HP 320 - Notebook PC Manual

Compaq 320 Notebook PC
Compaq 321 Notebook PC
Compaq 420 Notebook PC
Compaq 421 Notebook PC
Compaq 620 Notebook PC
Compaq 621 Notebook PC
HP 420 Notebook PC
HP 620 Notebook PC
Maintenance and Service Guide

Bluetooth is a trademark owned by its
proprietor and used by Hewlett-Packard
Company under license. Intel, Core, and
Celeron are trademarks of Intel Corporation
in the United States and other countries.
Microsoft, Windows, and Windows Vista
are U.S. registered trademarks of Microsoft
Corporation. SD Logo is a trademark of its
proprietor.
The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.
First Edition: April 2010
Document Part Number: 601871-001

Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not
place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a
hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft
surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to
contact the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer
and the AC adapter comply with the user-accessible surface temperature limits defined by the
International Standard for Safety of Information Technology Equipment (IEC 60950).
iii

iv Safety warning notice

Table of contents
1 Product description ........................................................................................................... 1
2 External component identification ................................................................................... 10
Top Components .................................................................................................................... 10
TouchPad ............................................................................................................... 10
Lights ..................................................................................................................... 11
Buttons, switch, and speaker ..................................................................................... 13
Keys ...................................................................................................................... 14
Front components ................................................................................................................... 16
Right-side components ............................................................................................................ 16
Left-side components ............................................................................................................... 18
Bottom components ................................................................................................................ 19
Multimedia components .......................................................................................................... 20
Wireless antennas (select models only) ..................................................................................... 22
Additional hardware components ............................................................................................ 23
3 Illustrated parts catalog .................................................................................................. 24
Service tag ............................................................................................................................ 24
Computer major components ................................................................................................... 26
Display assembly components ................................................................................................. 32
Plastics Kit ............................................................................................................................. 33
Cables .................................................................................................................................. 34
Mass storage devices ............................................................................................................. 36
Miscellaneous parts ................................................................................................................ 37
Sequential part number listing .................................................................................................. 39
4 Removal and replacement procedures ............................................................................ 46
Preliminary replacement requirements ....................................................................................... 46
Tools required ......................................................................................................... 46
Service considerations ............................................................................................. 46
Plastic parts ............................................................................................. 46
Cables and connectors ............................................................................. 47
Drive handling ......................................................................................... 47
v

Grounding guidelines .............................................................................................. 48
Electrostatic discharge damage .................................................................. 48
Packaging and transporting guidelines ........................................ 49
Workstation guidelines .............................................................. 49
Equipment guidelines ................................................................. 50
Component replacement procedures ........................................................................................ 51
Service tag ............................................................................................................. 51
Computer feet ......................................................................................................... 52
Battery ................................................................................................................... 53
Service door ........................................................................................................... 53
Hard drive ............................................................................................................. 56
Memory module ...................................................................................................... 59
WLAN module ........................................................................................................ 61
Optical drive .......................................................................................................... 62
Fan ....................................................................................................................... 64
Heat sink ............................................................................................................... 65
Processor ............................................................................................................... 66
Palm rest ................................................................................................................ 68
Keyboard ............................................................................................................... 73
Top cover ............................................................................................................... 77
Power switch board ................................................................................................. 82
Bluetooth module .................................................................................................... 84
USB connector assembly .......................................................................................... 85
Speaker ................................................................................................................. 87
Display assembly .................................................................................................... 88
System board ......................................................................................................... 96
Main battery connector .......................................................................................... 100
RTC battery .......................................................................................................... 102
Modem module .................................................................................................... 103
Audio board .........................................................................................................105
5 Computer Setup ........................................................................................................... 107
Computer Setup in Windows ................................................................................................. 107
Starting Computer Setup ........................................................................................ 107
Using Computer Setup ........................................................................................... 107
Navigating and selecting in Computer Setup ............................................. 107
Restoring factory settings in Computer Setup ..............................................108
Computer Setup menus .......................................................................................... 109
File menu .............................................................................................. 109
Security menu ........................................................................................ 111
System Configuration menu ..................................................................... 112
Computer Setup in Linux ....................................................................................................... 116
Starting Computer Setup ........................................................................................ 116
vi

Using Computer Setup ........................................................................................... 117
Navigating and selecting in Computer Setup ............................................. 117
Restoring factory settings in Computer Setup .............................................. 117
Computer Setup menus .......................................................................................... 118
File menu .............................................................................................. 118
Security menu ........................................................................................ 119
Diagnostics menu ................................................................................... 119
System Configuration menu ..................................................................... 120
6 Specifications ................................................................................................................ 122
Computer specifications ........................................................................................................ 122
39.6-cm (15.6-in) display specifications .................................................................................. 123
35.6-cm (14.0-in) display specifications .................................................................................. 125
33.8-cm (13.3-in) display specifications .................................................................................. 126
Hard drive specifications ...................................................................................................... 127
DVD-ROM Drive specifications ............................................................................................... 128
DVD±RW Double-Layer Combo Drive specifications ................................................................. 129
7 Backup and recovery .................................................................................................... 130
Backup and recovery in Windows 7 ....................................................................................... 130
Overview ............................................................................................................. 130
Backing up your information ................................................................................... 130
Performing a recovery ........................................................................................... 132
Using the Windows recovery tools .......................................................................... 132
Using f11 ............................................................................................................. 133
Using a Windows 7 operating system DVD (purchased separately) ............................. 133
Backup and recovery in Windows Vista .................................................................................. 134
Overview ............................................................................................................. 134
Backing up your information ................................................................................... 134
Performing a recovery ........................................................................................... 135
Using the Windows recovery tools .......................................................................... 136
Using f11 ............................................................................................................. 136
Using a Windows Vista operating system DVD (purchased separately) ........................ 137
Backup and recovery in Windows XP ..................................................................................... 138
Overview ............................................................................................................. 138
Backing up your information ................................................................................... 138
Performing a recovery ........................................................................................... 139
Recovering your information .................................................................... 139
Recovering the operating system and programs ......................................... 139
8 Connector pin assignments ........................................................................................... 141
Audio-in (microphone) .......................................................................................................... 141
Audio-out (headphone) ......................................................................................................... 141
vii

External monitor ................................................................................................................... 142
HDMI ................................................................................................................................. 143
RJ-11 (modem) ..................................................................................................................... 144
RJ-45 (network) .................................................................................................................... 145
Universal Serial Bus .............................................................................................................. 145
9 Power cord set requirements ........................................................................................ 146
Requirements for all countries and regions ............................................................................... 146
Requirements for specific countries and regions ....................................................................... 147
10 Recycling .................................................................................................................... 148
Battery ................................................................................................................................ 148
Display ............................................................................................................................... 148
Index ............................................................................................................................... 154
viii

1 Product description
Category Description UMA
graphics,
GL40 chipset
UMA
graphics,
GM45 chipset
Discrete
graphics,
PM45
chipset
Product Name Compaq 320 Notebook PC • •
Compaq 321 Notebook PC •
Compaq 420 Notebook PC • •
Compaq 421 Notebook PC •
Compaq 620 Notebook PC • •
Compaq 621 Notebook PC •
HP 420 Notebook PC • •
HP 620 Notebook PC • •
Processors Intel® Celeron® processors
T3300, 2.00-GHz, 800-MHz FSB, 1-MB
cache
• •
T3100, 1.90-GHz, 800-MHz FSB, 1-MB
cache
• •
T1700, 1.83-GHz, 667-MHz FSB, 1-MB
cache
• •
T1600, 1.66-GHz, 667-MHz FSB, 1-MB
cache
• •
900, 2.20-GHz, 800-MHz FSB, 1-MB cache • •
Intel® Pentium® processor
T4400, 2.20-GHz, 800-MHz FSB, TJ 100 • • •
T4300, 2.10-GHz, 800-MHz FSB, TJ 100 • • •
T4200, 2.00-GHz, 800-MHz FSB, TJ 100 • • •
Intel® Core™ 2 Duo processor
T5870, 2.00-GHz, 800-MHz FSB, 2-MB
cache
• for 39.6-cm
(15.6-in) only
••
1

Category Description UMA
graphics,
GL40 chipset
UMA
graphics,
GM45 chipset
Discrete
graphics,
PM45
chipset
P7570, 2.26-GHz, 1066-MHz FSB, 3-MB
cache
••
P7370, 2.00-GHz, 1066-MHz FSB, 3-MB
cache
••
T6670, 2.20-GHz, 800-MHz FSB, 2-MB
cache
••
T6570, 2.10-GHz, 800-MHz FSB, 2-MB
cache
••
Chipsets Intel GL40 with 667-MH FSB •
Intel GM45 with up to 1066-MHz FSB •
Intel PM45 with up to 1066-MHz FSB •
ICH-9M Southbridge • • •
Graphics Intel GMA 4500M Universal Memory
Architecture (UMA) graphics subsystem
integrated with shared video memory
(dynamically allocated)
•
Intel GMA 4500MHD Universal Memory
Architecture (UMA) graphics subsystem
integrated with shared video memory
(dynamically allocated)
•
ATI Mobility Radeon HD 530v with 512-MB
memory
•
Panels All display assemblies support privacy filter • • •
33.8-cm (13.3-in) HD LED backlight panel:
●1366×768 AntiGlare
●1366×768 AntiGlare for webcam
●1366×768 BrightView
●1366×768 BrightView for Webcam
•• •
35.6-cm (14.0-in) HD LED backlight panel:
●1366×768 AntiGlare
●1366×768 AntiGlare for webcam
●1366×768 BrightView
●1366×768 BrightView for Webcam
•• •
2 Chapter 1 Product description
