5 j1 j3 j8 j9
j10
j2
j4
12A
12A
10A
10A
8A
10A
10A
1A
1A
T
6
7
4
5
3
EMI
Wash Motor
Thermal
Protector
10A
1
2
RTN_IP
RTN_PORTA
3 phase
Wash Motor
Motor Frame
100 Kohms
to Earth
via Input Filter
Black
Pump
Door
Interlock
Tacho
1
2
3
4
5
6
8
9 7
j11
1
2
34
5
12345
1
12
2
j14
j13
1
2
Mains Input
Filter Pressure
Switch
11
12
j12
VNR
12345
LCD
DISPLAY
Module
j15
GND
SCL
SDA
Vcc
12345.
j7
SDA
SCL
GND
Vcc
j15
NC
Wash
Thermistor Water Valves
EVL
EVP
L
P
1
2
1
22
2
1
EVC
C
1
10w
10w
10w
Lav.
1
2
*
12
HOT
Cold
Filter
Pre-Wash COLD
Main Wash
Note: COLD VALVES
Pre-Wash & Wash Valves are both
energised to provide fabric conditioner.
Condenser Tumble Dryer
V4_3 phase wiring
1
A
1
1
Asc.
3
3
3
1
3 4678
48w
10w
