HP Net Vectra N30 1-1
1
1
HP Net Vectra N30
Models and Accessories
All models have an integrated ATI Rage LT Pro AGP video controller, 4 MB of
integrated video SGRAM, an integrated 16-bit audio controller, and an integrated
Intel 82558 or 82559 10/100BT LAN interface.
Product
Number
Cache
Memory
Hard Drive Std. RAM CD-ROM Floppy
Disk Drive
OS1
HP Net Vectra N30
HP Net Vectra N30 Celeron/366 (CPL: 03/99; discontinued 08/99)
D8053A 128 KB 4.3 GB IDE 32 MB SDRAM no yes Win 95
D8053N 64 MB SDRAM Win NT 4.0
D8870A yes Win 95
D8880N
D8881A Win 98
HP Net Vectra N30 Celeron/400 (CPL: 07/99; discontinued 09/99)
D8877A 128 KB 4.3 GB IDE 64 MB SDRAM yes yes Win 98
D8882A 6.4 GB Win 95
D8883A Win 98
D9046A 32 MB SDRAM no Win 95
D9046N 64 MB SDRAM Win NT 4.0
D9050A yes Win 95
netPC30.fm Page 1 Thursday, December 9, 1999 4:05 PM

HP Net Vectra N30
1-2 HP Net Vectra N30 Desktop
Vectras
1
HP Net Vectra N30 Pentium II/400 (CPL: 04/99; discontinued 09/99)
D8042N 512 KB 4.3 GB IDE 64 MB SDRAM no yes Win NT 4.0
D8042N
#G01
IBM-DOS
D8042N
#G02
128 MB SDRAM
D8051A 32 MB SDRAM Win 95
D8051N 64 MB SDRAM Win NT 4.0
D8874A yes Win 95
D8875N 8.4 GB IDE Win NT 4.0
D8884A 4.3 GB IDE Win 95
D8885A Win 98
HP Net Vectra N30 Pentium III/450 (CPL: 07/99; discontinued 01/00)
D8876A 512 KB 4.3 GB IDE 64 MB SDRAM yes yes Win 98
D8887A Win 95
D8888A Win 98
D8888N Win NT 4.0
D9048A 4.3 GB IDE 32 MB SDRAM no Win 95
D9048N 8.4 GB IDE 64 MB SDRAM Win NT 4.0
D9051A 4.3 GB IDE yes Win 95
D9052N Win NT 4.0
HP Net Vectra N30 Pentium III/500 (CPL: 07/99 )
D9053A 512 KB 8.4 GB IDE 64 MB SDRAM yes yes Win 95
D9054N Win NT 4.0
D9055A 32 MB SDRAM no Win 95
D9055N 64 MB SDRAM Win NT 4.0
D9056A yes DOS
D9057A Win 95
D9058A Win 98
D9058N Win NT 4.0
1. Operating system preloaded on these models, as indicated in the table.
Product
Number
Cache
Memory
Hard Drive Std. RAM CD-ROM Floppy
Disk Drive
OS1
netPC30.fm Page 2 Thursday, December 9, 1999 4:05 PM

HP Net Vectra N30
Desktop
Vectras
HP Net Vectra N30 1-3
1
Note
All models have an integrated PCI audio controller.
Supported Accessories
Support Documentation
Support documentation is available from the HP Web site at:
http://www.hp.com/go/vectrasupport/
Multimedia
HP Slim CD-ROM Drive and Cable D6889A
Other
Underdesk Socket for HP Net Vectra Products D7694A
netPC30.fm Page 3 Thursday, December 9, 1999 4:05 PM

HP Net Vectra N30
1-4 HP Net Vectra N30 Desktop
Vectras
1
System Board, BIOS, and Memory
DIMM1
DIMM2
SLOT 1
Processor:
Intel Pentium II or
Intel Celeron module.
Main Memory:
Two DIMM sockets which support up to
256 MB of memory.
Install 32 MB, 64 MB, or 128 MB SDRAM
modules.
System Board Switches:
See the table on the next page.
AGPset
Rear Panel Connectors
Backplane Slot
PCI set
LAN chip
82558/9
ROM BIOS
CD-ROM Drive Connector
Primary IDE Connector
Floppy Disk Drive Connector
Wake On LAN Connector
ATI Rage LT
PRO AGP
System Board Switches
netPC30.fm Page 4 Thursday, December 9, 1999 4:05 PM

HP Net Vectra N30
Desktop
Vectras
HP Net Vectra N30 1-5
1
System Board Switches
If SW5 and SW6 are set to ON and the PC is restarted, this will initiate the Boot Recovery
mode. Boot Recovery mode forces booting in the BIOS boot block area.
BIOS History
For the latest BIOS, the flasher utility program, and the BIOS history refer to the
HP World Wide Web site.
Switch Function Default
1-4 — Processor frequency, see the following table —
5On Clears CMOS (to reload the Setup program defaults) Off
Off Normal operation
6On Clears User and Administrator passwords Off
Off Normal operation
System Frequency1
1. System frequency is automatically determined by the type of processor.
Switch
Bus 100 MHz Bus 66 MHz 1234
350 MHz2
2. These options are not yet available in any model at the time of printing. This information is
provided for completeness only.
2332MHz On On Off Off
400 MHz 2662MHz On Off On On
450 MHz 3002MHz On Off On Off
500 MHz 3332MHz On Off Off On
Reserved 366 MHz On Off Off Off
Reserved 400 MHz Off On On On
http://www.hp.com/go/vectrasupport/
netPC30.fm Page 5 Thursday, December 9, 1999 4:05 PM

HP Net Vectra N30
1-6 HP Net Vectra N30 Desktop
Vectras
1
Part Numbers
5a
4
3
6
7
8
9
10
1
1a
1b
1c
2
5b
5c
11
netPC30.fm Page 6 Thursday, December 9, 1999 4:05 PM

HP Net Vectra N30
Desktop
Vectras
HP Net Vectra N30 1-7
1
Parts List
Item Description Repl.
Part Number
Exchange
Part Number
1 Box Assembly:
a Chassis Top Cover
b Front Panel Chassis
c Main Chassis
Not shown Plastic top cover and plastic base
5064-9755
5064-9181
—
2 Front bezel (with knobs and lens)
Front bezel (with knobs and lens) for floppy-
less models
Front bezel (with knobs and lens) for Unisys
5064-9199
5064-9198
5064-9731
—
—
—
3 System Board
Also refer to PC’s system board parts list
—D8041-69002
4 Power supply unit 0950-3500 —
5 Internal Cables Kit:
a FDD cable
b HDD cable
c CD-ROM cable and adapter
d Not shown: HDD power cable
5064-7443
Not
Shown
HDD cables (power and data cable) 5065-1248 —
CD-ROM cable and screws kit 5064-9734
6Slim 24✕Max CD-ROM drive 5064-7444 —
7Slim floppy disk drive 5064-7445 —
8 HP Small PC 30 Backplane with metal adapter 5064-9701 —
9 Hard Disk Drives:
4.3 GB
4.3 GB1
6.4 GB
8.4 GB
8.4 GB
8.4 GB1
1. Used on D8042N #G01 and D8042 #G02 only.
—
—
—
—
—
—
D8303-69001
D8304-69002
D8306-69001
D8304-69001
D8307-69001
D8305-69002
10 HP Mouse C3751-60201 —
11 Battery (type: CR2032) 1420-0356 —
Not
Shown
Status Panel with LEDs 5064-7442 —
Standard HP Keyboard C4735-603xx2
2. Where “xx” is the code for your national keyboard.
—
Standard HP Keyboard (Japan) C4732-60324 —
HP Recovery CD-ROM 5011-6649 —
Plastic foot stands (2✕)5042-3069 —
Rubber feet and screws kit 5064-9182 —
netPC30.fm Page 7 Thursday, December 9, 1999 4:05 PM

HP Net Vectra N30
1-8 HP Net Vectra N30 Desktop
Vectras
1
Notes: ______________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
System Board Parts List
Description Repl.
Part Number
Exchange
Part Number
Processors:
Intel Celeron 366/66 with heat sink
Intel Celeron 400/66 with heat sink
Intel Pentium II 400/100 with heat sink
Intel Pentium III 450/100 with heat sink
Intel Pentium III 500/100 with heat sink
Fan for Intel Pentium II and III processor
5064-9705
5064-9800
—
5065-0403
D8041-63104
5064-9706
—
—
D8041-69102
—
—
—
Main memory modules:
1 ✕32-MB main memory 60-ns SDRAM D6501-63101 —
1 ✕64-MB main memory 60-ns SDRAM D6502-63101 —
1 ✕128-MB main memory 60-ns SDRAM — D6503-69101
Manuals and Documentation1
1. Go to HP’s Support Web Site at http://www.hp.com/go/vectraupport/.
User’s Guide D8041-90001
Troubleshooting Guide no number2
2. Electronic file only.
Accessories Guide no number2
