Lascar Electronics EasyLog EL-PDF-1 Series User manual

1. Your new logger comes ready to go.
Simply press and hold the button until the green LED lights up to start logging.
2. Now place your logger in the location you want to monitor.
Once logging, pressing the button will light up an LED to give a quick indication of the
status. It will also add a marker to the data to show that you have checked it.
No alarms will be triggered in the rst 30 minutes to allow the logger to settle at the
monitored conditions.
Red + Green single ash
Logger is ready to start new logging session Push Start / Stop button
Green single ash
The data logger is currently logging
No alarm has been triggered
No action required
Red single ash
The data logger is currently logging
An alarm has been triggered!
Check status in the PDF
Green double ash
The data logger’s memory is full or the logger has been
stopped. No alarm was triggered during the session.
Plug your logger in to a PC and download
the PDF
Red double ash
The data logger’s memory is full or the logger has been
stopped.An alarm was triggered during the session!
Plug your logger in to a PC, download the PDF
and check alarm condition
No LEDs ash
The data logger has a at battery Contact your distributor for a new logger
Preset high
and low alarm
levels
Status LEDs
Push to start/stopStatus mark
STA RTSTAT US
MARK STOP
CHILLED GOODS
EasyLog
EL-PDF-1 Series
QUICK START GUIDE
STA RTSTAT US
MARK STOP
CHILLED GOODS
EasyLog
STA RTS TATU S
MARK STOP
AMBIENT PHARMA
EasyLog
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 -
TestEquipmentDepot.com

EL-CC-1
Temperature
FOOD
EL-CC-2
Temperature/Humidity
FOOD
EL-CC-2
Temperature/Humidity
PHARMACEUTICAL
3. When you are ready to view the recorded data on your logger, press and hold the
button to stop the current logging session. Remove the logger from the plastic sleeve and
connect it to a USB port.
4. Copy the le off the device as if it were a memory stick.
5. Press the button to start a new data logging session. To maintain IP67 status,
the logger must be placed in Lascar’s accessory bag, EL-CC-BAG.
Other EasyLog Cold Chain Data Loggers
CHILLED GOODS
ALARMS:
HIGH
LOW
8°C
2°C
STATUS:
Issue 1
PDF
Example
EL-PDF-1(F:)
EL-PDF-1(F:)
