HotWire V1 User manual

Vertical Towel Rail Installation Manual
Applies to all V1 Models

Vertical Towel Rail Installation & User
Instruction Manual
Please follow these installation instructions carefully to
ensure maximum value and enjoyment from your new
Hotwire Towel Rail.
Your Towel Rail also comes fitted with a timer and an
in built on / off function.
Timer Instructions
The timer is located at the bottom of the
upright. It has three options,
1. On / Off
Press the button in the middle of the
wheel as indicated in the diagram
and the screen will display --
Press the button again and the Heated Towel Rail
will turn on.
Press the button again and the unit will simply turn
on.
2. Timer on for a set number of hours.
You can choose to set your towel rail to run for a
certain amount of hours. While the display is
showing -- turn the wheel to the number of hours
you wish to run the towel rail for.
3. Timer set to come on at the same time every day.
Please note that when you set this option the
towel rail will come on at the same time every day.
E.g. If you are setting this at 5 pm then the time
will come again at 5 pm every day for the number
of hours you choose.
Press the button once. -- is shown on the display.
Turn the wheel until the required number of hours
is shown on the display.
Press and hold the button until the number of
hours is flashing. The timer is now set. -- will flash
on the display whilst not in the heating mode.
To cancel simply press the button to turn off.
There are two ways that you can connect your towel
rail.
1. Concealed wiring. All the electrical wiring is
completed inside the wall cavity and the arm of the
towel rail. No cable will be visible in your bath-
room.
2. Plug in. You simply plug in the towel rail to the
nearest power point. If you have the opportunity to
plan your bathroom accordingly only a very small
length of cable will be visible.
All the components to complete either method are
included in the package.
Installation Instructions:
Plug in connection Fig 1
1. Hold the towel rail against the wall. Make sure the
bottom of the rail is at least 600 mm from the floor.
2. Using a spirit level ensure the rail is perfectly
upright.
3. Mark a circle around the top and bottom fixing
points.
4. Hold the base and bottom plate against the wall
and mark the drilling points.
5. Drill the holes.
6. Fix the bases into position.
7. Fit the towel rail over the bases.
8. Tighten the grub screws.
9. Plug in your towel rail
HOTWIRE TOWEL RAILSPAGE 2
Fig. 1

Installation Instructions:
Concealed Wiring Fig 2
This method of connection will allow you to
completely conceal the cable for your towel rail.
Stud Wall:
1. Drill a 13mm hole into the face of the stud where
the base will sit. This will accommodate the cable
to be fed through. Drill the hole to a depth of
40mm.
2. Drill another hole into the side of the stud. This
will accommodate the cable feed. Drill this hole at
25mm diameter. See Fig 4.
3. Place a draw wire from the flush box through the
13mm hole so the power cable can be pulled
through at a later date.
4. Alternatively simply run a power cable through the
holes. Ensure this cable is not live.
HOTWIRE TOWEL RAILSPAGE 3
Fig. 2
Fig. 4

LEGAL:
If installed directly to fixed wiring, a qualified Electri-
cian must install this appliance in accordance with local
wiring regulations and this Instruction Manual. A means
of disconnection from the supply must be provided. If
connected to the supply via a three-pin plug to a fixed
socket, the plug must be accessible for disconnection.
If the power cord is damaged the complete appliance
should be returned to the Manufacturer for repair.
More Legal:
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervi-
sion or instruction concerning use of the appliance
by a person responsible for their safety.
• Children should be supervised to ensure that they
do not play with the appliance.
• Means for disconnection must be incorporated in
the fixed wiring in accordance with the wiring rules.
• If the supply cord is damaged, it must be replaced
by the Manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
• Keep heating surfaces at least 100 mm away from
surrounding structures.
WARNING: In order to avoid a hazard for very young
children, this appliance should be installed so that the
bottom is at least 600 mm above the floor.
WARRANTY
For warranty information please see enclosed sheet or
websites listed below.
AUSTRALIA
Hotwire Heating
www.hotwireheating.com.au
NEW ZEALAND
The Heating Company
www.theheatingcompany.co.nz
HOTWIRE TOWEL RAILSPAGE 4
IEC335-1: 1991
IEC60335-2-43, 1995
AS/NZS3350.1.2002.
IP Rating is IP34:
This appliance is rated for voltage 200v - 240v.
This appliance must be connected to the house Earth.
WIRING INSTRUCTIONS:
---- green/yellow: Earth
---- blue: Neutral
---- brown: Phase (power)
All Electrical connections and terminations must be
conducted by a licensed A Class Electrician.
Preparation Instructions:
Masonry Wall
Drill a 14mm diameter hole through to the cavity.
1. Cut the plug off the cable.
2. Connect it to the power supply.
3. Hold the towel rail against the wall. Make sure the
bottom of the rail is at least 600 mm from the floor.
4. Using a spirit level ensure the rail is perfectly
upright.
5. Mark a circle around the top and bottom fixing
points.
6. Hold the base and bottom plate against the wall
and mark the drilling points.
7. Drill the holes.
8. Fix the bases into position.
9. Fit the towel rail over the bases.
10. Tighten the grub screws.
Enjoy the luxury of your Hotwire Towel Rail.
INFORMATION:
This product is manufactured to International
Standards:
