QuickSpecs
HP EliteBook Revolve 810 G3
Overview
Americas –HP EliteBook Revolve 810 G3 –July 2015 - c04553273
Page 1
HP EliteBook Revolve 810 G3
Front, Right
1.
WLAN antennas
9
MicroSD slot
2.
Dual-microphone array
10.
Speaker
3.
Webcam LED
11.
Volume up/down button
4.
720p HD Webcam
12.
Rotation lock button
5.
Home button
13.
Power button
6.
WWAN antennas*
14.
Clickpad image sensor
7.
Side docking connector
15.
Ambient light sensor
8.
Audio jack
*. WWAN is an optional feature and requires separately purchased service contract. Check with service provider for coverage and
availability in your area. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE is
not available in models, in all regions.

QuickSpecs
HP EliteBook Revolve 810 G3
Overview
Americas –HP EliteBook Revolve 810 G3 –July 2015 - c04553273
Page 2
Rear
1.
RJ-45 (Ethernet) jack
4.
DisplayPort 1.2
2.
USB 3.0 port
5.
USB 3.0 charging port
3.
Security lock slot
6.
Power connector
Left
1.
Vent
2.
Speaker

QuickSpecs
HP EliteBook Revolve 810 G3
Overview
Americas –HP EliteBook Revolve 810 G3 –July 2015 - c04553273
Page 3
Bottom
1.
Service cover
4.
Battery bay cover release latch
2.
Vents
5.
Battery bay
3.
Near Field Communication (NFC) antenna

QuickSpecs
HP EliteBook Revolve 810 G3
Overview
Americas –HP EliteBook Revolve 810 G3 –July 2015 - c04553273
Page 4
At A Glance
Choose from versions of Windows 10, Windows 8.1, Windows 7 Professional, or FreeDOS 2.0
11.6-inch diagonal LED-backlit, ultra-slim, HD UWVA display (1366 x 768) with capacitive multi-touch screen
Industrial, business rugged HP DuraCase construction features a full magnesium alloy chassis, wear-resistant HP
DuraFinish, and stainless steel hinges
Full-sized backlit , spill-resistant keyboard with bottom-case drain
Clickpad image sensor
Choice of Future 5th Gen Intel® Core™processors with Turbo Boost Technology
Intel® vPro™technology enables you to remotely monitor, diagnose, and repair PCs over the network, even if a system's
OS is inoperable or it is powered off (vPro not available with Core i3-5010, Core i5-5200 or i7-5600)
Choice of up to 512 GB Solid State Drive or 256 GB SED Solid State Drive
Supports a broad range of wireless LAN and wireless WAN options, including 4G LTE, for connectivity on the go.
6-cell polymer long life battery (44 WHr)
Integrated Intel® HD 5500 Graphics
Integrated 720p HD Webcam
DTS Studio Sound™with integrated stereo speakers and dual microphone array
Security features including HP Client Security, Common Criteria Certified Discrete TPM 1.2 Embedded Security Chip, and
security lock slot
Separate launch buttons for easy access to the following features: Windows, power, rotation lock, volume up and down
DisplayPort v1.2 for high resolution support
Optional HP UltraSlim docking station
Sensors include Gyroscope, Accelerometer, Compass, Ambient Light Sensor, Near Field Communication (NFC)
microSD slot
NOTE: See important legal disclosures for all listed specs in their respective features sections.

QuickSpecs
HP EliteBook Revolve 810 G3
Features
Americas –HP EliteBook Revolve 810 G3 –July 2015 - c04553273
Page 5
PRODUCT NAME
HP EliteBook Revolve 810 G3 Tablet PC
OPERATING SYSTEM
Preinstalled
Windows 10 Pro641
Windows 10 Home 641
Windows 8.1 Pro 641
Windows 8.1 641
Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro) 3
Windows 7 Professional 64 (available through downgrade rights form Windows 8.1 Pro) 2
Windows 7 Professional 641
FreeDOS 2.0
Web only support
Windows 10 Pro 641
Windows 10 Home 641
Windows 8.1 Pro 641
Windows 8.1 641
Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro) 3
Windows 7 Professional 64 (available through downgrade rights form Windows 8.1 Pro) 2
Windows 7 Professional 641
Windows 7 Professional 321
Windows 10 Enterprise 641
Windows 8.1 Enterprise 641
Windows 8 Professional 641
Windows 8 641
Windows 7 Enterprise 641
Windows 7 Enterprise 321
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or
separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows
functionality. Windows 10 is automatically updated, which is always enabled. ISP fees may apply and
additional requirements may apply over time for updates. See http://www.microsoft.com
2. This system is preinstalled with Windows 7 Professional software and also comes with a license and media
for Windows 8 Pro software. You may only use one version of the Windows software at a time. Switching
between versions will require you to uninstall one version and install the other version. You must back up
all data (files, photos, etc.) before uninstalling and installing operating systems to avoid loss of your data
3. This system is preinstalled with Windows 7 Professional software and also comes with a license and media
for Windows 10 Pro software. You may only use one version of the Windows software at a time. Switching
between versions will require you to uninstall one version and install the other version. You must back up
all data (files, photos, etc.) before uninstalling and installing operating systems to avoid loss of your data.
4.
PROCESSOR*
Intel® Core™ i7-5600U with Intel HD Graphics 5500 (2.4 GHz, up to 3 GHz with Intel Turbo Boost Technology, 4 MB cache, 2
cores);
Intel® Core™ i5-5300U with Intel HD Graphics 5500 (2.3 GHz, up to 2.9 GHz with Intel Turbo Boost Technology, 3 MB cache, 2
cores);

QuickSpecs
HP EliteBook Revolve 810 G3
Features
Americas –HP EliteBook Revolve 810 G3 –July 2015 - c04553273
Page 6
Intel® Core™ i5-5200U with Intel HD Graphics 5500 (2.2 GHz, up to 2.7 GHz with Intel Turbo Boost Technology, 3 MB cache, 2
cores);
Intel® Core™ i3-5010U with Intel HD Graphics 5500 (2.1 GHz, 3 MB cache, 2 cores)
* Multi-Core is designed to improve performance of certain software products. Not all customers or software applications will
necessarily benefit from use of this technology. 64-bit computing on Intel® architecture requires a computer system with a
processor, chipset, BIOS, operating system, device drivers, and applications enabled for Intel® 64 architecture. Processors
will not operate (including 32-bit operation) without an Intel® 64 architecture-enabled BIOS. Performance will vary
depending on your hardware and software configurations. Intel's numbering is not a measurement of higher performance.
** Intel® Turbo Boost technology requires a PC with a processor with Intel Turbo Boost capability. Intel Turbo Boost
performance varies depending on hardware, software and overall system configuration. See
www.intel.com/technology/turboboost for more information.
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization
mode.
CHIPSET
Chipset is integrated with processor
INTEL CORE I5 WITH VPRO/CORE I7 WITH VPRO TECHNOLOGY CAPABLE
Intel Core i5 with vPro and Core i7 with vPro technology is a selectable feature that is available on units configured with
select processors, an Intel Centrino® Advanced-N or Ultimate-N WLAN module and a preinstalled Windows operating system.
It provides advances in remote manageability, security, energy efficient performance, and wireless connectivity. Intel Active
Management Technology 9.0 (iAMT) offers built-in manageability and proactive security for networked notebook PCs, even
when they are powered off* or when the operating system is inoperable. It can help identify threats before they reach the
network, isolate infected systems, and update PCs regardless of their power state.
*Requires a Windows operating system, network hardware and software, connection with a power source, and a direct (non-
VPN) corporate network connection which is either cable or wireless LAN.
NOTE: Some functionality of this technology, such as Intel® Active management technology and Intel Virtualization
technology, requires additional 3rd party software in order to run. Availability of future "virtual appliances" applications for
Intel vPro technology is dependent on 3rd party software providers. Microsoft Windows required.
GRAPHICS
Intel® HD Graphics 5500
DISPLAY
Internal
11.6-inch diagonal LED-backlit HD* UWVA Touch (1366 x 768)
Ultra- Wide-viewing angle
LVDS –low voltage differential signaling
Capacitive multitouch screen with digitizer
Tough, durable Corning® Gorilla® Glass 3
* HD content required to view HD images.

QuickSpecs
HP EliteBook Revolve 810 G3
Features
Americas –HP EliteBook Revolve 810 G3 –July 2015 - c04553273
Page 7
External
Up to 32-bit per pixel color depth
DisplayPort v1.2
Supports resolutions up to 3840 x 2160, 30-bit color depth at 60 Hz, and full HD (1920 x 1080) monitors, 24-bit color depth
at 120 Hz
Number of Supported Displays
Number of Displays with UltraSlim Docking Station
UMA
Discrete
EliteBook Revolve 810 G3
3
n/a
NOTE: Resolutions are dependent upon monitor capability, and resolution and color depth settings.
STORAGE AND DRIVES
Solid State Drive
128 GB SATA-3 Solid State Drive
180 GB SATA-3 Solid State Drive
180 GB SATA-3 Self-Encrypting Drive
256 GB SATA-3 Solid State Drive
256 GB SATA-3 Self-Encrypting Drive
512 GB SATA-3 Solid State Drive
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 16 GB (for Windows
7) and up to 30 GB (for Windows 8 and 10) of system disk is reserved for the system recovery software.
MEMORY
Standard
DDR3L PC3-12800 SDRAM (1600 MHz)
One SODIMM slot supporting up to 8 GB dual-channel memory plus 4 GB soldered down
Supports
4 GB Total System Memory (4 GB on motherboard)
8 GB Total System Memory (4 GB on motherboard + 4 GB DIMM)
12 GB Total System Memory (4 GB on motherboard + 8 GB DIMM)
Maximum
Upgradeable to 12 GB
NOTE: Maximum memory capacities assume Windows 64-bit operating systems. With Windows 32-bit operating systems,
memory above 3 GB may not all be available due to system resource requirements.
Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to
ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.

QuickSpecs
HP EliteBook Revolve 810 G3
Features
Americas –HP EliteBook Revolve 810 G3 –July 2015 - c04553273
Page 8
NETWORKING/COMMUNICATIONS
LOCAL AREA NETWORK (LAN)
Integrated Intel® 1218LMGigabit* Network Connection (vPro configurations)
WIRELESS
Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support for the latest
industry standards.Integrated Bluetooth® is also available as both a factory configurable and after-market option and can be
combined with any of the supported wireless LAN and wireless WAN options.
WWAN** (Mobile Broadband) options
HP lt4211 LTE/EV-DO/HSPA Qualcomm® Gobi™ 4G Mobile Broadband Module
Wireless LAN (WLAN)***
Intel® 7265 AC 802.11 ac (2x2) Bluetooth® 4.0 Combo****
Intel®7265N 802.11 a/b/g/n (2x2) Bluetooth® 4.0 Combo
COMMUNICATIONS
Intel® Wireless Display (WiDi)*****
Intel® WiDi technology enables users to stream content wirelessly from a compatible computer to a projector, TV or monitor.
Near Field Communication (NFC)
* The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet, and
does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and
network infrastructure is required.
** WWAN is an optional feature and requires wireless data service contract, network support, and is not available in all areas.
Contact your service provider to determine the coverage area and availability. Connection speeds will vary based on location,
environment, network conditions and other factors. 4G LTE is not available in all models, all regions.
***Wireless access point and Internet service is required and is not included. Availability of public wireless access points
limited.
****The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from
the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices.
***** Integrated Intel® Wi-Di Display is available on select configurations only and requires a separate projector, TV or
monitor with an integrated or external Wi-Di receiver. For more information on Intel® Wi-Di Display visit
www.intel.com/go/wirelessdisplay.
AUDIO/MULTIMEDIA
Audio
DTS Studio Sound™
Integrated stereo speakers
Integrated microphone (dual-microphone array)
Buttons for volume up and down
Headphone/microphone combo jack
Webcam
Integrated 720p HD* webcam
HD format (widescreen)
Supports videoconferencing and still image capture
High quality fixed focus lens

QuickSpecs
HP EliteBook Revolve 810 G3
Features
Americas –HP EliteBook Revolve 810 G3 –July 2015 - c04553273
Page 9
Video capture at various resolutions up to 1280x720 resolution (720p) and up to 30fps
M-JPEG compression supports higher frame rates for video capture and videoconferencing
Improved low light sensitivity
Improved dynamic range
* HD content required to view HD images.
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS
Keyboard
The HP backlit, spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and a drain system
that funnels fluid through a hole in the bottom of the notebook. This minimizes the risk of damage to sensitive components
underneath. The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop
keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right control and alt keys,
and 12 function keys. U.S. and International key layouts are available. Other features include an integrated numeric keypad,
hotkeys for instant access to power conservation, brightness, and other features, 19 mm x 19 mm key pitch (center-to-
center spacing), 2.0 mm stroke, and comfort-dished keycaps.
Pointing Devices
Clickpad image sensor
Multitouch gestures enabled
Taps enabled as default
Buttons and Function Keys
F1 - Ambient Light Sensor
F2 - Battery Gauge
F3 –Sleep
F4 - Display Switching
F5 - Speaker Mute
F6 - Volume Down
F7 - Volume Up
F8 - mic mute
F9 - Brightness Down
F10 - Brightness Up
F11 –Backlit
F12 - WiFi toggle
SENSORS
Gyro
Accelerometer
ALS
Proximity (SAR)
Compass
SOFTWARE AND SECURITY
Preinstalled Software with Windows Operating System
BIOS
Absolute Data Protect (Windows 8.1 only)2
HP BIOSphere1
HP Sure Start2
HP DriveLock | HP Automatic DriveLock
HP BIOS Protection3
HP Disk Sanitizer4

QuickSpecs
HP EliteBook Revolve 810 G3
Features
Americas –HP EliteBook Revolve 810 G3 –July 2015 - c04553273
Page 10
HP SpareKey5
BIOS Update via Network
Master Boot Record Security
Power On Authentication
Pre-Boot Security
Secure Erase6
Hybrid Boot (Windows 8.1 only)
Measure Boot (Windows 8.1 only)
Secure Boot (Windows 8.1 only)
Absolute Persistence Module7
MultiMedia
Cyberlink Power DVD, BD
Cyberlink Power2Go (Secure Burn)
Cyberlink YouCam BE (Windows 7 only)
Communication
HP GPS and Location (Windows 7 only)8
HP Connection Manager with support for HP Mobile Connect (Windows 7 only)9
HP Mobile Connect (Windows 8.1 only)
HP Wireless Hotspot (Windows 8.1 only)10
Intel® Wireless Display (WiDi) Software for Windows11
HP Roaming Alert (Windows 8.1 only)
Native Miracast Support12
HP Value Add Software
HP 3D DriveGuard
HP ePrint Driver13
HP Hotkey
HP PageLift
HP Recovery Manager (Windows 7 only)
HP Recovery Disc Creator (Windows 7 only)
HP Registration App (Windows 8.1 only)
HP Support Assistant
3rd Party
Foxit PhantomPDF Express for HP
Netflix Application (Window 8.1only)
Microsoft Products
Buy Office
Bing Search
Skype14
Manageability
HP Driver Packs15
HP SoftPaq Download Manager (SDM)
HP System Software Manager (SSM)15
HP BIOS Config Utility (BCU)15
HP Client Catalog15
HP CIK for Microsoft SCCM15
LANDESK Management16
For more information on HP Client Management Solutions refer to: http://www.hp.com/go/clientmanagement.
