Foreword
hotset's mobile D-System is a highly flexible and easy-to-use measuring device for in-situ analysis of the
energy balance of process water cycles. Wherever water circulates as a functional medium, this enables
rapid checking and visualization of flow rate, temperature progression and pressure differences. Some of
the applications of the D-System are troubleshooting, fine-tuning of fluid power processes, or monitoring
in the context of quality assurance. "Water is utilized for industrial purposes as a coolant and heating
medium, as a transport and hydraulic fluid, as an operating and drive medium, and even as a fuel
component. As a process optimization tool or mobile service tool, our D-System can therefore provide
valuable services in many industries.

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 5
Safety information
General instructions
Intended use
These operating instructions are intended to make it easier for the operator to understand and
operate the D-system.
They must be read prior to connecting the D-system, as they contain important information for
connection and operation.
The D-System includes at least one visualization and works only with one measuring module.
All electrical connections of the D-system are made by means of plug-in devices.

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 6
Symbols
Symbols –Display
USB port
Network connection (RJ45)
Measuring module connection (D-SUB15)
Power supply (3 pole, 5V DC)
I/O interface inputs/outputs (D-SUB9)
Symbols –Measuring module
Display connector (D-SUB15)
Medium connection inlet/flow (G3/4" inside)
Medium connection outlet/return (G3/4" inside)
Flow direction Medium

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 7
Component overview
Visualization with power supply
Dimensions (H x W x D) [mm] 240 x 190 x 85
Weight [kg] 2.7
Interface USB, WLAN, LAN
Display 7" LED TFT, 800 x 480 pixel
Operation Touch, max.10 fingers
Power supply 230 V / 5 V 50 Hz CE, power supply unit with 3 m
connection cable
Power consumption max. 15 W
Battery Lithium-Polymer, 12000 mA integrated.
The visualization includes a 7" touch screen with integrated rechargeable battery. The battery is
charged with the included power supply as soon as it is connected to the mains. The initial
charging time is about 2.5 hours. Once charged, the display can be used mobile for up to 4
hours, depending on the application, before it has to be charged again at the mains connection.
The supplied power supply has a power of 15 W at a voltage of 5 V. The use is exclusively
intended for 230 V/50 Hz networks.

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 8
Visualization
There are 5 ports with the following functions on the bottom of the visualization:
Mains connection for charging the battery and simultaneous voltage supply.
Symbol:
This plug-in connection is designed with 3 poles.
Only the supplied mains cable may be used to charge the battery.
The use of any other charging source may result in a fire hazard!

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 9
Connection of the connecting cable to the measuring module:
This is the communication connection to the measuring module. It transmits the measurement
data for visualization. This connection is 15-pole (D-SUB15).
Symbol:
USB port:
This port is suitable for USB storage media (USB stick), and can be written to with the log
function.
Symbol:

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 10
Network/LAN connection:
For integration into the local network, the connection can be established here with an RJ45
connector.
Symbol:
Digital inputs and outputs:
This connector is 9pin (D-SUB9) and serves as alarm output and synchronization/input.
Symbol:

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 11
Pin assignment of the D-SUB9
DI (digital inputs)
DO (digital outputs)
D-SUB9
D-SUB9
Uintern5V
3
Uext
1
DI1
8
DO1
6
DI2
4
DO2
2
DI3
9
DO3
7
GNDext
5
Connection cable visualization <-> measuring module
This connection cable is 15-pole and 3m long in the stand wheel.
Connection points:
Display
<->
Measuring module
Measuring module
The sensors for measurement data acquisition are integrated in the measuring module.
Dimensions (H x W x D) [mm] 225 x 190 x 85
Weight [kg] 5.5
Medium connection 4 x G 3/4" internal thread

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 12
Use of compressed air for emptying
ATTENTION! When using compressed air, the measuring components can be destroyed!
Measuring ranges of the components in the measuring box:
Measuring medium Water
Max. medium temperature 85 °C (short-term 95 °C)
Max. operating pressure at medium temperature over the service life 12 bar at +40 °C
over the service life 8 bar at +70 °C
Pressure measurement
Measuring range 0 –12 bar
Resolution 0.1 % of measuring range end
Measuring accuracy 0.5 % of measuring range end
Flow rate
Measuring range 1.8 –32 l/min
Measuring principle Piezoceramic sensor element
Measuring accuracy at < 50 % FS* (water) < 1 % FS*
Measuring accuracy at > 50 % FS* (water) < 2 % measured value
* Full scale (final value)
Temperature measurement
Measuring principle Resistance Pt1000
Measuring accuracy ± 0.3 K

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 13
Connection of the measuring module
There is a number or a flow symbol at each connection of the measuring module.
It is important that the flow direction is observed, otherwise incorrect measurements or
misinterpretation of the process may occur. The supply should always be on the side that is
shown (see connection 1). Observe the connection direction as follows:
Connection 1 or the arrow points into the circle
Here, the medium must flow into the measuring module. The inlet temperature T1 and the inlet
pressure p1 are measured in the measuring module.

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 14
Connection 2 or the arrow points out of the circle
The medium comes out of the measuring module at this connection point and can be
connected from here to a measurement object, such as an injection molding tool, heat
exchanger, etc.
It is also possible to make a direct connection from port 2 to port 3. This allows, for example,
pump capacities to be determined, or temperature control units to be calibrated.
Tip: Maximum pressure and flow values of the supply (observe maximum measuring range!) can
be tested if it is possible to integrate a valve for flow regulation in the hose connection from port
2to port 3.
Connection 3 or the arrow points into the circle
If the medium has flowed through the consumer/measurement object, it is connected to port 3.
The output temperature T2, output pressure p2 and flow rate q are measured in the measuring
module.

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 15
Connection 4 or the arrow points out of the circle
The medium has now flowed through all measuring points and, if applicable, the
consumer/measurement object and is now returned to the supply via port 4.

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 16
Connection diagram measuring module
In injection molding processes, we often use the terms flow and return. However, from the
observer perspective, this definition can be understood the other way around. Here, we show
the view from the measuring module's perspective. The side with the D-SUB15 or connection
point 1+4 is the supply side, i.e. the connection point where e.g. a temperature control unit,
cooling unit or similar conveying devices are connected. At the connection points 2+3 a
measurement object, e.g. a mold circuit, heat exchanger or other test objects is connected. If,
for instance, only a temperature control unit is connected to the supply side for testing, a direct
connection (hose bridge) can be used at connection point 2+3.
Feed
e.g. pump, temperature control unit, cooling system
Measurement object
e.g. injection mold, heat exchanger
1
2
3
4
Return
Flow

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 17
Operation of the measuring module
The position should always be selected below or at the same level as the measurement object
so that any air bubbles do not accumulate in the measuring module and lead to incorrect
measurements. Make sure that the system is well vented.
Measuring module
Measurement
object
Feed
Measurement
object
Feed
right
right
Measuring module
Measuring module
Measuring module
Measuring module
Measurement
object
Feed
Measurement
object
Feed
right
right
Measurement
object
Feed
wrong

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 18
Maintenance and water quality
Make sure that the medium is clean in order to avoid deposits such as lime, rust and dirt in the
measuring module. The water flowing through should be free of suspended particles and meet
the following requirements:
Min. –Max.
Unit
pH value
6.5 –9.5
-
Solid substances
free
mg/l
Electrical conductivity (20°C)
200 - 2000
µS/cm
Fe / Cu
0 - 1
mg/l
Total hardness
5 - 12
°dH
Using compressed air to clean or empty the measuring module can damage the measuring
components. Cleaning brushes or similar objects should also not be used to remove any
deposits. The individual components can only be cleaned carefully with a cloth once the
measuring module has been disassembled.
We recommend that you return the device to Hotset GmbH for maintenance and servicing.
Please contact us for this purpose:
Hotset GmbH
Hueckstraße 16
58511 Lüdenscheid / Germany
Office: [phone]
[email protected]

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 19
Battery display
The visualization can be charged and used at the same time. The capacity of the battery can be
checked by pressing the battery check button, or it is displayed in the program at the top right.
The battery level indicator can only be pressed when the display is already switched on.
Battery full
Battery medium
Battery low
Battery critical
The respective usage time depends on the power in the measuring box. During normal use, the
following operating times can be expected:
Operating time still
approx. 4 hours
Battery operation still
approx. 2 hours
Battery operation still
approx. 0.5 hours
Charge immediately!

D-System Operating Instructions
Hotset GmbH –Hueckstraße 16 –58511 Lüdenscheid, Germany –[phone] –[email protected] –www.hotset.com –04/2021 RS 20
Safety instructions battery
Read and observe all safety notes and instructions. Failure to comply with safety information
and instructions may result in electric shock, fire and/or serious injury.
The contents of lithium polymer battery cells are generally flammable under certain conditions.
▪Do not open the battery
▪Never remove the battery from the display case
▪Protect the battery from heat, fire, and immersion in water
▪Do not store or operate the battery near hot or flammable objects
▪Do not place the power plug or display near flammable materials
▪Only charge the battery when it is dry and in a fire-safe location.
▪Only charge the battery with the supplied hotset power plug
▪The battery must not be charged unattended
▪The rechargeable battery must not be subjected to mechanical stress
▪Vapors may escape if the rechargeable battery is damaged or used improperly.
Supply fresh air and consult a doctor if you experience any discomfort
Technical data:
Type: Lithium polymer
Rated voltage: 3.7 V
Rated capacity: 12,000 mA
Energy: 45 Wh
Operating temperature: +5…+40 °C
Storage temperature: +2…+50 °C
Permissible charging temperature range: +2…+40 °C
Maintenance and service
If the battery is no longer functional, please contact hotset.
The battery is subject to the requirements of dangerous goods legislation. When transported by
commercial users or third parties (e.g. forwarding agents), special requirements for packaging
and marking must be observed. Only ship the display with battery if the battery is undamaged.
