HP Compaq 6710b Notebook PC

TAILORED FOR BUSINESS

Extensive connectivity, 15.4” widescreen, Intel processors

HP recommends Windows Vista™ Business

Focused on your business

The HP Compaq 6710b Notebook PC offers cost-

effective business computing without compromising

on connectivity or productivity. This thin and light

notebook works just as hard as you do and

includes the latest Intel®Core™2 Duo Processors, a

range of mobile features, and compatibility with HP

Universal Accessories.

Broaden your perspective

Select the right 15.4-inch diagonal widescreen

display that best suits your needs – either a

WSXGA+ WVA (wide-viewing angle) anti-glare

display or a WXGA with your choice of an anti-

glare display or HP BrightView display.

Technology in tune with your needs

Experience new levels of system responsiveness

when running multiple applications and smarter

battery performance designed to help extend

mobility with Intel®Core™2 Duo Processor.2

Quickly store data and synchronize with different

types of devices with the integrated Media Card

Reader; while the optional DVD+/–RW SuperMulti

DL LightScribe3Drive lets you burn custom labels

directly to your disc.

Enjoy wireless in more places

Whether you’re across the street or across the

country, HP Broadband Wireless Plus4,5,6 (includes

built-in WWAN + 802.11n (draft) WLAN +

Bluetooth®technologies) allows you to conveniently

stay connected in more places.

HP Professional Innovations help you focus on your

business

Built to protect. Multi-layered, customizable security

solutions help defend your network, your

applications, and your data. The new Drive

Encryption for HP ProtectTools encodes all

information on the hard drive volume so it becomes

unreadable to an unauthorized person.

Built to simplify. Boost your productivity while

maximizing simplicity with features such as HP

QuickLook. Now you can quickly browse your

email, calendars, and contact information with a

touch of a button whether your PC is turned on or

not.

Built to last. Reliable features such as HP DuraFinish

and HP 3D DriveGuard so your notebook can go

the distance.

HP Compaq 6710b Notebook PC

HP recommends Windows Vista™ Business

Operating System Preinstalled:

Genuine Windows Vista Business 32/641

Genuine Windows Vista Home Basic1

Genuine Windows XP Professional

FreeDOS

Supported:

Genuine Windows Vista Enterprise

Certified:

SuSe Linux Enterprise Desktop 10

Processor2Intel®CoreTM2 Duo (up to 2.4-GHz, up to 4-MB L2 cache)

Chipset Mobile Intel®GM965

Memory DDR2 SDRAM, 667-MHz, two SODIMM slots supporting dual channel memory, 512/1024/2048/4096-MB

Hard drive(s)7SATA 80/120/160-GB 5400 rpm, 80-GB 7200 rpm, HP 3D DriveGuard

Removable media312.7-mm optical drives: DVD+/–RW SuperMulti DL LightScribe, DVD+/–RW SuperMulti DL, DVD/CD-RW Combo, DVD-ROM

Display 15.4-inch diagonal WSXGA+ WVA (1680 x 1050 and 16M colors), 15.4-inch diagonal WXGA (1280 x 800 and 16M

colors), 15.4-inch diagonal WXGA BrightView (1280 x 800 and 16M colors)

Graphics8Intel GMA X3100, up to 384-MB shared system memory

Audio High Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in, integrated mono microphone

Wireless support4,5,6 Optional HP ev2200 1xEV-DO Broadband Wireless Module (requires Verizon Wireless Service), optional HP hs2300 HSDPA

Broadband Wireless Module (requires mobile network operator service); Intel PRO/Wireless 802.11a/b/g/draft-n, a/b/g, b/g,

Broadcom 802.11a/b/g/draft-n, a/b/g, b/g, Bluetooth™ 2.0, HP Wireless Assistant

Communications Broadcom NetLink Gigabit Ethernet PCI Controller9(10/100/1000 NIC), 56K v.92 modem

Expansion slots 1 Type I/II PC Card slot supports 32-bit CardBus and 16-bit cards, Media Card Reader

Ports and connectors 4 USB 2.0 ports, VGA, stereo microphone in, stereo headphone/line out, 1394a, power connector, RJ-11/modem, RJ-

45/ethernet, S-video TV out, docking connector, secondary battery connector

Input device Full-sized keyboard, Touchpad with scroll zone, HP Fingerprint Sensor

Software HP Backup and Recovery Manager, Roxio Creator 9, Microsoft Office 2007 Small Business or Professional (optional)

Security HP ProtectTools, TPM Embedded Security Chip 1.2,12 HP Fingerprint Sensor, Symantec Norton Internet Security, optional Smart

Card Reader,10 Kensington lock, HP Privacy Filter (optional)

Dimensions (h × w × d) 1.37 in (at front) x 14.05 in x 10.43 in / 34.8 mm (at front) x 356.9 mm x 264.9 mm

Weight starting at weight: 5.93 lbs / 2.69 kg (weight will vary by configuration)

Power 6-cell (55 WHr) Lithium-Ion battery, 6-cell (47 WHr) Lithium-Ion battery, optional HP (52 WHr) Extended Life Battery,10 optional

HP (95 WHr) Ultra-Capacity Battery,10 90W HP Smart AC Adapter, HP Fast Charge11

Expansion solutions10 HP 3-in-1 NAS Docking Station, HP Advanced Docking Station, HP Docking Station, HP Monitor Stand, HP Adjustable Notebook

Stand, HP External MultiBay II

Warranty Limited 3-year, 1-year and 90-day warranty options available, depending on country, 1-year limited warranty on primary battery

1. Certain Windows Vista product features require advanced or additional hardware. See http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and

http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade Advisor can help you determine which features of Windows Vista will run on your computer. To download the

tool, visit www.windowsvista.com/upgradeadvisor. 2. Dual Core is a new technolo

y desi

ned to improve performance of certain software products. Not all customers or software applications will necessarily benefit

from use of this technology. 64-bit computing on Intel architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers and applications enabled for Intel® 64 architecture.

Processors will not operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary depending on your hardware and software configurations. See www.intel.com/info/em64t

for more information. 3. Do not copy copy-right protected materials. Intended for creation and storage of your original material and other lawful uses. Double Layer discs can store more data than single layer discs.

Double-layer discs burned with this drive may not be compatible with many existing single-layer DVD drives and players. LightScribe creates a monochrome image. LightScribe media required and sold separately.

Note that DVD-RAM cannot read or write to 2.6GB Single Sided/5.2 GB Double Sided – Version 1.0 media. 4. Wireless use requires separately purchased service contract. Check with service provider for

availability and coverage in your area. Available in select countries only. 5. The specifications for the 802.11n WLAN are draft specifications and are not final. If the final specifications differ from the draft

specifications, it may affect the ability of the notebook to communicate with other 802.11n WLAN devices. 6. Wireless access point required and is not included. Availability of public wireless access points limited.

Wireless Internet use requires separately purchased Internet service contract. 7. For hard drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 8GB (for XP) and 10GB (for Vista) of system disk is

reserved for the system recovery software. 8. Shared video memory (UMA) uses part of the total system memory for video performance. System memory dedicated to video performance is not available for other use

by programs. 9. The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/sec. For high speed

transmission, connection to a Gigabit Ethernet server and network infrastructure is required. 10. Sold separately or purchased as an optional feature. 11. HP Fast Charge recharges your primary battery up to 90%

within 90 minutes when the system is off. HP Fast Charge does not apply to 9 cell primary and 12 cell Ultra Capacity batteries. 12 TPM module disabled where not permitted by law (for example, Russia).
