Installation
Road Map
HP NetServer
Installation Overview
,
,
,
Configure ISA non-Plug-and-Play board (if installed)
Select Network Operating System (NOS)
Configure Integrated Remote Assistant
First: Install Hardware Using this Road Map
Second: Configure Hardware
,
,
Refer to the
Install HP TopTools
HP NetServer Remote Administrator Guide
Fourth: Install Server Management Software
Third: Install NOS
,
,
For certain versions of Novell NetWare and MS Windows NT, you may use the
HP automated installation process
For NOSs using a vendor-installation process, first create a NOS drivers
diskette, and view and print HP NOS Installation Instructions
5967-4216
Printed on recycled paper.
Printed in June 1998
,
,
,
,
,
,
,
,
Verify contents
Obtain HP Navigator CD-ROM release history
View the Readme File
Test the system hardware using Diagnostic Assistant (optional)
Install Information Assistant
Visit Order Assistant (optional)
Install all hardware accessories
Verify installed hardware accessories (optional)

Audience Assumptions
This road map is intended for the person who installs, administers,
and troubleshoots LAN servers. Hewlett-Packard Company assumes
that you are qualified in the servicing of computer equipment and
trained in recognizing hazards in products with hazardous energy
levels.
ESD Warning
Tools Required
This HP NetServer contains sensitive electronic devices that can be
damaged by electrostatic discharge (ESD). ESD hazards are a result
of installation or service personnel failing to ground themselves
properly. To be properly grounded, use a proper ESD wrist strap and
work surface grounded to the HP NetServer chassis.
Installation of some accessories require a T15 TORX or a 1/4-inch
flat blade screwdriver, depending on the accessory.
®
1. Verify Contents
2. Overview of NetServer Features
3. Obtain HP Navigator CD-ROM Release History
4. Connect Monitor, Keyboard, and Mouse
5. Preparation
6. Removing and Replacing the Covers
7. Install Additional Memory
8. Install All Accessory Boards
9. Install Additional Mass Storage Devices
10. Replace Covers and Cables
11. Verify Installed Accessories (Optional)
12. Configure the HP NetServer
NetServer LH 3 Installation Road Map
Table of Contents
Overview of NetServer Features
Serial B
Serial A
Parallel
Mouse
Keyboard
Monitor
AC Power
Connector
Front View Rear View
Left Front View
Shelf 1 (Flexible Disk Drive)
Shelf 2 (CD-ROM Drive)
System Board
Backplane
Hot-Swap
Power Supply
Expansion Bay
(Empty)
1
Shelf 3 (Empty)
Shelf 4 (Empty)
Hot-Swap
Mass Storage
Cage
Hot-Swap
Power Supply
Modules
Right Front View
Hot-Swap
Power Supply
Cage
Keyboard Lock Switch
Power Switch
Reset Switch
Bezel Lock
2
Verify Contents
Unpack and verify the contents of the shipping box against the Contents Checklist included with your HP NetServer. If anything is missing or damaged,
contact your reseller.
Hot-Swap
Mass Storage
Expansion
Bay (Empty) Hot-Swap
Power Supply
Expansion
Bay (Empty)
Status Lights
Display Control
Buttons
Front Panel
Display
Remote Management
I/O Connectors:
Accessory Board
Sockets
I/O Board
Accessory Board
Slot Covers
NOTE Power redundancy requires three power
supply modules. No redundancy is
available with two modules.
Redundant Fan
Expansion Bay
(Empty)
Non-Hot-Swap Shelves:

3
4
5
Obtain HP Navigator CD-ROM Release History
!
!
!
!
Call HP’s fax system at 1-800-333-1917 (or 1-208-344-4809 from
your fax machine), and request document number 6005
http://www.hp.com/netserver/servsup
ftp://ftp.hp.com/pub/servers
GO HPPC; download 6005.txt from the NetServer library
Fax—
Internet WWW—
Internet FTP—
CompuServe—
Connect Monitor, Keyboard, and Mouse
1. Connect cables:
2. Connect UPS:
Connect the monitor, keyboard, and
mouse cables and the AC power cord to the appropriate
connectors on the rear of the chassis.
If you have an uninterruptible power supply
(UPS), refer to the instructions supplied with it. Install and turn
on the UPS.
1. Boot the HP Navigator CD-ROM:
2. Read the Readme File
3. Run Diagnostic Assistant (Optional):
Turn on the monitor.
Press the power-on button on the HP NetServer, and press the
eject button on the CD-ROM drive. Place the HP Navigator CD-
ROM in the drive, and close the drive. Press the Reset button. If
the system fails to restart, follow the instructions on the screen.
When HP Navigator starts, you can set the time and date, and
change the display language.
Select "Readme File" from the HP
Navigator Main Menu. The Readme file contains the latest
information to help you install your HP NetServer.
To verify the HP
NetServer hardware as shipped, run Diagnostic Assistant from
the HP Navigator CD-ROM. Select "NetServer Utilities" from the
HP Navigator Main Menu, and then select "Diagnostic
Assistant" from the NetServer Utilities menu.
:
Preparation
6If you are installing accessory cards or mass storage devices,
remove the front bezel and cover 1. If you are installing memory,
remove the front bezel and cover 3.
To install some options, you will need a flat 1/4-inch screwdriver
and a T15 TORX driver.
®
Removing and Replacing the Covers
To remove a cover:
and disconnect the power cord
and telephone cord.
with the key from the key bag
located on the rear of the HP NetServer.
pull the top of the bezel away
from the chassis, and then lift the bezel up and off of the chassis.
at the front of the cover and pull
the cover forward, using the handle on the cover, and then lift it
off the chassis.
To replace a cover:
1. Turn off the HP NetServer
2. Unlock the bezel lock
3. To remove the front bezel,
4. Loosen the thumbscrew
WARNING Before removing cover(s), always disconnect the
power cord and unplug telephone cables.
Disconnect the power cord to avoid exposure to
high energy levels that may cause burns when
parts are short-circuited by metal objects, such as
tools or jewelry. Disconnect telephone cables to
avoid exposure to shock hazard from telephone
ringing voltages.
Note that the power switch does not turn off the
standby power. Disconnect the power cord to turn
off standby power. If the backlight on the LCD
display is on, standby power is on.
CAUTION Wear a wrist strap and use a static-dissipating work
surface connected to the chassis at all times.
4. Install Information Assistant:
5. Visit Order Assistant (optional)
6. Obtain IntranetWare key (optional):
Information Assistant will help you
install your HP NetServer. It is easier to use from a stand-alone system,
rather than from the HP NetServer you are installing. Install Information
Assistant from the onto
the client system that you will be using to manage your HP NetServer.
on the Internet at
http://www.hp.com/go/netserver
Order Assistant lists HP accessories, cables, and connectors for your
HP NetServer.
If you plan to install the
optional Novell IntranetWare software that came with your HP
NetServer, purchase the software and obtain the key before beginning
NOS installation in panel 12: "Configure the HP NetServer." Use the key
request form in the HP NetServer Software Option Package.
HP NetServer Online Documentation CD-ROM
Mouse
Keyboard
Monitor
Bezel Lock
Rear View
Before you begin installing your HP NetServer, ensure that you
have the latest version of the software by obtaining the current HP
NetServer Navigator CD-ROM release history. It describes the
latest software updates to each release of the Navigator CD-ROM,
as well as instructions for obtaining the current release.
AC Power Connector
Unlocked Position
1. To replace a cover,
2. To replace the bezel,
3. Replace all power, telephone, and I/O cables.
insert the tabs inside the rear of the cover
into the slots at rear of the chassis and slide the side cover toward
the rear. Tighten the thumbscrew at the front of the cover.
insert the tabs at the bottom of the bezel
into the slots at the bottom of the chassis front and press the top of
the bezel to the chassis until it snaps into place. Lock the bezel lock
with the key provided.
Thumbscrews
Tabs and Slots
Cover 1
Cover 2
Cover 3
You can obtain the release history from one of the HP NetServer
information resources listed here.
To obtain drivers and utilities for the non-HP components of your
system, follow the directions provided by the component or network
operating system (NOS) manufacturer to access the necessary
Internet, BBS, or CompuServe site containing the drivers and software.

7
1. Remove cover 3
2. Install the DIMMs
as described in panel 6, "Removing and
Replacing the Covers."
(refer to figure at right):
Choose a socket into which you want to install a DIMM. DIMMs
may be installed in any combination, in any socket.
Spread the two retaining clips on the socket outward.
Install All Accessory Boards
Install Additional Memory
8
1. Remove cover 1
2. Read the documentation
3. Remove the slot cover
4. Install the boards:
as described in panel 6: "Removing and
Replacing the Covers."
included with each accessory
board. Follow any special instructions and installation
recommendations. Some boards have preferred slot locations. If
not, consider the boot order (see below) when choosing the
accessory board socket in which to install the board.
for each slot to be used, and store it
for future use. If you are installing any full-length PCI boards, also
remove the accessory board retainer. Push on the button on the
retainer to release it, and then slide it out of the board guide.
Insert each board in the desired slot and
fasten the board's mounting screw at the slot opening at the rear of
the chassis. Connect any required cables to the boards. If you
removed the board retainer, reinstall it.
NOTE If you install an ISA non-Plug-and-Play board,
you must reserve system resources (some or
all of: memory addresses, I/O addresses,
IRQs, and DMA channels) for it. Write down
that information now for reference when you
reserve system resouces in Section 12:
"Configure the HP NetServer."
Boot order for PCI controllers is determined by slot location. The
system searches for a bootable device in the following order:
1. IDE CD-ROM drive with a bootable CD-ROM.
2. Flexible disk drive with a bootable flexible disk.
3. Embedded SCSI controller or embedded DAC.
4. PCI boards in slots in the following order: 8, 7, 6, 5, 4, 3, 2, 1.
This boot order can be changed using the SETUP utility
(press [F2] during the boot process).
Boot Device Priority
An accessory board can be identified by the offset of the bracket
and the shape of the edge connector:
PCI Board- Left-Side Offset
ISA Board- Right-Side Offset
NOTE For a list of boards HP has tested, see Help
topic "Tested Parts List" on the HP Navigator
CD-ROM.
NOTE Use only HP DIMMs listed in HP Information
Assistant or in HP Order Assistant.
System Board
DIMM Socket 0
DIMM Socket 1
DIMM Socket 2
DIMM Socket 3
Slot 1 16-bit ISA or 32-bit PCI
Slot 2 32-bit PCI
Slot 3 32-bit PCI
Slot 4 32-bit PCI
Slot 5 32-bit PCI
Slot 6 32-bit PCI
Slot 7 32-bit PCI
Slot 8 32-bit PCI
Notches
Keys
Retaining Clips
DIMM
Align the notches on the DIMM with the keys on the socket.
Holding the DIMM at 90 degrees to the system board, press the
DIMM fully into the socket until the retaining clips close. If the clips
do not close, the DIMM is not inserted correctly.
3. Replace the cover(s): If you are not installing any other
accessories, install the cover(s) as described in panel 6,
"Removing and Replacing the Covers."
Accessory
Board
Retainer
Accessory Board
Guide
Release Tab

9Install Additional Mass Storage Devices
This HP NetServer supports both hot-swap SCSI devices,
installed in the hot-swap mass storage cage, and non-hot swap
SCSI devices, installed in shelves 3 and 4 (located below the
CD-ROM drive).
Use only Ultra2 (LVD), SCA-2 connector hot-swap devices in
the hot-swap mass storage cage. You can use any standard
(non-Ultra2) wide, 68-pin single-ended SCSI device in non-hot-
swap shelves 3 and 4, such as a removable hard disk or a tape
backup drive. Narrow (50-pin) SCSI devices are supported in
the non-hot-swap shelves, but require a 68-to-50-pin cable
adapter for connecting the data cable to the device. (One
adapter is provided on the SCSI cable behind shelf 3.)
SCSI Addressing
Different form-factor hot-swap disk drive modules can be mixed and
matched within the hot-swap mass storage cage. Because so many
different configurations are possible, SCSI addresses assigned to the
modules will be different depending on the particular configuration.
See "Non-Hot-Swap SCSI Addressing," below, for addressing restrictions
on non-hot-swap devices.
Inserting a Hot-Swap Disk Drive Module
1. Open the drive by pressing in on the locking latch at the end of the drive
ejector handle and pulling open the handle.
2. Choose a location in the hot-swap mass-storage cage and gently slide
the drive into the cage. Stop when you feel resistance.
3. Verify that the locking pin behind the pivot end of the handle engages
the hole in the chassis. (See figure, at right).
4. With even pressure, gently close the ejector handle until the locking
latch clicks shut.
CAUTION Do not mix Ultra2 devices with other SCSI
devices. Use only Ultra2 devices in the
hot-swap mass-storage cages. Use only
non-Ultra2 (wide or narrow) devices in the
non-hot-swap shelves (shelves 3 and 4).
CAUTION Do not operate this NetServer -- even for
short periods -- without a tray, filler panel,
or drive spacer in every hot-swap and
non-hot-swap mass storage location.
Otherwise, damage to components may
result due to improper cooling airflow.
NOTE For maximum storage density and to avoid
configuration problems, install hot-swap drives in
consecutive locations only, beginning with the lowest
location in the mass-storage cage.
Both half-height (1.6-inch) and low-profile (1-inch) form-factor devices
may be installed in the hot-swap mass-storage cage. There are two
different height hot-swap trays available to accommodate drives of
different form factors.
Six low-profile devices or four half-height devices, or combinations of
these two devices may be installed in the hot-swap mass-storage cage.
Hot-Swap Module Configurations and SCSI Addresses
Key:
Half-Height
Disk Module
Disk Spacer
Low-Profile
Disk Module or
Filler Panel
Because of the height difference between half-height and low-profile
devices, some combinations of the two types of trays will require
spacers to take up space between devices. The figure below shows the
different combinations of hot-swap devices possible. SCSI addresses
are assigned automatically depending on the location of a drive module
within the mass storage cage.
SCSI addresses listed here are for SCSI A only. Refer to the
Removing a Hot-Swap Disk Drive Module
1. Let the drive spin down completely before removing it.
2. Press in on the locking latch at the end of the drive ejector handle and
gently open the handle.
3. Slowly pull the drive out of the cage.
Pin Engages
Hole in Edge
of Cage
1
0
9
8
88
333
222
111
000
99
88
33
21
00
88 8
9
33
3
3
11
1
1
000
0
Ejector Handle
Locking
Latch
Numbers on
the Modules
Indicate Assigned
SCSI Addresses
the Technical Reference Card, located in the pouch on the
inside of the NetServer cover, for the recommended SCSI
addresses.
The NetServer SCSI cable is terminated. Verify that no
added devices are terminated.
SCSI Termination
Non-Hot-Swap SCSI Addressing
SCSI Addresses
Jumper Settings
Each SCSI device must have a unique SCSI
address. Devices connected to the SE connector
(those located on the non-hot-swap shelves) and to
the SCSI B connector (not used in the factory-
configured models) share one SCSI bus. Therefore
each device connected to either of these connectors
must have a unique address (narrow devices may
use addresses 0-6; wide devices may use addresses
0-15, except address 7).
The figure to the right is typical of a SCSI hard disk
drive that may be used in this NetServer. Use this as
a general reference for jumper locations and
settings. Typically, jumpers A0, A1, A2, and A3
determine the SCSI address.
Refer to the documentation that came with the SCSI
device for the jumper location and settings. Refer to
JUMPERS
A0
A1
A2
A3
(Drive typical; your
model may differ)
A0
A1
A2
A3
01 2 3 4 56 8 9 10 11 12 13 14 15
Jumpers:
Address:

Replace Covers and Cables
101. as described in panel 6:
"Removing and Replacing the Covers."
2. and all other
cables.
Replace all covers
Connect the AC power cord
CAUTION Replace all covers before operating the NetServer,
even for a short time. Otherwise, damage to system
components may result due to improper cooling air
flow.
Verify Installed Accessories (Optional)
11 If you wish, you may now verify accessories you have
installed. Turn on power to the HP NetServer and the
monitor, and observe the boot screen.
The boot screen lists the hardware, as it is detected,
such as CPU, memory, and accessory boards. If the
system fails to boot, follow the instructions on the
screen.
NOTE SCSI devices connected to a disk array controller
board (DAC), or the integrated NetRAID controller
cannot be displayed at boot time, nor can an ISA
non-Plug-and-Play board be displayed at boot
time.
Configure the HP NetServer
12
2. Run Configuration Assistant and Installation
Assistant:
3. Choose a NOS:
4. Select the NOS installation mode:
5. View Configuration Advisories:
6. Configure Remote Management:
If you want to change the language, select
"Set Preferences" from the HP Navigator main menu
and choose a language. Select "Configuration and
Installation Assistant." Select "Express" from the next
screen to begin the "Express" mode of configuration.
"Custom" configuration mode and "Replication"
configuration mode are also available. Refer to the
for details.
Select the NOS you will install, and
the version, if necessary. Installing the optional
IntranetWare NOS, which is part of the HP NetServer
Software Option Package, requires a decryption key,
obtained in panel 5: "Preparation."
If you select
certain versions of Novell NetWare / IntranetWare or
Microsoft Windows NT Server, you will be asked,
"Would you like to use HP's automated mode of NOS
installation?"
Select "Yes" to choose automated NOS installation
for first-time installation of Novell NetWare /
IntranetWare or Microsoft Windows NT Server on a
factory-configured HP NetServer.
Use the manual NOS installation if you are installing a
NOS other than Novell NetWare / IntranetWare or
Microsoft Windows NT Server, or if you have replaced
accessory components (for example, if you replaced
an HP network interface controller board with a third-
party board, use the manual NOS installation).
Read the
Configuration Advisories and print them if necessary.
Make any changes suggested in the advisories.
If you plan to
manage the HP NetServer LH 3 remotely, refer to the
for
instructions. Select "Configure Remote Management"
on the Navigator screen to configure Integrated Remote
Assistant.
HP
NetServer LH 3/LH 3r User Guide
HP NetServer Remote Administrator Guide
!
!
1. Turn on the HP NetServer and monitor, insert the
HP Navigator CD-ROM into the drive, and press the
Reset button. If the system fails to boot, follow the
instructions on the screen.
NOTE If you have installed an ISA non-Plug-and-Play
accessory board, you must reserve system
resources for it by using the Setup Utility. Start the
Setup Utility by pressing function key [F2] when
prompted during the boot process.
When the Setup Utility starts, select "Configuration,"
and then select "ISA non-Plug-and-Play Devices."
Use the arrow keys to highlight a selection, press
ENTER to display its options, and use the +/- keys to
change values. When you've finished, save the
changes and exit the utility.
For more information about reserving system
resources, refer to Information Assistant and to
"Configuring an ISA Non-Plug-and-Play Board" in the
(If the system hangs before the Setup Utility starts,
remove the ISA non-Plug-and Play board, run the
Setup utility to reserve system resources for it, then
reinstall the board.)
HP NetServer LH 3/LH 3r User Guide.
7. Show System Information:
8. Configure Mass Storage.
9. Install the NOS:
Select "View System Information" to
get information about accessory boards and devices. Select "View
Resources" to view used and available system resources.
This NetServer is shipped with the hot-
swap mass storage device(s) unconfigured. To configure the
drive(s), do one of the following:
Run HP NetRAID Assistant to configure one or more RAID
logical drives. To run HP NetRAID Assistant, select "Execute"
from the Configure Disk Array screen.
Exclude SCSI A Channel from the integrated HP NetRAID
controller, as follows:
a. Restart the HP NetServer.
b. Press function key [F2] when prompted.
c. When the SETUP utility menu is displayed, use the up and
down keys to highlight the "Include SCSI A Channel [Yes]"
selection.
d. Use the + and - keys to change it to "Include SCSI A Channel
[No]."
e. Press function key [F10] to save the configuration and exit
the utility program.
f. Answer "Yes" to the question "Save Configuration and Exit
Now?" The HP NetServer will reboot, and HP Navigator will
restart.
If you selected the HP automated NOS
installation process, you will be guided through the process by a
series of HP display screens:
Install Utility Partition: This step creates an 8 MB disk partition
on the server boot hard disk drive where HP Navigator will copy
troubleshooting and other utilities. The utility partition is not
available under SCO UNIX. Select "Execute" on the Install
Utility Partition screen to install the partition.
Execute Card Utilities: Select "Execute" on the Execute Card
Utilities screen to run the accessory board configuration utilities.
Follow the instructions on the screen and in the network
operating system's installation instructions to perform the
manual NOS installation.
For Manual NOS Installation Only: Before you perform a
manual NOS installation, print out instructions and create NOS-
specific drivers diskette(s), as follows:
A. Create Drivers Diskette(s): On the Create Drivers Diskette(s)
screen, select Create Drivers Diskette(s) to create one or
more customized diskettes containing HP drivers and
configuration files to use when you install the NOS.
B. Print and Read Instructions: On the Show NOS Installation
Instructions screen, select "Save to Disk" to copy the NOS
installation instructions to disk. Then print them from disk.
Read the instructions first, and then follow them to manually
install the NOS.
Install NOS:
!
!
!
!
!
!
!
