HP Vectra XA 5 Series Manual

Familiarization Guide
HP Vectra XA
5/xxx PC
HP Vectra XA MT PC
HP Vectra XA PC
This guide is for experienced technicians who have already
completed the HP Vectra computer family training course.
In particular, it assumes that the reader is already familiar
with the HP Vectra XA 6/xxx and HP Vectra XM 5/xxx
Series 4 PCs, which have a similar structure.
This document serves as a self-paced training guide,
designed to train you for repair of the computer, and only
contains repair-specific information. For information on the
installation of accessories, see the User’s Guide and the
online documents that are supplied with the computer.

Notice
The information contained in this document is subject to change without notice.
Hewlett-Packard makes no warranty of any kind with regard to this
material, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose.
Hewlett-Packard shall not be liable for errors contained herein or for incidental
or consequential damages in connection with the furnishing, performance, or use
of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of its
software on equipment that is not furnished by Hewlett-Packard.
This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written consent
of Hewlett-Packard Company.
Centronics® is a registered trademark of Centronics Data Computer
Corporation.
Matrox® is a registered trademark of Matrox Electronic Systems Ltd.
MGATM is a trademark of Matrox Graphics Inc.
Microsoft®, Windows® and MS-DOS® are registered trademarks of Microsoft
Corporation.
MMXTM is a trademark of Intel Corporation.
NextStepTM is a trademark of Next Incorporated.
Novell® and Netware® are registered trademarks of Novell Inc.
OS/2TM is a trademark of International Business Machines Corporation.
Pentium® is a registered trademark of Intel Corporation.
SoundBlasterTM is a trademark of Creative Technology Limited.
Hewlett-Packard France
Performance Desktop Computing Orperation
38053 Grenoble Cedex 9
France
1997 Hewlett-Packard Company

1
HP Vectra XA 5/xxx PC
The major new hardware features are:
• New, high performance, Pentium MMX processor.
• 512 KB cache memory on all models.
• New and faster version of Matrox Millennium PCI graphics controller.
• New 10BT/100BT PCI network board on all models.

2
HP Vectra XA 5/xxx PC
External Features
External Features
Wty: WBK@
Sup: SAB@
Model XA 5/200
Prod: D3993A #ABA
S/N: FR63412345
Front label does not show processor
speed or series information. Instead
this information appears on a label
on the lower front recess (desktop
models) or on the right hand side
panel (minitower models).
Voltage selection Power connector
2 ✕USB
Network connectors:
100 BaseT supports Remote Wake-Up
(RWU) only.
10 BaseT supports Remote Power-On
(RPO) as well as RWU.

3
HP Vectra XA 5/xxx PC
Installing Main Memory Modules
Installing Main Memory Modules
• Each memory bank that you use must contain a pair of identical memory
modules, installed in the pair of sockets for that bank.
• The three memory banks (A, B, C) may be filled in any order, but it is ad-
visable, for performance reasons, to fill them in the order A then B then C.
• Memory can be upgraded in increments of 8 MB, 16 MB, 32 MB or 64 MB
(by installing pairs of 4 MB, 8 MB, 16 MB or 32 MB modules).
• HP does not support PCs in which the user has installed non-HP
memory modules.
Initial Configuration Example Upgrade Paths
Models are supplied with 16 MB or 32 MB
of main memory using a pair of 8 MB or
16 MB, 60 ns, EDO memory modules.
The main memory capacity can be extended
to 144 MB or 160 MB by installing a further
two pairs of 32 MB memory modules.
This can be further extended to 192 MB by
removing the original pair of modules, and
replacing them with a pair of 32 MB
modules.
C2 empty 32 MB
C1 empty 32 MB
B2 empty 32 MB
B1 empty 32 MB
A2 8 MB or 16 MB 8 MB or 16 MB
A1 8 MB or 16 MB 8 MB or 16 MB
Banks may be filled in any order, but it is
recommended to fill them in the order of A
then B then C.
Any banks which are occupied must always
be filled with a pair of modules of
identical capacity, type and speed.
Different banks can be occupied by different
capacities of modules, such as a pair of
32 MB modules, a pair of 16 MB modules,
and a bank of 32 MB modules.
C2 empty 32 MB
C1 empty 32 MB
B2 empty 4 MB
B1 empty 4 MB
A2 8 MB or 16 MB 8 MB or 16 MB
A1 8 MB or 16 MB 8 MB or 16 MB

4
HP Vectra XA 5/xxx PC
System Board
System Board
SW10

5
HP Vectra XA 5/xxx PC
Replacing the System Board
Replacing the System Board
Remove the old system board
Install the new system board
Update the product
identification field
Turn the PC off. Set SW10 of the
system board switches to closed.
Flash the System ROM with the latest version of the System BIOS
Turn the PC on. Wait until the
POST displays this message:
Turn the PC off. Set SW10 of the
system board switches to open.
Turn the PC on. Wait until the
POST stops at the 85% stage.
Select Vectra X series
from the menu.
Follow the instructions that are
displayed on the screen.
Product Flag cleared,
set switch to the
open position before
rebooting
0041-49 Invalid
internal product type,
correct with F2.
1.
2.
3.
4.

6
HP Vectra XA 5/xxx PC
MMX Processor
MMX Processor
The new P55C processors, from Intel, are Pentium processors, with the MMX
multimedia extension instructions added to the instruction set.
P55C processors require a different voltage supply. Only use the voltage
regulator model (VRM) that was supplied with the processor.
How to Identify the VRM
The 0950-3188 VRM has the characters “2.8V” marked on it. The 5063-7939
VRM has only the word “Pentium” or a voltage of the form “3.xxV” marked
on it.
How to Identify the Processor
HP Vectra XA PCs exist in two different
forms: one with a system board for a Pentium
or MMX processor, the other with a system
board for a Pentium Pro processor.
All models bear the same front panel logo. Other sources of information
must be sought, in order to ascertain what type of processor is installed.
• The serial label. This is found on the lower front recess of desktop models,
and on the lower part of the right side panel of minitower models. It gives
the following information:
❒Processor type (5/ = Pentium P54 or MMX P55; 6/ = Pentium Pro)
❒Processor frequency (/166 = 166 MHz; /200 = 200 MHz)
❒Product number (D3993A in the example).
The product number is particular useful, since it can be looked up in the
HP Vectra PC Service Handbook.
VRM 3.46 V VRM 2.8 V
P54CS/166 & P54CS/200 5063-7939 Not compatible
P55C/166 & P55C/200 Not compatible 0950-3188
Wty: WBK@
Sup: SAB@
Model XA 5/200
Prod: D3993A #ABA
S/N: FR63412345

7
HP Vectra XA 5/xxx PC
Precautions When Replacing the Power Supply
• The Intel Inside label. Only models containing an MMX (P55C) processor
have the MMX logo (shown at the top left of the previous page).
• The BIOS version number. This is displayed at the top of the summary
screen (obtained by typing whilst the initial Vectra logo is being dis-
played during the Power-On Self Test phase).
• The ultimate solution is to release the lever on the zero insertion force
(ZIF) socket, and to remove the heat-sink and processor together, as a
single unit. Look at the underside of the processor. Only P55Cs are
marked with the words “MMXTM tech”.
Precautions When Replacing the Power Supply
USB Connector
The HP Vectra XA 5/xxx and VL 5/xxx Series 5 PCs are the first Vectra PCs
to have a pair of USB connectors fitted as standard. When devices become
available on the market, they can be activated from the Setup program.
Model Processor BIOS Version Number
HP Vectra XA 5/xxx PC Pentium P54CS or MMX P55C HA.07.xx
HP Vectra XA 6/xxx PC Pentium Pro GZ.07.xx
With the minitower package, always check the position of the voltage
selection switch.

8
HP Vectra XA 5/xxx PC
Backplanes
Backplanes
XA Desktop (front view)
XA Desktop (rear view)
Half length PCI
(proprietary network)
slot
XA Minitower (top view)

9
HP Vectra XA 5/xxx PC
Windows Operating System
Windows Operating System
Some models are preloaded with the Windows NT 4.0 WS operating system.
TopTools 2.0 remote flash and NT local flash.
Graphics Controller Board
The new Matrox MGA Revision 6.0 Millennium board requires new drivers,
and a new 2 MB video memory upgrade part (D3557B).
Version of Matrox Rev. 5.0 Rev. 6.0
Used on HP Vectra XM 5/xxx Series 4 PC HP Vectra XA 5/xxx PC
Exchange part D3568-69005 D3568-69006
2 MB upgrade D3557A or D3557B D3557B only
2 MB upgrade replacement part D3557-63001 or D3557-63002 D3557-63002 only
Video drivers for Rev. 5.0 OK Will not work
Video drivers for Rev. 6.0 OK OK
Top and bottom halves of the
upgrade socket. (For the
installation of a video memory
upgrade module or the Matrox
MPEG module).
Display connector
2 MB memory chips
Configuration switches. (Set to
their bottom position for
normal operation).
576-006 marked on the board.

10
HP Vectra XA 5/xxx PC
Network Board
Network Board
The Ethernet 10/100 BT PCI board is a proprietary PCI network board, with
two network connectors.
If the user complains of poor network performance, check whether the 100
BaseT connector is being used on a 10 BaseT network. (Doing so causes the
100 BaseT connector to switch automatically to a back-up 10 BaseT mode of
operation, but with many retries and the consequent poor performance.)
Connector Properties Configuration needs
10 BT Remote power-on (RPO) and
Remote wake-up (RWU)
Must have cable plugged between the remote start connector on
the network board and the external start connector on the system
board.
Power-on integrated network field set to Enabled.
10 Mbits per second operation No requirements
100 BT Remote wake-up (RWU) Suspend wake-up.
Power-on integrated network field set to Enabled.
External cable not needed
100 Mbits per second operation No requirements
Remote start
10 BaseT RJ-45 UTP connector
100 BaseT RJ-45 UTP connector

11
HP Vectra XA 5/xxx PC
Audio Controller Board
Audio Controller Board
This ISA board is Plug-and-Play. It is supplied with the correct drivers, and
does not require specific configuration when installed in this PC.
Setup Program
Configuration Menu The USB device field is disabled (by default).
The Modem field is applicable to the HP Vectra 500 PC, not to the
HP Vectra XA 5/xxx PC.
Power Menu Remote Wake-Up and Remote Power-On, from the network, are controlled
from this menu.
Line-In
Microphone-In
Line-Out
Speaker-Out
Joystick
Internal
Front panel
CD-Audio
Speaker

12
HP Vectra XA 5/xxx PC
Complete the Questionnaire to Check Your Understanding
Complete the Questionnaire to Check Your Understanding
Draw a circle around each letter that corresponds with a correct answer.
(There may be more than one correct answer to each question).
1You have just replaced the system board, and you find that the PC no
longer responds to remote wake-up. What do you do?
aCheck that the product identification field, on the summary screen or
in the Setup program, has been correctly set for the HP Vectra XA 5/
xxx PC.
bCheck that the suspend-wakeup and the integrated network fields, in
the Setup program, have been enabled.
cCheck that the internal cable from the network board to the system
board is inserted correctly.
2The nine rows of the following table represent the data gathered from
nine PCs. In some of the rows, one of the three fields is inconsistent with
the other two. Strike out the data which are inconsistent.
Marking on the “Intel Inside”
Logo BIOS Revision Marking on the Warranty
Label
a Pentium Pro HA.07.02 XA 5/200
b MMX Pentium GZ.07.03 XA 5/200
c Pentium GZ.07.03 XA 6/200
d MMX Pentium HA.07.02 XA 5/200
e Pentium Pro GZ.07.03 XA 5/200
f MMX Pentium Pro GZ.07.03 XA 6/180
g Pentium Pro GZ.07.03 XA 6/200
h MMX Pentium HA.07.02 XA 5/133
i Pentium HA.07.02 XA 5/200

13
HP Vectra XA 5/xxx PC
Complete the Questionnaire to Check Your Understanding
3How can you identify whether a Pentium MMX processor is installed on a
given HP Vectra XA 5/xxx PC?
aLook on the summary screen, by pressing after a processor restart.
bRun the Setup program, by pressing after a processor restart.
cLook at the underside of the processor chip.
dRun HP TopTools 2.0 for Openview.
4Three clients (a, b and c) have reported having a faulty processor in their
PC. They are able to read out to you the marking on the “Intel Inside” logo,
on the warranty label, and on the summary screen. Which type of
processor (P54, P55 or P6) do you take along to each site? Draw a circle
round the correct answer for each of the three rows of the following table.
Marking on the
“Intel Inside” Logo
Marking on the
Warranty Label BIOS Revision Which processor does the PC need?
a Pentium Pro XA 6/200 GZ.07.03 P54 P55 P6
b Pentium XA 5/200 HA.07.02 P54 P55 P6
c MMX Pentium XA 5/200 HA.07.02 P54 P55 P6

14
HP Vectra XA 5/xxx PC
Answers and Explanations
Answers and Explanations
1The PC no longer responds to remote wake-up. What do you do?
a Check that the product identification field, on the summary screen or
Setup program, has been correctly set for the HP Vectra XA 5/xxx PC.
b Check that the suspend-wakeup and the integrated network fields, in
the Setup program, have been enabled.
Response (a) is the principle answer: an incorrect setting could cause
problems, since the BIOS for the V-line and 500 series do not always take
the network setup into account. If the product field is wrong, it should be
cleared as described on page 5. Response (b) is useful if response (a)
fails to resolve the problem. Response (c) is irrelevant since the problem
is with remote wake-up, not remote power-on.
2Strike out the data which are inconsistent.
3How can you identify whether a Pentium MMX processor is installed?
c Look at the underside of the processor chip.
Reading the marking on the “Intel Inside” logo is a quicker method, but
cannot be relied upon. It should be treated as a clue, not as a proof.
4Which type of processor (P54, P55 or P6) do you take along to each site?
Marking on the “Intel Inside”
Logo BIOS Revision Marking on the Warranty
Label
aPentium Pro HA.07.02 XA 5/200
bMMXPentium GZ.07.03 XA 5/200
cPentium GZ.07.03 XA 6/200
d MMX Pentium HA.07.02 XA 5/200
e Pentium Pro GZ.07.03 XA 5/200
fMMX Pentium Pro GZ.07.03 XA 6/180
g Pentium Pro GZ.07.03 XA 6/200
h MMX Pentium HA.07.02 XA 5/133
i Pentium HA.07.02 XA 5/200
Marking on the
“Intel Inside” Logo
Marking on the
Warranty Label BIOS Revision Which processor does
the PC need?
a Pentium Pro XA 6/200 GZ.07.03 P6
b Pentium XA 5/200 HA.07.02 P54
c MMX Pentium XA 5/200 HA.07.02 P55

15
HP Vectra XA 5/xxx PC
Answers and Explanations

Paper not bleached with chlorine.
Manual Part Number D3984-90901
Printed in France - 03/97
50%
