HP RC5 User manual

1
About this Guide
The content in this document is for information purpose and is subject to
change without prior notice. We have made every effort to ensure that
this User Guide is accurate and complete. However, no liability is assumed
for any errors or omissions that may have occurred. The manufacturer
reserves the right to change the technical specifications or accessories
without prior notice.
Regulatory notices
This document provides country and region specific non wireless and
wireless regulatory notices and compliance information for your product.
Some of these notices may not apply to your product.
WEEE Notice
Disposal of Waste Electrical and Electronic Equipment and/or
Battery by users in private households in the European nion
This symbol on the product or on the packaging indicates
that this cannot be disposed of as a household waste. You
must dispose of your waste equipment and/or battery by
handling it over to the applicable take back scheme for
the recycling of electrical and electronic equipment and/or
battery. For more information about recycling of this
equipment and/or battery, please contact your city office,
the shop where you purchased the equipment or your
household waste disposal service. The recycling of
materials will help to conserve natural resources and
ensure that it is recycled in a manner that protects human
health and environment.

2
CE Regulatory Notice
The product herewith complies with the requirements of the Low
Voltage Directive 2014/35/EU, the EMC Directive 2014/30/EU, and
the RoHS Directive 2011/65/EC.
Notes on Installation
1. Make sure that the lens is within the wiping range of the
windscreen wiper to ensure a clear view even when it rains.
2. Do not touch the lens with your fingers. Finger grease may be left
on the lens and will result in unclear videos or pictures. Clean the
lens on a regular basis.
3. Make sure that the installation position is not hindered by the
tinted window.
4. This product is suitable for light windshield or light color
heat resistant film windows , it will affect video quality if install it
on the dark windows or dark heat resistant film windows.
1Introduction
Thank you for purchasing this advanced Full HD rear camera. This
product is specifically designed for supporting HP car camcorder real
time video recording when driving.
1.1 Features
•Full HD recording videos (1920x1080P@25fps)
•Switch for rear view or in car recording
•Sony’s Starvis sensor

3
1.2 Package Contents
The package contains the following items. In case there is any
missing or damaged item, contact your dealer immediately.
Rear Camera User Manual USB Cable
1.3 Product Overview
No. Item–– No. Item
1 Wide Angle Lens 4 Camera Rotation Shaft
2 Base 5 Rear/ front image switch
3 Micro USB Connector Port 6 LED indicator

4
2Getting Started
2.1 Mount Rear Camera to the Windshield
1. Adjust rear camera position as the picture shown. Please
check the preview image is in right position (not upside down)
before installation. If the preview image is upside down,
please rotate the base 180∘to make it correct, or make sure
switch is REAR or FRONT position.
Rear view recording In car recording
2. Connect the USB cable with primary camcorder and power it
on to enter preview screen and confirm the field of view. Then
clean the surface of the windshield with alcohol to ensure that
the adhesion surface is clean.
3. Remove the transparent film on the base of rear camera, and
then hard press rear camera to ensure firmly stuck.

5
Note:
1. Do not install the device on a tinted window. Doing so may damage the tint film.
2. This product is suitable for light windshield or light color heat resistant film
windows, it will affect video quality if install it on the dark windows or dark
heat resistant film windows.
2.2 Adjust Rear Camera
2.2.1 Record Rear View
1. Once the rear camera is mounted to the rear windshield, the
lens should be rotated to accommodate external rear view as
shown by the illustrations below.
2. Slide the switch to “Rear”.
3. Use the preview screen from front camera to fine tune the
desired lens angle.

6
2.2.2 Record Inside the Vehicle
1. Once the rear camera is mounted to the rear windshield, the
lens should be rotated to accommodate internal cabin view as
shown by the illustrations below.
2. Slide the switch to “Front”.

7
3. Use the preview screen from front camera to fine tune the
desired lens angle.
Note: We recommend users to disconnect micro USB from rear camera before
adjusting.
2.3 Connect and Set p Rear Camera
Use the USB cable in the rear camera package to connect with front
camera and rear camera.
(Front camera is not included in the package. Please contact
distributor for further information.)
1. Plug phone jack into front camera’s 2CH port. (Front camera is
power off.)

8
2. Plug the other end of USB cable (micro USB connector) to rear
camera’s USB port.
3. Turn on front camera’s power, the rear camera image will be shown
on the right down corner of front camera screen. According to
different models, press Power button on front camera to
switch front or rear image.
Note:
1. Install rear camera at upper central position of the rear windshield.
2. Rear camera doesn’t support hot Plug n Play. Please turn off the front camera
before plugging the rear camera.

9
3sing the Rear Camera
3.1 Automatic Record
When installation is completed, dual camera recording will
automatically start or stop once the engine is switched on or off.
(Front camera is not included in the package. Please contact
distributor for further information.)
Note:
1. Some vehicle’s power supply would not turn on the peripheral devices
automatically with the car engine starts. If the camcorder doesn’t automatically
power on with the car engine, please manually power on and power off the camera.
2. According to front camera’s interval recording time setting, the rear camera is
configured to save a video file for every 30 seconds, 1 minute or 3 minutes.
3. All the videos and photos are saved in the memory card in front camera. If
memory card is full, loop recording will generally overwrite the oldest video file.
3.2 Resolution
Rear camera resolution is Full HD 1080P 25fps as always. The
resolution will not be changed by front camera’s resolution setting.

10
3.3 Recording image
The recording image differs from models. Different model will have
different icon allocation. Below image is for reference only.
No. Icon Item Description
1
VIV
(Video in
Video)
Indicates rear camera
recording screen.
2
Switch
Camera
Preview
Press Power button to
switch front/rear camera
preview screen.

11
3.4 Playback Videos and Photos
1. If recording is in progress, press the / button to
stop recording and enter Menu setting.
2. Press the or button to select Playback and press
button to confirm.
3. Press the or button to select the folder Video /
Emergency / Picture that you want to browse and press the
button to display thumbnail images of the recorded video
or photo files.
4. Use the or to browse the files, select the file and
then press
OK
button to enter Playback Mode. Press
Power button to switch front and rear camera’s recorded files.
5. Press the repetitively to return recording screen.
3.5 Deleting Files
To delete file(s), perform the following steps:
1. Press the / button to stop recording and enter
Menu setting.
2. Press the or button to select File Deletion and
press button to confirm.

12
3. Press the or button to select the folder Video /
Emergency / Picture that you want to browse and press
button to confirm.
4. Press the or button to select Delete One or Delete
All and press button to confirm.
Item
Description
Delete One Delete the current selected file.
Delete All Deletes all files in this folder.
Note:
1. Deleted files CANNOT be recovered. Ensure the files you wish to preserve are
backup before deletion.
2. If the file is taken by front camera and rear camera at the same time, no matter
you delete video or picture from Front camera folder or Rear camera folder, both
front camera file and rear camera file will be deleted.

13
4Specifications
Item Description
Image Sensor 1/2.8” Sony’s Starvis sensor
Effective Pixels 1920 (H) x 1080 (V)
Lens Wide Angle Fixed Focus lens F2.2, f=3.26mm
Focus Range 1.5m~Infinity
Movie Clip Resolution: 1080P 25fps
Format: TS
Operating
Temperature 0° ~ 50° C
Storage
Temperature 20° ~ 70° C
Dimensions 60 x 45.5 x 29.2 mm
Weight Approx. 36g

1
有關本手冊
本文件之內容只供參考，並得以隨時變更不需要事先通知。本公
司已盡全力確保本使用者手冊正確與完整。但有任何錯誤或遺漏
概不負責。製造廠保留不需事先通知，逕自變更技術規格或配件
之權利。
Regulatory notices
This document provides country- and region-specific non-wireless
and wireless regulatory notices and compliance information for your
product. Some of these notices may not apply to your product.
WEEE 通知
歐盟有關使用者處分私人家庭廢電子與電機產品和/或電池之指
令
產品上或包裝上有此一符號，表示此產品不能做為
家庭廢棄物處理。您必須依據相關之電子與電機產
品和/或電池回收辦法之規定，處分您的廢電子與電
機產品和/或電池。有關這類產品和/或電池的回收細
節，請聯絡當地的市政府、您購買該產品的商店或
您的家庭廢棄物處理公司。材料之回收有助於保護
自然資源及確保能以保護人類健康與環境之方式回
收。
CE Regulatory Notice
The product herewith complies with the requirements of the Low
Voltage Directive 014/35/EU, the EMC Directive 014/30/EU, and
the RoHS Directive 011/65/EC.

安裝須知
1. 確定鏡頭是在擋風玻璃雨刷的範圍內，確保視野良好，即使雨
天依然清晰。
. 不要用手指碰觸鏡頭。手指上的油垢可能會留在鏡頭上，導致
影片或照片不清楚。請定期清潔鏡頭。
3. 請勿將本設備安裝在深色車窗上，否則將使隔熱紙受損。
4. 本產品僅適用於淺色擋風玻璃或貼附淺色隔熱紙的車窗，若使
用深色車窗或車窗貼附有色隔熱紙，將影響錄影成像的效果。
1導論
謝謝惠顧此套先進的高清後置鏡頭。本產品專為支援HP行車紀錄
器於行車時之即時錄影。(前鏡頭行車紀錄器不包含在標準配備
中，請洽經銷商詢問詳細資訊。)
1.1 功能
•高畫質錄影 (19 0x1080P@ 5fps)
•可切換車後或是車內錄影
•星光級索尼影像傳感器
1.2 包裝內容
以下為包裝內容物。若有任何遺漏或損壞項目，請立即聯絡您的
經銷商。
後鏡頭 使用說明書 Micro USB
後鏡頭傳輸線

3
1.3 產品概要
編號 項目 編號 項目
1 廣角鏡頭 4 鏡頭轉軸
底座 5 前/後影像切換開關
3 Micro USB 連接埠 6 LED 工作指示燈

4
2開始
2.1 固定後鏡頭在車內的後擋風玻璃上
1. 如圖示調整後鏡頭位置，黏貼後鏡頭之前請務必確認錄影畫
面的方向正確(影像不是上下相反的)。如果影像是上下相反
的，可將底座180度轉向安裝，或是確認切換開關的撥桿有
在正確的REAR或是FRONT位置。
車外錄影 車內錄影
. 連接主鏡頭與後鏡頭，並開啟設備電源預覽後鏡頭的錄影畫
面，確認錄影範圍之後再以酒精清潔擋風玻璃的表面，確保
黏著表面乾淨無污。
3. 撕除背膠的透明離型紙。
4. 將後鏡頭底座黏貼於擋風玻璃上，按壓托架底座並確認已黏
貼牢固。
