HP PAVILION DV7 Assembly instructions

EL-MF877-00 Page 1
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Product End-of-Life Disassembly Instructions
Product Category: Notebooks and Tablet PCs
Marketing Name / Model
[List multiple models if applicable.]
HP Pavilion dv7 Entertainment PC
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Notes
Quantity
of items
included
in product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
PCA
2
Batteries
All types including standard alkaline and lithium coin
or button style batteries Battery pack;RTC
2
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries N/A
0
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Includes background illuminated displays with gas
discharge lamps LED
1
Cathode Ray Tubes (CRT)
N/A
0
Capacitors / condensers (Containing PCB/PCT)
N/A
0
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
PC4125/ PC4126/ PC9245/ PT4101
4
External electrical cables and cords
N/A
0
Gas Discharge Lamps
N/A
0
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
N/A
0
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations. N/A
0
Components and waste containing asbestos
N/A
0
All manuals and user guides at all-guides.com

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Components, parts and materials containing
refractory ceramic fibers
N/A
0
Components, parts and materials containing
radioactive substances
N/A
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Description #1 Philips Screw drivers (For disassembly 1 pc screw on Service door)
1#
2.55~3.00kgf.cm
Description #2 Philips Screw drivers (For disassembly 1 pc screw on ODD drivers)
1#
2.55~3.00kgf.cm
Description #3 Philips Screw drivers (For disassembly 2 pcs screws on 1st HDD drivers)
1#
2.55~3.00kgf.cm
Description #4 Philips Screw drivers (For disassembly 2 pcs screws on 2nd HDD drivers)
1#
2.55~3.00kgf.cm
Description #5 Philips Screw drivers (For disassembly 20 pcs screws on Low case)
1#
2.55~3.00kgf.cm
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Push Battery Latch and remove Battery module.
2. Remove 1 pc screw on Service door.
3. Remove 1 pc screw on ODD module.
4. Remove 2 pcs screws on 1st HDD drivers.
5. Remove 2 pcs screws on 2nd HDD drivers.
6. Remove 20 pcs screws on Low case.
7. Remove KB module.
8. Remove 1 pc screw on U case
9. Remove U case.
10. Remove 4 pcs screws on Hinge.
11. Remove 4 pcs screws on MB.
12. Remove 1 pc screw on Card reader Board.
13. Remove 1 pc screw on USB Board.
14. Remove 2 pcs screws on Sub Woofer.
15. Remove 2 pcs screws on ODD connector.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
