HP xp8010 series User manual

1
hp
xp8010 series
digital projector
reference guide

Notice
The information contained herein is subject to change without notice. The only warranties for HP
products and services are set forth in the express warranty statements accompanying such products
and services. Nothing herein should be construed as constituting an additional warranty. HP shall
not be liable for technical or editorial errors or omissions contained herein.
Consumer transactions in Australia and the United Kingdom: The above disclaimers and
limitations shall not apply to Consumer transactions in Australia and the United Kingdom and shall
not affect the statutory rights of Consumers.
© Copyright 2003, 2004 Hewlett-Packard Development Company, L.P. Reproduction, adaptation,
or translation of this manual is prohibited without prior written permission of Hewlett-Packard
Company, except as allowed under the copyright laws.
The programs that control this product are copyrighted and all rights are reserved.
Reproduction, adaptation, or translation of those programs without prior written permission of
Hewlett-Packard Co. is also prohibited.
Microsoft® and Windows® are U.S. registered trademarks of Microsoft Corporation. Adobe® and
Acrobat® are trademarks of Adobe Systems Incorporated.
Hewlett-Packard Company
Digital Projection and Imaging
1000 NE Circle Blvd.
Corvallis, OR 97330
Second Edition (April 2004)

Reference Guide 3
Contents
1 Installation and Setup
What’s in the Box?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Identifying Common Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Projector at a glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Projector buttons and lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Back panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Selecting a Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
To install on a table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
To install on the ceiling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
To install for rear projection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
To install the cable shroud. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Turning On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
To connect power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
To turn the projector on. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
To turn the projector off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
To operate the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
To reset the projector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Making Initial Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
To connect input sources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
To connect output devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
To connect control equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Configuring the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
To change settings using the on-screen menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
To set up network access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Securing the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

4Reference Guide
Contents
2 Adjustments
Making Basic Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
To aim the projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
To adjust the focus and zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
To adjust the audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Adjusting the Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
To adjust the image according to type of picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
To adjust other image settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
To make adjustments from the web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
3 Presentations
Connecting and Preparing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
To connect a computer using a VGA cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
To connect a handheld organizer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
To connect a computer using other types of cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
To connect other video sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Showing Presentations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
To present from a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
To change the source. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
To hide or show the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
4 System Management
Managing the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
To find the IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
To set basic projector properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
To set up email for notifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
To protect configuration changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Upgrading the Projector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
To update the firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
To install an add-on lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
To change the connectivity module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Reference Guide 5
Contents
5 Maintenance
Using the On-Screen Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Quick Choice menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Input menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Adjust Picture menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Audio menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Setup menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Help menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Performing Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
To get the projector status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
To clean the projector lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
To replace the lamp module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
To replace the battery in the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
6 Troubleshooting
Troubleshooting Suggestions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Start-up problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Picture problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Sound problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Interruption problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Remote control problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Networking problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Testing the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
To run the projector diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
7 Reference
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Laser safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
LED safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Mercury safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

6Reference Guide
Contents
Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
U.S.A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Japan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Korea . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
International. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Index

Reference Guide 7
1
Installation and Setup
The chapter explains how to install and set up the HP digital projector.
If you are a presenter who is setting up the projector for short-term use, see Chapter 3,
“Presentations.”
This chapter covers:
■“Identifying Common Features” on page 9.
■“Selecting a Location” on page 17.
■“Turning On and Off” on page 23.
■“Making Initial Connections” on page 27.
■“Configuring the Projector” on page 34.
■“Securing the Projector” on page 36.

8Reference Guide
Installation and Setup
What’s in the Box?
Before setting up your projector, be sure your shipping box includes the following
items. If the shipping box does not contain any of the following items, contact HP.
Identifying the contents of the box
Symbol Item Function
1Projector Displays images.
2Cable shroud Covers cable connections.
3Documentation CD Contains projector documentation.
4Warranty and support guides Provide warranty and support
information.
5Quick Setup Guide Provides setup instructions.
6Remote control Controls projector.
7Two AAA batteries Powers remote control.
8VGA to VGA cable Connects projector to computer.
9Power cord Connects projector to power source.

Reference Guide 9
Installation and Setup
Identifying Common Features
This section identifies common features and functions of the projector. The section
covers:
■“Projector at a glance” on page 10.
■“Projector buttons and lights” on page 11.
■“Back panel” on page 12.
■“Remote control” on page 14.
■“Accessories” on page 16.

10 Reference Guide
Installation and Setup
Projector at a glance
Identifying the projector
Symbol Item Function
1Infrared receiver Receive signals from the remote control.
2Cover latch Releases cover for replacing lamp module and
connectivity module.
3Control panel Contains buttons and lights.
4Zoom ring Enlarges picture size 100–120%.
5Focus ring Focuses at distances of 1.5–14 m (5–46 ft).
6Lens cover Protects lens.
7Height adjustment Adjusts the height of the picture.

Reference Guide 11
Installation and Setup
Projector buttons and lights
Identifying buttons and lights on the projector
Symbol Item Function
1Business graphics button Optimizes the picture for data input.
2Super bright button Maximizes brightness (grayscale picture).
3Power button Turns the projector on or off. Blinks during
warm-up and cool-down.
4Theatre video button Optimizes the picture for video input.
5Lamp-warning light Turns on when lamp fails.
6Temperature-warning light Turns on when the internal temperature is
too high.
7Auto sync button Resynchronizes the projector to input signal.
8Enter button, back button,
and directional arrows
Change projector settings using the on-screen
menu.
9Source button Switches to the next input source.

12 Reference Guide
Installation and Setup
Back panel
Identifying the back panel
Symbol Item Function
1VGA #1 and VGA #2 input
connectors
Connects desktop or notebook computers or
pocket PCs.
2RS232 port Connects control equipment. Also used for
firmware upgrades.
3VGA-out and audio-out Connects to a monitor or second projector.
Connects to amplified speakers or audio
equipment.
4IR receiver Receives infrared signals from the remote
control.
5LAN port Connects the projector to a network.
6Composite-video input Connects devices like VCRs.
7S-video input Connects devices like VCRs or camcorders.
8Component-video input Connects advanced DVD players or HDTV
devices with YPbPr output.

Reference Guide 13
Installation and Setup
✎Certain models contain an L1581A Advanced Connectivity Module with additional
ports. See the L1581A manual for information about using this module.
9Speakers Provides stereo sound.
:Security slot Secures the projector using a cable lock.
;Control power output Controls a motorized screen or similar device.
<Analog video input Connects various equipment with RGB, RGBS,
RGBHV, and YPbPr output.
=M1 input Connects various equipment with analog- and
digital-video output. Also supports USB-device
output.
>Main power Connects power cord to projector.
?Main disconnect switch Disconnects power. Turn off only when
disconnecting power cord.
@Remote input Provides a wired connection for the remote
control, such as for rear projection.
AUSB device output Sends mouse and keyboard signals from the
remote control to a computer.
Identifying the back panel (continued)
Symbol Item Function

14 Reference Guide
Installation and Setup
Remote control
✎Before using the remote control, install two AAA batteries.
Identifying the remote control with case closed
Symbol Item Function
1Page up and page down Scrolls up and down through pages on a
connected computer.
2Left-click and right-click mouse
functions
Performs left-click and right-click functions for
a connected computer.
3Hide Hides the display.
4Source Switches to the next input source.
5Power Powers on and off the projector.
6Laser ring Turns on the laser pointer.
7Mouse button Moves the mouse pointer on a connected
computer.

Reference Guide 15
Installation and Setup
ÅWARNING: To reduce the risk of injury to the eyes, do not look directly into the
remote control laser light, and do not point the laser light into anyone’s eyes.
Identifying remote control with case open
Symbol Item Function
1Theatre video button Optimizes the picture for video input.
2Menu buttons Change projector settings using the on-screen
menu.
3Auto sync Resynchronizes the projector to the input
signal.
4Business graphics button Optimizes the picture for data input.

16 Reference Guide
Installation and Setup
Accessories
The following list displays some of the accessories you can buy for the HP projector:
■Advanced connectivity module (add an optional 802.11b card for wireless
computer connections and more)
■Add-on lens
❏Short-throw
❏Long-throw
■Carrying case
■Ceiling mount
■Projector screen
■Power cables
■Replacement lamp module
■Video cables

Reference Guide 17
Installation and Setup
Selecting a Location
This section describes how to set up and plan for installing the projector:
■“To install on a table” on page 18
■“To install on the ceiling” on page 18
■“To install the cable shroud” on page 22
■“To install for rear projection” on page 21
Setting up the projector with respect to image size
Distance from
screen
Diagonal size of projected
Width of projected image
1.5 m 5 ft 0.8–0.9 m 31–37 in. 0.6–0.8 m 25–30 in.
2 m 7 ft 1.1–1.3 m 41–50 in. 0.8–1.0 m 33–40 in.
4 m 13 ft 2.1–2.5 m 83–99 in. 1.7–2.0 m 66–80 in.
6 m 20 ft 3.2–3.8 m 124–149 in. 2.5–3.0 m 99–119 in.
8 m 26 ft 4.2–5.1 m 165–199 in. 3.4–4.0 m 132–159 in.
10 m 33 ft 5.3–6.3 m 207–249 in. 4.2–5.1 m 165–199 in.
12 m 39 ft 6.3–7.6 m 248–298 in. 5.0–6.1 m 199–239 in.
14 m 46 ft 7.4–8.8 m 289–348 in. 5.9–7.1 m 232–278 in.

18 Reference Guide
Installation and Setup
If you do not want to use the distance table, you can use the following equations to
help determine where to install the projector relative to the screen.
If your installation does not fall within these ranges, an add-on lens might be required.
See “To install an add-on lens” on page 57.
To install on a table
1. Place the projector on a stable platform located 1.5 to 14 m (5 to 46 ft) in front of
the screen.
2. Connect all necessary cables to the projector.
3. If necessary, set the projector to match the installation. Open the on-screen menu
and select setup > Projector position. Then choose Front Table from the
drop-down list.
To install on the ceiling
Your ceiling mount might differ from the one shown in the following images.
However, the installation steps are basically the same.
✎HP recommends that a qualified carpenter or electrician install the ceiling mount.
Calculating projection dimensions
distance from screen = A × width of screen
min and max distance from screen = B
width of screen = 0.8 × diagonal of screen (for 4:3 screen)
projector lens at same level as bottom or top of screen
A = 1.98 to 2.38
B = 1.5 to 14 m (5 to 46 ft)

Reference Guide 19
Installation and Setup
1. Align the end of the ceiling-mount bracket 1with the center hole in the
lower-mount bracket 2, and firmly secure it with a washer 3and bolt 4.
2. Align the three holes on the projector with the lower-mount bracket and firmly
secure with three screws.

20 Reference Guide
Installation and Setup
3. Attach the ceiling-mount bracket to the ceiling, and firmly secure with four screws
capable of holding 9 kg (20 lb). The ceiling-mount bracket must be located 1.5 to
14 m (5 to 46 ft) in front of the screen.
4. Adjust the on-screen menu to match your settings. Open the on-screen menu and
select setup > Projector position. Then select Front Ceiling from the drop-down
list.
5. (Optional) Install the cable shroud to hide the cables. See “To install the cable
shroud” on page 22. If you secure the projector with a Kensington lock, the lock
also secures the shroud.
