HP Pavilion 17 Manual

HP Pavilion 17 TouchSmart Notebook
PC
HP Pavilion 17 Notebook PC
Maintenance and Service Guide

© Copyright 2014 Hewlett-Packard
Development Company, L.P.
AMD, the AMD Arrow logo, and
combinations thereof, are trademarks of
Advanced Micro Devices, Inc. Bluetooth is
a trademark owned by its proprietor and
used by Hewlett-Packard Company under
license. Intel, Celeron, Core, and Pentium
are U.S. registered trademarks of Intel
Corporation. Microsoft and Windows are
U.S. registered trademarks of the Microsoft
group of companies. SD Logo is a
trademark of its proprietor.
The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.
Third Edition: January 2014
First Edition: April 2013
Document Part Number: 718337-003
Product notice
This guide describes features that are
common to most models. Some features
may not be available on your computer.
Not all features are available in all editions
of Windows 8. This computer may require
upgraded and/or separately purchased
hardware, drivers, and/or software to take
full advantage of Windows 8 functionality.
See http://www.microsoft.com for details.
Software terms
By installing, copying, downloading, or
otherwise using any software product
preinstalled on this computer, you agree to
be bound by the terms of the HP End User
License Agreement (EULA). If you do not
accept these license terms, your sole
remedy is to return the entire unused
product (hardware and software) within 14
days for a refund subject to the refund
policy of your place of purchase.
For any further information or to request a
full refund of the computer, please contact
your local point of sale (the seller).

Important Notice about Customer Self-Repair Parts
CAUTION: Your computer includes Customer Self-Repair parts and parts that should only be
accessed by an authorized service provider. See Chapter 5, "Removal and replacement procedures
for Customer Self-Repair parts," for details. Accessing parts described in Chapter 6, "Removal and
replacement procedures for Authorized Service Provider only parts," can damage the computer or
void your warranty.
iii

iv Important Notice about Customer Self-Repair Parts

Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the device, do not
place the device directly on your lap or obstruct the device air vents. Use the device only on a hard,
flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft
surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to
contact the skin or a soft surface, such as pillows or rugs or clothing, during operation. The device
and the AC adapter comply with the user-accessible surface temperature limits defined by
the International Standard for Safety of Information Technology Equipment (IEC 60950).
v

vi Safety warning notice

Table of contents
1 Product description ........................................................................................................................................ 1
2 External component identification .............................................................................................................. 10
Finding your hardware and software information ............................................................................... 10
Locating hardware ............................................................................................................. 10
Display ................................................................................................................................................ 10
Buttons and speakers ......................................................................................................................... 12
Keys ................................................................................................................................................... 13
Lights .................................................................................................................................................. 14
TouchPad ........................................................................................................................................... 15
Left side .............................................................................................................................................. 15
Right side ........................................................................................................................................... 17
Bottom ................................................................................................................................................ 18
Labels ................................................................................................................................................. 18
3 Illustrated parts catalog ............................................................................................................................... 20
Computer major components ............................................................................................................. 20
Display assembly subcomponents ..................................................................................................... 28
Mass storage devices ......................................................................................................................... 30
Miscellaneous parts ............................................................................................................................ 31
Sequential part number listing ............................................................................................................ 31
4 Removal and replacement procedures preliminary requirements ........................................................... 41
Tools required .................................................................................................................................... 41
Service considerations ....................................................................................................................... 41
Plastic parts ....................................................................................................................... 41
Cables and connectors ...................................................................................................... 42
Drive handling .................................................................................................................... 42
Grounding guidelines ......................................................................................................................... 42
Electrostatic discharge damage ......................................................................................... 42
Packaging and transporting guidelines ............................................................. 44
Workstation guidelines ..................................................................... 44
5 Removal and replacement procedures for Customer Self-Repair parts ................................................. 46
Component replacement procedures ................................................................................................. 46
Battery ............................................................................................................................... 47
vii

Optical drive ....................................................................................................................... 48
Hard drive .......................................................................................................................... 49
WLAN module .................................................................................................................... 52
Memory module ................................................................................................................. 54
6 Removal and replacement procedures for Authorized Service Provider parts ...................................... 55
Component replacement procedures ................................................................................................. 55
Keyboard ........................................................................................................................... 56
Top cover ........................................................................................................................... 60
Power button board ........................................................................................................... 63
TouchPad button board ..................................................................................................... 64
Display assembly ............................................................................................................... 65
Display assembly subcomponents .................................................................................... 67
System board ..................................................................................................................... 73
RTC battery ....................................................................................................................... 78
Fan ..................................................................................................................................... 80
Heat sink ............................................................................................................................ 81
Processor ........................................................................................................................... 85
Speakers ............................................................................................................................ 86
RJ-45/USB board ............................................................................................................... 88
Power connector cable ...................................................................................................... 89
Optical drive connector cable ............................................................................................ 90
PCH heat sink .................................................................................................................... 91
7 Using Setup Utility (BIOS) and HP PC Hardware Diagnostics (UEFI) ...................................................... 93
Starting Setup Utility (BIOS) ............................................................................................................... 93
Updating the BIOS ............................................................................................................................. 93
Determining the BIOS version ........................................................................................... 93
Downloading a BIOS update ............................................................................................. 94
Using HP PC Hardware Diagnostics (UEFI) ...................................................................................... 95
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device ............................... 95
8 Specifications ................................................................................................................................................ 96
Computer specifications ..................................................................................................................... 96
17.3 inch display specifications .......................................................................................................... 96
Hard drive specifications .................................................................................................................... 97
9 Backing up, restoring, and recovering ....................................................................................................... 98
Creating recovery media and backups ............................................................................................... 98
Creating HP Recovery media ............................................................................................ 98
viii

Restore and recovery ......................................................................................................................... 99
Recovering using HP Recovery Manager ........................................................................ 100
What you need to know ................................................................................... 100
Using the HP Recovery partition ..................................................................... 100
Using HP Recovery media to recover ............................................................. 101
Changing the computer boot order ................................................................. 101
Removing the HP Recovery partition ............................................................................... 102
10 Power cord set requirements .................................................................................................................. 103
Requirements for all countries .......................................................................................................... 103
Requirements for specific countries and regions ............................................................................. 104
11 Recycling ................................................................................................................................................... 106
Index ................................................................................................................................................................. 107
ix

x

1 Product description
Category Description Computer models
equipped with an
AMD processor
Computer models
equipped with an
Intel processor
Product Name HP Pavilion 17 TouchSmart Notebook PC
HP Pavilion 17 Notebook PC
√√
Processors AMD
●AMD® A10-5750M 2.50 GHz
processor (turbo up to 3.50 GHz;
1600 MHz FSB, 4.0 MB L2 cache,
DDR3, quad core, 35 W)
●AMD A10-4600M 2.30 GHz
processor (turbo up to 3.20 GHz;
1600 MHz FSB, 4.0 MB L2 cache,
DDR3, quad core, 35 W)
●AMD A8-5550M 2.10 GHz processor
(turbo up to 3.10 GHz; 1600 MHz
FSB, 4.0 MB L2 cache, DDR3, quad
core, 35 W)
●AMD A8-4500M 1.90 GHz processor
(turbo up to 2.80 GHz; 1600 MHz
FSB, 4.0 MB L2 cache, DDR3, quad
core, 35 W)
●AMD A6-5350M 2.90 GHz processor
(turbo up to 3.50 GHz; 1600 MHz
FSB, 1.0 MB L2 cache, DDR3, dual
core, 35 W), not supported for use on
computer models equipped with
Windows® 8.1
●AMD A6-5200 2.0 GHz processor
(1600 MHz, 2 MB L2 cache, DDR3L,
quad core, 25 W)
●AMD A6-4400M 2.70 GHz processor
(turbo up to 3.20 GHz; 1600 MHz
FSB, 1.0 MB L2 cache, DDR3, dual
core, 35 W)
●AMD A4-5150M 2.70 GHz processor
(turbo up to 3.30 GHz; 1600 MHz
FSB, 1.0 MB L2 cache, DDR3, dual
core, 35 W); not supported for use on
computer models equipped with
Windows 8.1
●AMD A4-5000 1.5 GHz processor
(1600MHz, 2 MB L2 cache DDR3L,
quad core, 15 W)
●AMD E1-2500 1.4 GHz processor
(1600MHz, 1 MB L2 cache, DDR3L),
dual core 15 W)
√
1

Category Description Computer models
equipped with an
AMD processor
Computer models
equipped with an
Intel processor
Processors (continued) 4th Generation Intel Core
●Intel® Core® i7-4702MQ 2.20 GHz
processor (SC turbo up to 2.90 GHz;
1600 MHz FSB, 6.0 MB L3 cache,
quad core, 37 W)
●Intel Core i5-4200M 2.5 GHz
processor (SC turbo up to 3.10 GHz;
1600 MHz FSB, 3.0 MB L3 cache,
dual core, 37 W)
●Intel Core i3-4000M 2.40 GHz
processor (1600 MHz FSB, 3.0 MB
L3 cache, dual core, 37 W)
●Intel Pentium® 3550M 2.40 GHz
processor (1600 MHz FSB, 2.0 MB
L3 cache, dual core, 37 W)
●Intel Celeron® 2950M 2.00 GHz
processor (1600 MHz FSB, 2.0 MB
L3 cache, 37 W)
3rd Generation Intel Core
●Intel Core i7-3632QM (2.2 GHz
processor (SC turbo up to 3.2GHz,
1600 MHz, 6 MB L3 Cache, DDR3,
quad core, 35 W)
●Intel Core i5-3230M 2.60 GHz
processor (SC turbo up to 3.20 GHz;
1600 MHz FSB, 3.0 MB L3 cache,
dual core, 35 W)
●Intel Core i3-3130M 2.60 GHz
processor (1600 MHz FSB, 3.0 MB
L3 cache, dual core, 35 W)
●Intel Core i3-3110M 2.40 GHz
processor (1333 MHz FSB, 3.0 MB
L3 cache, dual core, 35 W)
●Intel Pentium 2030M 2.50 GHz
processor (1600 MHz FSB, 2.0 MB
L3 cache, dual core, 35 W)
●Intel Pentium 2020M 2.40 GHz
processor (1600 MHz FSB, 2.0 MB
L3 cache, dual core, 35 W)
●Intel Celeron 1005M 1.90 GHz
processor (1600 MHz, 2.0 MB L3
cache, dual core, 35 W)
√
Chipset AMD A76M fusion controller hub √
Intel HM86 Express Chipset
Intel HM76 Express Chipset
√
2 Chapter 1 Product description

Category Description Computer models
equipped with an
AMD processor
Computer models
equipped with an
Intel processor
Graphics Internal graphics:
●AMD Radeon™ HD 8650G graphics
on computer models equipped with
an AMD A10-5750M processor
●AMD Radeon HD 8550G graphics on
computer models equipped with an
AMD A8-5550M processor
●AMD Radeon HD 8450G graphics on
computer models equipped with an
AMD A6-5350M processor; not
supported for use on computer
models equipped with Windows 8.1
●AMD Radeon HD 8350G graphics on
computer models equipped with an
AMD A4-5150M processor; not
supported for use on computer
models equipped with Windows 8.1
●AMD Radeon HD 8400 graphics on
computer models equipped with an
AMD A6-5200 processor
●AMD Radeon HD 8330 graphics on
computer models equipped with an
AMD A4-5000 processor
●AMD Radeon HD 8240 graphics on
computer models equipped with an
AMD E1-2500 processor
●AMD Radeon HD 7660G on
computer models equipped with an
A10-4600M processor
●AMD Radeon HD 7640G on
computer models equipped with an
AMD A8-4500M processor
●AMD Radeon HD 7520G on
computer models equipped with an
AMD A6-4400M processor
√
3

Category Description Computer models
equipped with an
AMD processor
Computer models
equipped with an
Intel processor
Graphics (continued) Switchable graphics:
●AMD Radeon HD 8670M with 1 GB
of dedicated video memory (128 M x
16 DDR3 1 GHz x 4 pcs; 1 GHz
downgrade to 900 MHz)
●AMD Radeon HD 8670M with 2 GB
of dedicated video memory (256 M x
16 DDR3 1 GHz x 4 pcs; 1 GHz
downgrade to 900 MHz)
Support for HD decode, DX11, and HDMI
Support for PX5.5 (supported for use on
computer models equipped with Windows
8.0)
Support for PX7.0 (supported for use on
computer models equipped with Windows
8.1)
AMD Start Now (AMD IOIC) 1.0 on
computer models equipped with an AMD
A10-5750, A8-5550, A6-5350, or A4-5150
processor
√
Dual graphics:
●AMD Radeon HD 8650G + HD
8670M dual graphics on computer
models equipped with an AMD
A10-5750 processor
●AMD Radeon HD 8550G + HD
8670M dual graphics on computer
models equipped with an AMD
A8-5550 processor
●AMD Radeon HD 8450G + HD
8670M dual graphics on computer
models equipped with an AMD
A6-5350 processor; not supported for
use on computer models equipped
with Windows 8.1
●AMD Radeon HD 7660G + HD
8670M dual graphics on computer
models equipped with an AMD
A10-4600M processor
●AMD Radeon HD 7640G + HD
8670M dual graphics on computer
models equipped with an A8-4500M
processor
●AMD Radeon HD 7520G + HD
8670M Dual Graphics dual graphics
on computer models equipped with
an A6-4400M processor
√
4 Chapter 1 Product description

Category Description Computer models
equipped with an
AMD processor
Computer models
equipped with an
Intel processor
Graphics (continued) Internal graphics:
●Intel HD Graphics 4600 on computer
models equipped with an Intel 4th
Generation Core processor
●Intel HD Graphics 4000 on computer
models equipped with an Intel 3rd
Generation Core processor
●Intel HD Graphics on computer
models equipped with an Intel
Pentium or Celeron processor
Switchable Discrete Graphics:
●AMD Radeon HD 8670M (64 bit), M2
package, 28 nm, 25 W, 4 pcs of
dedicated video memory (2 GB
VRAM, 256 MB×16, DDR3, 1 GHz×4
pcs)
●AMD Radeon HD 8670M (64 bit), M2
package, 28 nm, 25 W, 4 pcs of
dedicated video memory (1 GB
VRAM, 128 MB×16, DDR3, 1 GHz×4
pcs, 1 GHz bridge to 900 MHz)
Support for HD decode, DX11, and HDMI
Support for PX5.5 (supported for use on
computer models equipped with Windows
8.0)
Support for MS Hybrid Graphic
√
Panel ●17.3 in, high-definition+ (HD+), white
light-emitting diode (WLED),
BrightView (1600×900), wedge (6.0
mm), SVA, typical brightness 200
nits, 16:9 ultra wide aspect ratio
●17.3 in, HD+ WLED AntiGlare
(1600x900) wedge (6.0 mm) SVA
touchscreen solution with flush glass,
multitouch enabled
√√
5

Category Description Computer models
equipped with an
AMD processor
Computer models
equipped with an
Intel processor
Memory Two customer-accessible/upgradable
memory module slots
Support for DDR3L (1600 MHz)
dual channel
Support for DDR3L-1600 MHz single
channel (for use on computer models
equipped with an AMD A6-5200, A4-500,
or E1-2500 processor)
Support for up to 12288 MB of system
RAM in the following configurations:
●12288 MB (8192 MB x 1+ 4096 MB x
1), not supported for use on computer
models equipped with a 32 bit OS
●8192 MB (8192 MB×1, 4096 MB×2),
not supported for use on computer
models equipped with a 32 bit OS
●6144 MB (4096 MB+2048 MB), not
supported for use on computer
models equipped with a 32 bit OS
●4096 MB (4096 MB×1)
√√
Hard drive Support for 6.35 cm (2.5 in) hard drives in
7.0 mm (.28 in) and 9.5 mm (.37 in)
thickness
Support for Serial ATA
Support for HP 3D DriveGuard hard drive
protection
Support for the following hard drives:
●1 TB, 5400 rpm, 9.5 mm
●750 GB, 5400 rpm, 9.5 mm
●640 GB, 5400 rpm, 9.5 mm
(supported for use on computer
models equipped with Intel
processors and supported for use on
computer models equipped with AMD
processors with Windows 8.0)
●500 GB, 5400 rpm, 9.5, and 7.0 mm
√√
Optical drive 9.5 mm tray load
SATA
Fixed (not modular)
DVD±RW Double Layer SuperMulti Drive
√√
6 Chapter 1 Product description

Category Description Computer models
equipped with an
AMD processor
Computer models
equipped with an
Intel processor
Audio and video Dual speakers
Single digital microphone
HD Audio
DTS sound+
Integrated HP TrueVision HD webcam
(fixed [no tilt], activity LED, 1280×720 by
30 frames per second)
√√
Ethernet Integrated 10/100 network interface card
(NIC)
√√
Wireless Integrated wireless local area network
(WLAN) options by way of
wireless module
Two WLAN antennas built into
display assembly
Compatible with Miracast-certified devices.
Support for the following WLAN formats:
●Qualcomm Atheros QCA9485
802.11b/g/n WiFi Adapter
●Qualcomm Atheros AR9565 802.11b/g/n
1×1 WiFi + Bluetooth 4.0
Combo Adapter
●Ralink RT3290LE 802.11b/g/n 1×1
WiFi and Bluetooth 4.0
Combo Adapter
●Realtek RTL8188EE 802.11b/g/n
WiFi Adapter
√√
●Intel Centrino Wireless-N 2230
Combo Adapter (not supported for
use on computer models equipped
with Windows 8.1)
●Intel Wireless-N 7260BN 802.11b/g/n
2×2 WiFi + Bluetooth 4.0
Combo Adapter
Antenna support for 802.11a/b/g/n -
Multiple-Input and Multiple-Output (MIMO)
support 2x2
√
External media cards HP 2 in-1 multiformat Digital Media
Reader Slot with push-push technology.
Reads data from and writes data to digital
memory cards such as Secure Digital
(SD).
√√
7

Category Description Computer models
equipped with an
AMD processor
Computer models
equipped with an
Intel processor
Ports ●AC adapter, HP Smart
●Audio in (mono microphone)/audio-
out (stereo headphone) combo jack
●HDMI v1.4 supporting up to
1920×1080 @ 60Hz
●RJ-45 (Ethernet)
●USB: two USB 3.0 ports, one USB
2.0 port
●VGA (Dsub 15 pin) supporting:
◦1920×1600 external resolution
@ 60 Hz
◦2048×1536 @ 75Hz (computer
models equipped with an Intel
processor only)
◦Hot plug and unplug
◦Autodetection for correct output
to wide-aspect versus standard
aspect video
√√
Keyboard/pointing
devices
Full-size, island-style keyboard with
numeric keypad in black or white finish
Gesture support: MultiTouch gestures
enabled, two-finger scrolling, and pinch-
zoom as default
Taps enabled by default
Support for Windows 8 modern trackpad
√√
Power requirements Support for the following AC adapters:
●90 W HP Smart AC adapter (PFC,
4.5 mm)
●65 W HP Smart AC adapter (non-
PFC, 4.5 mm)
√√
Support for the following batteries:
●6 cell, 62 Wh, 2.80 Ah, Li-ion battery
●6 cell, 47 Wh, 2.20 Ah, Li-ion battery
√√
Security Security cable lock √√
8 Chapter 1 Product description

Category Description Computer models
equipped with an
AMD processor
Computer models
equipped with an
Intel processor
Operating system Preinstalled:
●Windows 8.1 Standard
●Windows 8 Standard
●FreeDOS
√√
Serviceability End user replaceable parts:
●AC adapter
●Battery (system)
●Hard drive
●Memory modules (expansion and
primary)
●Optical drive
●WLAN module
√√
9

2 External component identification
Finding your hardware and software information
Locating hardware
To find out what hardware is installed on your computer:
1. From the Start screen, type control panel, and then select Control Panel.
2. Select System and Security, and then in the System area, click Device Manager in the left
column.
A list reveals all the devices installed in your computer.
Display
Item Component Description
(1) Internal display switch Turns off the display and initiates Sleep if the display is
closed while the power is on.
NOTE: The internal display switch is not visible from
the outside of the computer.
(2) WLAN antennas (2)* Send and receive wireless signals to communicate
with WLANs.
(3) Webcam light On: The webcam is in use.
(4) Webcam Records video and captures still photographs.
10 Chapter 2 External component identification
