1
HP D2840A 17-inch Color Display
15.7-inch Viewable Image
User’s Guide
On/Off switch
Full scan screen that gives
an edge to edge image
Sony Trinitron aperture grill
tube with 0.25 stripe pitch
for excellent graphics Non-glare, anti-static
screen coating
Control buttons used to adjust
the display’s settings
Status indicator
mykonos.bk : mykon-us.fb4 Page 1 Monday, November 25, 1996 5:41 PM

HP D2840A User’s Guide
Important Safety Instructions
2 English
Important Safety Instructions
Before you plug in your new display, read these important safety
instructions.
WARNING Connect the display only to a grounded power outlet. Use the power
cord supplied with the display or one with a properly grounded plug.
Ensure the cable meets your country’s standards for safety.
This display operates on all power systems, including “IT” power
systems. To completely disconnect power at the display, remove the
power cord from the power outlet. Ensure that the power outlet is
easily accessible.
To avoid electric shock and harm to your eyes by laser light, do not
open the display cover. The display should be serviced by service
personnel only. This HP display is a class I laser product. Do not
attempt to make any adjustments to any laser source inside this
display.
The display is quite heavy (the weight is shown in the technical
specifications). We recommend you ask the assistance of a second
person when lifting or moving it.
USA and Canada
If the power cord is not supplied with your display, select the proper
power cord according to your national electric safety codes.
•USA: use a UL Listeddetachable power cord.
•Canada: use a CSA certified detachable power cord.
Si le cordon secteur n’est pas livré avec votre moniteur, utiliser un
cordon secteur en accord avec votre code èlectrique national.
•USA: utiliser un cordon secteur UL Liste.
• Canada: utiliser un cordon secteur certifié CSA.
mykonos.bk : mykon-us.fb4 Page 2 Monday, November 25, 1996 5:41 PM

English 3
HP D2840A User’s Guide
What Your New Display Offers
What Your New Display Offers
The HP D2840A Ergo 1280 Display is a 17-inch, high resolution,
multi-synchronous color display. Multi-synchronous means that the
display supports a range of video modes. It can be used with
Hewlett-Packard personal computers (or equivalent). Your HP D2840A
color display has the following features:
•A 17-inch Sony Trinitron1tube, with a 15.7-inch viewable image, with
a 0.25 mm stripe pitch for excellent graphics. It has a non-glare,
antistatic screen coating.
•Support of video modes up to Ultra VGA 1600 at high refresh rates.
•Image adjustment using onscreen menus. Includes color adjustment
and image rotation controls to optimize the quality and position of the
image.
•Display power management system (VESA2standard) controlled
from suitably equipped HP Vectra PCs to automatically reduce the
power consumption of the display. Complies with the Energy Star
Computers Program initiated by the US EPA3, and with the Swedish
NUTEK4specification for energy efficient displays.
•Display Plug and Play capability (VESA DDC1/2B standard) that
enables the display to identify itself to suitably equipped HP Vectra
PCs.
•Uses the latest VESA DDC 2B+ standard. This enables you to control
the displayed image via the PC by using appropriate software (when
available).
•Compliance with ISO 9241-3 and ZH1/618 ergonomic standards.
•Your HP D2840A complies with MPRII guidelines for upper limits of
electrical and electrostatic emissions, from the Swedish National
Board for Measurement and Testing.
•Your HP D2840A complies with the TCO-925and TCO-95 guidelines
for low frequency electrical and magnetic fields, which require an
even lower level of emissions than the MPR-II recommendations.
•Complies with Blue Angel and the E2000 environmental
requirements.
1. Trinitron is a trademark of Sony.
2. VESA is the Video Electronics Standards Association
3. The US EPA is the United States Environmental Protection Agency
4. NUTEK is the Swedish National Board for Industrial and Technical Development
5. Swedish Confederation of Professional Employees
mykonos.bk : mykon-us.fb4 Page 3 Monday, November 25, 1996 5:41 PM

HP D2840A User’s Guide
Setting Up Your Display
4 English
Setting Up Your Display
Where to Place the Display
Place your display on a flat sturdy surface.
Ensure the operating site is free from excessive heat, moisture, and
sources of electromagnetic fields. Sources of electromagnetic fields
include transformers, motors, and other displays.
Connecting the Cables
1Before you connect any cables, refer to the safety instructions at the
beginning of this manual and make sure your PC and display are
switched off.
2Connect the video cable (it has a 15-pin plug) to the video outlet on
your PC. Tighten the thumbscrews on the plug.
3Connect the power cord to the display.
4Plug the power cord into the power outlet.
Video cable
Power cords
mykonos.bk : mykon-us.fb4 Page 4 Monday, November 25, 1996 5:41 PM

English 5
HP D2840A User’s Guide
Setting Up Your Display
NOTE The location of your PC’s video outlet may be different to the one shown
in the diagram. Refer to the manual that came with your PC, if
necessary.
Setting the Language used by the On-Screen Menus
After connecting the display to your PC, we recommend that you set
the language used by the on-screen menus. To do this, follow these
steps:
1Switch on your PC and the display.
2Press either the or the button on the front panel of the
display to make the on-screen menu appear.
3Use the and the buttons to scroll to TO MAIN MENU.
4Press the button to select TO MAIN MENU.
5Use the and the buttons to scroll to LANGUAGE.
6Press the button to select LANGUAGE.
7Use the and the buttons to scroll to the language you want.
8Press the button to select the language.
9Press at the same time both the or the buttons to close the
on-screen menu.
mykonos.bk : mykon-us.fb4 Page 5 Monday, November 25, 1996 5:41 PM

HP D2840A User’s Guide
Using the Display
6 English
Using the Display
You can adjust the quality, position, size, and shape of the displayed
image by using the on-screen menus. You use the buttons on the front
panel of the display to navigate through these menus.
The on/off switch is on the front of the display.
Buttons to navigate
through the on-screen
menus
On/off switch
mykonos.bk : mykon-us.fb4 Page 6 Monday, November 25, 1996 5:41 PM

English 7
HP D2840A User’s Guide
Using the Display
Navigating Through the On-screen Menus
Here is how to navigate through the on-screen menus using the buttons
on the front panel of the display:
To make this happen Press these
buttons
Directly adjust the default setting without making the on-screen
menus appear. (The default setting may be brightness, contrast,
or color. See “CREATE DEFAULT ITEM“ on page 9.
and
Make the on-screen menu appear (basic adjustments). or
Scroll between menu items. or
Select the highlighted menu item.
Adjust the selected value (for example, width of the displayed
image).
and
Exit the on-screen menu. Both
and
at the same time.
Directly adjust the last selected item for up to 20 seconds after
the on-screen menu disappears.
and
mykonos.bk : mykon-us.fb4 Page 7 Monday, November 25, 1996 5:41 PM

HP D2840A User’s Guide
Using the Display
8 English
A Map of the On-Screen Menus
CONTRAST
BRIGHTNESS
WIDTH
HORIZ CENTERING
HEIGHT
VERTICAL CENTERING
DEGAUSSING
CREATE DEFAULT ITEM
TO MAIN MENU
BASIC ADJUSTMENTS
70 Hz
LANGUAGE
BASIC ADJUSTMENTS
GEOMETRY
MAIN MENU
WIDTH
HORIZ CENTERING
HEIGHT
VERTICAL CENTERING
PINCUSHION CORRECT
HORIZ SYMMETRY
TRAPEZOID CORRECT
ORTHOGONAL CORRECT
TILT CORRECTION
FACTORY PRESET SHAPE
TO MAIN MENU
GEOMETRY
ENGLISH
DEUTSCH
ITALIANO
FRANÇAIS
ESPAÑOL
TO MAIN MENU
LANGUAGE
CONTRAST
BRIGHTNESS
COLOR TEMP
RED
GREEN
BLUE
MOIRE
CREATE CUSTOM IMAGE
FACTORY PRESET IMAGE
TO MAIN MENU
CONTRAST
BRIGHTNESS
RED
GREEN
BLUE
SAVE TO CUSTOM 1
SAVE TO CUSTOM 2
EXIT WITHOUT SAVING
CREATE CUSTOM IMAGE
mykonos.bk : mykon-us.fb4 Page 8 Monday, November 25, 1996 5:41 PM

English 9
HP D2840A User’s Guide
Using the Display
The Basic Adjustments Sub-Menu
Here is what the BASIC ADJUSTMENTS sub-menu contains:
CONTRAST To adjust the contrast (image white level), select this menu item.
Contrast is the difference in brightness between the dark and light
parts of the displayed image.
BRIGHTNESS To adjust the overall picture brightness (image black level), select this
menu item. Set the brightness so that the dark areas of the display
remain black.
WIDTH To adjust the width of the displayed image, select this menu item.
HORIZ CENTERING To adjust the horizontal position of the displayed image, select this
menu item.
HEIGHT To adjust the height of the displayed image, select this menu item.
VERTICAL CENTERING To adjust the vertical position of the displayed image, select this menu
item.
DEGAUSSING To degauss the display, select this menu item. If you always leave your
display switched on, it is recommended that you degauss at least every
week to remove any color impurities. Degaussing is accompanied by
brief instability of the displayed image and a brief humming sound.
CREATE DEFAULT ITEM To choose which setting is adjusted directly when you use the
buttons without displaying the on-screen menus, use this menu item.
You can choose from BRIGHTNESS, CONTRAST, and COLOR TEMP.
The current default item is indicated with a plus (+) sign next to it.
Scroll to the item you want as the the default adjustment and press the
button.
TO MAIN MENU To make the main menu appear, select this menu item.
Geometry Adjustments Sub-Menu
Here is what the GEOMETRY sub-menu contains:
WIDTH See The Basic Adjustments Sub-Menu.
mykonos.bk : mykon-us.fb4 Page 9 Monday, November 25, 1996 5:41 PM

HP D2840A User’s Guide
Using the Display
10 English
HORIZ CENTERING See The Basic Adjustments Sub-Menu.
HEIGHT See The Basic Adjustments Sub-Menu.
VERTICAL CENTERING See The Basic Adjustments Sub-Menu.
PINCUSHION CORRECT To adjust the displayed image if its vertical edges appear to bow in or
out, select this menu item.
HORIZ SYMMETRY To adjust the displayed image if its vertical edges appear curved, select
this menu item.
TRAPEZOID CORRECT To adjust the displayed image if its vertical edges do not appear parallel,
select this menu item.
ORTHOGONAL CORRECT To adjust the displayed image if its vertical edges appear tilted, select
this menu item.
TILT CORRECTION To adjust the displayed image if it appears to be rotated, select this
menu item. Depending on the orientation of your display, for example,
whether it faces north or south, you may experience some rotation of
the image. This effect is due to the influence of the earth’s magnetic field
and is normal for all displays.
FACTORY PRESET SHAPE To return all of the shape settings to those set by the factory, select this
menu item.
Image Adjustments Sub-Menu
Here is what the IMAGE ADJUSTMENTS sub-menu contains:
CONTRAST See The Basic Adjustments Sub-Menu.
BRIGHTNESS See The Basic Adjustments Sub-Menu.
COLOR TEMP To change the factory preset color, select this menu item. The lower the
color temperature, the warmer the hue. The higher the color
temperature, the colder the hue. For example, choosing 5000 gives a
white with a reddish tinge, choosing 6500 gives a white which is close to
average daylight, choosing 9300 gives a white with a noticeable bluish
tinge. You can also set the color to your own preferences by using the
menu items RED, GREEN, BLUE, and CREATE CUSTOM IMAGE.
mykonos.bk : mykon-us.fb4 Page 10 Monday, November 25, 1996 5:41 PM

English 11
HP D2840A User’s Guide
Using the Display
RED To adjust the amount of red present in the displayed image, use this
menu item.
GREEN To adjust the amount of green present in the displayed image, use this
menu item.
BLUE To adjust the amount of blue present in the displayed image, use this
menu item.
MOIRE To reduce moire interference with the displayed image, select this menu
item. Moire is a visual pattern with ripples and waves that can result
from using very high resolutions.
CAUTION Overcorrecting for the effects of horizontal or vertical moire may affect
the picture quality of your display.
CREATE CUSTOM IMAGE You can define two customized image settings. This enables you to
create different working environments for applications that require
different image settings. Text heavy applications require high color
temperatures (9300K); graphics intensive applications require a more
natural color setting (6500K).
To create and save personal settings for contrast, brightness, and color:
1Select the CREATE CUSTOM IMAGE menu item. The following menu
appears:
2Set values for each of the items that you want to change.
CONTRAST
BRIGHTNESS
RED
GREEN
BLUE
SAVE TO CUSTOM 1
SAVE TO CUSTOM 2
EXIT WITHOUT SAVING
CREATE CUSTOM IMAGE
mykonos.bk : mykon-us.fb4 Page 11 Monday, November 25, 1996 5:41 PM

HP D2840A User’s Guide
Using the Display
12 English
3Select SAVE TO CUSTOM 1 or SAVE TO CUSTOM 2.
To select the settings saved in CUSTOM 1 and CUSTOM 2, use the COLOR
TEMP menu item.
FACTORY PRESET IMAGE To return all of the image settings to those set by the factory, select this
menu item.
Setting the Amount of Displayed Information
To set the amount of displayed information, change the screen
resolution of your PC. The higher the screen resolution, the more
information you can see on the screen. It is recommended that you use
a resolution of 1024 ×768 at 85Hz or 1280×1024 at 85Hz. This gives
easy-to-read characters, a large amount of displayed information, and a
flicker-free image.
To find out which resolutions are supported by your display, refer to
“Supported Video Modes” on page 15. To change the screen resolution,
please refer to the manual that came with your PC or your operating
system documentation, if necessary.
Your display has a Plug and Play capability (VESA DDC1/2B+
standard) that enables it to identify itself to suitably equipped HP
Vectra PCs. This will automatically give you the best refresh rate for
the resolution that you have set. Also, by using the appropriate
software (when available), you can adjust the display settings directly
from your PC.
Minimizing Eye Strain
To avoid screen flicker and minimize eye strain, use the highest
supported image refresh rate for the chosen resolution, for example
85Hz for 1280×1024. The image refresh rate is the number of times per
second that the image is refreshed.
mykonos.bk : mykon-us.fb4 Page 12 Monday, November 25, 1996 5:41 PM

English 13
HP D2840A User’s Guide
Using the Display
To find out which image refresh rates are supported by your display,
refer to “Supported Video Modes” on page 15. To set the image refresh
rate (also known as the vertical frequency), refer to the manual that
came with your PC or your operating system documentation, if
necessary. If your PC supports Plug and Play, it will automatically
select the best refresh rate for the screen resolution you have set.
Minimizing Energy Consumption
If your PC supports VESA display power management (available on
many HP Vectra PCs), you can minimize the power consumed by the
display. There are two power saving modes:
•Standby mode1(uses less than 30W). In this mode, the display’s
front panel indicator light is green.
•Sleep mode2(uses less than 1W). In this mode, the display’s front
panel indicator light is green blinking.
To set these power saving modes, refer to the manual that came with
your PC. If your screen is not displaying an image, check the front
panel indicator light first — your display may be in a power saving
mode.
1. Standby mode is activated when vertical sync is cut by the video controller.
2. Sleep mode is activated when both vertical and horizontal sync are cut by the video controller.
mykonos.bk : mykon-us.fb4 Page 13 Monday, November 25, 1996 5:41 PM

HP D2840A User’s Guide
Technical Specifications
14 English
Technical Specifications
1. Use the standard image sizes to avoid distortion of the displayed image.
PICTURE TUBE
Size 17-inch Trinitron/ 15.7-inch viewable image
Phosphorous Red, Green, Blue short persistence
Stripe pitch 0.25 mm super-fine stripe pitch
Face Plate Anti-glare, anti-static coating
INPUT SIGNAL
Video 0.66 Vp-p analog RGB
Synchronization Separated H/V (TTL level), H/V mixed (TTL level
sync-on-green)
INTERFACE Input Connectors 15-pin mini D-SUB
SCANNING FREQUENCY Horizontal 31 to 92kHz
Vertical 50 to 150 Hz
MAX. RESOLUTION (H ×V) 1600 ×1200 mode (60 Hz refresh rate)
WARM-UP TIME 30 minutes to reach optimum performance level
PIXEL CLOCK 160 MHz Maximum
IMAGE SIZE Standard size1: 300(H) × 225(V) mm (for all resolutions)
Maximum size: 321(H) ×236.5(V)mm
POWER SOURCE AC 90 to 264 V, 47 to 63 Hz, 130 W (max), less than 30W in standby mode, less than 1W in sleep mode.
OPERATING ENVIRONMENT
Temperature +5 °C to +40 °C (operating)
- 40 °C to +65 °C (storage)
Humidity 5% RH through 90% (without condensation)
CABINET DIMENSIONS 413(H) ×422(W) ×433(D)mm
WEIGHT 23 kg
TILT/SWIVEL STAND Tilt Angle - 5°to +20°
Swivel Angle ±87.5°
mykonos.bk : mykon-us.fb4 Page 14 Monday, November 25, 1996 5:41 PM

English 15
HP D2840A User’s Guide
Supported Video Modes
Supported Video Modes
Your display supports the video modes shown in the table below.
CAUTION Selecting a screen resolution/vertical frequency combination higher than
1600×1200 at 60Hz can damage your display.
Screen Resolution Image Refresh Rate Video Solution
640×480 60 Hz VGA
640×480 75 Hz Ergonomic VGA
640×480 85 Hz Ergonomic VGA
800×600 75 Hz Ergonomic Super VGA
800×600 85Hz Ergonomic Super VGA
1024×768 75 Hz Ergonomic Ultra VGA 1024
1024×768 85Hz Ergonomic Ultra VGA 1024
1280×1024 75 Hz Ergonomic Ultra VGA 1280
1280×1024 85 Hz Ergonomic Ultra VGA 1280
1600×1200 60 Hz Ultra VGA 1600
mykonos.bk : mykon-us.fb4 Page 15 Monday, November 25, 1996 5:41 PM

HP D2840A User’s Guide
Care and Cleaning
16 English
Care and Cleaning
Do not place anything on top of the display. Doing so may block the
display vents and cause damage to the display due to overheating.
Do not let liquid get on or into the display.
To maximize screen life and prevent damage to the picture tube (such
as burned phosphor due to leaving the same image on the screen for a
long time), it is recommended that you:
•Use the display power management system (on HP Vectra PCs) or a
screen saver program.
•Avoid setting contrast and brightness to their maximum levels for
prolonged periods.
•If you do not have a power management system or a screen saver
program, switch the display off or reduce the brightness and contrast
to minimum levels when the display is not in use.
Your display is automatically demagnetized each time it is switched on.
This ensures color quality. To maintain color quality during use or after
turning or moving your display, use the degauss option. Refer to
“DEGAUSSING“ on page 9.
Your display has an anti-glare, anti-static screen coating. To prevent
damage to the display screen’s coating, use a regular household glass
cleaner when cleaning the screen. To clean the screen:
1Switch the display off and remove the power plug (pull the plug, not
the cable).
2Wet a soft cotton cloth with the cleaning solution and gently wipe the
screen. Do not spray cleaner onto the screen because the cleaner
may drip inside the display.
3Dry with a clean, soft cotton cloth.
Do not use cleaning solutions containing fluoride, acids, or alkalis.
mykonos.bk : mykon-us.fb4 Page 16 Monday, November 25, 1996 5:41 PM

English 17
HP D2840A User’s Guide
Hardware Warranty
Hardware Warranty
This HP display is covered by a limited hardware warranty for a period
of three years from the date of purchase by the original end-user. The
service provided includes on-site service during the first year of
purchase, and for the following two years, return to an HP or
repair-authorized reseller service-center.
The above warranty shall not apply to defects resulting from: misuse
(including “burned” screens); unauthorized modification; operation or
storage outside the environmental specifications for the product; or
in-transit damage. A defective display will be — at HP’s option —
either repaired or replaced with a new or as-new unit of the same or
equivalent model.
Please refer to the warranty statement provided with your HP Vectra
personal computer for customer responsibilities and other terms and
conditions.
Environmental Information
HP has a strong commitment toward the environment. Your HP display
has been designed to respect the environment as much as possible.
HP can also take back your old display for recycling when it reaches
the end of its useful life.
In fact, HP has a product take-back program in several countries. The
collected equipment is sent to of HP’s recycling facilities in Europe or
the USA. As many parts as possible are reused. The remainder is
recycled. Special care is taken for batteries and other potentially toxic
substances, which are reduced to non-harmful components through a
special chemical process. If you require more details about HP’s
product take-back program, contact your dealer or your nearest HP
Sales Office.
The cathode ray tube used in this display does not contain cadmium.
mykonos.bk : mykon-us.fb4 Page 17 Monday, November 25, 1996 5:41 PM

HP D2840A User’s Guide
Regulatory Information
18 English
Regulatory Information
CONFORMITY DECLARATION
according to ISO/IEC Guide 22 and EN 45014
Manufacturer’s Name: HEWLETT-PACKARD
Manufacturer’s Address: 5, Avenue Raymond Chanas
38320 Eybens, FRANCE
declares, that the product:
Product Name: HP Ergo 1280 Color Display
Model Number: D2840A
conforms to the following Product Specifications:
SAFETY International: IEC 950:1991 + A1 + A2 + A3
European: EN 60950:1992 + A1 + A2
EMC CISPR 22:1993 / EN 55022:1994 - Class B
EN 50082-1:1992
IEC 801-2:1992 / prEN 55024-2:1992 - 4kV CD, 8 kV AD
IEC 801-3:1984 - 3V/m
IEC 801-4:1988 / prEN 55024-4:1992 - 1 kV Power lines
IEC 555-2:1982 + A1:1985 / EN 60555-2:1987
IEC 1000-3-3:1994 / EN 61000-3-3:1995
Supplementary information: the product herewith complies with the requirements of the Low Voltage
Directive 73/23/EEC and the EMC Directive 89/336/EEC amended by the Directive 93/68/EEC, and
carries the CE-marking accordingly.
Jean Marc JULIA
Grenoble, March 1997 Quality Manager
mykonos.bk : mykon-us.fb4 Page 18 Monday, November 25, 1996 5:41 PM
