HP BP5000 User manual

Technical Support: For more detailed usage instructions, please download the
HP BP5000 / BP5000 Plus user manual at
GT Technology (Chongqing) Limited
The manufacturer under the
license of HP Inc.
Email: [email protected]
Web: www.hp-projector.com
Projector BP5000/BP5000PLUS
HP Projector
Quick Start Guide

Congratulations and thank you for choosing HP BP5000 / BP5000 Plus, part of the definitive premium
cinema projection series. Be prepared for unparalleled audio-visual immersive experiences of up to
150 inches.
Package Contents：
HP BP5000 or HP BP5000 PLUS *1
<Accessories>
·Power Cord * 1
· Remote Control * 1
· AA battery * 2
·Quick Start Guide * 1
·HP Warranty Card * 1
·Product Notice * 1
Device Overview：
-Do not place any articles around the air inlet hole to prevent cold air from entering
and heat exchange cannot be carried out.
-Do not place any articles near the air outlet, which will cause the internal heat
cannot be discharged and the internal heat will accumulate.
1
2
3
7
6
5
4
HDMI2
HDMI1(ARC)
AC IN
Notice:
8
10
9USB2.0
Adjustable Stand
Air inlet 11 Air outlet
USB2.0
AUX 3.5mm Stereo
(Audio-out External
Speakers/Headphone)
S/PDIF
LAN
EN
Specification parameter：
·USB ：5V,0.5A
·HDMI resolution：4K
·Hardware specifications：3G+32G
·Appearance of size：595*340*140 MM
·Resolution：4k UHD (3840*2160)
·Environmental characteristics: ambient
temperature 0-40℃, elevation below 5000m
·AC-IN：110-240V~,4A,50/60Hz
·LAN ：10/100Mbps
·Product size：595*340*140mm
·Product net weight：16kg

EN
How to use:
1. Place the projector onto a stable horizontal level surface (eg. table, TV stand) facing the desired vertical
projection surface (eg. wall,
projection screen). Plug the projector with the power cable into a working
AC power socket, connect your external video and
audio sources into the applicable input ports.
2. Before using the remote controller for the first time, insert the included AA batteries* 2 into the remote.
Power on the projector and follow the on-screen instructions to pair the remote.
3. Enter the main page, as shown in the figure below:
HP BP5000/BP5000 PLUS Supported Input Sources:
·Embedded digital content platform (via wireless stick and/or RJ45 Ethernet port)
· Digital and Ananlog TV
·HDMI * 2 (including HDMI ARC)
·USB2.0*2
HP BP5000/BP5000 PLUS features an embedded powerful 30-watt stereo speaker set with deep bass,
detailed mids and clear
treble. However, the below audio outputs are also supported to suit your
individual needs.
·S/PDIF * 1
·HDMI ARC *1
·3.5mm earphone out
·Bluetooth (4.0)

EN
4. If you would like to set-up the projection area yourself, please select (Settings > Projection >
Installation Assistant). Please follow the on-screen instructions. Alternatively,you may seek professional
assistance by contacting your local installation provider.

EN
5. When you are installing an external video device or audio system, the HP BP5000 /
BP5000 Plus position is touched to cause the image Out of focus or abnormal change,
please go to "Settings/Projection"
6.
To ensure safe viewing and prevent eyesight damage, we recommend you enable Smart Eye Protection
(Settings > Projection > Smart Eye Protection). During operation, DO NOT look directly straight-
on at the projector lens.
7. You may also use BP5000/BP5000 Plus as a speaker (audio-only) without using the screen.
(Settings > Switch off Display).
8. Voice input support is limited to mainland China.
9. If you want to watch photos and videos of mobile phones and Pads on the projector, you
can use the wireless projection screen on the main interface
To achieve screen sharing, you can refer to the connection instructions as shown in the figure
to complete the screen sharing function.
