1. WLAN antennas (3) 17. Stereo Speakers
2. WWAN antennas (2) 18. Touchpad on/off button with LED indicator
3. Dual-microphone array 19. Drive activity / HP 3D DriveGuard LED indicator
4. Webcam LED indicator 20. Battery charging LED indicator
5. Optional 720p HD Webcam 21. Power/standby LED indicator
6. HP Night Light button and ambient light sensor 22. Wireless on/off LED indicator
7. HP Night Light 23. Integrated Smart Card Reader
8. Wireless on/off button with LED indicator 24. Optical drive or weight saver
9. HP QuickWeb button with LED indicator 25. Optional RJ-11/modem port
10. Volume mute button with LED indicator 26. RJ-45/Ethernet port
11. Pointstick 27. Power connector
12. Optional HP Fingerprint Sensor 28. Power button with LED indicator
13. Pointstick buttons (2) 29. Volume down function key
14. Touchpad with scroll zone 30. Volume up function key
15. Touchpad buttons (2) 31. HP Power Assistant function key
16. Display release button
QuickSpecs
HP EliteBook 2560p Notebook PC
Overview
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 1

1. ExpressCard/34 slot 6. Vent
2. Secure Digital/MultiMediaCard slot 7. Docking connector
3. Combo headphone/microphone jack 8. Kensington Lock slot
4. DisplayPort 9. VGA connector (external monitor/projector)
5. eSATA/USB 2.0 combo port 10. (2) USB 2.0 ports
1. Bottom cover release latch 5. Stereo Speakers
2. Battery bay 6. Bluetooth compartment
3. Battery release latch 7. Hard drive, memory, and wireless compartments
4. SIM slot for WWAN (select models) under bottom cover
QuickSpecs
HP EliteBook 2560p Notebook PC
Overview
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 2

inside battery bay 8. Vents
At A Glance
Genuine Windows 7 versions or FreeDOS
12.5-inch diagonal LED-backlit HD display, ambient light sensor
Industrial, business rugged HP DuraCase construction features a full magnesium alloy chassis, wear-resistant HP DuraFinish,
precision aluminum-alloy hinges, and cast titanium-alloy display latches; designed to meet the military standard Mil-Std-810G
for vibration, dust, altitude, and high temperature operation *
Spill-resistant keyboard with drains
Choice of an Intel® Core™ i7 or Core i5 standard voltage processor for maximum performance
Intel vPro technology (optional) enables you to remotely monitor, diagnose, and repair PCs over the network, even if a system's
OS is inoperable or it is powered off
Optional fixed optical drive or weight saver
Choice of 7200 rpm 2.5-inch hard drive up to 750 GB, with HP 3D DriveGuard protection;
or 128/160/256 GB Solid State Drive
Flexible wireless connectivity options:
Integrated HP hs2340 HSPA+ Mobile Broadband Module connects to both HSPA and HSPA+ (UMTS) networks and provides
GPS functionality
Integrated HP un2430 EV-DO/HSPA Mobile Broadband Module (Gobi 3000) provides GPS functionality (availability
expected May, 2011)
Integrated Intel Centrino® 802.11 a/b/g/n 2x2 or a/b/g/n 3x3, or Broadcom 802.11 a/b/g/n 2x2 or b/g/n 1x1 wireless LAN
module
Bluetooth® v2.1+EDR
Choice of 9-cell, 6-cell, or 3-cell battery, including HP Long Life battery, to customize weight, run-time, and battery life to your
needs
HP Power Assistant to conserve power, increase battery run-time, monitor power needs, and report workforce power
consumption
Integrated Intel HD Graphics 3000
SRS Premium Sound optimized for high fidelity audio
Security features including HP ProtectTools, with central management across HP and non-HP client PCs
Separate launch buttons for easy access to the following features: wireless on/off, HP QuickWeb, and volume mute
HP DayStarter for display of calendar information during Windows startup
DisplayPort for high resolution support
Optional HP 2560 Series Docking Station provides additional DisplayPort, eSATA port, four additional USB ports (one charging),
audio in/out ports, RJ-45, VGA, power connector, and HP Docking Station Cable Lock
Optional 720p HD Webcam
Dual pointing devices (touchpad with scroll zone and pointstick)
HP Night Light
ExpressCard/34 slot
Secure Digital/MultiMediaCard slot
BFR/PVC-free**, ENERGY STAR qualified and EPEAT Gold Target registered in the U.S. EPEAT status varies by country- please see
epeat.net.
* Testing was not intended to demonstrate fitness for DOD contracts requirements or for military use. Test results are not a guarantee
of future performance under these test conditions.
** Meeting the industry definition of 'BFR/PVC-free' per the iNEMI Position Statement on "Low Halogen" Electronics. Plastic parts
incorporated into the chassis generally contain < 1000 ppm (0.1%) of bromine or chlorine. Printed circuit board and substrate
laminates generally contain < 1500 ppm (0.15%) of total bromine and chlorine. Service parts after purchase may not be BFR/PVC-free.
External accessories, including power supplies, power cords, and peripherals as well as the following customer-configurable internal
components: ATT SIM card are not BFR/PVC-free.
QuickSpecs
HP EliteBook 2560p Notebook PC
Overview
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 3

Processors 2
nd
Generation Intel Core i7 Processors
Intel Core i7-2620M Processor (2.70 GHz, 4 MB L3 cache, 2 cores/4 threads, 35W) *
Up to 3.40 GHz with Intel Turbo Boost Technology
2
nd
Generation Intel Core i5 Processors
Intel Core i5-2540M Processor (2.60 GHz, 3 MB L3 cache, 2 cores/4 threads, 35W) *
Up to 3.30 GHz with Intel Turbo Boost Technology
Intel Core i5-2520M Processor (2.50 GHz, 3 MB L3 cache, 2 cores/4 threads, 35W) *
Up to 3.20 GHz with Intel Turbo Boost Technology
Intel Core i5-2410M Processor (2.30 GHz, 3 MB L3 cache, 2 cores/4 threads, 35W) * †
Up to 2.90 GHz with Intel Turbo Boost Technology
* Intel's numbering is not a measurement of higher performance.
† Not available with vPro.
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in
battery optimization mode.
Operating System Preinstalled Genuine Windows 7 Professional 32 *
Genuine Windows 7 Professional 64 *
Genuine Windows 7 Home Premium 32 *
Genuine Windows 7 Home Premium 64 *
Genuine Windows 7 Home Basic 32 * (select countries)
FreeDOS
Supported Genuine Windows 7 Enterprise 32 *
Genuine Windows 7 Enterprise 64 *
Genuine Windows 7 Ultimate 32 *
Genuine Windows 7 Ultimate 64 *
Genuine Windows Vista Enterprise 32 **
Genuine Windows Vista Enterprise 64 **
Genuine Windows Vista Business 32 **
Genuine Windows Vista Business 64 **
Genuine Windows Vista Home Basic 32 ** †
Genuine Windows XP Professional 32
Certified SuSE Linux Enterprise Desktop 11
* System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the
Windows 7 software and take full advantage of Windows 7 functionality. See:
http://www.microsoft.com/windows/windows-7/ for details.
** Certain Windows Vista product features require advanced or additional hardware. See:
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade
Advisor can help you determine which features of Windows Vista will run on your computer. To download
the tool, visit: http://www.windowsvista.com/upgradeadvisor .
† Windows Vista Home Basic will not be a configuration choice after 9/30/11.
QuickSpecs
HP EliteBook 2560p Notebook PC
Standard Features (availability may vary by country)
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 4

Chipset Mobile Intel QM67 Express Chipset
Intel Core i5 with
vPro/Core i7 with vPro
technology capable
Intel Core i5 with vPro and Core i7 with vPro technology is a selectable feature that is available on units
configured with select processors, an Intel Centrino® Advanced-N or Ultimate-N WLAN module and a
preinstalled Windows operating system. It provides advances in remote manageability, security, energy
efficient performance, and wireless connectivity. Intel Active Management Technology 7.0 (iAMT) offers
built-in manageability and proactive security for networked notebook PCs, even when they are powered
off* or when the operating system is inoperable. It can help identify threats before they reach the network,
isolate infected systems, and update PCs regardless of their power state.
*Requires a Windows operating system, network hardware and software, connection with a power source,
and a direct (non-VPN) corporate network connection which is either cable or wireless LAN.
NOTE: Some functionality of Intel Core i5 with vPro/Core i7 with vPro technology, such as Intel Active
Management technology and Intel Virtualization technology, requires additional 3rd party software in
order to run. Availability of future "virtual appliances" applications for Intel Core i5 with vPro/Core i7 with
vPro technology is dependent on 3rd party software providers. Compatibility with future "virtual
appliances" is yet to be determined.
Graphics Intel HD Graphics 3000
Microsoft DirectX 10.1 (Shader Model 4.1) and OpenGL 3.0 capable
Display Internal 12.5-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
Ambient Light Sensor
HP Privacy Filter support
External Up to 32-bit per pixel color depth
DisplayPort supports resolutions up to 2560 x 1600, 30-bit color depth at 60
Hz, and full HD (1920 x 1080) monitors, 24-bit color depth at 120 Hz
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
NOTE: Resolutions are dependent upon monitor capability, and resolution and
color depth settings.
Memory Standard DDR3 PC3-10600 SDRAM (1333 MHz)
Two SODIMM slots supporting dual-channel memory
2 GB, 4 GB, and 8 GB SODIMMs
Maximum Upgradeable to 16 GB with 8 GB SODIMMs in slots 1 and 2
Dual-channel Maximized dual-channel performance requires SODIMMs of the same size and
speed in both memory channels.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP
branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower
memory speed. Full availability of 4 GB or more of memory requires a Windows 64-bit operating system or
Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your
configuration, so that above 3 GB all memory may not be available due to system resource requirements.
QuickSpecs
HP EliteBook 2560p Notebook PC
Standard Features (availability may vary by country)
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 5

Communications Integrated Intel 82579LM Gigabit * Network Connection
56K V.92 modem **
* The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is
subject to country regulatory approval.
Wireless Devices Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support
for the latest industry standards. Mobile Broadband (WWAN) requires a Windows operating system and is
available in select countries as a standard, factory configurable feature or as an option to be added later.
Integrated Bluetooth is also available (factory configurable only) and can be combined with any of the
supported wireless LAN and wireless WAN options.
Mobile Broadband
options
Two 850/900/1575/1700/1800/1900/2100 MHz antennas integrated in the
top of the display panel support current and future WWAN technologies.
NOTE: Separately purchased mobile network operator service is required.
HP hs2340 HSPA+ Mobile
Broadband Module
Integrated mobile broadband module that provides connectivity to both HSPA
and HSPA+ (UMTS) networks. It also provides standalone, Internet and
network assisted GPS functionality for various mapping applications and
security applications such as Computrace Pro for HP ProtectTools.
HP un2430 EV-DO/HSPA
Mobile Broadband Module
(availability expected
May, 2011)
Integrated mobile broadband module with Gobi global mobile Internet
technology that provides connectivity to both CDMA (EVDO) and UMTS (HSPA)
networks. It also provides GPS functionality for various mapping applications
and security applications such as Computrace LoJack Pro Premium for HP
ProtectTools.
All 802.11 integrated
wireless LAN options
Wi-Fi Certified *
Cisco Compatible Extensions support
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
Dual antennas integrated in the display enclosure
Intel Centrino Ultimate-N
6300 (3x3)
Integrated support for 802.11a, b, g, and n *
3 transmit, 3 receive antennas
Up to 450 mbps data rate
Intel Centrino Advanced-
N 6205 (2x2)
Integrated support for 802.11a, b, g, and n *
2 transmit, 2 receive antennas
Up to 300 mbps data rate
Broadcom 43224AGN
802.11a/b/g/n
WiFi Adapter
Integrated support for 802.11 a, b, g, and n
2 transmit, 2 receive antennas
Up to 300 mbps data rate
Broadcom 4313GN
802.11b/g/n
WiFi Adapter
Integrated support for 802.11 b, g, and n
1 transmit, 1 receive antenna
Up to 72 mbps data rate
QuickSpecs
HP EliteBook 2560p Notebook PC
Standard Features (availability may vary by country)
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 6

HP Integrated Module
with Bluetooth 2.1+EDR
Wireless Technology
Bluetooth Specification v2.1+EDR compliant
Works with a wide range of Bluetooth devices
* In countries where 802.11n is not allowed, this capability is not enabled (802.11a/b/g only).
Keyboard The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and a drain
system that funnels fluid through a hole in the bottom of the notebook. This minimizes the risk of damage
to sensitive components underneath. The 101/102-key compatible keyboard features an industry
standard, full-pitch key layout with desktop keyboard features, such as the isolated inverted-T cursor
control keys, editing keys, both left and right control and alt keys, and 12 function keys. U.S. and
International key layouts are available. Other features include an integrated numeric keypad, hotkeys for
instant access to power conservation, brightness, and other features, 19 mm x 19 mm key pitch (center-
to-center spacing), 2.0 mm stroke, and comfort-dished keycaps.
HP Night Light shines directly on keyboard for low-light conditions.
Launch Buttons and
Function Keys
Separate launch buttons provide easy access to the following features: wireless on/off, HP QuickWeb, and
volume mute. Function keys provide control of the following features: standby mode, external display,
volume down, volume up, HP Power Assistant, and display brightness.
Dual Pointing devices Touchpad with on/off button, two-way scroll, gestures, two pick buttons
Pointstick with two additional pointstick buttons
Internal Storage Hard drives 250/320/500/750 GB 7200 rpm SMART SATA II
320 GB 7200 rpm SMART SATA II Self Encrypting Drive
NOTE: These hard drives are customer removable and will withstand multiple insertion/removal cycles. Up
to 20 GB is reserved for the system recovery software.
HP 3D DriveGuard
(Windows only)
The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration. The digital accelerometer temporarily
halts all data transfer and parks the hard drive when abrupt motion is
detected.
Solid State Drive 128/160 GB
Optical Drive 9.5 mm SATA optical drive DVD+/-RW SuperMulti DL Drive
DVD-ROM Drive
-or-
Weight Saver
QuickSpecs
HP EliteBook 2560p Notebook PC
Standard Features (availability may vary by country)
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 7

Expansion card slots ExpressCard/34 slot Supports ExpressCard/34
Integrated Smart Card
Reader
Compatible with ISO 7816 compliant Smart Cards
PC/SC interface support
Secure Digital/
MultiMediaCard slot
Supports SD (Secure Digital), MultiMediaCard
Interfaces External monitor Two - (1) DisplayPort, (1) VGA
Combo
headphone/microphone
jack
One
Power connector One
RJ-11/modem One
RJ-45/Ethernet One
USB 2.0 Two (including one charging port)
eSATA/USB 2.0 combo One
Docking connector For HP 2560 Series Docking Station
Audio/Visual SRS Premium Sound™
Integrated stereo speakers
Integrated dual-microphone array
Button for volume mute; function keys for volume up and down
Combo headphone/microphone jack
Optional 720p HD webcam
HD format (widescreen)
Supports videoconferencing and still image capture
High quality fixed focus lens
Video capture at various resolutions up to 1280x720 resolution (720p) and up to 30fps
M-JPEG compression supports higher frame rates for video capture and videoconferencing
Improved low light sensitivity
Improved dynamic range
QuickSpecs
HP EliteBook 2560p Notebook PC
Standard Features (availability may vary by country)
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 8

Software Preinstalled software
with Windows operating
system
HP Recovery Manager
HP Support Assistant
HP ProtectTools Security Manager
HP ProtectTools for Central Management
HP Hotkey Support
HP QuickWeb
HP Power Assistant
HP Connection Manager
HP DayStarter
Microsoft Office 2010 preloaded (purchase of a Product
Key required to activate a full Office 2010 suite) *
Norton Internet Security 2011 **
PDF Complete Special Edition ***
Intervideo WinDVD - DVD Player (select models)
Roxio Burn Secure (select models)
Roxio MyDVD 10 SE (select models)
HP Webcam Software (select models)
Skype
Additional software
available from the web
HP SoftPaq Download Manager
* Microsoft Office 2010 Preloaded includes reduced functionality versions of Word and Excel. Purchase of
Product Key required to activate full Office 2010 suite available at participating resellers/retailers and
http://www.office.com .
** Norton Internet Security 2011 includes 60 days of complimentary live updates; subscription required for
live updates thereafter. Internet access required to receive updates.
*** PDF Complete Special Edition 60 day trial; purchase license afterwards for full functionality.
HP Recovery Manager Models shipped with Windows 7 or Windows Vista include HP Recovery Manager. HP Recovery Manager
enables fast recovery of the factory preinstalled image if the system becomes corrupted or if important
system files are accidentally deleted. Up to 20 GB of the hard drive is reserved for the system recovery
software.
QuickSpecs
HP EliteBook 2560p Notebook PC
Standard Features (availability may vary by country)
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 9

Security Standard Features HP ProtectTools Security Manager (standard modules include)
Credential Manager
Computrace * Pro
Device Access Manager
Drive Encryption
Face Recognition (webcam configurations only)
File Sanitizer
Privacy Manager
Embedded Security
Integrated Smart Card Reader
Enhanced Pre-Boot Security (Multiuser / Multifactor)
HP SpareKey
One-Step Logon
TPM 1.2 Embedded Security Chip **
HP Disk Sanitizer
Security lock slot
Support for Intel AT ***
Optional Features HP Fingerprint Sensor Enhanced sensor scans the fingerprint to uniquely
identify and authenticate a person.
HP Privacy Filter Narrows viewing area so that screen data is
visible only to persons directly in front of the
monitor.
Computrace * Pro for HP
ProtectTools with GPS
Tracking
Subscription based security solution providing the
ability to track, initiate physical recovery, conduct
asset management, and perform remote data
delete by utilizing GPS technology. GPS
functionality requires HP Mobile Broadband
Module.
* The Computrace agent is shipped turned off, and must be activated by customers when they purchase a
subscription with terms ranging from one to five years.
** TPM module disabled where use is restricted by law, for example, Russia and China.
For more information on HP security solutions refer to: http://www.hp.com/products/security .
*** Intel AT security requires a separately purchased Absolute Computrace service subscription and must
be activated and configured. Check with Absolute for availability in your country. Intel and HP assume no
liability for lost or stolen data and/or systems or any other damages resulting therefrom. See
http://www.intel.com/technology/anti-theft/
QuickSpecs
HP EliteBook 2560p Notebook PC
Standard Features (availability may vary by country)
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 10

HP ProtectTools Security
Manager with Central
Management
HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP
ProtectTools Security Manager is an extensible client security console that delivers enhanced security
capabilities through add-on software modules. The ProtectTools modules are available on the hard drive
(also downloadable from the web) and can be configured in Software Setup.
HP ProtectTools is centrally manageable with the capability to manage notebooks from a single point. HP
ProtectTools is management ready out of the box, in partnership with Digital Persona. Features address
requirements that customers expect from a centrally managed security solution such as user provisioning,
credential reset, and credential revocation.
HP ProtectTools provides two separate management solutions, targeted at the enterprise and the SMB:
Digital Persona Pro AD: Designed for the enterprise customer. Integrates with Active Directory and
gives IT Managers the ability to provision users, create login policies based on passwords,
biometrics or smartcards. Management features also include remote credential recovery in case the
user forgets the password, loses the smartcard or cannot use the fingerprint reader for any reason.
In addition, advanced auditing capabilities are also built in. Digital Persona Pro AD is available now.
Digital Persona Pro Workgroup: Designed for the small business customer. Provides features
similar to the Active Directory version, but for workgroups. Workgroup activation is built into HP
ProtectTools, and activation of up to 5 seats is completely free.
For more information on Central Management for HP ProtectTools, refer to:
http://www.hp.com/products/security .
Power Supply External HP 65-watt Smart AC adapter
Power cord included is 6-foot (1.8 meter).
Total length including external AC adapter is 12 feet (3.66 meter).
HP Fast Charge *
*HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. Fast Charge
Technology does not apply to 9-cell primary batteries.
Battery Primary Battery HP 9-cell 100 WHr Li-Ion Primary Battery
HP 6-cell 62 WHr Li-Ion Primary Battery
HP 3-cell 31 WHr Li-Ion Primary Battery
HP Long Life 6-cell 55 WHr Li-Ion Primary Battery
Battery Life HP 9-cell Primary Battery Up to 14 hours and 15 minutes
HP 6-cell Primary Battery Up to 8 hours and 30 minutes
HP 3-cell Primary Battery Up to 4 hours
NOTE: Battery life will vary depending on the product model, configuration, loaded applications, features,
use, wireless functionality and power management settings. The maximum capacity of the battery will
naturally decrease with time and usage. See MobileMark07 battery benchmark
www.bapco.com/products/mobilemark2007 for additional details.
System Standby Time Up to 1 week
QuickSpecs
HP EliteBook 2560p Notebook PC
Standard Features (availability may vary by country)
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 11

Power Conservation Supports enhanced Intel SpeedStep technology (allows Battery Optimized Mode, Maximum Performance
Mode, or Automatic mode)
Intel Display Power Saving technology
Hibernation
Standby
ACPI compliance
Docking and Stands HP 2560 Docking Station
HP USB 2.0 Docking Station
HP Essential USB 2.0 Port Replicator
HP LAN and USB Travel Hub
NOTE: Some HP Docking stations may not support every feature of some HP Notebook models. Please
refer to the individual docking station documentation for specific information about supported features.
Service and Support HP Services offers limited 3-year, 1-year and 90-day warranty options depending on country;
1-year limited warranty on primary battery. On-site service and warranty upgrades are also available. HP
Care Pack Services extend service contracts beyond the standard warranties. To choose the right level of
service for your HP product, use the HP Care Pack Services Lookup Tool at:
http://www.hp.com/go/lookuptool . Additional HP Care Pack Services information by product is available
at: http://www.hp.com/hps/carepack .
NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp .
QuickSpecs
HP EliteBook 2560p Notebook PC
Standard Features (availability may vary by country)
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 12

NOTE: Options/capabilities listed in the QuickSpecs represent those capabilities available through Base Units or Build to Order
configurations. The various product features and capabilities will vary in terms of configurable vs. aftermarket options (AMOs). There
may be options and capabilities available through CTO that are not available as AMOs.
Memory HP 1 GB (DDR3 1333 MHz) SODIMM AT911AA#xxx
HP 2 GB (DDR3 1333 MHz) SODIMM AT912AA#xxx
HP 4 GB (DDR3 1333 MHz) SODIMM AT913AA#xxx
HP 8 GB (DDR3 1333 MHz) SODIMM QP013AA#xxx
HP 2 GB PC3-12800 (DDR3 1600 MHz) SODIMM H2P63AA
HP 4 GB PC3-12800 (DDR3 1600 MHz) SODIMM H2P64AA
HP 8 GB PC3-12800 (DDR3 1600 MHz) SODIMM H2P65AA
NOTE: Full availability of 4 GB or more of memory requires Windows Vista Business 64-bit or Linux. With Windows 32-bit operating
systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may not be available
due to system resource requirements. Due to system limitations, DDR3-1600 MHz memory will only be supported at DDR3-1333 MHz.
Storage HP 250GB Pocket Media Drive FE477AA
HP Mobile USB DVD XQ543AA
HP Mobile USB DVDRW BU516AA
Expansion Solutions HP 2560 Series Docking Station LE877AA
HP USB 2.0 Docking Station AY052AA#xxx
HP Essential USB 2.0 Port Replicator AQ731AA#xxx
HP LAN and USB Travel Hub BM868AA#xxx
Power HP 65W Smart AC Adapter ED494AA#xxx
HP 90W Smart AC/Auto/Air Combo Adapter AJ652AA#xxx
HP 65W Slim AC Adapter AX727AA#xxx
HP 90W Slim AC Adapter BT796AA#XXX
Carrying Cases HP Basic Carrying Case AJ078AA
HP Business Nylon Case BP848AA
HP Professional Slim Top Load Case AY530AA
Security HP Notebook Combo Lock AY475AA#xxx
HP Keyed Cable Lock BV411AA
HP 12.5-inch Display Privacy Filter QA216AA
QuickSpecs
HP EliteBook 2560p Notebook PC
Options (availability may vary by country)
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 13

Input/Output Devices HP USB Optical Travel Mouse RH304AA
HP USB/PS2 Optical 2-Button Scroll Mouse DC369A
HP USB Keyboard & Mouse Bundle RC465AA#xxx
QuickSpecs
HP EliteBook 2560p Notebook PC
Options (availability may vary by country)
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 14

System Unit Dimensions (HxWxD) 1.08 in (at front) x 12.02 in x 8.23 in
27.4 mm (at front) x 305.2 mm x 209.0 mm
1.29 in (32.8 mm) height at rear
Weight Starting at 3.68 lb (1.67 kg) with weight saver (no optical drive)
Starting at 3.84 lb (1.75 kg) with optical drive
NOTE: Height varies depending upon where on the notebook the measurement is made. Weight varies by
configuration and components. Weight includes 3-cell battery and wireless LAN.
Stand-Alone Power
Requirements (AC Power)
Nominal Operating Voltage 18.5 V
Average Operating Power TBD W
Max Operating Power < 65 W
Temperature Operating 32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating –4° to 140° F (–20° to 60° C)
Relative Humidity Operating 10% to 90%, non-condensing
Non-operating 5% to 95%, 101.6° F (38.7° C) maximum wet bulb
temperature
Shock Operating 125 G, 2 ms, half-sine
Non-operating 200 G, 2 ms, half-sine
Random Vibration Operating 0.75 grms
Non-operating 1.50 grms
Altitude
(unpressurized)
Operating -50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating -50 to 40,000 ft (-15.24 to 12,192 m)
Industry Standard
Certifications
UL Yes
CSA Yes
FCC Compliance Yes
ENERGY STAR® Select models *
EPEAT Gold target **
ICES Yes
GS Yes
Australia / NZ A-Tick
Compliance
Yes
CCC Yes
Japan VCCI Compliance Yes
KCC Yes
BSMI Yes
CE Marking Compliance Yes
BNCI or BELUS Yes
CIT Yes
GOST Yes
Saudi Arabian Compliance
(ICCP)
Yes
QuickSpecs
HP EliteBook 2560p Notebook PC
Technical Specifications
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 15

SABS Yes
UKRSERTCOMPUTER Yes
* Configurations of the HP EliteBook 2560p that are ENERGY STAR qualified are identified as
HP EliteBook 2560p ENERGY STAR on HP websites and on www.energystar.gov .
** EPEAT TBD Registered in U.S. EPEAT registration varies by country. See www.epeat.net for registration
status by country.
NOTE: For accessibility information on HP products, please visit: http://www.hp.com/accessibility .
Audio SRS Premium Sound
Hardware Implementation IDT 92HD87 High Definition CODEC
Touch-Sensitive Volume
Controls
Volume up, volume down, and mute
Full Duplex Yes
Microphone In Stereo
Headphone/Line Out Stereo
Integrated Microphone Yes, dual digital microphone array when equipped with optional webcam
Audio Output Quality Frequency Response 20 Hz – 20 kHz
Signal to Noise Ratio >85 dB
Total Harmonic Distortion 0.01%
Noise Floor –110 dB
Play/Record Sampling
Rate (s)
8 kHz – 48kHz
DAC 16, 20 or 24-bit
ADC 16 or 20-bit
Integrated Stereo
Speakers
Power Rating 2 Watts
Impedance 4 Ohms
Power
QuickSpecs
HP EliteBook 2560p Notebook PC
Technical Specifications
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 16

HP 65W Smart AC Adapter Dimensions 4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
Weight 0.62 lb (280 g)
Input 100 to 240 VAC
Input Efficiency 87% min at 115 VAC
Input frequency range 47 to 63 Hz
Input AC current 1.7 A at 90 VAC, 0.85 A at 180 VAC
Output Output power 65W
DC output 18.5V
Hold-up time 5 msec at 115 VAC input
Output current limit <11A, Over voltage protection- 29V max
automatic shutdown
Connector 3 pin/grounded, mates with interchangeable cords
Environmental Design Operating temperature 32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
-4° to 149° F (-20° to 65° C)
Altitude 0 to 10,000 ft (0 to 3,048 m)
Humidity 20% to 80%
Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals -
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF - over 200,000 hours at 25°C ambient condition.
3-cell 31 WHr Li-Ion
Battery
SX03031
Dimensions (H x W x L) 0.8 x 1.2 x 8.1 in (2 x 3 x 20.5 cm)
Weight (max) 0.37 lb (0.166 kg)
Cells/Type Lithium-Ion
Energy Voltage 11.1V
Amp-hour capacity 2.8Ah
Watt-hour capacity 31Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 122° F(-10° to 50° C)
Non-operating -4° to 122° F (-20° to 50° C)
Battery Re-Charge Time System in OFF or Standby
Mode
2.5 hours
System ON 3 to 5 hours
Fuel Gauge LED No
Warranty 1 year
Optional Travel Battery
Available
No
QuickSpecs
HP EliteBook 2560p Notebook PC
Technical Specifications
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 17

6-cell 62 WHr Li-Ion
Battery
SX06062
Dimensions (H x W x L) 0.8 x 2.0 x 8.1 in (2 x 5 x 20.5 cm)
Weight (max) 0.71 lb (0.32 kg)
Cells/Type Lithium-Ion
Energy Voltage 11.1V
Amp-hour capacity 5.6Ah
Watt-hour capacity 62Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 122° F(-10° to 50° C)
Non-operating -4° to 122° F (-20° to 50° C)
Battery Re-Charge Time System in OFF or Standby
Mode
2.5 hours
System ON 3 to 5 hours
Fuel Gauge LED No
Warranty 1 year
Optional Travel Battery
Available
No
9-cell 100 WHr Li-Ion
Battery
SX09100
Dimensions (H x W x L) 1.6 x 2.0 x 8.1 in (4 x 5 x 20.5 cm)
Weight (max) 1.06 lb (0.475 kg)
Cells/Type Lithium-Ion
Energy Voltage 11.25V
Amp-hour capacity 8.85Ah
Watt-hour capacity 100Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 122° F(-10° to 50° C)
Non-operating -4° to 122° F (-20° to 50° C)
Battery Re-Charge Time System in OFF or Standby
Mode
3.5 to 5 hours
System ON 4 to 7 hours
Fuel Gauge LED Yes
Warranty 1 year
Optional Travel Battery
Available
No
Displays
QuickSpecs
HP EliteBook 2560p Notebook PC
Technical Specifications
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 18

12.5-inch LED-backlit HD
anti-glare
Active Area (W x H) 10.63 x 6.4 in (27.7 x 15.6 cm)
Diagonal Size 12.5 in (31.75 cm)
Surface Treatment Anti-glare
Contrast Ratio 400:1 (typical)
Refresh Rate 60 Hz
Brightness 200 nit (typical)
Pixel Resolution Pitch 0.2025 mm
Format 1366 x 768
Configuration RGB Stripe
Backlight LED
PPI 125
Viewing Angle ±30° Horizontal, ±10° Vertical (minimum) SVA
30/30/20/10 (Left/Right/Down/Up) (minimum) or
45/45/35/25 (Left/Right/Down/Up) (typical)
Internal Storage
750 GB 7200 rpm SATA
Hard Drive
Drive Weight 0.25 lbs (115g)
Capacity 750 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous (maximum) 300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 1.5 ms
Average 11 ms
Maximum 22 ms
Rotational Speed 7200 rpm
Logical Blocks 1,465,149,168
Operating Temperature 32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
QuickSpecs
HP EliteBook 2560p Notebook PC
Technical Specifications
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 19

500 GB 7200 rpm SATA
Hard Drive
Drive Weight 0.25 lbs (115g)
Capacity 500 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous (maximum) 300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 1.5 ms
Average 11 ms
Maximum 22 ms
Rotational Speed 7200 rpm
Logical Blocks 976,773,168
Operating Temperature 32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
320 GB 7200 rpm SATA
Hard Drive
Drive Weight 0.25 lbs (115 g)
Capacity 320 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous (maximum) 300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 1.5 ms
Average 11 ms
Maximum 22 ms
Rotational Speed 7200 rpm
Logical Blocks 625,142,448
Operating Temperature 32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
QuickSpecs
HP EliteBook 2560p Notebook PC
Technical Specifications
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 20
