Chapter I. Introduction
1.1 Features
Multilingual OSD adjustment
Compatible with IBM VGA, extended VGA, VESA VGA, SVGA, XGA, and SXGA modes
Wide range of applicable voltages (AC 100-240V 50/60Hz) enables direct use without any
setting.
Plug-and-play VESA DDC1/ 2B Standard. Compatible with Windows 9x / 2000 / XP / 7 /8/
Vista operation systems
1.2 Check list
Please make sure the following items are included with your LCD monitor;
The monitor (and the pedestal)
Lower stand
Power cord
VGA cable
DVI cable (Optional)
Documentation and software disc
Setup poster
Warranty
If any of these items are missing, please contact your dealer for technical support and custom service.
Note: Be sure to save original box and all packing materials for future transport.

3
Chapter II. Installation
2.1 Install the pedestal
Please follow the steps illustrated below to install the pedestal.

4
2.2 Connect your monitor to your computer
1. Power off and unplug your computer.
2. Connect the 15-Pin ends of the signal cable to the VGA port of your monitor and the VGA OUT jack
on the back of your computer. Secure the screws on both ends of the signal cable.
or, connect the DVI signal cable to the DVI port on the monitor and the other end of the
cable to the back of the computer or source device.
3. Connect one end of power cord to the monitor, then connect the other end of the power cords to the
nearest electrical outlet.
Warning! To reduce the risk of electric shock or damage to the equipment:
Do not disable the power cord grounding feature. The grounding plug is an
important safety feature.
Plug the power cord into an easily accessible grounded outlet.
Disconnect the power from the equipment by unplugging the power cord from
the electrical outlet.
4. Power on your computer and monitor. If your monitor displays an image, the installation has been
successfully done. If the monitor does not display any image, check all the connections.
Cautions: 1. For installation, please complete signal cord connection before plugging the power
cord into the electrical outlet to avoid damaging the monitor.
2. During installation, please support the front frame with your hand at its center of
gravity to avoid dropping and damaging the monitor. Do not touch the surface of the
LCD panel.
Pressure on the panel may cause non-uniformity of color or disorientation
of the liquid crystals. If this occurs the screen will not recover to its normal
condition.
AC DVI VGA

5
Overview of the ports of the monitor:
1. AC power supply input
2. DVI signal input
3. VGA signal input
2.3 Disconnect the pedestal for shipping
Press the clip button on the pedestal and remove the pedestal from the stand.

6
Chapter III. Monitor overview
Overview of front panel controls
Control Function
1 Menu Opens, select or exits the OSD menu
2 — Minus
If the OSD menu is on, press to navigate backward through
the OSD menu and decrease adjustment levels.
3 Plus/input If the OSD menu is on, press to navigate for
ward through the
OSD menu and increase adjustment levels.
If the OSD in inactive, press to activate the input button to
select the video signal input (DVl or VGA)
4 /OK Auto/OK If the OSD menu is on, press to
select the highlighted menu
items.
If the OSD menu is inactive, press to activate
the auto
adjustment feature to optimize the screen image.
5 Power Turns the monitor on or off
6 Power LED Blue=Fully powered.
Amber=Sleep mode.
Flashing Amber=Sleep Timer mode.

7
Chapter IV. Operational Instruction
4.1 Power ON/OFF Switch
Press this button to power on/off your monitor. Note: The ON/OFF switch does not disconnect
your monitor from the main voltage. To completely disconnect the main voltage, please remove
the power plug from the socket.
4.2 Power indicator
The power LED is blue when the monitor operates normally. If the monitor runs in power-saving
mode, this indicator changes to amber. When the monitor is turned off, this indicator is not lit.
4.3 Menu features
All the following features of your monitor can be accessed and adjusted by using the on screen
display (menu) system.
1. If your monitor is not powered on, press the "Power” button to turn it on.
2. Press the "Menu” button to activate the OSD menu. The OSD main menu will be displayed.
3. To view the main menu or submenu, press the “+” on the front panel of your monitor to scroll
up or the “-” to scroll down. Then press the "OK” button to select a highlighted function.
When the highlight scrolls down to the bottom of the menu, it returns to top of the menu. When
the highlight scrolls up to the top of the menu, it returns to bottom of the menu.
4. To adjust the selected option, press the “+” or “-” button.
5. Select “Save” and return. If you do not want to save the setting, select “Cancel” from the
submenu or “Exit” from the main menu.
6. Press the “Menu” button to exit from the OSD menu.

8
4.4 OSD operational instructions
Icon
Main menu option
Submenu option
Note
Brightness To adjust the brightness level of the
screen. The factory default range is 90.
Contrast To adjust the contrast level of the screen.
The factory default range is 80.
Color
Selects the screen color. The factory is
6500K or Custom color,
depending on the
mode.
Warm- 5000K
Changes color to slightly reddish white.
Standard- 6500K
Uses standard colors (default).
Cool- 9300K
Change color to slightly blueish white.
Custom (RGB)
Selects and adjusts your own color scales:
Red Color – sets your own red color
levels.
Green Color – sets your own green color
levels.
Blue Color – sets your own blue color
levels.
Image control
To adjust the image on the screen. The
ambient brightness sensor can also be
enabled or disabled (only applicable to
some models)
Auto-adjustment
To automatically adjust the image on the
screen (only applicable to VGA input).
Clock and Phase
To adjust the clock phase of the screen.
This adjustment eliminates all horizontal
noises to enable
clearer and more lifelike
images and
characters (only applicable to
VGA input)

9
Horizontal position To adjust the horizontal position of an
image (only applicable to VGA input).
Vertical position
To adjust the vertical position of an image
(only applicable to VGA input).
Custom Scaling
Selects the method on how displayed
information on the monitor will be
formatted. Select
Fill to Screen – image fills the entire
screen and may look distorted or
elongated because of non-proportional
scaling of height and width.
Fill to Aspect Ration –
image is sized to fit
the screen and maintains proportional
image.
Sharpness
Adjusts the screen image to look sharper
or soft.(range:1~6)
Dynamic Contrast Turns Dynamic Contrast Ratio On or Off.
The factory default is Off.
OSD Control Provides a menu for adjusting the
on-screen display (OSD) control.
OSD position To adjust OSD position for your monitor.
Horizontal OSD Position
To adjust the visual position of the OSD
menu to the right or left
of the screen. The
factory default horizontal position value is
97.
Vertical OSD Position
To adjust the visual position of the OSD
menu up or down the screen. The factory
default vertical position value is 13.
OSD Transparency
To adjust the transparency to enable
transparent background information under
the OSD. (range:0~7)
OSD Timeout
To set the OSD display time (in seconds)
after the last pressing the button. The
factory default setting is “30 seconds”.
