SMART MULTI-FUNCTIONS
DEVICES
VT 300, 300 PRO and 300 ST
Air velocity Pressure Humidity Air flow Temperature
DIRECTIONS FOR USE
300
VT

TECHNICAL SPECIFICATIONS .....................................................
...........................................................................
.............................................................................
.........................................................................
- Description
- Keyboard
- Connections
INTRODUCTION :
INTRODUCTION OF THE MENU
TEMPERATURE MENU
HOT-WIRE ANEMOMETRY MENU
VANE ANEMOMETRY MENU
HYGROMETRY MENU
TACHOMETER MENU
SUB-MENUS :
..................................................
....................................................................
.................................................
.........................................................
.....................................................................
.....................................................................
....................................................................................
.................................................................................
................................................................
............................................................
............................................
................................................................................
- Units
- Delta T
- Automatic average
- Point by point average
- Automatic point by point average
- Air flow
1-2
2
3
3
4
4
4-5
5
6
6
6
7
7
7
7
7-8
SUMMARY

SETTING :
DATA RECORDING, PRINTING AND DELETING
GUARANTEE
CALIBRATION
- Date and hour
- Retro-lighting
- Contrast
- Keys beep
- Languages
- Automatic stop
- New
- Print
- Delete
......................................................................
.......................................................................
...............................................................................
............................................................................
..........................................................................
......................................................................
.....................................................................................
.....................................................................................
..................................................................................
...................................................................................
.................................................................................
8
8
8
8
9
9
9
10
10
10
10

1
* The thermocouple K probes do not use the SMART PRO system.
TECHNICAL SPECIFICATIONS
* * Performed in laboratories conditions, accuracies mentioned in this document will be guaranteed, subject to the same conditions or to a
calibration balancing.
The VT 300 is a multi-function instrument, compatible with all SMART PRO probes, and with all thermocouple K temperature
probes. The SMART PRO probes are supplied with calibration or adjusting certificate (last calibration date display when
connected). They are automatically recognized when connected, and are fully interchangeable.
THERMO ANEMO
A HELICE
THERMO ANEMO
A FIL CHAUD
THERMO
HYGRO
THERMOMETRE
TACHY
Units of measure Measuring ranges Accuracies** Resolutions
0,20 to 3m/s ±2% ±0,06m/s 0,01m/s
m/s, fpm 3,1 to 35m/s ±2% ±0,2m/s 0,1m/s
-20 to +80°C ±2% ±0,1°C 0,1°C
Velocity hot-wire m/s, fpm 0 to 3m/s ±3% ±0,03m/s 0,01m/s
3,1 to 30m/s ±3% ±0,1m/s 0,1m/s
Humidity %RH, g/kg 3 to 98%RH ±1% ±1,5%RH 0,1%RH
Dew point °C, °F, K -20 to +80°C ±2% ±0,1°C 0,1°C
°C, °F, K ±0,5% 0,1°C
+1000 to +1300°C ±1% 1°C
Optic
tr/min, rpm, m/min, 60 to 50000tr/min ±0,5% ±1tr/min 1tr/min
Contact 4 to 2500m/min
Velocity vane Ø100mm
Velocity vane
(except vane ø 16mm)
hot-wire
Ambient temperature °C, °F, K
Ambient temperature °C, °F, K
Ambient temperature
Airflow m /h, cfm, l/s, m /s
Airflow
-100 to +400°C ±2% ±0,1°C 0,1°C
-200 to -40°C
-39 to +999°C
±1% ±1,2°C 0,1°C
ft/min, In/min
1 tr/min
33
Velocity telescopic
°C, °F, K
of reading
of reading
m/s, fpm 0,3 to 35m/s ±2% of reading ±0,1m/s 0,1m/s
m/s, fpm 0,6 to 40m/s ±2% of reading ±0,1m/s 0,1m/s
of reading
0 to 65000m /h ±3% of reading ±10m /h 1m /h
of reading
of reading
m/s, fpm 0 to 3m/s ±3% of reading ±0,03m/s 0,01m/s
3,1 to 30m/s ±3% of reading ±0,1m/s 0,1m/s
-20 to +80°C ±2% of reading ±0,1°C 0,1°C
m /h, cfm, l/s, m /s 0 to 65000m /h ±3% of reading ±10m /h 1m /h
of reading
of reading
-20 to +80°C ±2% of reading ±0,1°C 0,1°C
(2 channels) °C, °F, K of reading
Thermocouple K*
(2 channels) of reading
of reading ±0,8°C
of reading ±1,2°C
of reading
±2% of reading ±1m/min 0,1m/min
30 to 20000tr/min
Ø70mm
Velocity vane Ø16mm
333
33 3 3 3
Temperature PT 100
HYGROMETRY PROBE :
Maximum interval guaranteed* :
EMG (GAL) = ±2,70 %RH between 18 and 28°C (general field)
Range of measurement : 3 to 98%RH
Drift at short time : better than 1%RH / year
Response time : 10 seconds
* EMG = Et + Ehl + k (uet +ur +ud +us )1/2
As per the 2000/2001 hygrometer chart :
uet : uncertainty of calibration = ± 0,55%RH
ur : uncertainty of resolution = ± 0,003%RH
ud : uncertainty of manufacturing = ± 0,17%RH
us : repetition of comparison = 0,11%RH
Et : difference due to thermical deflection= ± 0,28%RH
Ehl : difference due to hysteresis and linearity = ± 1,25%RH
k : expansion factor = 2%RH
22 2 2

300
VT
Description :
Battery load
Scrolling down menu
Graphic display
System of probes
fixing
Connection of the
battery charger
2
Elastomer protection
INTRODUCTION
DISPLAY :
HOUSING :
KEYPAD :
CONNECTIONS
Connectors :
Thermocouple K connectors :
Numeric connection output :
COMMUNICATION MODE :
MEASURING ELEMENTS :
Vane anemometer :
Hotwire anemometer :
Hygrometry :
Pt 100 temperature :
Thermocouple temperature :
Optical tachometry :
Contact tachometry :
Graphic, with automatic backlighting. Size 66 x 33 mm.
Shock-proof, made of ABS/PC, with Elastomer edges.
Made of Elastomer : 4 keys and one control knob.
:
mini-DIN secured plugs.
compensated miniature plugs
USB.
RS 232.
Hall effect sensor
thermistance with negative temperature factor.
capacitive element
Pt 100 class A
Thermocouple K class 1
optical detection (phototransistor)
ETC type adaptor fitting optical tachometry probe.
CONFORMITY :
WORKING ENVIRONMENT :
WORKING TEMPERATURE :
STORAGE TEMPERATURE :
DIMENSIONS :
WEIGHT :
LANGUAGES AVAILABLE :
Electromagnetical compatibility (norm NF EN 61326-1)
Neutral gas
From 0 to 50°C.
183 x 100 x 40 mm
450 g
French, English, Spanish, Portuguese, Italian, German, Dutch.
POWER SUPPLY :
4 Alcaline batteries 1,5 V LR6
From 0 to 50°C.

Keyboard :
2
4
1. ON/OFF : Switch on / switch off the instrument.
ESC : Return to the previous page or on the last
validated data.
2. Press 1 time : HOLD function, freeze the current
measure.
Press 2 times : show the values minimum and
maximum measured.
Press 3 times : return to the current menu
measure.
3. Recording : allow to memorize data.
4. Press on the control knob to validate.
B
5. Print out of data on a printer.
rowse the menu by scrolling down the knob.
1
35
DISPLAY SIDE
-:Channel 1 (C1) Connection of the hot-wire air velocity, vane air
velocity, hygrometry, tachometry (optic or contact), and Pt 100
temperature probes.
-:
-:
Channel 2 (C2)
T1 and T2
Connection of a second PT100 probe.
Connection of thermocouple K probes
Connections :
Channel 1 (C1)
Channel 2 (C2)
Thermocouple K
input
(T1)
thermocouple K
input
(T2)
USB port for connection
to the printer and
joining to a PC 3

To switch on the instrument, press the key “ON/OFF”.
The screen shows the name of the device, its serial number, its calibration date, the date and hour (see photo
below).
To access to one menu, connect the corresponding probe. If this one
uses the SMART PRO system, the screen shows the type of the
connected probe, and its calibration or adjusting date. To access to the
menu press on the knob. To return to the homepage, disconnect the
probe.
To switch off the instrument, press some seconds on the “ON/OFF” key.
4
INTRODUCTION OF THE MENU
When you connect your probe(s) (see connections p. 3), the screen shows its characteristics. It is possible to
connect up to 2 probes PT100 and 2 probes thermocouple K at the same time. Press then on the knob to enter
in the menu temperature, the measured value is shown in the screen and the following menu appears on the
last line (by browsing the menu by scrolling down the knob):
- Units
- Delta T (only if 2 probes of identical technology are connected)
To validate a function, press on the knob when the wished function is shown on the screen.
Display : T1 and T2 :thermocouple K probes
C1 and C2 : PT100 probes
Units :
See p. 6
Delta T :
See p. 7
TEMPERATURE MENU
When you connect a hot-wire probe,the screen shows its characteristics (do not forget to slide below the
protective tube on a level of the sensitive element). Press then on the knob to enter in the menu hot-wire
anemometry, the screen shows the measured values in air velocity and in temperature, and the next menu
- Units
- Automatic average
- Point / point average
- Automatic point / point average
- Airflow (rectangular, circular, ariflow cones)
- Delta T (only if one PT100 probe is connected on C2)
appears on the last line (by browsing the menu by scrolling down the knob) :
To validate a function, press on the knob when the wished function is shown on the screen.
HOT-WIRE ANEMOMETRY MENU

Units :
See p. 6
Automatic average :
See p. 7
Point / point average :
See p. 7
Automatic point / point average :
See p. 7
Airflow :
See p. 7
Delta T :
See p.7
When you connect a vane probe,
(for the
Ø16mm vane probe, only the air velocity appears) and the next menu appears on the last line (
):
- Airflow (rectangular, circular, cone : only for the vane Ø100 mm )
- Delta T (only if one Pt100 probe is connected on C2 and if you use a vane probe Ø70 or
100mm)
T
the screen shows its characteristics.Press then on the knob to enter in the
menu vane anemometry, the screen shows the measured values in air velocity and in temperature
by browsing the
menu by scrolling down the knob
- Units
- Automatic average
- Point / point average
- Automatic point / point average
probe
o validate a function, press on the knob when the wished function is shown on the screen.
Units :
See p. 6
Automatic average :
See p. 7
Point / point average :
See p. 7
Automatic point / point average :
See p. 7
Airflow :
See p. 7
Delta T :
See p.7
5
VANE ANEMOMETRY MENU

When you connect a hygrometry probe,the screen shows its characteristics. Press then on the knob to enter
in the hygrometry menu, the screen shows the measured values in humidity, temperature, absolute humidity
and dew point temperature and the next menu appears on the last line (
- Units
- Psychrometry
- Contact dew point temperature (only if a PT100 probe is connected)
- Delta T
browse the menu by scrolling down
the knob) :
(only if a PT100 probe is connected)
To validate a function, press on the knob when the wished function is shown on the screen.
Units :
See p. 6
Psychrometry :
Contact dew point temperature :
When you enter to this sub-menu, the screen shows the temperature of the PT100 probe (external), the
temperature of the contact dew point (Td), the humidity and the temperature integrated in the hygrometry
probe. To come out of the dew point temperature menu, press on “ESC”.
Delta T :
See p. 7
When you connect a tachometry probe, the screen shows its characteristics. Press then on the knob to enter
in the tachometry menu. B , then select the type of the tachometry
probe you have connected (optic o contact). If you use an optical probe, it is necessary to mark the turning
part with a little piece of reflective tape. The screen shows the measured value and the next menu appears on
the last line :
- Units
To validate this function, press on the knob.
rowse the menu by scrolling down the knob
Units :
See p. 6
Units :
Browse the different available units validate pressing on the knob. When
you have the choice between various parameters (velocity and temperature, for example), you have to
validate each unit of measure.
by scrolling down the knob and
6
When you access to the sub-menu “Psychrometry”, the display shows the temperature, the humid
temperature (Tw), the humidity, the absolute humidity ( v) and the enthalpy (i). To come out of the
psychrometry menu, press on “ESC”.
HYGROMETRY MENU
TACHOMETRY MENU
SUB-MENUS

Delta T :
When 2 PT100 probes or 2 thermocouple K probes are connected, you have the possibility of calculate
the Delta T which corresponds to the difference between the temperature measured by C1 (or T1) and
C2 (or T2). If 2 PT100 probes and 2 thermocouple K probes are connected at the same time, the screen
shows 2 delta T. To come out of this function, press the touch " ESC ".
Reminder: possible only between 2 probes of identical technology.
Automatic average :
This function allows to calculate the average value that the device measured in an interval of chosen
time. When "Departure" appears on the screen, press on the knob to start the calculation. The screen
registers the sold time. To stop and reach the result, press again on the knob. The results are registered
on the screen: average (s), minimum value (s), maximum value (s), standard deviation(s) as well as the
duration of the calculation. Press on " ESC " to return to the previous page (by pressing on the knob, you
begin a new calculation).
Point / point average :
This function allows to calculate the average value of various points which you will have validated. The
s allows to validate a point or to reach the average of points previously validated. To
validate a point, press on the knob. Validate as many points as necessary, then by means of the knob,
choose "Average" and validate. The screen shows then: average(s), count of validated points, minimum
value(s), maximum value(s) and . To show the values of the various points, press
on the knob. Press then on " ESC ": once to return to the previous display, twice to begin another
calculation and three times to go out of the menu "point / point average".
crolling down menu
standard deviation(s)
Automatic point / point average :
This function allows to calculate the average value of various points, calculated themselves on a
duration beforehand defined.
It is necessary to choose at first the duration on which will be calculated each of the points;
and validate every number by pressing on the knob. Once the
duration validated, the scrolling down menu gives you access to the validation of points and to the
average. Proceed then in the same way as for the calculation of "average point / point" (previous
paragraph).
browse the
figures by scrolling down the knob
7
Airflow :
When you enter in this menu, it is necessary to begin by selecting the type of diffuser : rectangular,
circular or cone (with hot-wire probe and vane Ø100 mm )
validate. Enter
the length of the diffuser.Browse each figure by scrolling down the knob and validate pressing on the
knob ( to return to the previous figure, press on “ESC”). Proceed in the same way for the width.
You have access to a new scrolling down menu :
- Units (see p. 6)
- Automatic average (see p. 7)
- Point/point average (see p. 7)
- Automatic point/point average (see p. 7)
- Rectangular :
probe by scrolling down the knob
browse then the units of measurement by scrolling down the knob and

To reach the various settings, switch on the device (do not connect a probe). Press then on "ON / OFF".
The following scrolling down menu appears :
- Date and hour
- Retro-lighting
- Contrast
- Keys Beep
- Languages
- Automatic stop
To validate a function, press on the knob when the wished function is shown on the screen.
Date and hour :
Use the knob to settle each figures of the date and of the hour, and validate at each time pressing on the
knob. To return to a figure previously validated, press on " ESC ".
Retro-lighting :
It is possible to activate or to deactivate the retro-lighting of the display : by means of the knob choose
"ON", " OFF " or "automatic" and press to validate. To go out of this menu, press on " ESC ".
Contrast :
By the means of the knob, adjust the contrast of the screen from 0 to 7 and validate by pressing on
the knob.
Keys beep :
It is possible to activate or to deactivate the tone of keys. Validate the chosen option by pressing on
the knob.
8
SETTINGS
- Circular : browse then the units of measurement by scrolling down the knob and validate. Enter the
diameter of the diffuser. Browse each figures by scrolling down the knob and validate pressing on the
knob. You have access to a new scrolling down menu :
- Units (see p. 6)
- Automatic average (see p. 7)
- Point/point average (see p. 7)
- Automatic point/point average(see p. 7)
- Cones (for hot-wire and vane Ø100 mm anemometry) :
- : Select the reference of the cone used (K35, K75,...) by the means of the
knob, then the mode of ventilation (exhaust or supply). Validate, the measure appears and the screen
shows the following menu :
- Units (see p.6)
- : The screen displays “K25 cone”. Validate, the measure appears
and the screen shows the following menu :
- Units (see p.6).
For hot-wire anemometry
For vane Ø100 mm anemometry

Languages :
By the means of the knob, browse the different available languages and validate pressing on the knob.
Automatic stop :
It is possible to cancel the automatic stop of the device or to settle it. For that purpose, use the scrolling
down knob and choose " OFF " to cancel the automatic stop or choose a value (by slice of 15 minutes).
When you restore data on PC, the automatic stop does not work, but at the end of the load, the
device goes out automatically.
Before enter in the menu "recording", it is necessary to connect the probes that will be used. Enter in the menu
which you wish to record. Press the key "Recording" (see p. 3) to reach the menu " Datalogger ". At the bottom
of the screen appears the following scrolling down menu:
- New
- Print.
- Delete
It is thus possible to print data, to record or to delete them.
New :
This function allows to register a new campaign of measures. It is necessary to enter first of all the name
of the file (12 characters at most). B and validate every
character by pressing on the knob or by choosing the symbol if you enter less than 12 characters.
Choose then if you wish a manual or automatic recording of the data (by means of the knob).
validate as many points as you wish by pressing on the knob (the number of
registered points is indicated on the last line). Press on the key "Recording" to stop the recording. If you
really wish to stop, choose "Yes" and to continue to register points, click on "No" (by means of the knob).
- Manual recording :
rowse the letters by scrolling down the knob
9
- Automatic recording: By means of the knob, choose the interval of time between the recording of
each of the points (the minimum is of 5 seconds). Choose then the duration on which points are going to
be registered (validate the number of days, hours and minutes) then validate. The recapitulative
appears on the screen. To begin the recording, press twice on the knob. Once the ended recording, the
device switches of. To stop the current recording, press on "Recording". If you really wish to stop,
choose "Yes" and to continue the recording, click on "No" (by means of the knob).
DATA RECORDING, PRINTING AND DELETING
To restore the data registered on a PC, s (without any probe) and connect the cordon
on the port USB (see p. 3). During the recordings, the automatic stop of the device does not work,
but at the end of the procedure, it will switch off automatically.
witch on the device

KIMO provides a one-year guarantee, starting from the date on which the appliance was originally
purchased, that any new appliance will be free of any manufacturing or structural defects. This guarantee
does not cover defects resulting from incorrect handling or from any repairs which may been made by
persons other than the manufacturer.
Any defects covered by this guarantee will be repaired free of charge. An estimate will be provided for any
damage not covered by this guarantee. The customer’s prior approval will be requested before any repairs
are done.
KIMO will see to the replacement of any constituent parts of this appliance.
Any appliance, whether under guarantee or not, must be returned carriage paid. A letter detailing the faults
defected should be sent with the appliance whenever possible.
All KIMO devices are calibrated in our premises and supplied with a calibration certificate, as per the AFNOR
FD X 07-012 norms, in accordance with the National Standards.
In order to comply with standards of Quality Assurance, measuring devices should be checked annualy.
10
Print :
When "Print" is validated, by means of the knob, choose the campaign which you wish to print and
validate by pressing on the knob. Go out of the menu "printing" by pressing on " ESC ".
GUARANTEE
CALIBRATION
Delete :
This function allows to delete the campaigns of measure stored in the device. To enter in the menu
“delete”, validate by pressing on the knob. Then, always by means of the knob, choose to cancel or to
confirm the demand.

Ref. NT Ang - VT 300 - 11/02 C
@
EXPORT DEPARTMENT
Boulevard de Beaubourg
Emerainville - BP 48
77312 MARNE LA VALLEE CEDEX 2
Tel : [phone]
Fax : [phone]
www.kimo.fr
