HP Kayak XU 03xx Manual

HP Kayak XU 03xx PC Workstation
Technical Information
This section provides technical information about your PC Workstation
and includes details about the system board connectors and switches.

HP Kayak XU 03xx PC Workstation Technical Information
Features
2English
Features
Feature: Description:
Processor (standard) Pentium II (single or dual)
Cache Memory
(integrated in processor package)
•Level-One: 16 KB code, 16 KB data
•Level-Two: 512 KB
Main memory (size/speed) Upgradeable to 1 GB (SDRAM) using either:
•64 MB or 128 MB 100 MHz Non-Buffered ECC SDRAM,
or
•256 MB Registered ECC SDRAM memory modules
Video Your PC Workstation could be supplied with either a:
•Matrox 2D Integrated Graphics Accelerator installed on
the AGP slot, or
•ELSA GLoria Synergy AGP, 8 MB on board,
not upgradeable.
LAN Ethernet 10BT/100TX LAN controller on PCI accessory board
(combined LAN/SCSI board).
Audio Integrated 16-bit high fidelity with high-end mixing capability
and SigmaDelta converters
Disk drive controller An integrated Ultra 16-bit SCSI controller,
An Ultra ATA-33 IDE controller, and
An Ultra SCSI 16-bit interface board (combined with the LAN)
Rear connectors •Mini-DIN mouse
•Mini-DIN keyboard
•25-pin parallel
•9-pin serial (two, buffered)
•Two USB connectors
•Joystick/Dual MIDI connector
•LINE IN jack (3.5 mm)
•LINE OUT jack (3.5 mm)
•MIC IN jack (3.5 mm)
25-pin parallel connector •Mode: Centronics or bidirectional modes (ECP/EPP)
•Parallel port: 1 (378h, IRQ 7), 2 (278h, IRQ 5), or Off.

English 3
HP Kayak XU 03xx PC Workstation Technical Information
Features
9-pin serial connectors •Standard: Two UART 16550 buffered serial ports
(both RS-232-C).
•Serial Ports A and B: 2F8h (IRQ 3), 2E8h (IRQ 3),
3F8h (IRQ 4), 3E8h (IRQ 4), or Off—
(if one port uses 2xxh, the other port must use 3xxh).
Disk drive shelves Seven mass storage shelves supporting:
•Two front-access, third-height, 3.5-inch drives
•Three front-access, half-height, 5.25-inch drives
•Two internal 3.5-inch hard disk drives
System board connectors •One flexible disk drive connector
•One ATA/33 IDE connector (for up to two IDE devices)
•One Ultra SCSI 16-bit connector (for up to five internal
SCSI devices)
•One CD-ROM audio connector
•AUX connector
•Multimedia front panel connector
•Front panel MIC connector
•Internal speaker connector
•One external start connector
•External battery connector
Accessory slots •One AGP (Accelerated Graphics Port) slot
•Three 32-bit PCI slots (one with an HP RAIDport)
•One 16-bit ISA (Industry Standard Architecture) slot
•One combination ISA or PCI slot
Keyboard/Mouse •HP enhanced keyboard with mini-DIN connector
•HP enhanced scrolling mouse with mini-DIN connector
HP UltraFlow cooling system Cooling system with multiple temperature-regulated fans to
optimize cooling
Headset Stereo headset with microphone
Feature: Description:

HP Kayak XU 03xx PC Workstation Technical Information
System Specifications
4English
System Specifications
Power Consumption Information
NOTE When the PC Workstation is turned off with the power button on the
front panel, the power consumption falls below 5 Watts, but is not zero.
The special on/off method used by this PC Workstation considerably
extends the lifetime of the power supply. To reach zero power
consumption in “off” mode, either unplug the PC Workstation from the
power outlet or use a power block with a switch. You should be aware
that, in this case, the PC Workstation will lose its time settings within a
few days.
Maximum Loads Available for Accessory Slots
The load limits for the ISA and PCI accessory slots are compliant with
ISA and PCI specifications. More details of permitted loads are
provided on the World Wide Web in the support documentation section
for your PC Workstation.
Maximum power consumption 260 W
Typical consumption with:
•One processor installed
•Two processors installed
approx. 85 W
approx. 99 W
Off 2.5 W1
1. The power supply in your PC Workstation continues to supply power to the CMOS
memory, even when switched off.

English 5
HP Kayak XU 03xx PC Workstation Technical Information
System Specifications
IRQs, DMAs, and I/O Addresses Used by Your PC Workstation
The IRQ, DMA, and I/O address mappings shown here are for a basic
configuration. The resources used by your PC Workstation may vary,
depending on which accessory boards are bundled with the
PC Workstation. Resources are allocated by the system BIOS or the
Plug and Play operating system.
IRQs used by
PC Workstation
IRQ0 System timer
IRQ1 Keyboard controller
IRQ2 Free
IRQ3 COM2, COM4
IRQ4 COM1, COM3
IRQ5 AD1816, LPT2
IRQ6 Flexible disk drive controller
IRQ7 LPT1
IRQ8 Real-time clock
IRQ9
IRQ10
IRQ11 AD1816 MIDI
IRQ12 Mouse
IRQ13 Not connected
IRQ14 Integrated IDE controller
IRQ15
DMAs used by
PC Workstation
DMA 0 Capture
DMA 1 Playback
DMA 2 Flexible disk drive controller
DMA 3 LPT ECP
DMA 4 Cascade
DMA 5 free
DMA 6 free
DMA 7 free

HP Kayak XU 03xx PC Workstation Technical Information
System Specifications
6English
I/O Addresses used by PC
Workstation
0000 - 000F DMA controller 1
0020 - 0021 Master interrupt controller
002E - 002F Configuration registers
0040 - 0043 Timer 1
0060, 0064 Keyboard controller
0061 Port B (speaker, NMI status and control)
0070 Bit 7: NMI mask register
0070 - 0071 RTC and CMOS
0080 Manufacturing port (POST card)
0081 - 0083,
008F DMA low page register
0092 PS/2 reset and Fast A20
0096 - 0097 Little Ben
00A0 - 00A1 Slave interrupt controller
00C0 - 00DF DMA controller 2
00F0 - 00FF Coprocessor error
0130 - 013F AD1816 sound system
0170 - 0177 Free (IDE secondary channel)
01F0 - 01F7 IDE primary channel
0200 AD1816 Joystick
0220 - 0232 AD1816 Sound Blaster
0278 - 027F LPT 2
02E8 - 02EF Serial port 4 (COM4)
02F8 - 02FF Serial port 2 (COM2)
0330 - 0331 AD1816 MIDI
0372 - 0377 Free (Secondary flexible disk drive)
0378 - 037A LPT1
0388 - 038B AD1816 Adlib (FM)
03B0 - 03DF VGA
03E8 - 03EF COM3
03F0 - 03F5 Flexible disk drive controller
03F6 IDE primary channel
03F7 Flexible disk drive controller
03F8 - 03FF COM1
04D0 - 04D1 Interrupt edge/level control
0678 - 067B LPT2 ECP
0778 - 077B LPT1 ECP
0CF8 - 0CFF PCI configuration space
8000 PIIX4 Power Management I/O space
8400 NS317 ACPI Registers
8800 PIIX4 SMBus I/O space

English 7
HP Kayak XU 03xx PC Workstation Technical Information
System Specifications
Audio Features
Feature: Description:
Digitized Sounds •Compatible SoundBlaster® Pro Adlib® /OPL3®
•16-bit and 8-bit stereo sampling from 4 kHz to 55.2 kHz
•Programmable sample rates with 1 Hz resolution
•Full duplex capture and playback at different sample rates
•Up to six different simultaneous sample rates
•Dual Tune F DMA transfer on channel 0, 1, 2 or 3
•Advanced 16-bit software-based real-time audio
compression/decompression system with the following
standards: PCM, Microsoft ADPCM, SoundBlaster
ADPCM in SB mode, CCITT A-Law, CCItt
•16-bit software-based real-time audio
compression/decompression system with the following
standards: Creative ADPCM (16:4), CCITT A-law (16:8),
and CCITT µ-law.
•Automatic dynamic filtering for digital audio recording
and playback
Music Synthesizer •MPU401 compatible MIDI port
•Support for Hardware and Software Wave table
Synthesizer
•Integrated OPL3 compatible music synthesizer
Enhanced Stereo •Built-in “Phat Stereo” for enlargement of Stereo Image
Mixer •MPC-3 audio mixer
•Input mixing sources: MIDI, microphone, LINE IN,
CD Audio, AUX Audio, and up to four digitized sounds
•Output mixing of all audio sources to the LINE OUT or
integrated PC Workstation speaker
•Multiple source recording and Left/Right channels mixing
•32-level volume control for microphone, LINE IN, CD
Audio, AUX Audio and master volume.
•64-level volume control for digital sounds, wave or PCM
data
LINE IN •Input impedance: 4 ohms
•Input range: 0 to 1Vrms
LINE OUT •Stereo output of 5 mW a channel with headphone
speakers (impedance >600 ohms)

HP Kayak XU 03xx PC Workstation Technical Information
System Specifications
8English
SCSI Features
MIDI/Joystick Interface •Built-in MIDI interface for connection to external MIDI
devices
•Sound Blaster and MPU-401 UART mode compatible
•MIDI time-stamp for multimedia extension
•Input buffer: 64-byte FIFO
•Microsoft Direct Input standard dual joystick port
Audio Front Panel •Microphone In jack
•Headphone Out jack
Microphone In jack •20 dB gain preamplifier. The boost can be muted with
software
•32-level programmable volume control
•Input impedance: 600 ohms
•Sensitivity: 30 mVpp to 283 mVpp
Headphone Out jack •Impedance: 32 ohms
Feature: Description:
Feature: Description:
Dual Controllers •Integrated UltraWide 16-bit SCSI Controller
•UltraWide 16-bit SCSI Accessory Board Controller
Dedicated Controller Integrated UltraWide 16-bit SCSI controller dedicated to hard disk
drives for full-time top-speed performance
Internal UltraWide 16-bit
SCSI (integrated)
•Based on Adaptec AIC7880 chip
•40 MB per second band width
•Supports multiple internal SCSI devices
•SCAM support
UltraWide 16-bit SCSI
(accessory board)
•Based on Symbios Logic
•40 MB per second band width
•68-pin 16-bit internal connector (with 16-bit to 8-bit convertor)
•68-pin 16-bit external connector
•Automatic switching to non-Ultra for external SCSI devices
(20 MB per second)
•SCAM support

English 9
HP Kayak XU 03xx PC Workstation Technical Information
System Specifications
Disk Striping Features (FastRAID)
HP FastRAID •Acceleration of Internal UltraWide 16-bit SCSI only
•Top performance with two superfast 4.5 GB or 9.1 GB
10,000 rpm hard disks
•SCAM not supported
Feature: Description:
Computer bus 32-bit PCI local bus and HP FastRAID socket connector
Host bus data transfer rate Up to 133 MB per second
Device protocol UltraWide 16-bit SCSI
Advanced HP FastRAID
features
•Array status monitoring and event notification
•Adjustable stripe width
Device support Up to 5 HDD/non-HDD SCSI devices per system board channel
Array support •Drives can be configured as RAID 0 (with 1 or 2 disk drives) and
RAID 1 (with 2 disk drives).
With 2 disk drives, both drives should be the same speed
(10,000 rpm) and the same capacity (both 14.5 GB or
9.1 GB)
•Drives can also be added in non-array environments
Operating system Windows NT 4.0
Remote management Windows NT 4.0
SCAM Not supported; SCSI addresses must be set manually on UltraWide
16-bit SCSI channel

HP Kayak XU 03xx PC Workstation Technical Information
The HP FastRAID Option
10 English
Network Features
The HP FastRAID Option
HP FastRAID uses RAID technology to accelerate the performance of
your PC’s hard drives. Rather than focussing on data protection, as
with server-based RAID technologies, HP FastRAID brings top
performance to your computer.
If you purchased your computer with the HP FastRAID option, an
Adaptec ARO-1130 PCI RAIDport™adapter will have been pre-
installed in the RAIDport connector slot of your PC’s system board, and
configured to provide maximum I/O throughput for your PC’s two hard
drives.
Although your ARO-1130 adapter and hard drives come pre-configured
for maximum performance (RAID 0), you can also configure the
RAIDport adapter and drives to provide protection against data loss
(RAID 1).
Feature: Description:
LAN Controller AMD PCNET-Fast Chip
RJ45 Connector 10BT/100TX autonegotiation
Remote Boot Protocols integrated in System BIOS
ExStart Connector •Connection to CPU board
•LAN Remote Wake Up or Remote Power On signals
•Auxiliary power
•Hardware Control Panel LAN LED signal
Remote Power On •Full remote power on with Magic Packet
•Power: Auxiliary power (during power off)
Remote Wake Up •Wake Up from Suspend state with Magic Packet
•Power: Main power

English 11
HP Kayak XU 03xx PC Workstation Technical Information
System Connectors and Switches
System Connectors and Switches
System Board Connectors
Multimedia Front
Panel Connector
16-bit Wide SCSI
Processor 1
Processor 2
AGP Slot
PCI Slots
Fan
Fan (airflow guide)
Status Panel MT
Power
Fan
System Board
Switches
FDD
VRM 1
VRM 2 Memory
Modules
ISA Slots
LCD Panel
Wake On Lan Status Panel DT
IDE 1
IDE 2*
*Selected models only
Loudspeaker
Aux In Audio
CD In Audio
Mic In
RAIDport
External Start

HP Kayak XU 03xx PC Workstation Technical Information
System Connectors and Switches
12 English
System Board Switches
Switches 1 through 5 are used for processor settings and should not be
changed. Replacing the processor with a different processor is not
supported by HP. Switches 6 to 10 are used as shown in the following
table:
System Board
Switches
Switch1
1. On the switch, UP=OFF and DOWN=ON.
Use Switch to:
6 - CLEAR CMOS Retain or clear CMOS memory:
•UP to retain CMOS memory — DEFAULT
•DOWN to clear CMOS memory.
7 - PSWRD Enable or clear (and disable) User and System Administrator Passwords
stored in EEPROM:
•UP to enable passwords — DEFAULT
•DOWN to clear passwords.
8 - KEYB power on Enable or disable power on using the keyboard:
•UP to disable keyboard power on
•DOWN to enable keyboard power on — DEFAULT.
9 - BOX DEFINITION Select box type:
•UP to select a Mini Tower model — DEFAULT.
•DOWN to select a Desktop model.
10 - BIOS Recovery
Mode
•UP to enable normal mode — DEFAULT.
•DOWN to enable recovery mode.

English 13
HP Kayak XU 03xx PC Workstation Technical Information
System Connectors and Switches
Internal Audio Connectors
The PC Workstation’s system board has several connectors that allow
you to internally connect to other devices. This includes:
•A CD audio connector
•An auxiliary (AUX) connector
•An Audio Front Panel connector
•A Front Panel Microphone connector
CD Audio Connector The CD Audio Connector labeled “CD IN,” is a 4-pin connector that is
connected to the internal CD drive. This connector allows you to listen
to audio from the CD-ROM drive.
The CD Audio Connector has the following pin assignments:
Auxiliary (AUX)
Connector
The AUX Connector labeled “AUX IN,” is a 4-pin connector that is
connected to the internal AUX. This connector allows you to listen to
audio from an auxiliary source.
The AUX Connector has the following pin assignments:
Pin Signal I/O
1 Analog Ground
2 CD right channel IN
3 Analog Ground
4 CD left channel IN
Pin Signal I/O
1 Analog Ground
2 AUX right channel IN
3 Analog Ground
4 AUX left channel IN

HP Kayak XU 03xx PC Workstation Technical Information
System Connectors and Switches
14 English
Audio Front Panel
Connector
The Audio Front Panel Connector, labeled “Audio Front Panel,” is a
10-pin connector that links the system board with the multimedia Front
Panel. This connector directs stereo output to either the front panel
headphone jack or the rear panel stereo jack, as follows:
•When the headphone jack on the Audio Front Panel of the
PC Workstation is not being used, the audio signal is available on the
rear panel and the internal speakers are active.
•When external speakers are plugged into the rear jack, the audio
signal is directed to the rear jack and the internal speakers are
muted.
•When a headphone is plugged into the headphone jack, the audio
signal is directed to the headphone jack, no sound is available on the
rear panel and the internal speakers are muted.
The Audio Front Panel Connector has the following pin assignments:
Refer to the online guide Using Sound, preloaded on your PC
Workstation, for more information about the Audio Front Panel.
Pin Signal I/O
1 Analog Ground
2 Key Way
3 Front Panel input left IN
4 Front Panel return left OUT
5 Front Panel input right IN
6 Front Panel return right OUT
7 Reserved
8 Reserved
9 Reserved
10 Reserved

English 15
HP Kayak XU 03xx PC Workstation Technical Information
System Connectors and Switches
Front Panel Microphone
Connector
The Front Panel Microphone Connector, labeled “Front Panel Micro,” is
a 3-pin connector. The Audio signal from this connector is directly
mixed with the signal from the rear panel Microphone jack. The
connector has the following pin assignments:
Pin Signal I/O
1 MIC signal + power (tip) IN
2 Analog Ground
3 MIC signal + power (ring)
