HP EliteBook x360 1030 Assembly instructions

EL-MF877-00 Page 1
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Product End-of-Life Disassembly Instructions
Product Category: Notebooks and Tablet PCs
Marketing Name / Model
[List multiple models if applicable.]
HP EliteBook x360 1030 G2 Notebook PC
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HP products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description Notes
Quantity
of items
included
in product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
2
Batteries
All types including standard alkaline and lithium
coin or button style batteries
1
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
0
Liquid Crystal Displays (LCD) with a surface
greater than 100 sq cm
Includes background illuminated displays with gas
discharge lamps
1
Cathode Ray Tubes (CRT)
0
Capacitors / condensers (Containing PCB/PCT)
0
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
0
External electrical cables and cords
1
Gas Discharge Lamps
0
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
0
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
0
Components and waste containing asbestos
0

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Components, parts and materials containing
refractory ceramic fibers
0
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Screwdriver #1
Electric cross
screwdriver
Description #2
TORX T8
(2.31mm)
Description #3
D73 1 * 3.0 *
20 * 40
Description #4
Description #5
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Follow steps described in Disassembly instruction (file attached)
2. If parts can be removed without using a tool, remove it first
3. Use correct screwdriver and torque value before unlock the screw.
4.
5.
6.
7.
8.
9.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).

MANUFACTURING PROCESS INSTRUCTIONS
MECHANICAL ASSEMBLY
MODEL : Oldman
Tabulator: Tzan.Uen-Tung
Auditor : Tzan.Uen-Tung

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
Disassemble BTCB
1. Loosen BTCB Screws * 5
2. Disassemble BTCB
1(1/1)
Electric cross screwdriver T5 1
Fig1
1
2 3 4
5
2016/12/05
1.00

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
1. Disassmble battery cable CNTR
2. Disassmble M/B mylar
3. Disassmble Wlan mylar
2(1/1)
Disassemble Battery CNTR &mylar
Fig1
Fig2 Fig3
2016/12/05
1.00

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
1. Loosen SSD CARD Screws*1 (Fig1),
2. Disassemble SSD .
3. Loosen Battery Screws** 6
4. Disassemble Battery ,Fig2
3(1/1)
Fig1
Electric cross screwdriver #1 1
Disassemble SSD & Battery
1
2
3
4
5 6
Fig2
4 3
1 5
6 2
2016/12/05
1.00

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
1. Disassemble NFC module Gasket,Fig1.
2. Disassemble NFC module .Fig2
4(1/1)
Disassemble NFC
Fig1
Fig2
2016/12/05
1.00

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
1. Disassemble FP FPC ,Fig1
2. Disassemble audio FFC,Fig2
3. Disassemble smart card FPC ,Fig3
5(1/1)
Disassemble FPC
Fig1
Fig2
Fig3
2016/12/05
1.00

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
Disassemble WLAN&camera cable
1. Disassemble WLANAntenna (Fig1)
2. Disassemble hinge Screws
3. Disassemble IR cable(Fig2/3)
4. Disassemble camera cable CNTR,Fig4
6(1/1)
Fig4
Fig1
Fig3
Fig2
2016/12/05
1.00
Electric cross screwdriver #1 1

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
Disassemble WWAN
1. Disassemble WWANAntenna (Fig1)
2. Loosen Screws *1 .
3.Disassemble WWAN module(Fig2)
7(1/1)
Fig2
Fig1
2016/12/05
1.00
Electric cross screwdriver #1 1

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
1. Loosen Screws *1 ,
2. Disassemble LVDS Cable
8 (1/1)
Fig2
Disassemble LVDS Cable
Fig1
Fig3
2016/12/05
1.00

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
1. Disassemble KB FFC & backlight FPC(Fig1/2)
2. Disassemble FAN cable TAPE ,Fig3
3. Loosen Screws *2 & CNTR
4. Disassemble FAN, Fig4/5
9(1/1)
Fig4
Disassemble FAN
Fig1 Fig2
1
2
Fig3
Fig5
2016/12/05
1.00
Electric cross screwdriver #1 1

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
1. Loosen Speaker Screws *2,Fig1/2
2. Disassemble Speaker CNTR, Disassemble Speaker,Fig3
Disassemble speaker 10(1/1)
Fig1 Fig2
2016/12/05
1.00
speaker
CNTR
Fig4 Fig3
Electric cross screwdriver #1 1

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
1. Loosen M/B Screws *7 (Fig1/2)
2. Disassemble M/B
Disassemble M/B
11(1/1)
Fig1
1
2
3
4
5
2
1
Fig2
2016/12/05
1.00
Electric cross screwdriver #1 1

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
1.Loosen Thermal sensor/B Screws * 4(Fig1)
2.Disassemble thermal sensor FFC CNTR
3.Disassemble FFC
4.Disassemble thermal sensor/B(Fig2)
Disassemble thermal sensor/B 12(1/1)
Fig1
1
2 3
4
Fig2
2016/12/05
1.00
Electric cross screwdriver #1 1

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
1. Disassemble Wlan antenna (Fig1)
2. Loosen Screws * 2(Fig2)
13(1/1)
Disassemble Wlan antenna
Fig1
Fig2
2016/12/05
1.00
Electric cross screwdriver #1 1

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
1. Disassemble Audio/B screw& (Fig1)
2. Disassemble FP screw & breaket & FP.Fig2
14(1/1)
DisassembleAudio/B,FP
Fig1 Fig2
2016/12/05
1.00

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
1. Loosen Screws * 2 (Fig1)
2. Disassemble smart card FFC,
3. Disassemble smart card/B ,Fig2
Disassemble Smart /B
15(1/1)
Fig1
1 2
2016/12/05
1.00
Electric cross screwdriver #1 1

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
16(1/1)
1. Disassemble hinge screws * 6
2. Disassemble LCM Fig1/2
扭力值：2.5 ±0.1Kgf．cm
Fig1
Disassemble LCM
Fig2
1 2
3 5 6
2016/12/05
1.00
Electric cross screwdriver #1 1

Standard Operation Procedure
Document No. Oldman FA DIS ASS’Y SOP Station :
Name : Ver. : Date :
Step：
Notes : If finding anything uncommon, notice foreman or assistant at once.
Holding fixture list (holding fixture standard) Qty Holding fixture list (holding fixture standard) Qty
Tabulator：Issue department：
Tzan.Uen-tung NPSU-PPE
Auditor ：
Tzan.Uen-tung
1. Disassemble Click pad BRKT Screws * 4
2. Disassemble click pad (Fig1)
DisassembleClick pad
17(1/1)
Fig1
1
2
3 4
2016/12/05
1.00
Electric cross screwdriver #1 1
