HP 930 User manual

user's manualuser's manual
hp
photosmart
930
series
digital
camera
user's manual
2005.09.01
数码说明书之家
www.54gg.com
数码说明书之家
www.54gg.com
2005.09.01

Trademark and copyright information
© Copyright 2003 Hewlett-Packard Company
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated to another language without the prior written
consent of Hewlett-Packard Company.
The information contained in this document is subject to change
without notice. Hewlett-Packard shall not be liable for errors contained
herein or for consequential damages in connection with the furnishing,
performance, or use of this material.
Microsoft® and Windows® are U.S. registered trademarks of
Microsoft Corporation.
Apple®, Macintosh®, and Mac® are registered trademarks of Apple
Computer, Inc.
PENTAX® is a registered trademark of PENTAX Corporation.
The SD logo is a trademark of the SD Card Association.
MultiMediaCardTM is a trademark of Infineon Technologies AG.
2005.09.01
数码说明书之家
www.54gg.com

Table of Contents
Chapter 1:
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Camera parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Attaching the wrist strap . . . . . . . . . . . . . . . . . . 15
Installing the batteries . . . . . . . . . . . . . . . . . . . 16
Installing the memory card . . . . . . . . . . . . . . . . 16
Turning on power . . . . . . . . . . . . . . . . . . . . . . 17
Understanding the status screen . . . . . . . . . . . . 17
Restoring previous settings . . . . . . . . . . . . . . . . 18
Choosing the language . . . . . . . . . . . . . . . . . . 18
Setting the date and time . . . . . . . . . . . . . . . . . 18
Installing the software . . . . . . . . . . . . . . . . . . . 19
Windows . . . . . . . . . . . . . . . . . . . . . . . . . 19
Macintosh . . . . . . . . . . . . . . . . . . . . . . . . 20
Camera states and menus . . . . . . . . . . . . . . . . . . . . 21
Chapter 2:
Taking pictures and recording video clips . . . .22
Taking still pictures . . . . . . . . . . . . . . . . . . . . . . . . . 22
Recording audio with still pictures . . . . . . . . . . . . . . 23
Recording video clips . . . . . . . . . . . . . . . . . . . . . . . 24
Taking self-timer pictures . . . . . . . . . . . . . . . . . . . . . 25
Using the focus brackets . . . . . . . . . . . . . . . . . . . . . 26
Using focus lock . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Using live view . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Setting the focus range . . . . . . . . . . . . . . . . . . . . . . 30
Setting the exposure mode . . . . . . . . . . . . . . . . . . . 31
Using exposure compensation . . . . . . . . . . . . . . . . . 32
Setting the flash . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Using zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Optical zoom . . . . . . . . . . . . . . . . . . . . . . . . . 35
Digital zoom . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Using the capture menu . . . . . . . . . . . . . . . . . . . . . 36
Help for the menu options . . . . . . . . . . . . . . . . 37
Self-timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
White balance . . . . . . . . . . . . . . . . . . . . . . . . 39
AE metering . . . . . . . . . . . . . . . . . . . . . . . . . . 41
ISO speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Red-eye reduction . . . . . . . . . . . . . . . . . . . . . . 43
Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Compression . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Saturation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Sharpness . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Chapter 3:
Reviewing images and video clips . . . . . . . . . .49
Using playback . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Using the playback menu . . . . . . . . . . . . . . . . . . . . 51
Play/Record audio . . . . . . . . . . . . . . . . . . . . . 54
Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Record audio . . . . . . . . . . . . . . . . . . . . . . 54
Delete . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Magnify . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Rotate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Image info . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Chapter 4:
Using hp instant share . . . . . . . . . . . . . . . . . . . .59
Using the share menu . . . . . . . . . . . . . . . . . . . . . . . 60
Using hp instant share to print pictures . . . . . . . . . . . 61

hp photosmart 930 series user’s manual
Using the hp instant share e-mail service . . . . . . . . . .62
Adding e-mail addresses and
group distribution lists . . . . . . . . . . . . . . . . . . .62
Selecting images to be e-mailed . . . . . . . . . . . .65
Windows . . . . . . . . . . . . . . . . . . . . . . . . .66
Macintosh . . . . . . . . . . . . . . . . . . . . . . . . .66
Chapter 5:
Unloading and printing images . . . . . . . . . . . . 67
Unloading to a computer . . . . . . . . . . . . . . . . . . . . .67
Printing images . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Chapter 6:
Using the setup menu . . . . . . . . . . . . . . . . . . . . 70
Camera sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . .71
Date & time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
USB configuration . . . . . . . . . . . . . . . . . . . . . . . . . .72
TV configuration . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Chapter 7:
Troubleshooting and support . . . . . . . . . . . . . . 75
Problems and solutions . . . . . . . . . . . . . . . . . . . . . .75
Resetting the camera . . . . . . . . . . . . . . . . . . . . . . . .83
Error messages on the camera . . . . . . . . . . . . . . . . .84
Error messages on the computer . . . . . . . . . . . . . . . .91
Getting assistance . . . . . . . . . . . . . . . . . . . . . . . . . .93
HP accessibility website . . . . . . . . . . . . . . . . . . .93
HP photosmart website . . . . . . . . . . . . . . . . . . .93
Support process . . . . . . . . . . . . . . . . . . . . . . . .93
Phone support in the United States . . . . . . . . . . .95
Phone support in Europe, the Middle East,
and Africa . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Other phone support worldwide . . . . . . . . . . . .98

Appendix A:
Batteries and camera accessories . . . . . . . . . .100
Managing batteries . . . . . . . . . . . . . . . . . . . . . . . 100
Extending battery life . . . . . . . . . . . . . . . . . . . 101
Rechargeable batteries . . . . . . . . . . . . . . . . . . 102
Power conservation . . . . . . . . . . . . . . . . . . . . 102
Purchasing camera accessories . . . . . . . . . . . . . . . 103
Appendix B:
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . .105
Memory card capacity . . . . . . . . . . . . . . . . . . . . . 110

8 hp photosmart 930 series user’s manual
Chapter 1:
Getting started
Congratulations on your purchase of this digital camera! Your
new camera has many features to enhance your picture-taking
experience, including HP Instant ShareTM, direct printing
capability, manual and automatic controls, on-camera Help,
and an optional camera dock.
With HP Instant Share, you can easily select pictures on your
camera to e-mail or print automatically the next time you
connect the camera to your computer. So, within minutes, your
friends and family can be viewing your pictures without
burdening them with large e-mail attachments. Or you can use
the direct printing capability with any HP Photosmart printer or
other select HP printer without ever connecting to your
computer. What a great way to keep others close while you
capture precious memories!
To further enhance your experience, you may purchase an
HP Photosmart 8886 camera dock (see page 103). The
camera dock allows you to easily download images to a
computer, send images to a printer or television, and recharge
the camera batteries.
NOTE A dock insert is included in your
camera box which enables your
camera (and others of the same
model) to use the HP camera dock.
Please do not use the dock insert
without the camera dock and do not discard it. See the
HP 8886 Camera Dock User’s Manual for instructions on
using the dock insert with the camera dock.
2005.09.01
数码说明书之家
www.54gg.com

Chapter 1: Getting started 9
Camera parts
NOTE Refer to the pages in parentheses after the part names
for more information about those parts.
#Name Description
1ON/OFF
switch (page 17)
Turns the camera power on and off
2Zoom lever with
Zoom Out
and Zoom In
controls
(page 35)
Zooms out the lens to the wide angle
position, and zooms in the lens to the
telephoto position
3 Wrist strap
mount (page 15)
Allows you to attach a wrist strap
10
2
3
4
5
6
78
9
11
1
13
12

10 hp photosmart 930 series user’s manual
4 Power/Memory
light (page 17)
Solid—camera is on
Fast blinking—camera is writing to the
memory card
Slow blinking—camera is off and is
charging the batteries
Off—camera is off
5Memorycard
door (page 16)
Allows you access to insert or remove
the memory card
6OK button
(pages 36, 51)
Allows you to display the Capture
and Playback menus and to select
menu options on the Image Display
7Controller
with and
buttons
Allows you to move through menus
and images on the Image Display
8Share
button (page 60)
Turns the Share menu on and off the
Image Display
9Playback
button (page 49)
Turns Playback on and off the Image
Display
10 Live View
button (page 28)
Turns Live View on and off the Image
Display
11 Image Display
(page 28)
Allows you to frame pictures and video
clips using Live View and review them
afterward in Playback, and to view all
the menus
#Name Description
/

Chapter 1: Getting started 11
12 Viewfinder
(page 22)
Allows you to frame the subject of your
picture or video clip
13 Viewfinder lights:
Video and
AF/ Auto
Exposure/Auto
Focus and Flash
is solid red—video is recording
AF/ is solid green—after you
pressed the Shutter button halfway
down, the camera is ready (auto
exposure and auto focus are locked,
and the flash is ready)
AF/ is blinking green—either a
focus error occurred when you pressed
the Shutter button halfway down, the
flash is charging, or the camera is
processing a picture (see the following
NOTE)
Both and AF/ are blinking—an
error has occurred, for example, the
memory card is full or there is no
memory card in the camera (see the
following NOTE)
NOTE If an error prevents a picture
from being taken, then an error
message will display on the
Image Display. See Error
messages on the camera on
page 84.
#Name Description

12 hp photosmart 930 series user’s manual
#Name Description
1Focus button
(page 30) Allows you to select the Macro
focus range setting (to take close-up
pictures), or the Infinity focus range
setting (to take pictures of distant
objects and landscapes)
2Focuslights:
Macro and
Infinity focus
(page 30)
Lights solid when you select the
Macro or the Infinity focus
range setting
3 Speaker Plays camera sounds and audio clips
4Shutter button
(pages 22, 25)
Takes a picture and records audio
5Video
button
(page 24)
Starts and stops recording a video clip
4
5
7
3
86
12

Chapter 1: Getting started 13
6 Flash lights:
Flash Off,
Flash On,
and Night
(page 33)
Lights solid when you select the Flash
Off , Flash On , or Night
flash setting
7Flash button
(page 33) Allows you to select the Flash Off ,
Flash On , or Night flash setting
8Exposure Mode
dial with
Action,
Landscape,
Portrait,
Auto, and
Av Aperture
Priority settings
(page 31)
Allows you to select the exposure mode
#Name Description

14 hp photosmart 930 series user’s manual
#Name Description
1Microphone
(page 23)
Records audio clips
2Self-Timerlight
(page 25)
Blinks during the 10-second
countdown before taking a picture
when Self-Timer in the Capture menu
is set to On or On - 2 shots. When set
to On - 2 shots, blinks during the
additional time between the first and
second shots.
3 Flash (page 33) Provides additional light to improve
picture-taking
4USBconnector
(pages 67, 68)
Allows you to connect a USB cable
from the camera to a USB-enabled
computer or printer
678
1
4
5
23

Chapter 1: Getting started 15
Setup
Attaching the wrist strap
Attach the wrist strap to the
wrist strap mount on the side
of the camera as shown.
5 Power adapter
connector
(page 104)
Allows you to connect an optional
HP AC power adapter to the camera to
either operate the camera without
batteries, or recharge the batteries in
the camera
6 Tripod mount Allows you to mount the camera to
a tripod
7 Camera dock
connector
(page 103)
Allows you to connect the camera to
the optional HP 8886 camera dock
8 Battery door
(page 16)
Allows access to insert and remove
the batteries
#Name Description

16 hp photosmart 930 series user’s manual
Installing the batteries
1Open the battery door on
the bottom of the camera.
2Insert the batteries as
indicated inside the door.
3Close the battery door.
NOTE For more information about batteries, see Managing
batteries on page 100. You can also use an optional HP
AC power adapter to power the camera and recharge
batteries in the camera. For more information about the
HP AC power adapter, see Purchasing camera accessories
on page 103.
Installing the memory card
1With the camera turned off and
the back of the camera facing you,
open the memory card door by
sliding the door to the right.
2Insert the memory card, making
sure that it snaps into place.
3Close the memory card door.
To remove the memory card, first
make sure the camera is turned off.
Open the memory card door, then
push the memory card in and it will
spring outward from the connector.

Chapter 1: Getting started 17
Turning on power
Turn the camera on by sliding the
ON/OFF switch to the right and
then releasing it.
The lens extends, the Image Display
turns on, and the Power/Memory
light turns on solid.
Understanding the status screen
When you turn on the camera, the HP logo screen and then the
status screen display for a few seconds on the Image Display.
The main part of the status screen
shows the current focus, flash,
Resolution, and Compression
settings, as well as the battery level
and pictures remaining count. Any
non-default Capture menu settings
are also shown across the top of the
status screen.
The status screen is also displayed for a few seconds any time
you change the focus range, exposure mode, or flash settings
on the camera. (See Setting the focus range on page 30,
Setting the exposure mode on page 31, and Setting the flash
on page 33.)

18 hp photosmart 930 series user’s manual
Restoring previous settings
Some of the settings that you can change in the camera menus
do not remain set after you turn the camera off. However, you
can restore the settings from the last time the camera was on
and had at least one non-default setting (which could actually
be several power cycles ago) by holding down the OK button
while also sliding the ON/OFF switch to turn the camera on.
The restored settings are then displayed across the top of the
status screen. (See the previous section.)
Choosing the language
The first time you turn the camera on, the following screen
appears and prompts you to choose a language.
1Scroll to the language that you
want by using the buttons
on the Controller .
2Press the OK button to select the
highlighted language.
Setting the date and time
The camera has a clock that records the date and time at which
you take each picture. The first time you turn the camera on, the
following screen appears after you choose the language.
1Adjust the value of the
highlighted selection by
using the buttons.
2Press the buttons to move to
the other selections.

Chapter 1: Getting started 19
Repeat steps 1 and 2 until the correct date, time, and date/
time format are set.
NOTE In the date/time format, mm=month, dd=day, and
yyyy=year.
3Press the OK button when the proper values are entered.
The Image Display then turns off.
Installing the software
The camera software allows you to unload images from the
camera, view them, print them, and e-mail them. It also allows
you to configure the Share menu on the camera.
See Chapter 4: Using hp instant share on page 59 for
information about configuring the Share menu on the
camera, and Chapter 5: Unloading and printing images on
page 67 for information about connecting the camera to a
computer or printer.
NOTE Copies of this User’s Manual are located on the HP
Photo & Imaging software CD. Look in the \docs\Readme
file on the CD to see where the manual in your language
is located.
Windows
NOTE For the HP Instant Share component of the HP Photo &
Imaging software to function properly on your Windows
computer, you must have installed at least Internet Explorer
5.01 on Windows 2000 or XP, or Internet Explorer 5.01
Service Pack 2 on Windows 98, 98 SE, or Me.
1Insert the HP Photo & Imaging software CD into the CD
drive of your computer. The installation window
automatically appears.

20 hp photosmart 930 series user’s manual
NOTE If the installation window does not appear, click Start,
and then click Run. Type X:\Setup.exe, where X
is the
letter of your CD drive.
2Click Next, and then follow the on-screen instructions to
install the software.
Your Windows CD may also include bonus software from other
manufacturers. To install any bonus software:
1Click Start, click Run, and in the Open box, type
X:\Bonus\setup.exe (where Xis the letter of your CD drive).
2Click OK, and then follow the on-screen instructions to
install the bonus software.
Macintosh
1Insert the HP Photo & Imaging software CD into the CD
drive of your computer.
2Double-click the CD icon on the computer desktop.
3Double-click the installer icon, and then follow the on-screen
instructions to install the software.
NOTE Before you can unload images from the camera to a
Macintosh computer, you must first change the USB
Configuration setting to Disk Drive in the Setup menu on
the camera. See Chapter 6: Using the setup menu on
page 70, and then see USB configuration on page 72.
Your Macintosh CD may also include bonus software from
other manufacturers. To install any bonus software:
1Double-click the Bonus folder icon.
2Double-click the installer icon for the bonus software.
3Follow the on-screen instructions to install the software.
