1. Input select 3. Brightness up
2. Brightness down 4. Power on or off
Models
Workstation Volume and Business Desktop Channel EZ320A4#XXX
QuickSpecs
HP LP3065 30-inch Widescreen LCD Monitor
Overview
DA - 12621 Worldwide QuickSpecs — Version 16 — 12/15/2008 Page 1

Panel Type 30.0-inch Wide Format Active Matrix TFT (thin film transistor)
Viewable Image Area
(diagonal)
29.77 in (75.623 cm)
Screen Opening (WxH) 25.3 x 15.8 in (64.3 x 40.3 cm)
Panel Type IPS
Aspect Ratio 16:10
Viewing Angle
(typical)
1
Up to 178° H/ 178° V (10:1 minimum contrast ratio)
Brightness (typical)
1
370 nits (cd/m
2
)
Contrast Ratio
(typical)
1
1000:1
Dynamic Contrast
Ratio (typical)
1
3000:1
Response Rate
(typical)
1
12 ms (5 ms average gray to gray)
Pixel Pitch 0.250 mm
Backlight Lamp Life
(to half brightness)
40K hours
Color Gamut 102% of NTSC
Bezel Width 24 mm (left and right)
User Controls Buttons and Switches Input select, brightness up, brightness down, power
User Controls Brightness, input selection
Signal Interface/
Performance
Horizontal Frequency 100 KHz
Vertical Frequency 60 Hz
Native Resolution 2560 x 1600 @ 60 Hz (native aspect ratio of 16:10)
2
Pixel Clock Speed 275 MHz
Anti-Glare Yes
Anti-Static Yes
Default Color
Temperature
6500 K
Video/Other Inputs Plug and Play Yes
Self Powered USB 2.0
Hub
One upstream, four downstream ports (located on side of monitor,
cable included)
Input Connectors Three dual-link DVI-D inputs with HDCP over digital DVI
2
Video Cable Two dual-link DVI cables
Video Cable Length 5.9 ft (1.8 m)
Power Input Power Auto-Ranging, 100 to 240 VAC; internal power supply, 50 Hz/60 Hz
Typical Power
Consumption
132 watts
Maximum < 176 watts
Power Saving < 2 watts
Power Cable Length 5.9 ft (1.8 m)
Mechanical Dimensions
(H x W x D)
Unpacked 19.3 to 23.2 x 27.2 x 9.5 in
(49.0 to 59.0 x 69.2 x 24.0 cm)
Unpacked w/o stand
(head only)
17.9 x 27.2 x 3.3 in
(45.5 x 69.2 x 8.4 cm)
QuickSpecs
HP LP3065 30-inch Widescreen LCD Monitor
Technical Specifications
DA - 12621 Worldwide QuickSpecs — Version 16 — 12/15/2008 Page 2

Packaged 22.4 x 31.1 x 14.9 in
(56.8 x 79.0 x 37.8 cm)
Weight Unpacked 30.6 lbs (13.9 kg)
Head only 21.8 lbs (9.9 kg)
Tilt Range -5° to + 30° vertical
Swivel Range -45° to + 45°
Height Adjustable Yes, range 5.1 in (100 mm)
Pivot Rotation No
Base Detachable, ships detached
Environmental Temperature –
Operating
46° to 95° F (10° to 35° C)
Temperature –
Non-operating
6° to 140° F (-10° to 60° C)
Humidity – Operating 20% to 80% non-condensing
Humidity –
Non-operating
5% to 85%
Altitude – Operating +12,000 ft (3657.6 m)
Altitude –
Non-operating
+40,000 ft (12,192 m)
Environmental Data Eco-Label
Certifications and
Declarations
This product has received or is in the process of being certified to the
following approvals and may be labeled with one or more of these
marks:
IT Eco Declaration
TCO 99
Taiwan Green Mark
CECP
Korea Eco-label
Longevity and
Upgrading
Upgradeability features contained in the product include:
One upstream and four downstream USB ports
Ergonomics The monitor meets the ergonomic requirement of EN-ISO 13406-2 for
flat panel displays.
Additional Information This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) Directive, 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive, 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at
the SILVER level, see http://www.epeat.net .
Plastics parts weighing over 25 grams used in the product are marked
per ISO 11469 and ISO1043.
Display meets the requirement for low frequency electromagnetic fields
per TCO and prEN50279 A/B/C.
This product contains 0% recycled materials (by wt.)
This product is 97.6% recyclable when properly disposed of at end of
QuickSpecs
HP LP3065 30-inch Widescreen LCD Monitor
Technical Specifications
DA - 12621 Worldwide QuickSpecs — Version 16 — 12/15/2008 Page 3

life.
Packaging Materials
Corrugated Paper – 2.19 kg
PE-LD Bags – 0.09 kg
EPS Molded Foam – 1.07 kg
RoHS Compliance Hewlett-Packard is committed to compliance with all applicable
environmental laws and regulations, including the European Union
Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to
exceed compliance obligations by meeting the requirements of the
RoHS Directive on a worldwide basis. By July 1, 2006, RoHS
substances will be virtually eliminated (virtually = to levels below legal
limits) for all HP electronic products subject to the RoHS Directive,
except where it is widely recognized that there is no technically feasible
alternative (as indicated by an exemption under the EU RoHS
Directive).
Material Usage This product does not contain any of the following substances in
excess of regulatory limits (refer to the HP General Specification for the
Environment at www.hp.com/hpinfo/globalcitizenship/
environment/supplychain/gen_specifications.html ):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as
flame retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel – finishes must not be used on the external surface
designed to be frequently handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) – except for wires and cables, and
certain retail packaging has been voluntarily removed from most
applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging HP follows these guidelines to decrease the environmental impact of
product packaging:
Eliminate the use of heavy metals such as lead, chromium,
mercury and cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in
packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
QuickSpecs
HP LP3065 30-inch Widescreen LCD Monitor
Technical Specifications
DA - 12621 Worldwide QuickSpecs — Version 16 — 12/15/2008 Page 4

packaging materials.
Use readily recyclable packaging materials such as paper and
corrugated materials.
Reduce size and weight of packages to improve transportation
fuel efficiency.
Plastic packaging materials are marked according to ISO 11469
and DIN 6120 standards.
End-of-life
Management and
Recycling
Hewlett-Packard offers end-of-life HP product return and recycling
programs in many geographic areas. To recycle your product, please
go to: www.hp.com/recycle or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
Hewlett-Packard
Corporate
Environmental
Information
For more information about HP's commitment to the environment:
Global Citizenship Report
www.hp.com/hpinfo/globalcitizenship/
gcreport/index.html
Eco-label certifications
www.hp.com/hpinfo/globalcitizenship/environment/
productdesign/ecolabels.html
ISO 14001 certificates:
www.hp.com/hpinfo/globalcitizenship/environment/
operations/envmanagement.html
Options HP LCD Speaker
Bar—Part number:
EE418AA
Powered directly by the monitor or PC, the Speaker Bar seamlessly
attaches to the monitor's lower bezel to bring full audio support to
select HP flat panel monitors. Features include dual speakers with full
sound range and an external jack for headphones. Sold separately. For
more information, refer to the HP LCD Speaker Bar QuickSpec.
HP Security Lock-Part
number PC766A
Combines aircraft-grade steel and Kevlar fiber to securely lock down
your monitor and help prevent theft.
Other Accessories Included Two dual link DVI-D to DVI-D cables – connects the graphic card's
DVI-D digital connector to the monitor's input (DVI-D digital)
connectors; power cord
User Guide Languages English, B. Portuguese, French, LA Spanish, Korean, S. Chinese, T.
Chinese, Bahasa, Japanese, Danish, Finnish, German, Norwegian,
Spanish, Swedish, Greek, Polish, Russian, Slovenian, Turkish
Warranty Languages English, Canadian French, LA Spanish, Brazilian Portuguese, Danish,
German, Castilian Spanish, French, Italian, Dutch, Norwegian, Finnish,
Swedish, Bahasa Indonesian, Korean, T. Chinese, S. Chinese
Color Carbonite
VESA External
Mounting
Yes (Standard 4 hole pattern, 100 mm)
Security Lock-Ready Yes
QuickSpecs
HP LP3065 30-inch Widescreen LCD Monitor
Technical Specifications
DA - 12621 Worldwide QuickSpecs — Version 16 — 12/15/2008 Page 5

Certification and
Compliance
Australian ACA Approval, Canadian Requirements/CSA, CE Marking,
China CCIB/CCEE Approval, CISPR Requirements, Eastern European
Approvals, FCC Approval, German Ergonomic (TUV and GS Mark), ISO
13406-2 Pixel Defect Guidelines, Mexican NOM Approval, MIC
Requirements (New Zealand), Nordic Approvals (Nemko, Fimko, Demko,
Semko), S. Korean MIC Approval, Taiwan BSMI Approval, TCO 99
(emissions, ergonomics, environment), TUV-Ergo, UL Listed, VCCI
Approvals, Windows Vista® Premium Certification
Compatibility Compatible with platforms using the VESA standard video modes. Recommended for use with HP
products.
Service and Warranty Three years parts, labor, and on-site service. 24-hour, 90-day, toll-free technical support.
Replacement options may include second business day on-site service, or next business day
direct replacement, at HP's sole discretion.
3
With direct replacement, HP will ship a replacement
display product directly to you. Using the prepaid shipping labels provided, return your failed
display to HP in the same packaging as the replacement. Certain restrictions and exclusions
apply. For details see your product warranty or contact HP Customer Support.
1
All performance specifications represent the typical specifications provided by HP's component manufacturers; actual
performance may vary either higher or lower.
2
This is the only resolution supported by the monitor. Windows PC and graphics card that supports DVI ports with dual-
link digital bandwidth and VESA DDC standard for plug-and-play setup requires a DVI-D dual-link graphic card that
supports WQXGA (2560 x 1600) resolution.
3
Service levels and response times for HP Care Pack Services may vary depending on your geographic location. Service
starts from date of hardware purchase. Restrictions and limitations apply. HP Care Pack Services extend service contracts
beyond the standard warranties. To choose the right level of service for your HP product, use the HP Care Pack Services
Lookup Tool at: www.hp.com/go/lookuptool . Additional HP Care Pack Services information by product is available at:
www.hp.com/hps/carepack .
QuickSpecs
HP LP3065 30-inch Widescreen LCD Monitor
Technical Specifications
DA - 12621 Worldwide QuickSpecs — Version 16 — 12/15/2008 Page 6

1. Release/locking 1. Four 100 mm VESA mount screw
holes
1. Locking pin screw
2. Four 100 mm VESA mount screw
holes
2. Locking pin hole on release/locking
arm
3. Mounting holes for attachment to
back of HP LP1965, LP2065, and HP
LP2465 monitor stands
Introduction
The HP Quick Release, which ships standard with the HP LP3065 30-inch Widescreen LCD Monitor, is an easy to use, 100
mm VESA-compliant, flat panel monitor mounting solution that allows you to quickly and securely attach a flat panel monitor
to a variety of stands, brackets, arms or wall mounts. HP Quick Release can also be used for mounting any combination of
devices that are compatible with the 100 mm VESA Flat Display Mounting Interface Standard. The failsafe "Sure-Lock"
mechanism snaps the monitor (or mounted device) securely in place, and can be further secured with a theft-deterrent
security screw.
Uniquely flexible product configurations
HP Quick Release enables uniquely flexible product configuration alternatives in a variety of settings, such as:
Storefronts/kiosks: Mount flat panel monitors for easy viewing and add touchscreens for interactivity.
Trade shows: Securely mount LCD TVs or monitors in common areas and quickly remove them for safekeeping at the
end of the day.
Front office environments: Minimize desk space requirements with wall or swing-arm mounting of monitors in
reception areas.
Training labs: Mount a monitor directly on a 100 mm VESA-compatible PC or an HP Thin Client for all-in-one
convenience.
Medical/institutional settings: Securely mount monitors in nursing stations and public areas.
Conference rooms: Mount projectors (with 100 mm VESA-compliant pre-drilled holes) on ceilings, and monitors on
walls or tables.
QuickSpecs
HP LP3065 30-inch Widescreen LCD Monitor
Overview - HP LCD Monitor Quick Release (included)
DA - 12621 Worldwide QuickSpecs — Version 16 — 12/15/2008 Page 7

Mechanical Dimensions
(H x W x D)
Packaged 7.8 x 6.25 x 1.5 in (19.8 x 15.9 x 3.8 cm)
Unpackaged 6.3 x 5.2 x 0.65 in (16 x 13.2 x 1.65 cm)
Weight Packaged 1.1 lb (0.49 kg)
Unpackaged 0.82 lb (0.37 kg)
Additional
components
Eight 10 mm mounting screws (for attachment to VESA compliant monitor mounts)
Eight 15.5 mm mounting screws (for attachment to HP Thin Client products)
Four 20 mm mounting screws (for attachment to back of select HP flat panel monitor
stands)
One Quick Release "locking" screw
Color Carbonite
Notes No HP monitors allow positioning of a thin client product between a monitor screen and its
stand.
1.
The Quick Release device is not to be used between a monitor screen and its stand unless
provided that way from the factory.
2.
Under no circumstances is the Quick Release device intended to be used in an orientation
where the Release/Lock lever is oriented downward.
3.
Supported weight
capacity
The HP Quick Release has been designed to support a maximum of up to 24 lbs (10.9 kg)
depending upon the mounting configuration used. Please note this is a total weight limit for all
devices mounted, i.e. the combined weight of the monitor and a second device such as an HP
Thin Client cannot exceed 24 pounds. Because mounting surfaces vary widely and the final
mounting method and configuration may vary, mounting fasteners are not supplied (other than
the VESA-compliant screws). HP recommends that you consult with a qualified engineering,
architectural or construction professional to determine the appropriate type and quantity of
mounting fasteners required for your application and to ensure that your mounting solution is
properly installed to support applied loads.
© Copyright 2008 Hewlett-Packard Development Company, L.P.
Windows Vista is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other
countries.
HP shall not be liable for technical or editorial errors or omissions contained herein. The information is provided as is
without warranty of any kind and is subject to change without notice. The warranties for HP products are set forth in the
express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an
additional warranty. All performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
QuickSpecs
HP LP3065 30-inch Widescreen LCD Monitor
Technical Specifications - HP LCD Monitor Quick Release (included)
DA - 12621 Worldwide QuickSpecs — Version 16 — 12/15/2008 Page 8
