QuickSpecs
HP Z27n 27-inch Narrow Bezel IPS Display
Overview
c04675159 —15272 —Worldwide —Version 1 —May 18, 2015
Page 1
HP Z27n 27-inch Narrow Bezel IPS Display
1.
Menu button
4.
Color control
2.
Information
5.
Luminance
3.
Input control
6.
Power button/LED
1.
Master power switch
6.
Mini-DisplayPort
2.
Power connector
7.
DisplayPort v 1.2 in
3.
Audio output 3.5 mm
8.
DisplayPort v 1.2 out
4.
DVI-Dual Link
9.
(4) USB 3.0 downstream ports (one fast charging)
5.
HDMI v 1.4 input (MHL 2.0)
10.
(1) USB 3.0 upstream port

QuickSpecs
HP Z27n 27-inch Narrow Bezel IPS Display
Overview
c04675159 —15272 —Worldwide —Version 1 —May 18, 2015
Page 2
Overview
Enable a virtually borderless Quad HD panorama of multiple displays1with the edge-to-edge screen of the HP Z27n
27-inch Narrow Bezel IPS Display.
Key features:
Get Quad HD visuals from a three-sided borderless design that reveals more of the screen.
Enjoy reliable color accuracy across all of your projects with a factory-calibrated 99% sRGB color gamut.
Connect to multiple display1and devices with a range of integrated ports right at the display.
Use picture-in-picture or picture-by-picture to boost your multi-tasking productivity.
Work comfortably with customizable tilt, height adjustment, swivel, and pivot settings.
Get world-class service and support, and extend your protection with optional HP Care Packs.2
Reduce power consumption and help lower your costs with an energy-efficient design.
1Each display sold separately.
2Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of hardware purchase.
Restrictions and limitations apply. For details, visit www.hp.com/go/cpc. HP services are governed by the applicable HP terms and conditions of service
provided or indicated to Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and such
rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided with your HP Product.

QuickSpecs
HP Z27n 27-inch Narrow Bezel IPS Display
Technical Specifications
c04675159 —15272 —Worldwide —Version 1 —May 18, 2015
Page 3
Models: K7C09A4, K7C09AT
Panel
Type
27-inch IPS w/LED backlight
Viewable Image Area
(diagonal)
68,47 cm (27-inch) widescreen; diagonally measured
Panel Active Area
(W × H)
59,67 x 33,56 cm (23.49 × 13.21 in)
Resolution
2560 x 1440 @ 60 Hz (QHD)
Aspect Ratio
16:9
Viewing Angle
Up to 178° horizontal/178° vertical typical
Brightness
350 cd/m2
Contrast Ratio (Typical)
1000:1 Static; 5,000,000:1 Dynamic (DCR)
Response Times*
14 ms typical (G-to-G); 8ms with scalar overdrive
Pixel Pitch
0.2331 mm
Pixels Per Inch (PPI)
108.8 DPI
Backlight Lamp Life
(to half brightness)
30,000 hours minimum
Color Gamut
Up to 16.7 million colors with the use of FRC technology
Color Gamut (Typical)
99% sRGB
* Performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
User Controls
Buttons or Switches
Menu, Information, Input Control, Color Control, Luminance
User Programmable
Modes
20
Languages
10 (English, Spanish, German, French, Italian, Netherlands,
Portuguese, Japanese, T-Chinese and S-Chinese)
On Screen Display
(OSD) User Controls
Luminance, Color Control, Input Control, Image Control, PIP
Control, Power Control, OSD control, Management, Language,
Information
Audio Controls
N/A
Signal
Interface/
Performance
Horizontal Frequency
30 - 90 kHz (DVI, DP, HDMI); 27 - 75 (MHL)
Vertical Frequency
50 - 60 Hz (DVI, DP, HDMI); 24 - 60 (MHL)
Native Resolution
2560 x 1440 @ 60 Hz (QHD)
NOTE: The video card must be capable of supporting 2560 x 1440
@ 60 Hz to drive the monitor at the Preferred Mode.
Preset Graphic Modes
(non-interlaced)
640 x 480 @ 60Hz
720 x 400 @ 70 Hz
800 x 600 @ 60 Hz
1024 x 768 @ 60 Hz
1280 x 720 @ 60 Hz
1280 x 800 @ 60 Hz

QuickSpecs
HP Z27n 27-inch Narrow Bezel IPS Display
Technical Specifications
c04675159 —15272 —Worldwide —Version 1 —May 18, 2015
Page 4
1280 x 1024 @ 60 Hz
1366 x 768 @ 60 Hz
1440 x 900 @ 60 Hz
1600 x 900 @ 60 Hz
1600 x 1200 @ 60 Hz
1680 x 1050 @ 60 Hz
1920 x 1080 @ 60 Hz
1920 x 1200 @ 60 Hz
2560 x 1440 @ 60 Hz
Maximum Pixel Clock
Speed
250 MHz(DVI, DP, HDMI); 150 MHz (MHL)
Anti-Glare
Yes
Video/Other
Inputs
Plug and Play
Yes
Input/Output
Connectors
(1) DVI-Dual Link
(1) MHL 2.01/HDMI 1.4
(1) DisplayPort 1.2 In, (1) DisplayPort 1.2 Out
(1) Mini DisplayPort In
HDCP support on all inputs
USB
4 USB 3.0 [4 downstream (one fast charging), 1 upstream]
Video Cables Included
(1) DisplayPort 1,8 m (5.9 ft) (1) Mini-DisplayPort 1,8 m (5.9 ft)
(1) USB 3.0 1,8 m (5.9 ft)
Audio
(1) 3.5 mm audio-out connects headphones or HP speaker bar*
*Sold separately.
Multimedia
Speakers
N/A
Power
Power Supply
Internal
Input Power
100 - 240 VAC 50/60 Hz
Maximum Power
83 W
Typical Power
47 W
Sleep Power
0.5W (standby)
Power Cable Length
1,8 m (5.9 ft)
Mechanical
Dimensions
(W × D × H)
Unpacked w/stand
61,43 x 21,82 x 53,37 cm
24.2 x 8.6 x 21.0 in
(max height)
61,43 x 21,82 x 40,37 cm
24.2 x 8.6 x 15.9 in
(min height)
Unpacked w/o stand
(head only)
61,43 x 5,39 x 36,41 cm
(24.2 x 2.1 x 14.3 in)
Packaged
73,1 x 28,5 x 47,9 cm
(28.8 x 11.2 x 18.9 in)
Weight
Head Only
5,1 kg (11.16 lb)
Unpacked
7,66 kg (16.89 lb)
Packaged
10 kg (22.1 lb)

QuickSpecs
HP Z27n 27-inch Narrow Bezel IPS Display
Technical Specifications
c04675159 —15272 —Worldwide —Version 1 —May 18, 2015
Page 5
Ergonomic
Features
Detachable Stand
Yes, ships detached
Height Adjustment
Yes, 130 +/-3 mm
Tilt Range
-5° to + 22° vertical
Swivel
Yes, 45° +/-2°
Pivot
Yes, 90°
Quick Release5
HP QR2 quick release included
Environmental
Temperature -
Operating
5° to 35° C (41° to 95° F)
Temperature - Non-
operating
–20° to 60° C (-4° to 140° F)
Humidity - Operating
20% to 80% non-condensing
Humidity - Non-
operating
5% to 95%, 38.7° C max wet-bulb
Altitude - Operating
0 to 5,000 m (0 to 16,404 ft)
Altitude –Non-
operating
0 to 12,192 m (0 to 40,000 ft)
White LED Backlights
Yes
CCFL Panel
No
Arsenic-Free Display
Glass
Yes
Low Halogen2
Yes (except cables)
Mercury-Free Display
Backlighting
Yes

QuickSpecs
HP Z27n 27-inch Narrow Bezel IPS Display
Environmental Data
c04675159 —15272 —Worldwide —Version 1 —May 18, 2015
Page 6
Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following approvals and
may be labeled with one or more of these marks:
IT ECO declaration
US ENERGY STAR®
TCO 6.0
EPEAT® <Gold> registered in the United States. See http://www.epeat.net for
registration status in your country
Energy Consumption
(in accordance with US
ENERGY STAR® test method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation
28.2 W
27.9 W
28.4 W
Sleep
0.5 W
0.5 W
0.5 W
Off
0.5 W
0.4 W
0.4 W
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation
96 BTU/hr
95 BTU/hr
97 BTU/hr
Sleep
2 BTU/hr
2 BTU/hr
2 BTU/hr
Off
2 BTU/hr
1 BTU/hr
1 BTU/hr
*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level
is attained for one hour.
Additional Information
This product is in compliance with the Restrictions of Hazardous Substances (RoHS)
directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and Electronic
Equipment (WEEE) Directive –2002/96/EC.
This product is in compliance with California Proposition 65 (State of California; Safe
Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the Gold level,
see www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per ISO 11469
and ISO1043.
This product contains 37.5 % post-consumer recycled plastic (by wt.)
This product is 97.6 % recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Corrugated
1308 g
Internal:
PLASTIC/EPS (Expanded Polystyrene)
517 g
PLASTIC/EPE-Expanded Polyethylene
56.4 g
RoHS Compliance
Hewlett-Packard is committed to compliance with all applicable environmental laws and
regulations, including the European Union Restriction of Hazardous Substances (RoHS)
Directive. HP’s goal is to exceed compliance obligations by meeting the requirements of the
RoHS Directive on a worldwide basis. By July 1, 2006, RoHS substances will be virtually
eliminated (virtually = to levels below legal limits) for all HP electronic products subject to the
RoHS Directive, except where it is widely recognized that there is no technically feasible
alternative (as indicated by an exemption under the EU RoHS Directive).

QuickSpecs
HP Z27n 27-inch Narrow Bezel IPS Display
Environmental Data
c04675159 —15272 —Worldwide —Version 1 —May 18, 2015
Page 7
Material Usage
This product does not contain any of the following substances in excess of regulatory limits
(refer to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants –may not be used as flame retardants in
plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel –finishes must not be used on the external surface designed to be frequently
handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) –except for wires and cables, and certain retail packaging has
been voluntarily removed from most applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging
HP follows these guidelines to decrease the environmental impact of product packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in
packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in packaging
materials.
Use readily recyclable packaging materials such as paper and corrugated materials.
Reduce size and weight of packages to improve transportation fuel efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN 6120
standards.
End-of-life Management and
Recycling
Hewlett-Packard offers end-of-life HP product return and recycling programs in many
geographic areas. To recycle your product, please go to: http://www.hp.com/go/reuse-recycle
or contact your nearest HP sales office. Products returned to HP will be recycled, recovered or
disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information
for each product type for use by treatment facilities. This information (product disassembly
instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers.
These instructions may be used by recyclers and other WEEE treatment facilities as well as HP
OEM customers who integrate and re-sell HP equipment.

QuickSpecs
HP Z27n 27-inch Narrow Bezel IPS Display
Environmental Data
c04675159 —15272 —Worldwide —Version 1 —May 18, 2015
Page 8
Hewlett-Packard Corporate
Environmental Information
For more information about HP’s commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ecolabels.
html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/operations/envmanageme
nt.html

QuickSpecs
HP Z27n 27-inch Narrow Bezel IPS Display
Environmental Data
c04675159 —15272 —Worldwide —Version 1 —May 18, 2015
Page 9
Options
HP LCD Speaker Bar—
Part number NQ576AA
Powered directly by the connected PC, the Speaker Bar seamlessly
attaches to the monitor's lower bezel to bring full audio support to
select HP flat panel monitors. Features include dual speakers with
full sound range and dual external headphone jacks. Sold
separately. For more information, refer to the product’s
QuickSpecs.
HP Single Monitor
Arm—Part number
BT861AA
The flexible design of the HP Single Monitor Arm provides a
seemingly endless range of display adjustments with an amazing
13 inches of lift, 75 degrees of tilt, and 360 degrees of pan and
rotation –all at your fingertips -- helping you stay comfortable and
productive throughout the day.
HP DisplayPort Cable
Kit —Part number
VN567AA
Connects a DisplayPort connector on an HP Business Desktop
computer to a DisplayPort connector on a monitor
HP Quick Release
Bracket—Part number
EM870AA5
An easy-to-use, VESA-compliant, LCD monitor mounting solution
that allows you to quickly and securely attach an LCD monitor to a
variety of stands, brackets, arms or wall mounts. For more
information, refer to this product's QuickSpecs document.
HP Business PC Security
Lock Kit —Part number
PV606AA
Attaches to the rear of the PC with a six-foot steel cable that can be
used to secure a PC or peripherals such as mice, keyboards,
monitors or USB security devices to protect them against
unauthorized removal by physically connecting the system to an
anchor point.
What’s in the
box?
Monitor and
Accessories
HP Z27n 27-inch Narrow Bezel IPS Display, AC power cord (1.8m)
5.9 ft, DisplayPort cable 1,8 m (5.9 ft), Mini-DisplayPort cable 1,8 m
(5.9 ft), USB 3.0 cable1,8 m (5.9 ft)
Documentation
CD (includes user guide, warranty, drivers)
Software
HP Display Assistant
Other
User Guide Languages
English, Arabic, S. Chinese, T. Chinese, Czech, Danish, Dutch, Finnish, French,
German, Greek, Hungarian, Italian, Japanese, Kazakh, Korean, Norwegian, Polish,
Brazilian Portuguese, Russian, Slovenian, Spanish, Swedish and Turkish.
Warranty Languages
English, Arabic, S. Chinese, T. Chinese, Czech, Danish, Dutch, Finnish, French,
German, Greek, Hungarian, Italian, Japanese, Kazakh, Korean, Norwegian, Polish,
Brazilian Portuguese, Russian, Slovenian, Spanish, Swedish and Turkish.
Color
Black
VESA Mounting
100 mm VESA mount
Security Lock-Ready
Yes
Country of Origin
China
Certification
and Compliance
TCO Certified, CEL Grade 2, ENERGY STAR®Qualified, EPEAT®Gold3, CB; TUV/GS; TUV/Ergo; TUV-S; UL; TCO
Edge; CCC; CECP; CEL; SEPA; BSMI; CE; FCC(Canada); BSMI; KC; VCCI; C-Tick; Microsoft WHQL Certification
(Windows 8.1 and Windows 7); SmartWay Transport Partnership (NA)
Compatibility
Compatible with platforms using the VESA standard video modes. Recommended for use with HP products.

QuickSpecs
HP Z27n 27-inch Narrow Bezel IPS Display
Environmental Data
c04675159 —15272 —Worldwide —Version 1 —May 18, 2015
Page 10
Service and
Warranty
Protected by HP, including a 3 year standard limited warranty. Optional HP Care Pack Services are extended
service contracts that extend your protection beyond the standard warranties.4
© Copyright 2015 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without
notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for
technical or editorial errors or omissions contained herein.
ENERGY STAR® and the ENERGY STAR® mark are registered trademarks of the U.S. Environmental Protection Agency.
1. MHL 2.0 port will charge a MHL compatible smart phone and tablet battery. Requires the smart phone or tablet to be enabled for MHL or
have an HDMI dongle to connect to the monitor. See your mobile device specifications.
2. Power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be Low Halogen.
3. EPEAT® registered where applicable. EPEAT® registration varies by country. See www.epeat.net for registration status in your country.
4. Service levels and response times for HP Care Pack Services may vary depending on your geographic location. Service starts from date
of hardware purchase. Restrictions and limitations apply. See www.hp.com/go/cpc for details.
5. The HP Quick Release has been designed to support a maximum of up to 24 lbs (10.9 kg) for all devices mounted. Because mounting
surfaces vary widely and the final mounting method and configuration may vary, mounting fasteners are not supplied (other than the
VESA-compliant screws). HP recommends that you consult with a qualified engineering, architectural or construction professional to
determine the appropriate type and quantity of mounting fasteners required for your application and to ensure that your mounting
solution is properly installed to support applied loads.

QuickSpecs
HP Z27n 27-inch Narrow Bezel IPS Display
Change Log
c04675159 —15272 —Worldwide —Version 1 —May 18, 2015
Page 11
Change Log
