HP DESKJET 460 Assembly instructions

EL-MF877-00 Page 1
Template Revision C
Last revalidation date 09-May-2018
HPI instructions for this template are available at EL-MF877-01
Product End-of-Life Disassembly Instructions
Product Category: Personal Computers
Marketing Name / Model
[List multiple models if applicable.]
HP Desktop PC 460
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions for the
disassembly of HPI products to remove components and materials requiring selective treatment, as defined by EU directive
2012/19/EC, Waste Electrical and Electronic Equipment (WEEE).
NOTE: Recyclers should sort plastic materials into resin streams for recycling based on the ISO 11469 plastic marking code on the
plastic part. For any questions on plastic marking, please contact HP’s Sustainability Contact.
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as applicable.
Item Description
Notes
Quantity of
items
included in
product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
1
Batteries, excluding Li-Ion batteries.
All types including standard alkaline, coin or button style
batteries Lithium Coin Battery on MB
1
Li-Ion batteries. Include all Li-Ion batteries if more than
one is provided with the product (such as a detachable
notebook keyboard battery, RTC coin cell, etc.)
Battery(ies) are attached to the product by (check all
that apply with an “x” inside the “[ ]”):
[X] screws
[X] snaps
[X] adhesive
[ ] other. Explain NA
NOTE: Add detailed removal procedures including
required tools in the sections 3.1 and 3.2.
0
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries NA
0
Liquid Crystal Displays (LCD) with a surface greater than
100 sq cm
Includes background illuminated displays with gas
discharge lamps NA
0
Cathode Ray Tubes (CRT)
NA
0
Capacitors / condensers (Containing PCB/PCT)
NA
0
Electrolytic Capacitors / Condensers measuring greater
than 2.5 cm in diameter or height
NA
0
External electrical cables and cords
DC Cable for External Power Supply
0

EL-MF877-00 Page 2
Template Revision C
Last revalidation date 09-May-2018
HPI instructions for this template are available at EL-MF877-01
Item Description
Notes
Quantity of
items
included in
product
Gas Discharge Lamps
NA
0
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
NA
0
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
0
Components and waste containing asbestos
NA
0
Components, parts and materials containing refractory
ceramic fibers
NA
0
Components, parts and materials containing
radioactive substances
NA
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components and
materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Description T15 screw driver (Disassemble 3 pcs screws for side bkt and main bkt)
T15 3.0~4.0
kgf-cm
Description T15 screw driver (Disassemble 3 pcs screws for ODD cage and main bkt)
T15 3.0~4.0
kgf-cm
Description T15 screw driver (Disassemble 2 pcs screws for PCI cover and main bkt)
T15 3.0~4.0
kgf-cm
Description T15 screw driver (Disassemble 4 pcs screws for MB and main bkt)
T15 3.0~4.0
kgf-cm
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment
including the required steps to remove the external enclosure:
1. Loosen thumb screw and remove Access panel from hosing
2. Pull off ODD SATA con &ODD power con.
3. Remove ODD from hosing
4. Remove front bezel.
5. Loosen 3 screws on side bkt then remove it.
6. Loosen 3 screws on front brkt then remove ODD cage.
7. Pull off all cables on MB.
8. Loosen 2 screws on Rear brkt then remove System Fan.
9. Loosen 2 screw on PCI cover then remove it.
10. Remove VGA card from hosing.
11. Loosen 4 screws on MB then remove it.
12. Loosen 4 screws on PSU then remove it.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items contained in the
product that require selective treatment (with descriptions and arrows identifying locations).
